2BA2H-GVM-MIC-LM2wireless microphone

GVMOfficial website Facebook Web:www.gvmled.com B&HEmail:[email protected] GVMEmail:[email protected] AmazonEmail:[email protected] GVM-MIC-LM2 WarehouseAdd:4301NDelawareave,unitD.PHILADELPHIA,PA19137,USA CONTENTS productFeatures------------------------------------1page ProductParameters---------------------------------2page Disclaimer-------------------------------------------2page ProductHandlingInstructions------------------3~4page TFTscreeniconandLEDlightfunctionintroduction------ –---------------------------------------------------5~6page Instructions--------------------------------------7~8page PackageContents-----------------------------------9page Precautions-------------------------------------9~10page SecurityInformation----------------------------11-12page PRODUCTFEATURESPRODUCTPARAMETERS ◆ Workingfrequency:2.4-2.4835GHZ ◆ Powersupply:3.7Vlithiumbattery ◆ Acoustic/RadioSensitivity:-40DB+/-2dB ◆Maximumsoundpressurelevel(SPL):25DBSPL ◆ 1.Built-inmicrophoneandexternalextensionmicrophone. 2.2.4Gwirelesstransmission,stablesignal,lowdistortion,low delay,highlyrealisticreproductionofhumanvoice. 3.Intelligentnoisereductionalgorithm,whichcanmeetthesound pickuprequirementsofanycomplexenvironment. Frequencyresponse:20HZ-20KHZ ◆Inputsignaltonoiseratio:≥73DB1KHZ/1PA 4.Thereceiver'sTFTscreendisplaysthetransmitter'svoice intensity/voiceprogressbar,whichisbeautifulandtrulyshows thevolumeofthehumanvoice.Themicrophonehasalocal recordingfunctionandabuilt-inlarge-capacitymemorychip, whichcanbeusedasavoicerecorderwithoutfearofdataloss duetodisconnectionofthereceiveroraccidentaldataloss, makingvideorecordingorinterviewssafer. ◆Transmitpower:10dBm ◆ Receivingsensitivity:-94dBm ◆ Modulation:GFSKπ/4DQPSK ◆TransmissionBandwidthandSamplingRate:16bit48KHZ ◆Audiooutput:stereophony ◆ Delay:≤20mS 5.SupportTYPE-Cdigitalaudioand3.5mmTRSanalogaudio output,applicableto:mobilephones,computers,SLRcameras, camcordersandotherrelatedequipment. ◆ Transmissiondistance:≥100m 6.Equippedwith3.5mmheadphonemonitoringoutput,which supportsreal-timemonitoring. DISCLAIMER 7. FixedEQvalueswitch,one-clicktoopenvocalbeautification. 1.Beforeusingthisproduct,pleasereadthetextcarefullytoensureproper operationoftheproduct.Failuretofollowandoperateinaccordancewith theinstructionsandprecautionsinthisarticlemaycauseinjurytoyouand thepeoplearoundyou,orevendamagetheproductorothersurrounding items. 8.High,mediumandlowthree-stagevolumecontrol,whichis convenientforuserstochoosethevolume. 9.suitableforthecurrentenvironmentsimplyandquickly. 2.Onceyouusethisproduct,itisdeemedthatyouhavecarefullyreadthe disclaimerandprecautions,understoodandrecognizedallthetermsand contentsofthisstatement,andpromisetotakefullresponsibilityforthe useofthisproductandpossibleconsequences. 10. Equippedwithalarge-capacitybatterystoragebox,itmeets therequirementsoflongbatterylifefortravel,livebroadcast, andinterviews,andisnolongertroubledbybatterylife. 3.Designandspecificationsaresubjecttochangewithoutnotice. 12 PRODUCTHANDLINGINSTRUCTIONS Volumekey/mutekey(RX): 3 ①ShortpresstoadjustthevolumeThevolumeisdividedintothree levels:low,mediumandhigh.(rebootaftershuttingdownRecallthe volumebeforeshutdown)3RX. RX 5 ②Longpressfor2secondstomute,themutesymbolwillbedisplayed ontheLCDscreen,longpressagaintoexitmute. 4 5 Noisereductionkey/Americantonekey(RX): ①Shortpresstoenternoisereduction(TXentersambientnoise reduction),shortpressagaintoturnoffnoisereduction. ②LongpresstoenterthefixedEQvaluesoundeffect(enhancemiddle andlowfrequency),longpressagaintoexitEQ. 2 1 7 3 6 4 TFT0.96(RX): ①DisplayTXandRXbatterypowerorchargingindication,connection status,microphonevoiceinputstrength,systemvolume,EQ,mute, noisereduction,etc. TX ②ReducethebrightnessoftheLCDscreenafter10secondsofno operation,andtriggeranybuttontorestorethebrightness. 9 6 7 8 Audiooutput/LINEOUT(RX): outputaudiotorecordingequipment. 8 10 2 1 Headphoneoutput/HEADPHONE(RX): plugina3.5mmheadphonetomonitorthevolumeofthetransmitter. 1 2 Type-csocket(TXRX): ①Charging(TXRX). ②ConnecttoacomputerormobilephoneforUSBmicrophone(RX) Recordkey(TX): ①Shortpresstoenterrecording.(-6DBsaferecordingtobuilt-ineMMC flashmemory,eMMCcapacity:8GB) ②Automaticlooprecording,whenthememoryisfull,itwillautomatically deletetherecordingfileattheearliesttime. function. ③Connecttothecomputertoreadtherecordingfile(TX)intheFLASH IC. ON/OFF(TXRX): ①Longpresson/off(2seconds). ②Pressandholdfor5secondstoenterpairingwhenthedeviceis poweredoff. 9 Externalmicrophone(TX): externalmicrophoneinput.(disconnectthebuilt-inmicrophonewhenthe externalmicrophoneispluggedin) ③Pressandholdfor5secondstoresetthesysteminthepower-on state. 10Built-inmicrophone(TX): built-inmicrophoneaudioInput. 34 TFTSCREENICONANDLEDLIGHT FUNCTIONINTRODUCTION ②TransmitterLEDIndicators ①ReceiverTFTdisplay Bluelight Green,red two-colorlights 1.TXworklight(bluelight):flashes1timepersecondwhenthereisno connection,andstaysonwhentheconnectionissuccessful. 1.Volumeicon:minimumvolume,mediumvolume,maximum volume. 2.TXpairinglight(bluelight):PressandholdtheON/OFFbuttonfor5 secondstoenterpairingintheoffstate,thebluelightwillflashquickly (onceevery0.5seconds),andthedevicewillautomaticallyshutdownafter waitingfor5minutesiftheconnectionfails. 2.Thevoiceinputsignalstrengthofthemicrophone isdisplayed. 3.Thenoisereductionsymbollightsupinthenoisereductionstate. Chargingsymbol. 3.TXrecordinglight(greenlight):Itisalwaysonwhentherecordingisturned on,andthelightisoffwhentherecordingisturnedoff. 4. 5. 6. 7. 8. 9. 10. 11. Chargingcompletesymbol. 4.PromptwhentheTXrecordingmemoryisfull:thegreenlightflashesonce every0.5seconds. Lowbatterysymbol. Twogridelectricitysymbols. 5.TXlowpowerflashinglight:Greenandredlightsflashalternately. Threegridelectricitysymbols. 6.TXchargingindication:Theredlightisflashing(onceevery1.5seconds), andtheflashinglightisturnedoffafteradelayof5secondsafterfully charged. Fullbatterysymbol. Muteicon,lightupwhenmute. EQsymbol,lightupwhenEQisturnedon.(enhancemiddleandlow frequencysounds) 12.RXpairing…

