2BA76BT17MNT009BLE module

BT17 Bluetooth module Bluetooth module type：PCB module Dimension： 26mm*16mm 1. Bluetooth module photo 2.Technical Parameter 1.Maximum working frequency: 192 M 2.Version: V5.0+BR+EDR+BLE 3.Voltage: VBAT 2.2V to 5.5V, VDDIO 2.2V to 5.5V, RTCVDD 2.2V to 3.6V 4.Operating temperature -20 ~70°C, storage temperature: -65°C~150°C 5.Power source value nominal: 5V 6.Maximum Peak/RMS Conducted Power: 4.33 dBm 7.Maximum RX/TX packet length support to 37 BYTES 8.Steady modulation coefficient transmit receive: YES 9.Channel Spacing:1 MHz/2MHz 10.Channel Number: 79/40 11.Antenna gain: -0.58 dBi 12.Supported Bluetooth protocols：A2DP1.0 AVRCP1.5 AVDTP1.0 AVCTP 1.4 HFP 1.5 GAVDP 1.0 3. Details of Transmitter 1. Frequency range: 2402-2480MHz 2. No. of preset switchable channels: 79/40 3. No. of voice /Data/ TV Channels: 7 (In case of multi- channel equipment) 4. Tx-Rx channel separation time division multiplex frequency hopping (In case of Duplex/multi-channel equipment) 5. Frequency stability: 25ppm 6. Spurious/ Harmonic radiation: i. Carrier suppression: < -35dB (In case of carrier suppressed systems) ii. Unwanted side band suppression:< -35dB (low side band)( In case of SSB systems) iii. 2nd Harmonic radations:< -40dB iv. 3rd Harmonic radiations:< -40dB 7. Max. Frequency Deviation: ±75KHz 8. Mode of emission: TX Mode 9. Bandwidth of emission: 1MHz 10. Test Tone deviation: 25ppm 11. Base band frequency:1MHz (In case of multi channel equipment) 12. Type of modulation to be required : GFSK 、π/4 DQPSK 13. Pre-emphasis: No 4. Details of Receivers 1. Frequency range: 2402-2480MHz 2. Mode of reception Receive: RX 3. Spurious response of receiver: C/I -40 dB 4. Sensitivity: < -85dBm 5. Frequency stability: 25ppm 6. (a) Effective noise temperature :-40°C~+85°C (b) Threshold input level: 0dBm - -85dBm 7. Intermediate frequency : 1.5MHz 8. De-emphasis: No 9. Selectivity: 1MHz FCC regulatory compliance statement §15.19 Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1). this device may not cause harmful interference. (2). this device must accept any interference received, including interference that may cause undesired operation. §15.21 Information to user Warning: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Exposure compliance statement This Module complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Country Code selection feature to be disabled for products marketed to the US/Canada. This device is intended only for OEM integrators under the following conditions: (1). The antenna must be installed such that 20 cm is maintained between the antenna and users. (2). The transmitter module may not be co-located with any other transmitter or antenna. As long as the two conditions above are met, further transmitter testing will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed. Operational use conditions Module has professional users use condition limitations, this module is limited to be used in control box which is produced by MotoMotion China Corporation, it should be installed and operated with a minimum distance of 20cm between the radiator and your body. Host product manufacturer please ensure giving such warning like “Product is limited to professional users use” in your product’s instruction. Antenna used Antenna Type Brand/ manufacturer Model No. Max. Antenna Gain PCB JIELI 2.4G ANT MAX. Gain: -0.58dBi Labelling Instruction for Host Product Integrator. Please notice that if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. For FCC, this exterior label should follow “Contains FCC ID: 2BA76BT17MNT009”. In accordance with FCC KDB guidance 784748 Labeling Guidelines. § 15.19 Labelling requirements shall be complied on end user device. Labelling rules for special device, please refer to §2.925, § 15.19 (a)(5) and relevant KDB publications. For E-label, please refer to §2.935. Installation Notice to Host Product Manufacturer In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re- evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. Antenna Change Notice to Host Manufacturer If you desire to increase antenna gain and either change antenna type or use same antenna type certified, a Class II permissive change application is required to be filed by us, or you (host manufacturer) can take responsibility through the change in FCC ID (new application) procedure followed by a Class II permissive change application. FCC other Parts, Part 15B Compliance Requirements for Host product Manufacturer This modular transmitter is only FCC authorized for the specific rule parts listed on our grant, host product manufacturer is responsible for compliance to any other FCC rules that apply to the host not covered by the modular transmitter grant of certification. Host manufacturer in any case shall ensure host product which is installed and operating with the module is in compliant with Part 15B requirements. Please note that For a Class B or Class A digital device or peripheral, the instructions furnished the user manual of…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.1 Jan 17, 2024 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name MotoMotion China Corporation Address No. 61 Xinggang Road, Zhonglou Economic Development Zone, Changzhou, Jiangsu, P.R. China FRN 0033781410 Grantee Code 2BA76 FCC ID 2BA76BT17MNT009 Authorized Contact Name Sunny Zhou Contact Email [email protected] Contact Phone 0519-83903901 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [MotoMotion China Corporation] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [MotoMotion China Corporation] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2023/12/13 Print Name: Sunny Zhou Title: Compliance Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

