2BA8A-TEDPROHOMEResidential Energy Monitor

Address: 20800 Boulevard Industriel, Sainte-Anne-de-Bellevue, QC H9X 0A1, Canada Phone: (800) 959-5833 Email: [email protected] TED Pro Home 2.0 Lite Manual Introduction Thank you for purchasing the TED Pro Home 2.0 Lite. Our mission is to guide and support you in getting everything installed and up and running as smoothly as possible. Let's get started so you can start monitoring your energy consumption. The TED Pro Home 2.0 Lite is a complete system that provides you with everything needed in order to get started. Here’s a summary of what’s included with your system. Package Contents Description Quantity Measuring Transmitting Unit (MTU) 1 200A Split-Core Current Transformers 2 MTU Power Cable 1 Cable Tie Wraps 3 Self-Drilling Screws 2 Breaker Panel Sticker 1 USB Type-C Cable 1 Quick Start Guide 1 Safety The installation of this device must be performed by a professional electrician. After the circuit breaker panel cover has been removed, the potential hazard of shock, burn, or even electrocution now exists. Even when the main circuit breaker has been turned to the “OFF” position, certain areas within the circuit breaker panel may still be electrified. Do not attempt installation unless you know where these electrified areas are. WARNING - These servicing instructions are for use by qualified personnel only. To reduce the risk of electric shock, DO NOT perform any servicing other than that contained in these operational instructions unless you are qualified to do so. Address: 20800 Boulevard Industriel, Sainte-Anne-de-Bellevue, QC H9X 0A1, Canada Phone: (800) 959-5833 Email: [email protected] WARNING - The MTU must be connected to a switch or circuit breaker in close proximity to the equipment and within easy reach of the operator. It must be marked as the disconnecting device for the MTU. WARNING - If the equipment is used in a manner not specified in these instructions, the protection provided by the equipment may be impaired. WARNING - To reduce the risk of electric shock, always open or disconnect circuit from power-distribution system (or service) of building before installing or servicing current sensors or metering equipment. FCC Compliance Statement - This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ISED Regulatory Compliance Statement - This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. Specifications Measuring Transmitting Unit (MTU) Voltage Range 100-240V Frequency 50/60Hz Maximum Current (Per Phase) 200A Power Supply Single-Phase (3-Wire) Power Supply Cable Length 4.1' (1.25m) Current Transformer (CT) (Model T20200A) Range 15 to 200A Accuracy ±1.5% rdg. Maximum Wire Size 24mm OD (up to 500 MCM) Cable Length 3.5' (1.06m) Overvoltage Category CAT. III 300V Product Certification ETL General Specifications Service Single-Phase LED Status Indicator Yes Sampling Rate 1x/2 secs. System Power Consumption 1W, 0.2A Product Certifications ETL Conforms to / Certified to ANSI/CAN/ UL STD 2808 FCC Part 15 Subpart B EU/EN 61326-1 IEC 61010-1 Pollution Degree 2 Address: 20800 Boulevard Industriel, Sainte-Anne-de-Bellevue, QC H9X 0A1, Canada Phone: (800) 959-5833 Email: [email protected] Operating Temperature 0 to 104°F (0 to 40°C) Storage Temperature -4 to 140°F (-20 to 60°C) Operating Humidity Range 10-85% Maximum Operating Altitude 6561' (2000m) Dimensions MTU: 4.3 x 2.4 x 1.6" (102 x 60 x 40 mm) CT: 45 x 35 x 65" (111 x 111 x 111 mm) Weight MTU: 5.00oz (142g) Without antenna CT: 6.06oz (172g) CT302 Instrument Dimensions Address: 20800 Boulevard Industriel, Sainte-Anne-de-Bellevue, QC H9X 0A1, Canada Phone: (800) 959-5833 Email: [email protected] Installation Procedure Step 1 - Locating the electrical service When the electrical panel has been located, turn off the main power and remove breaker panel cover. WARNING - To reduce the risk of electric shock, always open or disconnect circuit from power- distribution system (or service) of building before installing or servicing current sensors or metering equipment. Address: 20800 Boulevard Industriel, Sainte-Anne-de-Bellevue, QC H9X 0A1, Canada Phone: (800) 959-5833 Email: [email protected] Step 2 – Installing the MTU Please make sure to follow the guidelines highlighted below to correctly mount the TED 2.0 Measuring Transmitting Unit (MTU) inside the breaker panel. The included self-drilling screws can be used to mount the MTU directly in the breaker box. 1) Submetering equipment shall not be mounted within 50.8 mm (2 in) in of any live parts including primary conductors, primary terminals, primary lugs. This requirement excludes insulated cables. 2) Submeters attached to the enclosure shall not contact the panel interior insulation. 3) Mounting provisions shall not be attached to any live part. 4) Voltage sensing and power supply connections to the primary voltage shall have overcurrent protection. 5) Do not install submetering equipment in any area where breaker arc venting exhaust gasses could be re- directed as a result of submetering equipment installation. Step 3 – Installing the Current Transformers (CTs) Please make sure to follow the guidelines highlighted below to correctly install the Current Transformers (CTs). Address: 20800 Boulevard Industriel, Sainte-Anne-de-Bellevue, QC H9X 0A1, Canada Phone: (800) 959-5833 Email: [email protected] 1) Always open or disconnect circuit from power-distribution system (or service) of building b…