Text truncated - open the document above for the full version.

Huizhou LATU FILM EQUIPMENT Co., Ltd 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – EquipmentType Company name: Huizhou LATU FILM EQUIPMENT Co., Ltd Address: No. 9 Tai’an Road, Ma’an Town, Huicheng District, Huizhou City, Guangdong Province, China Product Name: wireless microphone FCCID: 2BA2H-GVM-MIC-LM2 Model(s): GVM-MIC-LM2 2.911(d)(5)(i) EquipmentType We, [Huizhou LATU FILM EQUIPMENT Co., Ltd] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: YuYijuan Date: May. 09, 2023 Title: Manager Company name: Huizhou LATU FILM EQUIPMENT Co., Ltd Signature: NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Huizhou LATU FILM EQUIPMENT Co., Ltd 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Huizhou LATU FILM EQUIPMENT Co., Ltd Address: No. 9 Tai’an Road, Ma’an Town, Huicheng District, Huizhou City, Guangdong Province, China Product Name: wireless microphone FCCID: 2BA2H-GVM-MIC-LM2 Model(s): GVM-MIC-LM2 2.911(d)(5)(ii) Applicant filing We, [Huizhou LATU FILM EQUIPMENT Co., Ltd] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to §1.50002 of this chapter,as an entity producing coveredcommunications equipment. Yours sincerely, Name: YuYijuan Date: May. 09, 2023 Title: Manager Company name: Huizhou LATU FILM EQUIPMENT Co., Ltd Signature: NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Huizhou LATU FILM EQUIPMENT Co., Ltd Agent Authorization Company: Huizhou LATU FILM EQUIPMENT Co., Ltd Address: No. 9 Tai’an Road, Ma’an Town, Huicheng District, Huizhou City, Guangdong Province, China Product Name: wireless microphone Model Number(s): GVM-MIC-LM2 Product Description: wireless microphone We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: May. 09, 2023 Name: YuYijuan Title: Manager Company: Huizhou LATU FILM EQUIPMENT Co., Ltd

