2BA7Y-6459-001XAudiometer

Audhere User Manual Rev B 1.4.3 Edare Oct 6, 2023 CONTENTS 1 Preface1 1.1 Manufacturer Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.2 Device Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.3 Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 2 Safety and Warnings3 3 Introduction4 3.1 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 3.2 What’s a WAHTS? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 3.3 What is Audhere? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 4 Getting Started6 4.1 WAHTS Headset Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 4.2 Audhere . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 4.3 Audhere App Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 4.4 New session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 4.5 Advanced Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 5 Suggested Workflow23 5.1 Chat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 6 Troubleshooting27 6.1 Headset not connected to tablet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 6.2 Blue light does not appear when the headset is powered on . . . . . . . . . . . . . . . . . . . . . . . 27 6.3 Tests are taking longer than expected/some results are noted as “DNC” . . . . . . . . . . . . . . . . 27 7 Frequently Asked Questions28 7.1 How do I install Audhere apps? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 7.2 How do I know if a test location is quiet enough? . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 7.3 Is it okay to wear glasses with the WAHTS? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 7.4 How do I make sure the WAHTS is charging? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 7.5 How do I reboot the WAHTS? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 7.6 The Bluetooth connection to the WAHTS is dropping. What should I do? . . . . . . . . . . . . . . . 31 7.7 How should the WAHTS be cleaned? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 7.8 How do I retrieve tablet logs? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 7.9 What should I do if the daily calibration check fails? . . . . . . . . . . . . . . . . . . . . . . . . . . 32 7.10 What are the advised operating and storage conditions? . . . . . . . . . . . . . . . . . . . . . . . . . 32 7.11 How do I dispose of the WAHTS? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 7.12 Who do I contact for additional help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 i 8 Technical Data34 8.1 Audiometer Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 8.2 Hearing Protector Fit Testing Performance Statement. . . . . . . . . . . . . . . . . . . . . . . . . . 36 8.3 Operating and Storage Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 8.4 Electromagnetic Compatibility/Immunity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 8.5 Radio Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 8.6 Audhere and Third-Party Licenses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 9 Acknowledgments43 ii CHAPTER ONE PREFACE 1.1 Manufacturer Information Edare LLC 48 Lafayette St. Lebanon, NH, 03766 USA DUNS: 006702621 https://www.wahtshearing.com [email protected] OMC Medical Unit - 763 Moat House Business Centre 54 Bloomfield Avenue Belfast, Northern Ireland, BT5 5AD Registration Number: NI685047 1.2 Device Identification Trade Name: WAHTS AC WAHTS AC: 00860005068302 Audhere Software: 00860005068319 Device Classifications •FDA Class II •EU MDR Class IIa •IEC 60645-1:2017 and ANSI/ASA S3.6-2018 Type 4 Diagnostic Audiometer intended for diagnosis of human hearing loss 1 1.4.3 Audhere User Manual Rev A Accessories •Calibration Check Fixture •Mobile Tablet (with battery charger and charging cable) •Headset Battery Charger •Headset Charging Cable •Sound Level Meter 1.3 Symbols ManufacturerDate of Manufacture Authorized Representative in the European Community Caution: Consult the instructions for use for important cautionary information such as warnings and precautions Unique Device IdentifierBatch Code CE Mark with Notified Body ReferenceMedical Device Catalog NumberSerial Number Temperature range to which medical device can be safely exposed Humidity range to which the medical device can be safely exposed Atmospheric pressure range acceptable for transport and storage Keep Dry; Device needs to be protected from moisture Consult instructions for use WEEE Symbol; Signifies waste from electrical and electronic equipment Type BF Part Protected against ingress of solid foreign objects≥12.5푚푚in diameter Non-ionizing electromagnetic radiation ©2023, Edare. All rights reserved. This user manual contains proprietary information, which is protected by copyright. No part of this manual may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Edare. Chapter 1. Preface2 CHAPTER TWO SAFETY AND WARNINGS Caution: 1. No operator-serviceable parts inside unit. 2. Refer Servicing to qualified personnel. 3. Use only dat…

Text truncated - open the document above for the full version.

