2BA38-Q1ADFPortable Speaker

FCC Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The device has evaluated to meet general RF exposure requirement. The device can be used be in portable exposure without restriction.

DongguanKangjindaElectronicTechnologyCo.,Ltd 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType Companyname:DongguanKangjindaElectronicTechnologyCo.,Ltd Address:Room801,No.36,YuchengRoad,Chang'anTown,Dongguan,Guangdong ProductName:PortableSpeaker FCCID:2BA38-Q1ADF Model(s):Q1,Q2,Q3,Q5,Q6,Q7,Q8,Q9,Q10,A1,A2,A3,A5,A6,A7,A8,A9,A10 D1,D2,D3,D5,D6,D7,D8,D9,D10,F1,F2,F3,F5,F6,F7,F8,F9,F10 2.911(d)(5)(i)EquipmentType We,[DongguanKangjindaElectronicTechnologyCo.,Ltd](“theapplicant”)certifythattheequipment forwhichauthorizationissoughtthroughcertificationisnot: Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules. Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:LaiZhifuDate:2023.07.04 TitleandCompanyname:Manager/DongguanKangjindaElectronicTechnologyCo.,Ltd NOTE1 “CoveredList ” ;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

DongguanKangjindaElectronicTechnologyCo.,Ltd 2.911(d)(5)(ii)ApplicantAttestationv1.3 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname:DongguanKangjindaElectronicTechnologyCo.,Ltd Address:Room801,No.36,YuchengRoad,Chang'anTown,Dongguan,Guangdong ProductName:PortableSpeaker FCCID:2BA38-Q1ADF Model(s):Q1,Q2,Q3,Q5,Q6,Q7,Q8,Q9,Q10,A1,A2,A3,A5,A6,A7,A8,A9,A10 D1,D2,D3,D5,D6,D7,D8,D9,D10,F1,F2,F3,F5,F6,F7,F8,F9,F10 2.911(d)(5)(ii)Applicantfiling We,[DongguanKangjindaElectronicTechnologyCo.,Ltd](“theapplicant”)certifythat,asofthedate ofthefilingoftheapplication,theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE2 , establishedpursuantto§1.50002ofthischapter,asanentityproducingcoveredcommunications equipment. Yourssincerely, Name:LaiZhifuDate:2023.07.04 TitleandCompanyname:Manager/DongguanKangjindaElectronicTechnologyCo.,Ltd . NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList ” ;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

DongguanKangjindaElectronicTechnologyCo.,Ltd AgentAuthorization Company:DongguanKangjindaElectronicTechnologyCo.,Ltd Address:Room801,No.36,YuchengRoad,Chang'anTown,Dongguan,Guangdong ProductName:PortableSpeaker ModelNumber(s):Q1,Q2,Q3,Q5,Q6,Q7,Q8,Q9,Q10,A1,A2,A3,A5,A6,A7,A8,A9,A10 D1,D2,D3,D5,D6,D7,D8,D9,D10,F1,F2,F3,F5,F6,F7,F8,F9,F10 ProductDescription:PortableSpeaker WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2023.07.04 Name:Laizhifu Title:Manager Company:DongguanKangjindaElectronicTechnologyCo.,Ltd

DongguanKangjindaElectronicTechnologyCo.,Ltd OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2023.07.04 Subject;RequestforConfidentiality FCCID:2BA38-Q1ADF ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:Laizhifu Title:Manager

ExternalPhotos

Lable:

InternalPhotos BTantenna

FCC ID:2BA38-Q1ADF RF Exposure Evaluation According to KDB 447498 V06 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the correspondingSAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 5 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, So a SAR test is not required ModeFrequen cy (MHz) Max Power (dBm) Target power W/ tolerance (dBm) Max tune up power tolerance (dBm) Max Power (mW) Min. Distance (mm) Calc. thresholds limit EDR GFSK 2402 1.253 2±1.0 3 1.9953 5 0.6185 3.0 2441 1.406 2±1.03 1.9953 5 0.6235 3.0 2480 1.767 2±1.0 3 1.9953 5 0.6284 3.0 π/4-DQ PSK 2402 2.142 2±1.03 1.9953 5 0.6185 3.0 2441 2.252 2±1.0 3 1.9953 5 0.6235 3.0 2480 2.587 2±1.03 1.9953 5 0.6284 3.0 8-DPSK 2402 2.651 3±1.0 4 2.5119 5 0.7786 3.0 2441 2.803 3±1.04 2.5119 5 0.7849 3.0 2480 3.108 3±1.0 4 2.5119 5 0.7911 3.0

