2BA2LH7GPSAi Navigator Halo Remote

MGI Golf Inc 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: MGI Golf Inc Address: 6825 Speedway Blvd Suite #B101B Las Vegas, Nevada 89115 United States Product Name: Ai Navigator Halo Remote FCC ID: 2BA2LH7GPS Model(s): Ai Navigator Halo Remote 2.911(d)(5)(i) Equipment Type We, [MGI Golf Inc] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Miranda Turner Date: 2026.01.22 Title and Company name: CEO / MGI Golf Inc NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

MGI Golf Inc 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: MGI Golf Inc Address: 6825 Speedway Blvd Suite #B101B Las Vegas, Nevada 89115 United States Product Name: Ai Navigator Halo Remote FCC ID: 2BA2LH7GPS Model(s): Ai Navigator Halo Remote 2.911(d)(5)(ii) Applicant filing We, [MGI Golf Inc] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Miranda Turner Date: 2026.01.22 Title and Company name: CEO / MGI Golf Inc NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

2.911 (d)(7)USA Agent v1.5 MGI Golf Inc Section 2.911(d)(7) USA Agent for Service of Process Company name: MGI Golf Inc Address: 6825 Speedway Blvd Suite #B101B Las Vegas Nevada 89115 United States Product Name: Ai Navigator Halo Remote FCC ID: 2BA2LH7GPS Model(s): Ai Navigator Halo Remote 2.911(d)(7) USA Designated Agent for Service of Process We, [MGI Golf Inc] (“the applicant”) designate [MGI Golf Inc] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: MGI Golf Inc USA Address: 6825 Speedway Blvd Suite #B101B Las Vegas Nevada 89115 United States FRN Number: 0030129688 Contact Name: Miranda Turner Telephone No: (800) 617-2990 Email: [email protected] Applicant Company name: MGI Golf Inc Address: 6825 Speedway Blvd Suite #B101B Las Vegas Nevada 89115 United States Grantee FRN Number: 0030129688 FCC Grantee Code: 2BA2L Contact Name: Miranda Turner Telephone No: (800) 617-2990 Email: [email protected] Signature: Title: CEO Date: 2026.01.22 Signature: Title: CEO Date: 2026.01.22 MGI Golf Inc 2.911 (d)(7)USA Agent v1.5 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

MGI Golf Inc Agent Authorization Company: MGI Golf Inc Address: 6825 Speedway Blvd Suite #B101B Las Vegas, Nevada 89115 United States Product Name: Ai Navigator Halo Remote Model Number(s): Ai Navigator Halo Remote Product Description: Ai Navigator Halo Remote We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: January 22, 2026 Name: Miranda Turner Title: CEO Company: MGI Golf Inc

MGI Golf Inc Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: January 22, 2026 Subject; Request for Confidentiality FCC ID: 2BA2LH7GPS To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Miranda Turner Title: CEO

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 3 Model: Ai Navigator Halo Remote External Photos Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 3 Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 3

LABEL: Label Location:

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 3 Model: Ai Navigator Halo Remote Internal Photos Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 3 ANT Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 3 of 3

Shenzhen CTB Testing Co., Ltd. FCC ID:2BA2LH7GPS Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BLE: Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 0.38 1.09 0±1 1.00 1.26 <5 0.39023 3.00 YES 2.44 -0.022 0.99 0±1 1.00 1.26 <5 0.39330 3.00 YES 2.480 -1.014 0.79 -1±1 0.00 1.00 <5 0.31496 3.00 YES GFSK Conclusion: For the max result : 0.39330≤ FCC Limit 3.0 for 1g SAR.