____________________________________________________________________________________ Edare LLC • 48 Lafayette Street • Lebanon, NH 03766 603-640-2865 • www.edareinc.com Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to 47 CFR part §2.911(d)(7) of the FCC rules To whom it may concern, This letter is to certify that Edare (“Applicant”) accepts responsibilities to act as its own agent pursuant to 47 CFR part §2.911(d)(7) of the FCC rules for service of process. I consent to the obligation to accept service of process on behalf of the Applicant for all certification applications to the FCC. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : Edare LLC Contact Name : Dan Weinstein Address : 48 Lafayette Street Lebanon, NH 03766 Telephone No : 603-640-2865 Email : [email protected] Applicant FRN : 0033778713 Signature: ____________________________________ Date: ____________________________________ Daniel J. Weinstein (Sep 22, 2023 13:27 EDT) Sep 22, 2023 Edare WAHTS US Agent Final Audit Report2023-09-22 Created:2023-09-22 By:Amaris Ajamil ([email protected]) Status:Signed Transaction ID:CBJCHBCAABAAMHxK6BN8xE6Fs1CypPjSF6lmIkJ93BJR "Edare WAHTS US Agent" History Document created by Amaris Ajamil ([email protected]) 2023-09-22 - 2:18:48 PM GMT Document emailed to [email protected] for signature 2023-09-22 - 2:19:10 PM GMT Email viewed by [email protected] 2023-09-22 - 5:27:16 PM GMT Signer [email protected] entered name at signing as Daniel J. Weinstein 2023-09-22 - 5:27:43 PM GMT Document e-signed by Daniel J. Weinstein ([email protected]) Signature Date: 2023-09-22 - 5:27:45 PM GMT - Time Source: server Agreement completed. 2023-09-22 - 5:27:45 PM GMT

____________________________________________________________________________________ Edare LLC • 48 Lafayette Street • Lebanon, NH 03766 603-640-2865 • www.edareinc.com Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: Edare LLC FCC ID: 2BA7Y-6459-001X To whom it may concern, Edare (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. Daniel J. Weinstein (Sep 22, 2023 13:27 EDT) Daniel J. Weinstein President Edare LLC Sep 22, 2023 Edare WAHTS FCC Covered List Attestation Final Audit Report2023-09-22 Created:2023-09-22 By:Amaris Ajamil ([email protected]) Status:Signed Transaction ID:CBJCHBCAABAAiEAtDBPI-eAGoOeRZqQ21PUcNcpWC3U3 "Edare WAHTS FCC Covered List Attestation" History Document created by Amaris Ajamil ([email protected]) 2023-09-22 - 2:17:49 PM GMT Document emailed to [email protected] for signature 2023-09-22 - 2:18:20 PM GMT Email viewed by [email protected] 2023-09-22 - 5:25:41 PM GMT Signer [email protected] entered name at signing as Daniel J. Weinstein 2023-09-22 - 5:27:07 PM GMT Document e-signed by Daniel J. Weinstein ([email protected]) Signature Date: 2023-09-22 - 5:27:09 PM GMT - Time Source: server Agreement completed. 2023-09-22 - 5:27:09 PM GMT

____________________________________________________________________________________ Edare LLC • 48 Lafayette Street • Lebanon, NH 03766 603-640-2865 • www.edareinc.com Attention: Application Examiner Re: Request for confidentiality Applicant: Edare LLC FCC ID: 2BA7Y-6459-001X To whom it may concern, Permanent Confidentiality Request is hereby submitted by Edare to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: · Schematics · Detailed Block diagrams · Detailed Operational/Functional Description Rationale for request for confidentiality: Edare has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. The fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact the undersigned. Sincerely, Edare LLC Daniel J. Weinstein (Sep 22, 2023 13:25 EDT) Daniel J. Weinstein President Sep 22, 2023 Edare WAHTS FCC Confidentiality Request Final Audit Report2023-09-22 Created:2023-09-22 By:Amaris Ajamil ([email protected]) Status:Signed Transaction ID:CBJCHBCAABAAxdDu2w5s0DODQrJOraCoT4Ev_8SjS0pk "Edare WAHTS FCC Confidentiality Request" History Document created by Amaris Ajamil ([email protected]) 2023-09-22 - 2:15:04 PM GMT Document emailed to [email protected] for signature 2023-09-22 - 2:17:09 PM GMT Email viewed by [email protected] 2023-09-22 - 5:24:59 PM GMT Signer [email protected] entered name at signing as Daniel J. Weinstein 2023-09-22 - 5:25:31 PM GMT Document e-signed by Daniel J. Weinstein ([email protected]) Signature Date: 2023-09-22 - 5:25:33 PM GMT - Time Source: server Agreement completed. 2023-09-22 - 5:25:33 PM GMT

BACK LEFT BOTTOM FRONT TOP RIGHT Red Inside Ear Cup Red Inside Ear Seal Blue Inside Ear Cup Blue Inside Ear Seal Charging port connection (View 1) Charging port connection (view 2) Charging Port connection (view 3) Charging port connection (Battery side)

IP2X 0297 AC 1 www.wahtshearing.com FCC ID: 2BA7Y-6459-001X WAHTS

Battery Connector 1 Battery Connector 1 USB 2 L/R Speaker Connectors 3 L/R Mic Connectors 4 USB 2 Cable to opposite earcup for battery, right speaker and right microphone USB (used for charging) 2 L Speaker L Mic Battery Connector 1 L Speaker Connector 3 USB 2 R Speaker Connector 3 R/L Mic Connectors 4 BLE Antenna 5 RN-52 Antenna 6 USBSwitchUSBSwitch 22

