2BA7C-IGENEVCBluetooth headset

FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

- Qiaoqiao Acoustics Technology (Dongguan) ., . . ,. 多？ － ` - · 鲁 . . Co.,LTD � - . 、蠡｀. f .j 一 ｀ Federal Comm unications Commissio n Author ization and Evaluation Division Equip ment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 』 ． ． 、 ， 一 r 、 - · • . • -、 妒 ｀ . · 5/16/23 � . US. Aqent DesiqnatLQ_n Linkwld LLC acknowledges their obligation to accept service of process on behalf of Qiaoqiao Acoustics Technology < Dongguan ) Co.,LTD acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment tor which authorization is sought (FCC ID: 2BA7C-I G ENE V C): Name and company of U.S. agent: Linkwld LLC Physical U.S. address of agent: 1942 Broadway St. STE 314C, Boulder, CO, 80302, US FRN of U.S. agent: 0033625682 Email address of U.S. agent: Timothy.linkwld@prot on.me Qiaoqiao Acoustics Technology < Dongguan) Co.,L TD. By signing this form, we confirm the above and that we are aware of the application requi『eme _ Qiaoqiao Acoustics Technology (Dongguan) Co.,LTD with the FRN [0033777194) accepts· its obligation to maintain an agent for service of process in the United States for no fess than one year after either the grantee has permanently terminated all marketing and importation of the appfi氓bfe equipment within the U.;J., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. nts listed under§ 2.911 (d)(7). Sincerely, 沧 叩 门 吨 Signature . [Name] Y e Chun Y ang 、 艺＞ · n,e(p)二 6t' 一u�av - sn (ppou』「 OO寸 [Company]Qiaoqiao Acoustics Technology (Dongguan) [Tit i e ] Project manager Co.,L TD 飞 4 多 Signature [Name of U.S. agent] Timothy Zhu [Title of U.S. agent]Manager [Company of U.S. agent] Linkwld LLC The informatio n provided in this letter is b ased on the referenced ru le parts of Title 47 of the CF R as well as K DB 986446 D 01. An e x piration date fo r this letter does not e x ist. In case the U.S. agent changes, the grantee is obligated to noti fy the FCC within 30 days via the granting TCB. 扫描全能王

-QiaoqiaoAcousticsTechnology(Dongguan)Co.,LTD- TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB986446D01. FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 5/27/23 Towhomitmayconcern: We,[QiaoqiaoAcousticsTechnology(Dongguan)Co.,LTD],herebycertifythattheequipmentfor whichauthorizationissought(FCCID:[2BA7C-IGENEVC])isnot“covered”equipmentprohibited fromreceivinganequipmentauthorizationpursuantto§2.903oftheFCCrules. Wealsocertifythat,asofthedateofthefilingoftheapplication,wearenotidentifiedontheCovered List(https://www.fcc.gov/supplychain/coveredlist)asanentityproducing“covered”equipment. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirements listedunder§2.911(b)and(d)(5)and(6). Sincerely, Signature [YangChunYe] [Projectmanager] [QiaoqiaoAcousticsTechnology(Dongguan)Co.,LTD] 6 2 _ [ m o d e l ] C o v e r e d E q u _ 2 . 9 1 1 ( d ) ( 5 ) ( i ) a n d ( i i ) - U , V 0 2

Code:AB-RF-05-b ExternalPhotograph Code:AB-RF-05-b Code:AB-RF-05-b Code:AB-RF-05-b Code:AB-RF-05-b Code:AB-RF-05-b Code:AB-RF-05-b

LabelLocationOnEUT Label FCCID:2BA7C-IGENEVC

Code:AB-RF-05-b InternalPhotograph Code:AB-RF-05-b Code:AB-RF-05-b Code:AB-RF-05-b Code:AB-RF-05-b ANT Code:AB-RF-05-b