Huizhou LATU FILM EQUIPMENT Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May. 09, 2023 Subject; Request for Confidentiality FCC ID: 2BA2H-GVM-MIC-LM2 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: YuYijuan Title: Manager

Annex A External Photos Report No.: HK2304211555-E Page 1 of 5 Report No.: HK2304211555-E Page 2 of 5 Report No.: HK2304211555-E Page 3 of 5 Report No.: HK2304211555-E Page 4 of 5 Report No.: HK2304211555-E Page 5 of 5

FCC ID LABEL: Ca. 10mm x 20mm label location FCC ID: 2BA2H-GVM-MIC-LM2

Annex B Internal Photo Report No.: HK2304211555-E Page 1 of 3 Antenna Report No.: HK2304211555-E Page 2 of 3 Report No.: HK2304211555-E Page 3 of 3

FCC RF Exposure EUT Description: wireless microphone Model No.: GVM‐MIC‐LM2 FCC ID: 2BA2H‐GVM‐MIC‐LM2 1. Limits According to KDB 447498 D01 General RF Exposure Guidance v06 The 1‐g and 10‐g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤50 mm are determined by: [(max power of channel, including tune‐up tolerance, mW)/(min. test separation distance, mm)]·[√ f(GHz)]≤3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR, Where: Result=P/D*√F F= the RF channel transmit frequency in GHz P=Maximum turn‐up power in mw D=Min. test separation distance in mm 2. Test Result of RF Exposure Evaluation 2480MHz: EIRP(dBm)=101.65(dBuV/m)-95.3=6.35(dBm) Frequency (MHz) Output power (dBm) Tune Up Power (dBm) Max Tune Up power dBm/mW Min test separatio n distance mm Result Limit (mW/cm 2 ) SAR Test Exclusion 2.4G TX 6.35 6±1 7/5.01 5 1.57854 3.0 Pass Note: PK Output power= conducted power. Conducted power see the test report HK2304211555‐E, antenna gain= 2.05dBi Per KDB 447498 D01, when the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine RF Exposure test exclusion. The test exclusion threshold is 1.57854 which is<= 3, RF Exposure testing is not required. Note: Exclusion Thresholds Results=[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] f(GHz) is the RF channel transmit frequency in GHz Distance=5mm