FRN： 0033781410

MotoMotion China Corporation Date: 2023-12-13 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2BA76BT17MNT009 To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with MotoMotion China Corporation. This authorization is valid until further written notice from the applicant. Name (Printed): Sunny Zhou Title: Compliance Manager Signature: On behalf of Company: MotoMotion China Corporation Telephone: 0519-83903901

MotoMotion China Corporation To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: MotoMotion China Corporation No. 61 Xinggang Road, Zhonglou Economic Development Zone, Changzhou, Jiangsu, P.R. China Regarding: Confidentiality Request regarding application for FCC ID: 2BA76BT17MNT009 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Sunny Zhou Title: Compliance Manager Company Name: MotoMotion China Corporation

MotoMotion China Corporation Cover Letter-Modular Approval FCC ID: 2BA76BT17MNT009 Date: 2024-02-27 Gentlemen: There’s a BT Module that would like to have your authorization as a modular approval. The specific product as below, BT Module with its designed features and specified description, meets special requirements for limited modular approval on FCC KDB996369 by cross-reference list below. Company MotoMotion China Corporation Product Name BLE module Model Number BT17 FCC ID 2BA76BT17MNT009 Requirement of FCC KDB996369 Comply（Y/N） 1. The modular transmitter must have its own RF shielding. N The EUT does not have RF shielding. Please refer to EUT Photos. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Y The EUT uses the chip: KT1025A as an embedded processor to buffer the data. Please refer to Schematics. 3. The modular transmitter must have its own power supply regulation. Y The EUT has its own power supply regulation, The power supply of this module is DC 5V. Please refer to Schematics. 4. The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Y The EUT meets the FCC antenna requirements; The photo of antenna is shown in the internal photos. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. Y It has been performed the testing as a stand-alone and then confirmed the compliance. Please refer to setup photo. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: 2BA76BT17MNT009” or “Contains FCC ID: 2BA76BT17MNT009” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module Y Please see exhibition label sample for the FCC ID of this module. And also in the exhibition User’s manual, there are instructions to the OEM on how to label the end product. MotoMotion China Corporation which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are given in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Y The EUT complies with RF exposure requirement. Thank you. Sincerely, Print Name: Sunny Zhou Title: Compliance Manager Signature: On behalf of Company: MotoMotion China Corporation Telephone: 0519-83903901

Compliance Certification Services (Kunshan) Inc. Page: 1 of 3 External Photos for KSCR2312002290AT Test Model No.: BT17 Compliance Certification Services (Kunshan) Inc. Page: 2 of 3 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 3

FCC ID: 2BA76BT17MNT009 Remark: It’s hard to put FCC §15.19 statement on the product due to device’s irregular appearance. FCC §15.19 statement(as below shows) will be placed in the user manual which the device is marketed. §15.19 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 2 Internal Photos for KSCR2312002290AT Test Model No.: BT17 Compliance Certification Services (Kunshan) Inc. Page: 2 of 2 EUT Constructional Details (EUT Photos)

