2BA2K-TCS-07505TUO Contact Sensor

TUO Getting Started Empezando Contact Sensor 1 Press the button on the front of the contact sensor to activate. Presione el botón en la parte frontal del sensor de contacto para activarlo. Getting started • Empezando Pairing & activation • Emparejamiento y activación 2 Pair the TUO Contact Sensor to the home hub of your choice. Ensure your network has a compatible read Border Router. To learn more about read Border Routers, head to http://findtuo.com/borderrouter Empareje el sensor de contacto TUO con el concentrador doméstico de su elección. Asegúrese de que su red tenga un enrutador de borde de hilo compatible. Para obtener más información sobre los enrutadores de borde de subprocesos, diríjase a http://find- tuo.com/borderrouter Pairing & activation • Emparejamiento y activación 3 Remove the backplate and flip it over to reveal the pairing code. Scan or type in the manual pairing code in the platform of your choice. Retire la placa posterior y gírela para revelar el código de emparejamiento. Escanee o escriba el código de emparejamiento manual en la plataforma de su elección. 123-45-678 4 Battery replacement • Cambio de batería When it is time to replace the battery, simply turn the TUO Contact Sensor around and remove the backplate. Cuando llegue el momento de reemplazar la batería, simplemente gire el sensor de contacto TUO y retire la placa posterior. 5 Resetting the device • Restablecer el dispositivo To preform a so reset, push the button on the front of the TUO Contact Sensor. e green light will begin to flash when a reboot is successful. Push it in and hold for 5 seconds to completely reset the device. Please note that this will remove the device from the platform you are using and will require re-pairing. Para realizar un restablecimiento parcial, presione el botón en la parte frontal del sensor de contacto TUO. La luz verde comenzará a parpadear cuando el reinicio sea exitoso. Presiónelo y manténgalo presionado durante 5 segundos para restablecer completamente el dispositivo. Tenga en cuenta que esto eliminará el dispositivo de la plataforma que está utilizando y requerirá volver a emparejarlo. 6 Backplate mounting • Montaje de placa posterior e backplate can be removed from the TUO Contact Sensor and can be mounted by screws or tape to the door / window. La placa trasera se puede quitar del sensor de contacto TUO y se puede montar con tornillos o cinta adhesiva en la puerta/ventana. Backplate mounting • Montaje de placa posterior Magnet warning: is device contains a magnet and should be kept away from people with pacemakers or other medical devices that may be affected by magnetic fields. It is important to keep the device at a safe distance from these individuals to avoid any potential harm or interference with their medical devices. Please note that failure to follow the safety instructions and warnings provided in the user manual may result in injury, damage to property, or other harmful consequences. Warning Legal information is device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. is equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC rules. ese limits are designed to provide reasonable protection against harmful interference in a residential installation. is device generates uses and can radiate radio frequency energy, and if not installed and used in accordance with instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harm to television reception, which can be determined by turning the equipment off and on, you are encouraged to try to correct the interference by one or more of the following measures: re-orient or relocate the receiving antenna, increase separation between the equipment and receiver, or consult a dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by TUO Accessories LLC can void the user's authority to operate this device. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body. Información legal Este dispositivo cumple con la parte 15 de las normas de la FCC. El funcionamiento está sujeto a las siguientes dos condiciones: (1) este dispositivo no puede causar interferencias y (2) este dispositivo debe aceptar cualquier interferencia recibida, incluidas las interferencias que puedan causar un funcionamiento no deseado. Este equipo ha sido probado y se encontró que cumple con los límites para un dispositivo digital de Clase B de conformidad con la parte 15 de las normas de la FCC. Estos límites están diseñados para brindar una protección razonable contra interferencias dañinas en una instalación residencial. Este dispositivo genera usos y puede irradiar energía de radiofrecuencia y, si no se instala y utiliza de acuerdo con las instrucciones, puede causar interferencias dañinas en las comunicaciones por radio. Sin embargo, no hay garantía de que no se produzcan interferencias en una instalación en particular. Si este dispositivo causa daño a la recepción de televisión, lo que se puede determinar apagando y encendiendo el equipo, se recomienda que intente corregir la interferencia mediante una o más de las siguientes medidas: reoriente o reubique la antena receptora, aumente separación entre el equipo y el receptor, o consulte a un distribuidor o a un técnico de radio/TV experimentado para obtener ayuda. Los cambios o modificaciones no aprobados expresamente por TUO Accessories LLC pueden anular la autoridad del usuario para operar es…

Text truncated - open the document above for the full version.