RFEXPOSUREEVALUATION FCCID:2BA7C-IGENEVC AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeused toevaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF) Radiationasspecifiedin§1.1307(b): RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,using measurementsorcomputersimulation.WhenroutineSARevaluationisnot required,portabletransmitterswithoutputpowergreaterthantheapplicable lowthresholdrequireSARevaluationtoqualifyforTCBapproval. Channel (MHz) Maximum output power (dBm) Tuneup tolerance (dBm) MaxTuneUp Power(dBm) Distance (mm) Calculation results Limit Operating Mode 2402-2.53-2.53 ±1 -1.53050.2183 GFSK2441-1.88-1.88±1 -0.880 5 0.2553 2480-1.85-1.85±1 -0.850 5 0.2593 2402-1.69-1.69 ±1 -0.69050.2643 π/4-DQPSK 2441-1.08-1.08±1 -0.080 5 0.3073 2480-1.16-1.16±1 -0.160 5 0.3043 Result:NoStandaloneSARtestisrequired.

Page1of40 AppendixTestData ReportNo.:18220WC30085701TestSampleNo.:1-2-2 StartTestDate:2023.05.15FinishTestDate:2023.05.17 TestEngineer:Auditor: Temperature:25.5 °C RelativeHumidity:51% Pressure:1012hPa AppendixA:20dBEmissionBandwidth TestResult TestModeAntennaFrequency[MHz] 20db EBW[MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict DH5Ant1 24020.9542401.5142402.468------ 24410.9542440.5142441.468------ 24800.9512479.5142480.465------ 2DH5Ant1 24021.3142401.3162402.630------ 24411.3232440.3132441.636------ 24801.3232479.3102480.633------ Page2of40 TestGraphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Page3of40 2DH5_Ant1_2402 2DH5_Ant1_2441 Page4of40 2DH5_Ant1_2480 Page5of40 AppendixB:OccupiedChannelBandwidth TestResult TestModeAntennaFrequency[MHz] OCB[MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict DH5Ant1 24020.852552401.54532402.3978------ 24410.856452440.54512441.4016------ 24800.857422479.53692480.3943------ 2DH5Ant1 24021.18712401.38372402.5708------ 24411.17952440.38462441.5641------ 24801.17412479.38922480.5633------ Page6of40 TestGraphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Page7of40 2DH5_Ant1_2402 2DH5_Ant1_2441 Page8of40 2DH5_Ant1_2480 Page9of40 AppendixC:Maximumconductedoutputpower TestResultPeak Test Mode AntennaFrequency[MHz] ConductedPeak Power[dBm] Conducted Limit[dBm] Verdict DH5Ant1 2402-2.53≤20.97PASS 2441-1.88≤20.97PASS 2480-1.85≤20.97PASS 2DH5Ant1 2402-1.69≤20.97PASS 2441-1.08≤20.97PASS 2480-1.16≤20.97PASS Page10of40 TestGraphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Page11of40 2DH5_Ant1_2402 2DH5_Ant1_2441 Page12of40 2DH5_Ant1_2480 Page13of40 AppendixD:Carrierfrequencyseparation TestResult TestModeAntennaFrequency[MHz]Result[MHz]Limit[MHz]Verdict DH5Ant1Hop0.986≥0.954PASS 2DH5Ant1Hop0.99≥0.882PASS Page14of40 TestGraphs DH5_Ant1_Hop 2DH5_Ant1_Hop Page15of40 AppendixE:Timeofoccupancy TestResult TestModeAntennaFrequency[MHz] BurstWidth [ms] TotalHops [Num] Result[s]Limit[s]Verdict DH1Ant1Hop0.3813190.122≤0.4PASS