Product specification Quick Reference Date Antenna module on the system board Frequenc Range 2400 ~ 2500MHz Ant. Port Input Pwr. (dBm) 0 (Typ. BT class 2 output power) Tot. Rad. Pwr. (dBm) -1.2 (Input pwr – loss pwr) Peak EIRP(dBm) 0.7 Directivity (dBi) 1 (all direction antenna) Efficiency (dB) 6 0.2 % Gain (dBi) 1.9(Peak Gain XY-plane) Maximum Power (dBm) 1.9 (XY-plane) Minimum Power (dBm) -4(XY-plane) Avg. Power (dBm) -0.5(XY-plane) Input Impendence(ohm) 50 Polarization Type V ertical & Horizontal V . S .W . R < 1.4 All the technical data and information contained herein are subject to ch ange without prior notice Antenna Layout & module on the system board Antenna Gain Gain Table Unit in dBi @2.4GHz XY-plane XZ-plane YZ-plane Efficiency Peak Avg. Peak Avg. Peak Avg. Module Board 1.2 -0.5 1.9 -3.6 1.1 -3.0 6 0.2 % Retum Loss The Environment of Antenna Radiation Pattem 3D radiation pattern diagram XY-plane XZ-plane YZ-plane

ProjectNo.:ZKT-230508L3315E Page 1 of 67 FCCTESTREPORT FCCID:2BA38-Q1ADF ReportNumber. .................................... :ZKT-230508L3315E DateofTest......................................................:May.4,2023toMay.12,2023 Dateofissue.........................................:May.12,2023 Totalnumberofpages.........................67 TestResult..........................................: PASS TestingLaboratory...........................: ShenzhenZKTTechnologyCo.,Ltd. Address...............................................: 1/F,No.101,BuildingB,No.6,TangweiCommunityIndustrial Avenue,FuhaiStreet,Bao'anDistrict,Shenzhen,China Applicant'sname.............................: DongguanKangjindaElectronicTechnologyCo.,Ltd Address ............................................... : Room801,No.36,YuchengRoad,Chang'anTown,Dongguan, Guangdong Manufacturer'sname......................: DongguanKangjindaElectronicTechnologyCo.,Ltd Address...............................................: Room801,No.36,YuchengRoad,Chang'anTown,Dongguan, Guangdong Testspecification: Standard ................................................ : FCCCFRTitle47Part15SubpartCSection15.247 ANSIC63.10:2013 Testprocedure ..................................... : / Non-standardtestmethod................:N/A TestReportFormNo........................: TRF-EL-112_V0 TestReportForm(s)Originator ..... : ZKTTesting MasterTRF ........................................ : Dated:2021-04-22 ThisdevicedescribedabovehasbeentestedbyZKT,andthetestresultsshowthattheequipmentunder test(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlytothetestedsample identifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofZKT,thisdocumentmay bealteredorrevisedbyZKT,personalonly,andshallbenotedintherevisionofthedocument. Productname ..................................... : PortableSpeaker Trademark...........................................: N/A Model/Typereference.........................: Q1,Q2,Q3,Q5,Q6,Q7,Q8,Q9,Q10,A1,A2,A3,A5,A6,A7,A8,A9,A10 D1,D2,D3,D5,D6,D7,D8,D9,D10,F1,F2,F3,F5,F6,F7,F8,F9,F10 Ratings..................................................: DC5VfromAdapterinputAC120V/60HzorDC3.7VfromBattery ProjectNo.:ZKT-230508L3315E Page 2 of 67 Testingprocedureandtestinglocation: TestingLaboratory .......................................... :ShenzhenZKTTechnologyCo.,Ltd. Address............................................................:1/F,No.101,BuildingB,No.6,TangweiCommunity IndustrialAvenue,FuhaiStreet,Bao'anDistrict, Shenzhen,China AlenHe