DATASHEET PartNo.1001312 Product: Wi-Fi/Bluetooth orUWBCeramicAntenna PartNo.1001312 Wi-Fi /BT/ Zigbeeor UWB CeramicAntenna 2.4GHzor6.0–8.5GHz Supports:Wi-Fiapplications,Agriculture,Automotive,Bluetooth,Zigbee,WLAN,SmartHome,Healthcare,DigitalSignage,UWB 8/4/2022Proprietary www.KYOCERA-AVX.com Layouts: 1001312-01:SingleBand2.4GHzlayout 1001312-04:UWB6.0-8.5GHzlayout(Appendix1) ElectricalSpecifications Typicalperformanceon55x25mmPCB MechanicalSpecifications&OrderingPartNumber *UWBlayoutofferedinAppendix1 CeramicWi-FiorUWB CeramicAntenna 2400–2485MHz; 6.0–8.5GHz •Embedded design •Cellular, Headsets, Tablets •Gateway, Access Point •Handheld •Telematics •Tracking •Healthcare •M2M, Industrial devices •SmartGrid •OBD-II •UWB KEYBENEFITS Stay-in-Tune The ceramic antenna provides superior RF field containment, resulting in less interaction with surrounding components. Quicker Time-to-Market Byoptimizingantennasize, performance and emissions, customer and regulatoryspecifications aremoreeasilymet. Reliability Products are the latest RoHSversioncompliant. APPLICATIONS OrderingPartNumber1001312 Size(mm)2.00x1.20x0.55 MountingSMT Weight(grams)0.003 Packaging Tape&Reel, 1001312–5,000piecesper reel DemoBoard 1001312-01(2.400-2.485GHz) 1001312-04(UWB6.000-8.500GHz) KYOCERAAVXceramicantennadesignedforWi-Fi/BTandUWBapplications exhibitsthehighefficiencyinasmallfootprintanddeliversthekeyneedstothe deviceengineersforthehigherfunctionalityandbetterperformanceinasmaller andthinnerdesigns.Forfurtheroptimizationtocustomdesignandforsupport tointegrateandtestthisantennaperformanceinyourdevice,contactour CustomerSupportTeam. Real-WorldPerformanceandImplementation Ceramicantennasmaylookalikeontheoutside,buttheimportantdifference isinside.OtherantennasmaycontainsimplePIFAormonopoledesignsthat interactwiththeirsurroundings,complicatinglayoutorchangingperformance withuseposition. Frequency2400–2485MHz6.0–8.5GHz PeakGain1.88dBi AverageEfficiency62% VSWRMatch1.8:1max FeedPointImpedance50ohmsunbalanced PolarizationLinear PowerHandling0.5WattCW TDS-ANT-0080 | Rev. 1 © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 TopView BottomView Pin#1 PinDescription 1 Feed 2 Ground PartNumberA(mm)B(mm)C(mm) 10013122.0±0.31.2±0.30.55±0.2 Height DATASHEET|PartNo. 1001312 C Pin#2 AntennaDimensions Typicalantennadimensions(mm) A B *Pin #1 and Pin #2 are interchangeable. 2.4 GHz KYOCERA AVXEmbeddedAntennaSpecifications KYOCERA AVXproducesawidevarietyofstandardandcustomantennastomeetuserneeds. TDS-ANT-0080 | Rev. 1 © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 VSWR Efficiency AntennaRadiationPatterns Typicalperformanceon55x25mmPCB Measured@2440MHz Frequency(MHz)Frequency(MHz) Effi c ie n cy ( %) VS W R Y X Y Z X Z DATASHEET|PartNo. 1001312 2.4GHz KYOCERA AVXEmbeddedAntennaSpecifications KYOCERA AVXproducesawidevarietyofstandardandcustomantennastomeetuserneeds. VSWR,EfficiencyPlots Typicalperformanceon55x25mmPCB TDS-ANT-0080 | Rev. 1 © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 Antenna Outline DATASHEET|PartNo. 1001312 Pin#1 Pin#2 Pin#Description 1 Feed 2 Ground MatchingPiNetwork(DemoBoard) ComponentValueTolerance P1 4.7nH±0.1nH P2 DNIN/A S1 0ΩN/A R1 0ΩN/A R2–R8 DNIN/A 50Ω Transmission line S1 Antenna Outline P1 P2 Pin#2 *Actualmatchingvalues dependon customerdesign *0Ωmaybeaddedtoshift frequencyhigher Pin#1 R1 R2 50ohm P1 S1 P2 R3 R4 R5 R6 R7 R8 •AdditionalVIAS:Diam.0.2mmto beplacedaroundantenna, (novias ontransmissionlines). •Viaholesmustbecoveredbysolder mask PinDescriptions R1 R2R3R4R5R6 R7 R8 AntennaLayout(1001312-01) Typicallayoutdimensions(mm) 2.4 GHz KYOCERA AVXEmbeddedAntennaSpecifications KYOCERA AVXproducesawidevarietyofstandardandcustomantennastomeetuserneeds. TDS-ANT-0080 | Rev. 1 © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 PartNumberABC 1001312-0155.025.026.0 DATASHEET|PartNo. 1001312 A B C AntennaDemoBoard Typicallayoutdimensions(mm) 2.4 GHz KYOCERA AVXEmbeddedAntennaSpecifications KYOCERA AVXproducesawidevarietyofstandardandcustomantennastomeetuserneeds. TDS-ANT-0080 | Rev. 1 © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 DATASHEET|PartNo. 1001312 Appendix1 UWBCeramicKYOCERA AVXEmbeddedAntennaSpecifications KYOCERA AVXproducesawidevarietyofstandardandcustomantennastomeetuserneeds. Frequency(GHz)6.0–8.5 PeakGain4.8dBi AverageEfficiency84% VSWRMatch2.0:1max FeedPointImpedance50ohmsunbalanced PolarizationLinear PowerHandling2WattCW Appendix1 Appendix 1 gives instructions on how to achieve UWB performances through layout and impedance matchingnetwork. (6.0–8.5GHz) *Datashownabovehas Appendix1 matchingappliedon 26.0 x25.0mm PCB, UsingUWB1001312-04layout TDS-ANT-0080 | Rev. 1 © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 VSWR,EfficiencyPlots Typicalperformanceon26.0x25.0mmPCB VSWR Efficiency AntennaRadiationPatterns Typicalperformanceon26.0x25.0mmPCB Measured@6500,7000,8000 MHz Y X Y Z X Z DATASHEET|PartNo. 1001312 Appendix1 UWBCeramicKYOCERA AVXEmbeddedAntennaSpecifications KYOCERA AVXproducesawidevarietyofstandardandcustomantennastomeetuserneeds. TDS-ANT-0080 | Rev. 1 © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 Antenna Outline DATASHEET|PartNo. 1001312 Antenna Outline S1 P1 Pin#1 Pin#2 Pin#Description 1 Feed 2 Ground MatchingPiNetwork(DemoBoard) ComponentValueTolerance P1 DNIN/A S1 0ΩN/A P2 DNIN/A 50Ω Transmission line •AdditionalVIAS:Diam.0.2mmto beplacedaroundantenna, (novias ontransmissionlines). •Viaholesmustbecoveredbysolder mask PinDescriptions P2 *Actualmatchingvaluesdependon customerdesign Pin#1 Pin#2 Appendix1 UWBCeramicKYOCERA AVXEmbeddedAntennaSpecifications KYOCERA AVXproduces…