SHENZHENFEIMINTECHNOLOGYCO.,LTD. 1 深圳市飞敏科技有限公司 ShenZhenFeiMinTechnologyCO.,LTD. 产品承认书 SPECIFICATIONFORAPPROVED 客户 CUSTOMER: 产品名称 PRODUCTS:321610—X6贴片天线 客户料号 PARTNO: 产品型号 Spec.:X6 日期 Data:2021.12.14 备注：承认盖章后请回复一份承认书（或复印件）给我司，其余由贵公司存档 REMARK:Pleasesendusone(orcopy)ofthisapprovalwithstampafteraccepting,othercopiesfiled bythecustomer. 地址：深圳市宝安区西乡街道固戍社区恒南一路C栋厂房303室 ADD:Room303,BuildingC,HengnanoneRoad,Gushucommunity,XixiangStreet,Bao’an District,ShenzhenCity 电话Tel:0755-23035723传真Fax:0755-23036702 邮箱E-mail:[email protected]网址HTTP:www.fmant.cn 客户 CUSTOMER 承认 ACCEPTEDBY 审核 CHECKEDBY 批准 APPROVEDBY 供应商 SUPPLIER 拟制 PREPAREDBY 审核 CHECKEDBY 批准 APPROVEDBY 杨轩 夏兴喜马冬冬 SHENZHENFEIMINTECHNOLOGYCO.,LTD. 深圳市飞敏科技有限公司 ShenzhenFeiminTechnologyCo.,Ltd2 2 1. 项目信息 ProjectInformation 1.1.外观尺寸AppearanceandDimensions SymbolDimension(mm) L（长度） 3.2±0.20 W（宽度） 1.6±0.20 T（厚度） 1.0±0.20 S（电极宽度） 0.4±0.20 SHENZHENFEIMINTECHNOLOGYCO.,LTD. 深圳市飞敏科技有限公司 ShenzhenFeiminTechnologyCo.,Ltd3 3 1.2.天线净空区面积antennaClearancearea 在设计天线时，应远离金属部件和不相关的部件，如电池、振荡器、防护罩、摄像头等，为天线留出 干净的空间。这个间隔简称为净空区。以下是我们建议预留的净空区面积大小。 Whendesigningtheantenna,itshouldbefarawayfrommetalcomponentsandirrelevant componentssuchasbatteries,oscillators,shields,cameras,etc.toleaveacleanspacefortheantenna. Thisintervaliscalledclearancearea.Thefollowingisthesizeofclearanceareawerecommendto reserve. 天线型号（Model） 天线尺寸 （size） 净空区面积 Clearancearea L*W(mm) A1（2.4G单极） 5.5*1.2*1.29.1*5.6 X5（2.4G单极） 5.2*2.2*1.08.7*6.5 X6（2.4Gpifa） 3.2*1.6*1.07.0*6.0 D1（2.4G单极） 5.2*2.2*1.08.7*6.5 D2（2.4G单极） 5.2*2.2*1.08.7*6.5 D3（2.4G单极） 3.4*1.7*1.27.2*6.5 F01（2.4Gpifa） 3.2*1.6*0.47.0*6.0 S2（2.4/5.8G双频） 7.0*3.0*2.09.0*7.0 U1(UHF单极） 15.0*3.0*1.019.0*8.0 G2（GPS单极） 8.5*3.0*1.013.5*7.5 SHENZHENFEIMINTECHNOLOGYCO.,LTD. 深圳市飞敏科技有限公司 ShenzhenFeiminTechnologyCo.,Ltd4 4 1.3.天线Demo测试板DemoTestBoardwithAntenna(Unit:mm) 1.4.匹配电路MatchingCircuit 使用以下推荐的匹配和调谐元件值，在我们的标准25*60mm评估板上，中心频率约为2440mhz。然 而，这些是典型的参考值，当电路板或零件供应商不同时，可能需要更改。 Withthefollowingrecommendedvaluesofmatchingandtuningcomponents,thecenter frequencieswillbeabout2440MHzatourstandard25*60mmevaluationboard.However,theseare typicalreferencevalueswhichmayneedtobechangedwhencircuitboardsorpartvendorsare diffierent. 3 421 系统匹配电路元件(村田) SystemMatchingCircuitComponent（Murata） LocationDesciptionTolerance 10.75pF(0402) ±0.1pF 2NC/ 31.0pF(0402) ±0.1pF 4NC/ SHENZHENFEIMINTECHNOLOGYCO.,LTD. 