Text truncated - open the document above for the full version.

ITM Instruments Inc. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 6/29/2023 U.S. Agent Designation IT M Instruments Inc. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BA8A- TEDPROHOME): Name and company of U.S. agent: FCC US Agent, LLC Physical U.S. address of agent: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN of U.S. agent: 0033402884 Email address of U.S. agent: [email protected] FCC US Agent, LLC acknowledges their obligation to accept service of process on behalf of ITM Instruments Inc.. ITM Instruments Inc. with the FRN 0033781584 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Since rely, Signature Chris Korres Director of Business Development ITM Instruments Inc. Signature Tim Payne Manager FCC US Agent, LLC 48_[model] US_Agent_2.911(d)(7)-U, V05

Page 1 of 6 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 6 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 6 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 6 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Page 5 of 6 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 9 Fig. 10 Page 6 of 6 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 11

Page 1 of 1 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L4.0cm x 4.0cm) Label Location Residential Energy Monitor Model: TED Pro Home 2.0 Lite FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME HVIN: TED Pro Home 2.0 Lite

Page 1 of 4 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Antenna Page 2 of 4 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 4 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 4 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7

Page 1 of 4 FCC ID: 2BA8A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC RF Exposure Evaluation 1. Product Information FCC ID 2BA8A-TEDPROHOME Product name Residential Energy Monitor Model number TED Pro Home 2.0 Lite Power supply Input: AC 110-250V, 50/60Hz, 200mA, 1W Modulation Type GFSK for Bluetooth V4.2 IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Type External Antenna Antenna Gain 2dBi(Max.) Hardware version / Software version / FCC Operation frequency 2402MHz-2480MHz 2412MHz-2462MHz Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Devices 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. Page 2 of 4 FCC ID: 2BA8A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information Ceramics Antenna can only use antennas certificated as follows provided by manufacturer; Internal Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Note Antenna External Antenna 2400MHz-2500MHz 2dBi BT WIFI Antenna Page 3 of 4 FCC ID: 2BA8A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 6. Conducted Power < BT LE Max Conducted Power > Mode Channel Frequency(MHz) Max Conducted Power (dBm) GFSK 0 2402 -4.59 19 2440 -3.68 39 2480 -3.28 <2.4GWLAN Max Conducted Power > Mode Channel Frequency(MHz) Max Conducted Power (dBm) IEEE 802.11b 1 2412 14.47 6 2437 14.07 11 2462 13.82 IEEE 802.11g 1 2412 14.94 6 2437 15.45 11 2462 14.45 IEEE 802.11n HT20 1 2412 14.96 6 2437 13.71 11 2462 15.07 IEEE 802.11n HT40 3 2422 13.40 6 2437 13.50 9 2452 13.43 7. Manufacturing Tolerance <BT LE> GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) -4.0 -3.0 -3.0 Tolerance ±(dB) 1.0 1.0 1.0 <2.4G WIFI> 11B (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 14.0 14.0 13.0 Tolerance ±(dB) 1.0 1.0 1.0 11G (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 14.0 15.0 14.0 Tolerance ±(dB) 1.0 1.0 1.0 11N20SISO (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 14.0 13.0 15.0…

Text truncated - open the document above for the full version.