DH3Ant1Hop1.6371620.265≤0.4PASS DH5Ant1Hop2.8851180.34≤0.4PASS 2DH1Ant1Hop0.3893160.123≤0.4PASS 2DH3Ant1Hop1.6431690.278≤0.4PASS 2DH5Ant1Hop2.8891250.361≤0.4PASS Page16of40 TestGraphs DH1_Ant1_Hop DH3_Ant1_Hop Page17of40 DH5_Ant1_Hop Page18of40 2DH1_Ant1_Hop 2DH3_Ant1_Hop Page19of40 2DH5_Ant1_Hop Page20of40 Page21of40 AppendixF:Numberofhoppingchannels TestResult TestModeAntennaFrequency[MHz]Result[Num]Limit[Num]Verdict DH5Ant1Hop79≥15PASS 2DH5Ant1Hop79≥15PASS Page22of40 TestGraphs DH5_Ant1_Hop 2DH5_Ant1_Hop Page23of40 AppendixG:Bandedgemeasurements TestResult TestModeAntennaChNameFrequency[MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant1 Low2402-2.68-50.64≤-22.68PASS High2480-1.94-52.53≤-21.94PASS LowHop_2402-2.49-54.43≤-22.49PASS HighHop_2480-1.69-54.8≤-21.69PASS 2DH5Ant1 Low2402-2.49-52.38≤-22.49PASS High2480-1.66-53.5≤-21.66PASS LowHop_2402-3.35-54.37≤-23.35PASS HighHop_2480-1.62-53.33≤-21.62PASS Page24of40 TestGraphs DH5_Ant1_Low_2402 DH5_Ant1_High_2480 DH5_Ant1_Low_Hop_2402 Page25of40 DH5_Ant1_High_Hop_2480 2DH5_Ant1_Low_2402 Page26of40 2DH5_Ant1_High_2480 2DH5_Ant1_Low_Hop_2402 2DH5_Ant1_High_Hop_2480 Page27of40 Page28of40 AppendixH:ConductedSpuriousEmission TestResult TestModeAntennaFrequency[MHz] FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant1 2402 Reference-3.12-3.12---PASS 30~1000-3.12-69.24≤-23.12PASS 1000~26500-3.12-50.81≤-23.12PASS 2441 Reference-2.49-2.49---PASS 30~1000-2.49-68.82≤-22.49PASS 1000~26500-2.49-45.87≤-22.49PASS 2480 Reference-2.48-2.48---PASS 30~1000-2.48-68.86≤-22.48PASS 1000~26500-2.48-47.47≤-22.48PASS 2DH5Ant1 2402 Reference-7.20-7.20---PASS 30~1000-7.20-68.99≤-27.2PASS 1000~26500-7.20-50.21≤-27.2PASS 2441 Reference-5.75-5.75---PASS 30~1000-5.75-69.67≤-25.75PASS 1000~26500-5.75-45.63≤-25.75PASS 2480 Reference-6.25-6.25---PASS 30~1000-6.25-68.49≤-26.25PASS 1000~26500-6.25-49.89≤-26.25PASS Page29of40 TestGraphs DH5_Ant1_2402_0~Reference DH5_Ant1_2402_30~1000 DH5_Ant1_2402_1000~26500 Page30of40 DH5_Ant1_2441_0~Reference DH5_Ant1_2441_30~1000 Page31of40 DH5_Ant1_2441_1000~26500 DH5_Ant1_2480_0~Reference DH5_Ant1_2480_30~1000 Page32of40 DH5_Ant1_2480_1000~26500 2DH5_Ant1_2402_0~Reference Page33of40 2DH5_Ant1_2402_30~1000 2DH5_Ant1_2402_1000~26500 2DH5_Ant1_2441_0~Reference Page34of40 2DH5_Ant1_2441_30~1000 2DH5_Ant1_2441_1000~26500 Page35of40 2DH5_Ant1_2480_0~Reference 2DH5_Ant1_2480_30~1000 2DH5_Ant1_2480_1000~26500 Page36of40 Page37of40 AppendixI:DutyCycle TestResult TestModeAntennaFrequency[MHz] ONTime [ms] Period [ms] DutyCycle [%] DutyCycle Factor[dB] DH5Ant1 24022.883.7477.011.13 24412.893.7577.071.13 24802.883.7576.801.15 2DH5Ant1 24022.893.7577.071.13 24412.893.7577.071.13 24802.893.7577.071.13 Page38of40 TestGraphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Page39of40 2DH5_Ant1_2402 2DH5_Ant1_2441 Page40of40 2DH5_Ant1_2480 ---End---