深圳市飞敏科技有限公司 ShenzhenFeiminTechnologyCo.,Ltd5 5 2. 电特性 ElectricalCharacteristics(25*60mmgroundplane) 2.1.电子表格ElectricalTable 特征Characteristics规范Specifications单位Unit 轮廓尺寸OutlineDimensions 3.2*1.6*1.0mm 工作频率WorkingFrequency 2400-2500MHz 电压驻波比VSWR <2/ 阻抗Impedance 50 Ω 极化Polarization线极化 / 增益Gain 峰值Peak 2dBi 效率Efficiency 50% 2.2.电压驻波比与Smith圆图VSWR&Smith VSWRS11 SHENZHENFEIMINTECHNOLOGYCO.,LTD. 深圳市飞敏科技有限公司 ShenzhenFeiminTechnologyCo.,Ltd6 6 2.3.天线增益与效率GainandEfficiency 测试系统Testsystem Frequency(MHz)Gain(dBi)Efficiency(%) 2400MHz 1.4350.15 2410MHz 1.3850.78 2420MHz 1.4950.49 2430MHz 1.3450.43 2440MHz 1.3050.04 2450MHz 1.5752.50 2460MHz 1.7656.12 2470MHz 1.8957.29 2480MHz 2.0558.23 2490MHz 2.0655.99 2500MHz 2.0653.66 SHENZHENFEIMINTECHNOLOGYCO.,LTD. 深圳市飞敏科技有限公司 ShenzhenFeiminTechnologyCo.,Ltd7 7 2.4.天线辐射方向图Antennaradiationpattern [email protected]@2.44GHz [email protected]@2.44GHz SHENZHENFEIMINTECHNOLOGYCO.,LTD. 深圳市飞敏科技有限公司 ShenzhenFeiminTechnologyCo.,Ltd8 8 3. 包装信息 PackagingInformation 3.1.胶带规范Tapespecification 指数Index A0B0K0P0PP2 φD0 WEFT 尺寸 Dimension( mm) 1.85 ±0.1 3.50 ±0.1 1.30 ±0.1 4.00 ±0.1 4.00 ±0.1 2.00 ±0.1 1.50 +0.1 12.00 ±0.3 1.75 ±0.1 3.20 ±0.1 0.30 ±0.05 1.10链轮孔距累积公差±0.20。10sprocketholepitchcumulativetolerance±0.20. 2.在250毫米中，载体的拱度在1毫米以内。Carriercamberiswithin1mmin250mm. 3.所有尺寸符合EIA-481-C要求。AlldimensionsmeetEIA-481-Crequirements. 4.材料:透明PS。Material:TransparentPS. 5.包装长度每7“卷:12.5米。Packinglengthper7"reel:12.5Meters. 6.组件加载/7”卷:3000个。Componentloadper7"reel:3000pcs.(前后共预留120pcs) 3.2.卷规范Reelspecification IndexABCD Dimension(mm)13.3±0.3100±0.3330±0.324.5±0.3 SHENZHENFEIMINTECHNOLOGYCO.,LTD. 深圳市飞敏科技有限公司 ShenzhenFeiminTechnologyCo.,Ltd9 9 4. 注意事项 Notes 1)产品应小心处理，以避免汗水和皮肤油脂损坏或污染。 Productsshouldbehandledwithcaretoavoiddamageorcontaminationfromperspirationandskinoils. 2)对于单个部件，强烈建议使用镊子或真空拾取。 Theuseoftweezersorvacuumpickupisstronglyrecommendedforindividualcomponents. 5. 储存条件 StorageConditions 1)推荐产品从交货之日起6个月内使用。 Recommendedproductsshouldbeusedwithin6monthsformthetimeofdelivery. 2)存储环境条件 Storageenvironmentcondition 温湿度条件:-10~40°C，30~70%RH。 Temperatureandhumidityconditions:-10~40°Cand30~70%RH. 包装材料应保存在空气中不含氯或硫的地方。 Thepackagingmaterialshouldbekeptwherenochlorineorsulfurexistsintheair. 产品应储存在仓库内，无热震、振动、阳光直射等。 Productsshouldbestorageinthewarehousewithoutheatshock,vibration,directsunlightandsoon.