厦门长京电子科技有限公司 Xiamen Changjing Electronic Technology Co., LTD 承认书 acknowledgement 客户 client: 产品类别 Product category: 2.4-2.5GHz 2dBi 黑色天线 2.4-2.5GHz 2dBi black antenna 客户项目号 Customer item number： 客户物料编码 Customer material code： 产品型号： 2.4G 黑色外置天线108mm-SMA 接头 Product model： 2.4G black external antenna 108mm-SMA connector Xiamen Changjing Electronic Technology Co., LTD 拟制 fiction： 审核 examine： 批准 approve： HSQ HJF CYM 厦门长京电子科技有限公司 Xiamen Changjing Electronic Technology Co., LTD 一、天线规格表/Antenna specification sheet Specification 1. ElectricalProperties 1.1 FrequencyRange---------------------2.4- 2. 5GHz 1.2 Impedance-----------------------------50 Ω 1.3 VSWR---------------------------------1.92 ： 1 1.4 ReturnLoss----------------------------10 dB or Less 1.5 Radiation------------------------------Omni-directional 1. 6 Gain -----------------------------------2dB i 1. 7 Polarization-------------------------Linear polarization 1. 8 AdmittedPower----------------------1W 2 ． PhysicalProperties 2.1 AntennaCover -----------------------TPEE 2. 2 AntennaBase ------------------------PC 2. 3 AntennaBase ------------------------PBT 2. 4 OperatingTemp--------------------- -10 °C ~+60 °C 2.5 StorageTemp-------------------------10 °C ~+70 °C 2.6 Color -----------------------------------Black 2.7 CONN.---------------------------------Tin 厦门长京电子科技有限公司 Xiamen Changjing Electronic Technology Co., LTD 二、成品图/Finished drawing： 厦门长京电子科技有限公司 Xiamen Changjing Electronic Technology Co., LTD 三、测试报告/Test report： 测试设备：ETS7*4*3暗室.8960/E5515C Test equipment: ETS7*4*3 darkroom.8960/E5515C Returnloss: 厦门长京电子科技有限公司 Xiamen Changjing Electronic Technology Co., LTD 2D、3DRaditation Pattern: 四、材质要求/Material requirement： 1. 本体Body: ■TPEE；黑色/BLACK 2. 基座Base: ■PBT; 黑色/BLACK 3. 基座Base: ■PC; 黑色/BLACK 4. 铆钉Rivet:■POM; 黑色/BLACK 5. PCB板：单频PCB板/Single frequency PCB board 6. Cable: ■棕色Ф编织镀锡，内导体镀锡，外被FEP,绝缘体 FEPBrown braided tinning, inner conductor tinned, outer FEP, insulator FEP 厦门长京电子科技有限公司 Xiamen Changjing Electronic Technology Co., LTD 五、外观检查/Visual inspection 1、外观颜色/Appearance color： ■黑色/BLACK Cable：黑色/BLACK 2、外观判定基准：无毛边；无破损；无刮伤;无颜色不符; 无内导体脱落,松动等不良。Appearance criteria: no rough edges; No damage; No scratches; No color inconsistency; No inner conductor falling off, loose and other bad. 六、试装检验/Trial assembly inspection 项目 item 检查内容 Check content 检测工具 Detection tool 测 试 方 法 与 判 定 标 准 Test method and determination criteria 判定 determine 组装检验 Assembly inspection 装配效果 Assembly effect 目视 厚薄规 Look thick and thin 将天线与PCB、机壳 、天线馈线装配时,须组装顺畅,不可有松动、难装或装不到位的现象 When assembling the antenna with the PCB, shell, and antenna feeder, it must be assembled smoothly, and it must not be loose, difficult to install or not installed in place OK 七、电气性能/Electrical performance 项目/item 试验方法及条件/Test methods and conditions 规格及要求/Specifications and requirements 结果/result 1.