Testedby(name+signature) ....................... : JoeLiu Reviewer(name+signature) ....................... : LakeXie Approved(name+signature) ....................... : ProjectNo.:ZKT-230508L3315E Page 3 of 67 TableofContents Page 1.VERSION.............................................................5 2.TESTSUMMARY......................................................6 2.1TESTFACILITY.......................................................7 2.2MEASUREMENTUNCERTAINTY.......................................7 3.GENERALINFORMATION..............................................8 3.1GENERALDESCRIPTIONOFEUT.....................................8 3.2TestSetupConfiguration...............................................9 3.3SupportEquipment....................................................9 3.4TestMode...........................................................10 3.5EQUIPMENTSLISTFORALLTESTITEMS.............................11 4.EMCEMISSIONTEST.................................................13 4.1Conductedemissions.................................................13 4.1.1POWERLINECONDUCTEDEMISSIONLimits........................13 4.1.2TESTPROCEDURE................................................13 4.1.3DEVIATIONFROMTESTSTANDARD................................13 4.1.4TESTSETUP......................................................13 4.1.5EUTOPERATINGCONDITIONS.....................................14 4.1.6TestResult........................................................15 4.2Radiatedemissions...................................................17 4.2.1RadiatedEmissionLimits............................................17 4.2.2TESTPROCEDURE................................................17 4.2.3DEVIATIONFROMTESTSTANDARD................................18 4.2.4TESTSETUP......................................................18 4.2.5EUTOPERATINGCONDITIONS.....................................19 4.2.6TESTRESULTS....................................................20 5.RADIATEDBANDEMISSIONMEASUREMENT..........................25 5.1TestRequirement:....................................................25 5.2TESTPROCEDURE..................................................25 5.3DEVIATIONFROMTESTSTANDARD..................................26 5.4TESTSETUP........................................................26 5.5EUTOPERATINGCONDITIONS.......................................26 5.6TESTRESULT.......................................................27 6.CONDUCTEDBANDEDGEANDSPURIOUSEMISSION..................29 6.1Limit................................................................29 6.2TestSetup..........................................................29 6.3Testprocedure.......................................................29 6.4DEVIATIONFROMSTANDARD.......................................29 6.5TestResult..........................................................30 7.20DB&99%BANDWIDTH..............................................42 7.1TestSetup..........................................................42 7.2Limit................................................................42 7.3Testprocedure.......................................................42 7.4DEVIATIONFROMSTANDARD.......................................42 ProjectNo.:ZKT-230508L3315E Page 4 of 67 7.5TestResult..........................................................42 8.MAXIMUMPEAKOUTPUTPOWER....................................49 8.1BlockDiagramOfTestSetup.............…

Text truncated - open the document above for the full version.