Page 1 of 7 EDARE LLC SAR EXCLUSION TEST REPORT SCOPE OF WORK SAR EXCLUSION CALCUALTION on WAHTS Audiometer REPORT NUMBER 105406683BOX-022.1_R1 ISSUE DATE [REVISED DATE] 08/23/2023 10/25/2023 DOCUMENT CONTROL NUMBER Non-Specific Radio Report Shell Rev. October 2022 © 2022 INTERTEK Non-Specific Radio Report Shell Rev. October 2022 Page 2 of 7 Client: Edare LLC – Model: AC SAR EXCLUSION TEST REPORT (FULL COMPLIANCE) Report Number: 105406683BOX-022.1_R1 Project Number: G105406683 Report Issue Date: 08/23/2023 Report Revision Date: 10/25/2023 Model(s) Tested: AC Model(s) Partially Tested: None Model(s) Not Tested but declared equivalent by the client: None Standards: FCC Part 1 Subpart I, April 2021 Procedures Implementing the National Environmental Policy Act of 1969 §1.1307 Actions that may have a significant environmental effect, for which Environmental Assessments (EAs) must be prepared. ISED RSS-102 Issue 5, March 19, 2015 Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) Tested by: Client: Intertek Testing Services NA, Inc. 70 Codman Hill Road Boxborough, MA 01719 USA Edare LLC 48 Lafayette St Lebanon, NH 03766 USA Report prepared by Report reviewed by Vathana Ven / Senior Staff Engineer Kouma Sinn / Senior Staff Engineer This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Report Number: 105406683BOX-022.1_R1 Issued: 08/23/2023 Revised: 10/25/2023 Non-Specific Radio Report Shell Rev. October 2022 Page 3 of 7 Client: Edare LLC – Model: AC Table of Contents 1 Introduction and Conclusion .............................................................................................................. 4 2 Test Summary ...................................................................................................................................... 4 3 SAR Exclusion Evaluation .................................................................................................................. 5 4 Revision History ................................................................................................................................... 7 Intertek Report Number: 105406683BOX-022.1_R1 Issued: 08/23/2023 Revised: 10/25/2023 Non-Specific Radio Report Shell Rev. October 2022 Page 4 of 7 Client: Edare LLC – Model: AC 1 Introduction and Conclusion The tests indicated in section 2.0 were performed on the product constructed as described in section 4.0. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test Method, a list of the actual Test Equipment Used, documentation Photos, Results and raw Data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested complies with the requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. Intertek does not make any claims of compliance for samples or variants which were not tested. 2 Test Summary Section Test full name Result 1 SAR Exclusion Evaluation (FCC §1.1310; ISED RSS-102 Issue 5) Pass 2 Revision History -- Intertek Report Number: 105406683BOX-022.1_R1 Issued: 08/23/2023 Revised: 10/25/2023 Non-Specific Radio Report Shell Rev. October 2022 Page 5 of 7 Client: Edare LLC – Model: AC 3 SAR Exclusion Evaluation FCC SAR Test Exclusion Thresholds (FCC KDB Publication 447498 D01 v06): For 100 MHz ≤ f ≤ 6 GHz and dmin ≤ 50 mm: Calculation: Type of TX Frequency, f (GHz) Minimum Separation Distance, dmin (mm) Power*, Pmax (dBm eirp) Peak Antenna Gain (dBi) Pmax (dBm cond.) Pmax (mW) (Pmax/ dmin)* SQRT(f) SAR Test Exclusion Threadhold (Extremity) Result BLE 2480 5 -3.33 2.75 -6.07 0.46452 0.014631 3.0 Compliant *: data was taken from Intertek 105295733BOX-022 test report Evaluation Results, FCC: Complies Intertek Report Number: 105406683BOX-022.1_R1 Issued: 08/23/2023 Revised: 10/25/2023 Non-Specific Radio Report Shell Rev. October 2022 Page 6 of 7 Client: Edare LLC – Model: AC ISED RSS-102 Issue 5 §2.5.2 Exemption: SAR evaluation is not required when the maximum of the conducted output power or EIRP is less than the exemption limits given in RSS-102 Issue 5 Table 1, above. Type of TX Frequency, f (GHz) Minimum Separation Distance, dmin (mm) Power*, Pmax (dBm eirp) Peak Antenna Gain (dBi) Pmax (dBm cond.) Pmax (mW) SAR Test Exclusion Threadhold EIRP (mW) Result BLE 2480 5 -3.33 2.75 -6.07 0.46452 2 Compliant *: data was taken from Intertek 105406683BOX-022 test report Note: The separation distance between a radio’s antenna structure to the user is less than 5mm. Evaluation Results, RSS-102: Complies Intertek Report Number: 105406683BOX-022.1_R1 Issued: 08/23/2023 Revised: 10/25/2023 Non-Specific Radio Report Shell Rev. October 2022 Page 7 of 7 Client: Edare LLC – Model: AC 4 Revision History Revision Level Date Report Number Prepared By Reviewed By Notes 0 08/23/2023 105406683BOX-022.1 VFV KPS Original Issue 1 10/25/2023 105406683BOX- 022.1_R1 VFV KPS Addressed TCB re…