ReportNo.:18220WC30085701FCCID:2BA7C-IGENEVCPage1of32 Code:AB-RF-05-b FCCTestReport Applicant: QiaoqiaoAcousticsTechnology(Dongguan) Co.,LTD Address: 3rdFloor,BuildingD,SecondRoad,Fulong SecondIndustrialZone,ShipaiTown, DongguanCity,China ProductName:Bluetoothheadset ReportDate:May25,2023 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC30085701FCCID:2BA7C-IGENEVCPage2of32 Code:AB-RF-05-b Contents 1.GeneralInformation ............................................................................................................................................6 1.1.ClientInformation ....................................................................................................................................6 1.2.DescriptionofDevice(EUT) ..................................................................................................................6 1.3.AuxiliaryEquipmentUsedDuringTest ................................................................................................7 1.4.DescriptionofTestConfiguration ..........................................................................................................7 1.5.DescriptionOfTestSetup ......................................................................................................................8 1.6.TestEquipmentList .................................................................................................................................9 1.7.MeasurementUncertainty ....................................................................................................................10 1.8.DescriptionofTestFacility ...................................................................................................................10 2.SummaryofTestResults ................................................................................................................................11 3.ConductedEmissionTest ................................................................................................................................12 3.1.TestStandardandLimit .......................................................................................................................12 3.2.TestSetup ...............................................................................................................................................12 3.3.TestProcedure .......................................................................................................................................12 3.4.TestData .................................................................................................................................................12 4.RadiationSpuriousEmissionandBandEdge .............................................................................................15 4.1.TestStandardandLimit .......................................................................................................................15 4.2.TestSetup ...............................................................................................................................................15 4.3.TestProcedure .......................................................................................................................................16 4.4.TestData .................................................................................................................................................17 5.MaximumPeakOutputPowerTest ...............................................................................................................25 5.1.TestStandardandLimit .......................................................................................................................25 5.2.TestSetup ...............................................................................................................................................25 5.3.TestProcedure .......................................................................................................................................25 5.4.TestData .................................................................................................................................................25 6.20DBOccupyBandwidthTest ........................................................................................................................26 6.1.TestStandard .........................................................................................................................................26 6.2.TestSetup ...............................................................................................................................................26 6.3.TestProcedure .......................................................................................................................................26 6.4.TestData .................................................................................................................................................26 7.CarrierFrequencySeparationTest ................................................................................................................27 7.1.TestStandardandLimit .......................................................................................................................27 7.2.TestSetup ...............................................................................................................................................27 7.3.TestProcedure .......................................................................................................................................27 7.4.TestData .................................................................................................................................................27 8.NumberofHoppingChannelTest ..................................................................................................................28 8.1.TestStandardandLimit ...................................................................…

Text truncated - open the document above for the full version.

version01 QiaoqiaoAcousticsTechnology(Dongguan)Co., LTD DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:iGene-VC FCCID:2BA7C-IGENEVC fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsforinternalantennatype(s) describedbelow: ModelNo.ofantenna:PBX3216DA01 Typeofantenna:CeramicAntenna Gainoftheantenna:2.7dBi Frequencyrange:2400-2500MHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:QiaoqiaoAcousticsTechnology(Dongguan)Co.,LTD Address:3rdFloor,BuildingD,SecondRoad,FulongSecondIndustrialZone,Shipai Town,DongguanCity,China City:Dongguan ZIP/Postalcode:/ Country:China Place:DongguanDate:5/27/2023 Signature:

PengBanXingYe ShenZhen Technology Co. , Ltd UNLESS OTHER SPECIFIED TOLERANCES ON： X＝±X.X＝±X.XX＝ AN G L E S＝ ± H O L E D I A＝ ± PengBanXingYeShenZhen Technology Co. , Ltd SCALE：N/AUNIT：mm THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PBXY TECHNOLOGY Limited AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY : SeraCHECKED BY: XD DESIGNED BY: SeraAPPROVED BY: XD TITLE：CHIP2450-3216 Specification DOCUMENT NO. 3216 SPEC REV. P1 产品规格承认书 SPECIFICATIONS 客户: CUSTOMER: 产品名称: DESCRIPTION: Ceramic Antenna 客户型号: CUSTOMER PART No: 产品型号: OUR MODEL NO:PBX3216DA01 日期: DATE: 确认签字,盖章后请返回承认书一份 PLEASERETRUV TO US ONE COPY OF “SPECIFICATION FOR APPROVAL” WITY YOUR APPROVED SIGNATURES ApprovedLiuFeiAuditLiuFeiMakingLiuXiaoMei Customer Acknowledges Signature Date PengBanXingYe ShenZhen Technology Co. , Ltd UNLESS OTHER SPECIFIED TOLERANCES ON： X＝±X.X＝±X.XX＝ AN G L E S＝ ± H O L E D I A＝ ± PengBanXingYeShenZhen Technology Co. , Ltd SCALE：N/AUNIT：mm THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PBXY TECHNOLOGY Limited AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY : SeraCHECKED BY: XD DESIGNED BY: SeraAPPROVED BY: XD TITLE：CHIP2450-3216 Specification DOCUMENT NO. 3216 SPEC REV. P1 PBX3216DA01 Specification Operating Temp. : -40°C~+85°C 1. FEATURES : ●Light weight, compact ●Wide bandwidth, low cost ●Built-in antenna with high gain 2. APPLICATIONS : ●Bluetooth, Wireless LAN, Mobile TV ●Home RF System, etc 3. PRODUCT IDENTIFICATION (1)(2)(3) (1) Product type: Multilayer chip Antenna (2) Center Frequency: 2450MHz (3) External Dimensions (L×W) (mm): 3.2*1.6 4. SHAPE AND DIMENSIONS: L W H A 3.2±0.2 1.6±0.2 0.75±0.1 0.4±0.1 CH IP45 032 2 16 PengBanXingYe ShenZhen Technology Co. , Ltd UNLESS OTHER SPECIFIED TOLERANCES ON： X＝±X.X＝±X.XX＝ AN G L E S＝ ± H O L E D I A＝ ± PengBanXingYeShenZhen Technology Co. , Ltd SCALE：N/AUNIT：mm THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PBXY TECHNOLOGY Limited AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY : SeraCHECKED BY: XD DESIGNED BY: SeraAPPROVED BY: XD TITLE：CHIP2450-3216 Specification DOCUMENT NO. 3216 SPEC REV. P1 Test plate reference size：（Note: Please Point the white end of the antenna towards the chip） Company：mm PengBanXingYe ShenZhen Technology Co. , Ltd UNLESS OTHER SPECIFIE D TOLERANCES ON： X＝±X.X＝±X.X X＝ AN G L E S＝ ± H O L E D I A＝ ± PengBanXingYeShenZhen Technology Co. , Ltd SCALE：N/AUNIT：mm THESE DRAWINGS AND SPECIFICATIONS ARE THE PROP ERTY OF PBXY TECHNOLOGY Limited AND SHALL NOT BE REPROD UCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOU T PERMISSION DRAWN BY : SeraCHECKED BY: XD DESIGNED BY: SeraAPPROVED BY: XD TIT LE：CHIP 2450-3216 Specif ic atio n DOCUMENT NO. 3216 SPEC REV. P1 APPLI CATION GUIDE 5. SPEC IFICATION S: No.Pr oduct numberPB X3 216DA01 1Centr al Frequency2440MHz 2Bandwidth100 (M