ProjectNo.:ZKT-230508L3315E Page 49 of 67 8.MaximumPeakOutputPower TestRequirement:FCCPart15CSection15.247(b)(1) TestMethod:ANSIC63.10:2013 Limit:Pleaseseethe8.2 8.1BlockDiagramOfTestSetup 8.2Limit Forfrequencyhoppingsystemsoperatinginthe2400-2483.5MHzbandemployingatleast75 non-overlappinghoppingchannels,andallfrequencyhoppingsystemsinthe5725-5850MHzband:1watt. Forallotherfrequencyhoppingsystemsinthe2400-2483.5MHzband:0.125watts. ForFHSsoperatingintheband2400-2483.5MHz,themaximumpeakconductedoutputpowershallnot exceed1.0Wifthehopsetuses75ormorehoppingchannels;themaximumpeakconductedoutputpower shallnotexceed0.125Wifthehopsetuseslessthan75hoppingchannels.Thee.i.r.p.shallnotexceed4W. 8.3Testprocedure 1.RemovetheantennafromtheEUTandthenconnectalowRFcablefromtheantennaporttothespectrum. 2.Setthespectrumanalyzer:RBW=1MHz.VBW=3MHz.Sweep=auto;DetectorFunction=Peak. 3.KeeptheEUTintransmittingatlowest,mediumandhighestchannelindividually.Recordthemaxvalue. 8.4DEVIATIONFROMSTANDARD Nodeviation. 8.5TestResult ModeTestchannel PeakOutputPower (dBm) FCCLimit (dBm) Result GFSK Lowest1.253 30PassMiddle1.406 Highest1.767 π/4-DQPSK Lowest2.142 20.97PassMiddle2.252 Highest2.587 8-DPSK Lowest2.651 20.97PassMiddle2.803 Highest3.108 ProjectNo.:ZKT-230508L3315E Page 50 of 67 Testplots GFSKLowChannel GFSKMiddleChannel ProjectNo.:ZKT-230508L3315E Page 51 of 67 GFSKHighChannel π/4-DQPSKLowChannel ProjectNo.:ZKT-230508L3315E Page 52 of 67 π/4-DQPSKMiddleChannel π/4-DQPSKHighChannel ProjectNo.:ZKT-230508L3315E Page 53 of 67 8-DPSKLowChannel 8-DPSKMiddleChannel ProjectNo.:ZKT-230508L3315E Page 54 of 67 8-DPSKHighChannel ProjectNo.:ZKT-230508L3315E Page 55 of 67 9.HOPPINGCHANNELSEPARATION TestRequirement:FCCPart15CSection15.247(a)(1) TestMethod:ANSIC63.10:2013 Receiversetup: RBW=100KHz,VBW=300KHz,detector=Peak Limit: GFSK&π/4-DQPSK&8DSK:0.025MHzor2/3ofthe20dBbandwidth (whicheverisgreater) 9.1TestSetup 9.2Testprocedure 1.RemovetheantennafromtheEUTandthenconnectalowRFcablefromtheantennaport tothespectrum. 2.Setthespectrumanalyzer:RBW=100kHz.VBW=300kHz,Span=3.0MHz.Sweep=auto;Detector Function=Peak.Trace=Maxhold. 3.Allowthetracetostabilize.Usethemarker-deltafunctiontodeterminetheseparationbetweenthepeaksof theadjacentchannels.ThelimitisspecifiedinoneofthesubparagraphsofthisSectionSubmitthisplot. 9.3DEVIATIONFROMSTANDARD Nodeviation. ProjectNo.:ZKT-230508L3315E Page 56 of 67 9.4TestResult ModulationTestChannelSeparation(MHz)Limit(MHz)Result GFSKLow0.9990.869PASS GFSK Middle1.0020.924PASS GFSK High1.0050.907PASS π/4-DQPSK Low1.0020.839PASS π/4-DQPSK Middle0.9990.836PASS π/4-DQPSK High0.9960.837PASS 8-DPSK Low0.9990.866PASS 8-DPSK Middle1.0110.869PASS 8-DPSKHigh1.0050.869PASS Testplots GFSKLowChannel ProjectNo.:ZKT-230508L3315E Page 57 of 67 GFSKMiddleChannel GFSKHighChannel ProjectNo.:ZKT-230508L3315E Page 58 of 67 π/4-DQPSKLowChannel π/4-DQPSKMiddleChannel ProjectNo.:ZKT-230508L3315E Page 59 of 67 π/4-DQPSKHighChannel 8-DPSKLowChannel ProjectNo.:ZKT-230508L3315E Page 60 of 67 8-DPSKMiddleChannel 8-DPSKHighChannel ProjectNo.:ZKT-230508L3315E Page 61 of 67 10.NUMBEROFHOPPINGFREQUENCY TestRequirement:FCCPart15CSection15.247(a)(1)(iii) TestMethod:ANSIC63.10:2013 Receiversetup: RBW=100kHz,VBW=300kHz,Frequencyrange=2400MHz-2483.5MHz, Detector=Peak Limit: 15channels 10.1TestSetup 10.2Testprocedure 1.RemovetheantennafromtheEUTandthenconnectalowRFcablefromtheantennaporttothespectrum. 