Page 1 of 28 Report No.: HK2304211555-E FCC Test Report Test report On Behalf of Huizhou LATU FILM EQUIPMENT Co., Ltd For wireless microphone Model No.: GVM-MIC-LM2 FCC ID: 2BA2H-GVM-MIC-LM2 Prepared For : Huizhou LATU FILM EQUIPMENT Co., Ltd No. 9 Tai’an Road, Ma’an Town, Huicheng District, Huizhou City, Guangdong Province, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Apr. 19, 2023 ~ Apr. 26, 2023 Date of Report: Apr. 26, 2023 Report Number: HK2304211555-E Page 2 of 28 Report No.: HK2304211555-E TEST RESULT CERTIFICATION Applicant’s name ................. : Huizhou LATU FILM EQUIPMENT Co., Ltd Address ................................. : No. 9 Tai’an Road, Ma’an Town, Huicheng District, Huizhou City, Guangdong Province, China Manufacture's Name ............ : Huizhou LATU FILM EQUIPMENT Co., Ltd Address ................................. : No. 9 Tai’an Road, Ma’an Town, Huicheng District, Huizhou City, Guangdong Province, China Product description Trade Mark: Great Video Maker Product name ........................... : wireless microphone Model and/or type reference : GVM-MIC-LM2 Standards ............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.249 ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Apr. 19, 2023 ~ Apr. 26, 2023 Date of Issue ........................................... : Apr. 26, 2023 Test Result .............................................. : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 3 of 28 Report No.: HK2304211555-E Table of Contents Page 1 . Test Summary 5 1.1 . Test Procedures and Results 5 1.2 . Information of the Test Laboratory 5 1.3 . Measurement Uncertainty 5 2 . General Information 6 2.1 . General Description of EUT 6 2.2 . Operation of EUT During Testing 7 2.3 . Description of Test Setup 8 2.4 . Measurement Instruments List 9 3 . Conducted Emissions Test 10 3.1. Conducted Power Line Emission Limit 10 3.2. Test Setup 10 3.3. Test Procedure 10 3.4. Test Result 11 4. Radiated Emission Test 13 4.1. Radiation Limit 13 4.2. Test Setup 13 4.3. Test Procedure 14 4.4. Test Result 14 5. Band Edge 20 5.1. Limits 20 5.2. Test Procedure 20 5.3. Test Result 21 6. Occupied Bandwidth Measurement 23 6.1. Test Setup 23 6.2. Test Procedure 23 6.3. Measurement Equipment Used 23 6.4. Test Result 23 7. Antenna Requirement 25 8. Photograph of Test 26 9. Photos of the EUT 28 Page 4 of 28 Report No.: HK2304211555-E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release Apr. 26, 2023 Jason Zhou Page 5 of 28 Report No.: HK2304211555-E 1. Test Summary 1.1. Test Procedures and Results DESCRIPTION OF TEST SECTION NUMBER RESULT CONDUCTED EMISSIONS TEST 15.207 COMPLIANT RADIATED EMISSION TEST 15.249(a)/15.209 COMPLIANT BAND EDGE 15.249(d)/15.205 COMPLIANT OCCUPIED BANDWIDTH MEASUREMENT 15.215（c） COMPLIANT ANTENNA REQUIREMENT 15.203 COMPLIANT 1.2. Information of the Test Laboratory Shenzhen HUAK Testing Technology Co., Ltd. Add.: 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Testing Laboratory Authorization： A2LA Accreditation Code is 4781.01. FCC Designation Number is CN1229. Canada IC CAB identifier is CN0045. CNAS Registration Number is L9589. 1.3. Measurement Uncertainty Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.71dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.90dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 3.90dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.28dB, k=2 Page 6 of 28 Report No.: HK2304211555-E 2. General Information 2.1. General Description of EUT Equipment: wireless microphone Model Name: GVM-MIC-LM2 Series Model: N/A Model Difference: N/A FCC ID: 2BA2H-GVM-MIC-LM2 Antenna Type: Ceramic Antenna Antenna Gain: 2.05dBi Operation frequency: 2402-2480MHz Number of Channels: 79CH Modulation Type: GFSK Power Source: DC 3.7V from battery or DC 5V from Type-C or DC 5V from Charging bay Power Rating: DC 3.7V from battery or DC 5V from Type-C or DC 5V from Charging bay Page 7 of 28 Report No.: HK2304211555-E 2.1.1. Carrier Frequency of Channels Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 1 2402 28 2429 55 2456 2 2403 29 2430 56 2457 3 2404 30 2431 57 2458 4 2405 31 2432 58 2459 5 2406 32 2433 59 2460 6 2407 33 2434 60 2461 7 2408 34 2435 61 2462 8 2409 35 2436 62 2463 9 2410 36 2437 63 2464 10 2411 37 2438 64 2465 11 2412 38 2439 65 2466 12 2413 39 2440 66 2467 13 2414 40 2441 67 2468 14 2415 41 2442 68 2469 15 2416 42 2443 69 2470 16 2417 43 2444 70 2471 17 2418 44 2445 71 2472 18 2419 45 2446 72 2473 19 2420 46 2447 73 2474 20 2421 47 2448 74 2475 21 2422 48 2449 75 2476 22 2423 49 2450 76 2477 23 2424 50 2451 77 2478 24 2425 51 2452 78 2479 25 2426 52 2453 79 2480 26 2427 53 2454 27 2428 54 2455 2.2. Operation of EUT During Testing Operating Mode The mode is used: Transmitting mode Low Channel: 2402MHz Middle Channel: 2441MHz High Channel: 2480MHz Page 8 of 28 Report No.: HK2304211555-E 2.3. Description of Test Setup Operation of EUT during conducted testing and radiation below 1GHz testing: AC Plug Operation of EUT during radiation above 1GHz testing: Adapter information Model: HW-059200CHQ Input: 100-240V, 50/…

Text truncated - open the document above for the full version.

Model: GVM-MIC-LM2 Radiated Emissions Conducted Emission