in.)MHz 3Retu rn Loss-1 1.96 (M ax.)dB 4Pe ak Ga indB2.7i 5Impedance50Ω 6Op erati ng Temperatu re -4 0~+85 °C 7Maximum Po wer5W 8Resista nce to soldering heat 10 (@ 260°C) Se c. 9Po larizati onLinear 10Azimuth Beam widthOm ni-d irecti onal 11Terminati onSn (l eadless) PengBanXingYe ShenZhen Technology Co. , Ltd UNLESS OTHER SPECIFIED TOLERANCES ON： X＝±X.X＝±X.XX＝ AN G L E S＝ ± H O L E D I A＝ ± PengBanXingYeShenZhen Technology Co. , Ltd SCALE：N/AUNIT：mm THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PBXY TECHNOLOGY Limited AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY : SeraCHECKED BY: XD DESIGNED BY: SeraAPPROVED BY: XD TITLE：CHIP2450-3216 Specification DOCUMENT NO. 3216 SPEC REV. P1 6. Electrical Characteristics : PengBanXingYe ShenZhen Technology Co. , Ltd UNLESS OTHER SPECIFIED TOLERANCES ON： X＝±X.X＝±X.XX＝ AN G L E S＝ ± H O L E D I A＝ ± PengBanXingYeShenZhen Technology Co. , Ltd SCALE：N/AUNIT：mm THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PBXY TECHNOLOGY Limited AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY : SeraCHECKED BY: XD DESIGNED BY: SeraAPPROVED BY: XD TITLE：CHIP2450-3216 Specification DOCUMENT NO. 3216 SPEC REV. P1 X-Y Plane X-Y Plane X-Y Plane PengBanXingYe ShenZhen Technology Co. , Ltd UNLESS OTHER SPECIFIED TOLERANCES ON： X＝±X.X＝±X.XX＝ AN G L E S＝ ± H O L E D I A＝ ± PengBanXingYeShenZhen Technology Co. , Ltd SCALE：N/AUNIT：mm THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PBXY TECHNOLOGY Limited AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY : SeraCHECKED BY: XD DESIGNED BY: SeraAPPROVED BY: XD TITLE：CHIP2450-3216 Specification DOCUMENT NO. 3216 SPEC REV. P1 3D Radiation Pattern PengBanXingYe ShenZhen Technology Co. , Ltd UNLESS OTHER SPECIFIED TOLERANCES ON： X＝±X.X＝±X.XX＝ AN G L E S＝ ± H O L E D I A＝ ± PengBanXingYeShenZhen Technology Co. , Ltd SCALE：N/AUNIT：mm THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF PBXY TECHNOLOGY Limited AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY : SeraCHECKED BY: XD DESIGNED BY: SeraAPPROVED BY: XD TITLE：CHIP2450-3216 Specification DOCUMENT NO. 3216 SPEC REV. P1 7. Environmental Characteristics (1) Reliability Test (2) Storage Condition (a) At warehouse: The temperature should be within 0 ~ 30°Cand humidity should be less than 60% RH. The product should be used within 1 year from the time of delivery. (b) On board: The temperature should be within -40~85°Cand humidity should be less than 85% RH. (3) Operating Temperature Range Operating temperature range : -40 °C to +105 °C . PengBanXingYe ShenZhen Technology Co. , Ltd UNLESS OTHER SPECIFIED TOLERANCES ON： X＝±X.X＝±X.XX＝ AN G L E S＝…

Text truncated - open the document above for the full version.

Code:AB-RF-05-b TestSetupPhotograph PhotoofConductedEmissionMeasurement PhotoofRadiationEmissionTest Code:AB-RF-05-b