2.Setthespectrumanalyzer:RBW=100kHz.VBW=300kHz.Sweep=auto;DetectorFunction=Peak. Trace=Maxhold. 3.Allowthetracetostabilize.Itmayprovenecessarytobreakthespanuptosections.inordertoclearly showallofthehoppingfrequencies.ThelimitisspecifiedinoneofthesubparagraphsofthisSection. 4.Setthespectrumanalyzer:StartFrequency=2.4GHz,StopFrequency=2.4835GHz.Sweep=auto; 10.3DEVIATIONFROMSTANDARD Nodeviation. 10.4TestResult TestPlots: 79Channelsintotal GFSK ProjectNo.:ZKT-230508L3315E Page 62 of 67 π/4-DQPSK 8-DPSK ProjectNo.:ZKT-230508L3315E Page 63 of 67 11.DWELLTIME TestRequirement:FCCPart15CSection15.247(a)(1)(iii) TestMethod:ANSIC63.10:2013 Receiversetup: RBW=1MHz,VBW=3MHz,Span=0Hz,Detector=Peak Limit: 0.4Second 11.1TestSetup 11.2Testprocedure 1.RemovetheantennafromtheEUTandthenconnectalowRFcablefromtheantennaporttothespectrum. 2.Setspectrumanalyzerspan=0Hz; 3.SetRBW=1MHzandVBW=3MHz.Sweep=asnecessarytocapturetheentiredwelltimeperhopping channel.SettheEUTforDH5,DH3andDH1packettransmitting. 4.Usethemarker-deltafunctiontodeterminethedwelltime.Ifthisvaluevarieswithdifferentmodesof operation(e.g..datarate.modulationformat.etc.).repeatthistestforeachvariation.Thelimitisspecifiedin oneofthesubparagraphsofthisSection.Submitthisplot(s). 11.3DEVIATIONFROMSTANDARD Nodeviation. ProjectNo.:ZKT-230508L3315E Page 64 of 67 11.4TestResult GFSKmode: FrequencyPacketDwelltime(ms)Limit(ms)Result 2441MHzDH1122.56400Pass 2441MHzDH3262.24400Pass 2441MHzDH5308.05400Pass Remarks: 1.Thetestperiod:T=0.4Second/Channelx79Channel=31.6s Testchannel:asblow CH:2441MHztimeslot=0.383(ms)*(1600/(2*79))*31.6 CH:2441MHztimeslot=1.639(ms)*(1600/(4*79))*31.6 CH:2441MHztimeslot=2.888(ms)*(1600/(6*79))*31.6 2.Wetestedallmodesandrecordedtheworstinthereport. TestPlots GFSKDH12441MHz ProjectNo.:ZKT-230508L3315E Page 65 of 67 GFSKDH32441MHz GFSKDH52441MHz ProjectNo.:ZKT-230508L3315E Page 66 of 67 12.AntennaRequirement Standardrequirement: FCCPart15CSection15.203/247(c) 15.203requirement: Anintentionalradiatorshallbedesignedtoensurethatnoantennaotherthanthatfurnishedbytheresponsiblepartyshall beusedwiththedevice.Theuseofapermanentlyattachedantennaorofanantennathatusesauniquecouplingtothe intentionalradiator,themanufacturermaydesigntheunitsothatabrokenantennacanbereplacedbytheuser,butthe useofastandardantennajackorelectricalconnectorisprohibited. 15.247(c)(1)(i)requirement: (i)Systemsoperatinginthe2400-2483.5MHzbandthatisusedexclusivelyforfixed.Point-to-pointoperationsmay employtransmittingantennaswithdirectionalgaingreaterthan6dBiprovidedthemaximumconductedoutputpowerof theintentionalradiatorisreducedby1dBforev…