TUO Accessories LLC 410 Park Avenue16th Floor New York,United States Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023-7-7 U.S. Agent Designation TUO Accessories LLC acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BA2K-TCS-07505): Name and company of U.S. agent: TUO Accessories LLC Physical U.S. address of agent: 410 Park Avenue16th Floor New York,United States FRN of U.S. agent: 0033714205 Email address of U.S. agent: [email protected] TUO Accessories LLC acknowledges their obligation to accept service of process on behalf of TUO Accessories LLC . TUO Accessories LLC with the FRN [0033714205] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Sam Gabbay Manager TUO Accessories LLC Signature Sam Gabbay Manager TUO Accessories LLC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5

Sincerely, Name/Title： Sam Gabbay/Manager Company: TUO Accessories LLC Address: 410 Park Avenue16th Floor New York,United States Phone: (732) 861-9716 Fax: N/A E-Mail: [email protected]

FCC ID: 2BA2K-TCS-07505 External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BA2K-TCS-07505 Photo 4 Photo 5 Photo 6 FCC ID: 2BA2K-TCS-07505 Photo 7 Photo 8

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location Model No.: TCS-07505 FCC ID : 2BA2K-TCS-07505

FCC ID: 2BA2K-TCS-07505 Internal Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BA2K-TCS-07505 Photo 4 Photo 5

RF Exposure evaluation FCC ID: 2BA2K-TCS-07505 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) -2.0 -1.0 -1.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.450 5 0.0 1.0000 0.3130<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

1. Antenna Description: Antenna type PCB antenna Model TCS-07505 Frequency range 2400-2500MHz Manufacturer TUO Accessories LLC ANT Peak Gain 0.58 dBi 2. Antenna Photo: Length :10.95mm Width:3.59mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ........................................... : CTA23070401501 2BA2K-TCS-07505 Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Amy Wen Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Jul. 05, 2023 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : TUO Accessories LLC Address ............................................ : 410 Park Avenue16th Floor New York, NY 10022 Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment description ................... : TUO Contact Sensor Trade Mark ....................................... : N/A Manufacturer .................................... : Jiangxi Kemei Electronic Technology Co., Ltd. Model/Type reference....................... : TCS-07505 Listed Models .................................. : N/A Modulation ....................................... : GFSK Frequency .......................................... From 2402MHz to 2480MHz Ratings ............................................. : DC 3.0V From Battery Result................................................ : PASS Report No.: CTA23070401501 Page 2 of 33 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : TUO Contact Sensor Model /Type : TCS-07505 Listed Models : N/A Applicant : TUO Accessories LLC Address : 410 Park Avenue16th Floor New York, NY 10022 Manufacturer : Jiangxi Kemei Electronic Technology Co., Ltd. Address : No.3 Industrial Park, Guang'Chang County, FuZhou City, JiangXi Province China 344999 Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA23070401501 Page 3 of 33 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S .................................................................. 4 2 S U M M A R Y ............................................................................. 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T ............................................................... 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ............................................ 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emissions and Band Edge 11 4.3 Maximum Peak Output Power 18 4.4 Power Spectral Density 19 4.5 6dB Bandwidth 21 4.6 Out-of-band Emissions 23 4.7 Antenna Requirement 27 5 T E S T S E T U P P H O T O S O F T H E E U T .......................................... 28 6 P H O T O S O F T H E E U T ............................................................. 29 Report No.: CTA23070401501 Page 4 of 33 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V05r02: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: CTA23070401501 Page 5 of 33 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Jun. 30, 2023 Testing commenced on : Jun. 30, 2023 Testing concluded on : Jul. 05, 2023 2.2 P…

Text truncated - open the document above for the full version.

FCC ID: 2BA2K-TCS-07505 Test Setup Photos of the EUT