Text truncated - open the document above for the full version.

Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 36 TEST REPORT Compiled by: Reviewed by: Approved by: Kai Chen Martin Feng Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were fulfilled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Test item description: Ai Navigator Halo Remote FCC ID: 2BA2LH7GPS Trademark(s): Model/Type reference: Ai Navigator Halo Remote Applicant’s name: MGI Golf Inc Address: 6825 Speedway Blvd Suite #B101B Las Vegas, Nevada 89115 United States Manufacturer: Millennium Electronics Intemational Pty Ltd Address: 1 Webber Parade, Keilor East,VIC,3033,Australia Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Building A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Dec. 11, 2025 Sample tested Date: Dec. 11, 2025 to Jan. 22, 2026 Issue Date: Jan. 22, 2026 Report No.: CTB25111101403RF01 Test Standards FCC CFR Title 47 Part 15 Subpart C Section 15.247 ANSI C63.10:2020 Test Results PASS Remark: This is Bluetooth radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB25111101403RF01 Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 36 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ........................................................................................................................................ 3 2. TEST SUMMARY ........................................................................................................................... 4 3. MEASUREMENT UNCERTAINTY ................................................................................................. 5 4. PRODUCT INFORMATION AND TEST SETUP ............................................................................ 6 4.1 Product Information .......................................................................................................................... 6 4.2 Test Setup Configuration .................................................................................................................. 6 4.3 Support Equipment........................................................................................................................... 6 4.4 Channel List ..................................................................................................................................... 7 4.5 Test Mode ........................................................................................................................................ 7 4.6 Test Environment ............................................................................................................................. 7 5. TEST FACILITY AND TEST INSTRUMENT USED ....................................................................... 8 5.1 Test Facility ...................................................................................................................................... 8 5.2 Test Instrument Used ....................................................................................................................... 8 6. AC POWER LINE CONDUCTED EMISSION ................................................................................ 11 6.1 Block Diagram Of Test Setup ......................................................................................................... 11 6.2 Limit ................................................................................................................................................ 11 6.3 Test procedure ............................................................................................................................... 11 6.4 Test Result ..................................................................................................................................... 13 7. RADIATED SPURIOUS EMISSION ............................................................................................. 15 7.1 Block Diagram Of Test Setup ......................................................................................................... 15 7.2 Limit ................................................................................................................................................ 15 7.3 Test procedure ............................................................................................................................... 15 7.4 Test Result ..................................................................................................................................... 17 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS ............................................... 24 8.1 Block Diagram Of Test Setup ......................................................................................................... 24 8.2 Limit ................................................................................................................................................ 24 8.3 Test procedure ............................................................................................................................... 24 8.4 Test Result ..................................................................................................................................... 25 9. COUDUCTED OUTPUT POWER ................................................................................................. 27 9.1 Block Diagram Of Test Setup .................................…

Text truncated - open the document above for the full version.

Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 1 of 2 Model: Ai Navigator Halo Remote Radiated Emission Below 1G Above 1G Shenzhen CTB Testing Technology Co., Ltd. Report Tel: 4008-707-283 Web: http://www.ctb-lab.net Page 2 of 2 Conducted emissions