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR231200229003 Page: 1 of 10 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms- and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and- Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) 1 Cover Page RF Exposure Evaluation Report Application No.: KSCR2312002290AT FCC ID: 2BA76BT17MNT009 Applicant: MotoMotion China Corporation Address of Applicant: No. 61 Xinggang Road, Zhonglou Economic Development Zone, Changzhou, Jiangsu, P.R. China Manufacturer: MotoMotion China Corporation Address of Manufacturer: No. 61 Xinggang Road, Zhonglou Economic Development Zone, Changzhou, Jiangsu, P.R. China Equipment Under Test (EUT): EUT Name: BLE Module Model No.: BT17 Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2023-12-14 Date of Test: 2024-02-26 to 2024-02-29 Date of Issue: 2024-03-01 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR231200229003 Page: 2 of 10 Revision Record Version Description Date Remark 00 Original 2024-03-01 / Authorized for issue by: Tested By Damon Zhou /Project Engineer Approved By Terry Hou /Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: KSCR231200229003 Page: 3 of 10 2 Contents Page 1 Cover Page ........................................................................................................................................ 1 2 Contents ............................................................................................................................................ 3 3 General Information .......................................................................................................................... 4 3.1 General Description of E.U.T. ................................................................................................. 4 3.2 Details of E.U.T. ........................................................................................................................ 4 3.3 Test Location ............................................................................................................................ 5 3.4 Test Facility ............................................................................................................................... 5 4 FCC Radiofrequency radiation exposure limits ............................................................................ 6 4.1 Blanket 1 mW Blanket Exemption .......................................................................................... 6 4.2 MPE-based Exemption ............................................................................................................ 7 4.3 SAR-based Exemption ............................................................................................................. 8 5 Measurement and Calculation ....................................................................................................... 10 5.1 Maximum transmit power ...................................................................................................... 10 5.2 RF Exposure Calculation ....................................................................................................... 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: KSCR231200229003 Page: 4 of 10 3 General Information 3.1 General Description of E.U.T. Power supply: DC 5V 3.2 Details of E.U.T. BLE Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: PCB Antenna Antenna Gain: -0.58dBi(Provided by the manufacturer) BT Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK, pi/4DQPSK Number of Channels: 79 Channel Spacing: 1MHz Spectrum Spread Technology: Frequency Hopping Spread Spectrum(FHSS) Antenna Type: PCB Antenna Antenna Gain: -0.58dBi(Provided by the manufacturer) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: KSCR231200229003 Page: 5 of 10 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. Note: 1. SGS is not responsible for wrong test results due to incorrect information (e.g., max. internal working frequency, antenna gain, cable loss, etc) is provided by the applicant. (If applicable). 2. SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (If applicable). 3. Sample source: sent by customer. 3.4 Te…

Text truncated - open the document above for the full version.

Inverted F Antenna Specification Summary ITEMANT SPEC Model Name 2.4G ANT HorizontalVertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1. 26dBi -0.76dBi-0.58dBi-5.25dBi-2.46dBi-1.86dBi MAX. Gain -0.58dBi PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) Address No. 333 Kexing Road, Xiangzhou District, Zhuhai City Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain (dB) Frequency (MHz) MaxMinAvg 2400-5.2537-22.1424-12.4294 2450-2.4652-24.5837-10.4702 2500-1.86120-29.5214-9.20432

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR231200229001 Page: 1 of 56 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) TEST REPORT Application No.: KSCR2312002290AT FCC ID: 2BA76BT17MNT009 Applicant: MotoMotion China Corporation Address of Applicant: No. 61 Xinggang Road, Zhonglou Economic Development Zone, Changzhou, Jiangsu, P.R. China Manufacturer: MotoMotion China Corporation Address of Manufacturer: No. 61 Xinggang Road, Zhonglou Economic Development Zone, Changzhou, Jiangsu, P.R. China Equipment Under Test (EUT): EUT Name: BLE Module Model No.: BT17 Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2023-12-14 Date of Test: 2024-02-26 to 2024-02-29 Date of Issue: 2024-03-01 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR231200229001 Page: 2 of 56 Revision Record Version Description Date Remark 00 Original 2024-03-01 / Authorized for issue by: Tested By Damon_Zhou/Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR231200229001 Page: 3 of 56 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Customer Declaration Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR231200229001 Page: 4 of 56 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 Test Summary .................................................................................................................................................. 3 3 Contents ........................................................................................................................................................... 4 4 General Information ........................................................................................................................................ 5 4.1 Details of E.U.T. ........................................................................................................................................ 5 4.2 Power level setting using in test: .............................................................................................................. 5 4.3 Description of Support Units ..................................................................................................................... 5 4.4 Measurement Uncertainty ......................................................................................................................... 6 4.5 Test Location ............................................................................................................................................ 7 4.6 Test Facility ............................................................................................................................................... 7 4.7 Deviation from Standards ......................................................................................................................... 7 4.8 Abnormalities from Standard Conditions ......................…

Text truncated - open the document above for the full version.