特性阻抗 Characteristic impedance 用TDR 测试天线特性阻抗 /antenna characteristic impedance was measured by TDR 阻抗 50 欧±10 欧 Impedance 50 Ω ±10 Ω OK 2 驻波比 Standing-wave ratio 在 2.4 GHz- 2.5 GHz，用网络分析仪测试驻波比 At 2.4GHz-2.5GHz, the standing wave ratio is tested with a network analyzer VSWR 驻波比1.92:1 MAX VSWR standing wave ratio 1.92:1 MAX OK 3 回波损耗 Return loss 在 2.4GHz-2.5GHz，用网络分析仪测试回波损耗 At 2.4GHz-2.5GHz, the return loss was tested with a network analyzer 回波损耗-10dB MAX Return loss -10dB MAX OK 4 增益 transmission gain 在 2.4GHz-2.5GHz 微波暗室测试增益和场型图 gain and field pattern were tested in a 2.4GHz-2.5GHz microwave darkroom 场形图增益符合规格要求 gain of the field graph meets the specifications OK 厦门长京电子科技有限公司 Xiamen Changjing Electronic Technology Co., LTD 八、可靠性测试/Reliability test 项目/item 试验方法及条件 Test methods and conditions 规格及要求 Specifications and requirements 结果/result 盐雾测试 Salt spray test 判定方法:试验后用20 倍放大镜观察;无氧化之不良; 即判定合格 Determination method: observation with 20x magnifying glass after test; No adverse oxidation; Instant acceptance OK 振动测试 Vibration test 振 频10-2000-10HZ振 幅 1.52mm沿X.Y.Z方向各10次 外观无明显变化 ，各电性参数符合规格误差 appearance has no obvious change, and the electrical parameters meet the specification error OK 跌落测试 Drop test 从 1M 处跌落在木板上 Fell about 1 meter onto the board 外观无明显变化 ，各电性参数符合规格误差 appearance has no obvious change, and the electrical parameters meet the specification error OK 温度循环测试 Temperature cycle test 高温: 70°C ；低温：－20°C持续时间：每种温 度持续30分钟；转换时间：10分钟；循环次 数：5次；恢复时间：4 to 6hrs High temperature: 70°C; Low temperature: -20°C Duration: Each temperature lasts for 30 minutes Transfer time: 10 minutes Number of cycles: 5 Recovery time: 4 to 6hrs 外观无明显变化 ，各电性参数符合规格误差 appearance has no obvious change, and the electrical parameters meet the specification error OK 恒温恒湿测试 Constant temperature and humidity test 温湿度：40±2°C,90-95%RH 持续时间：500hrs 恢复时间：4 to 6hrs检测时间：240 & 500hrs Temperature and humidity: 40±2°C,90-95% RH Duration: 500hrs Recovery time: 4 to 6hrs Detection time: 240 & 500hrs 外观无明显变化，各电性参数符合规格误差 appearance has no obvious change, and the electrical parameters meet the specification error OK 高温测试 High temperature test 温度： 85°C； 持续时间： 240hrs； 恢复时间： 4 to 6hrs； 检测时间： 240 hrs Temperature: 85°C Duration: 240hrs Recovery time: 4 to 6hrs Test time: 240 hrs 外观无明显变化，各电性参数符合规格误差 appearance has no obvious change, and the electrical parameters meet the specification error OK 低温测试 Low temperature test 温度：－ 20°C；持续时间：240hrs；恢复时 间：4 to 6hrs；检测时间：240 hrs； Temperature: -20°C Duration: 240hrs Recovery time: 4 to 6hrs Test time: 240 hrs 外观无明显变化，各电性参数符合规格误差 appearance has no obvious change, and the electrical parameters meet the specification error OK 盐水浓度50+/-10g/l(约5%);PH6.5-7.2;试验温 度35+/-1度;腐蚀时间16H. Brine concentration 50+/-10g/l(about 5%); PH6.5-7.2; Test temperature 35+/-1 degrees; Corrosion time 16H 厦门长京电子科技有限公司 Xiamen Changjing Electronic Technology Co., LTD 九、包装要求/Packing requirement: ■ PE袋/PE bag■纸箱/Paper box

Page 1 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix A RF Test Data for BLE (Conducted Measurement) Product Name: Residential Energy Monitor Test Model: TED Pro Home 2.0 Lite Environmental Conditions Temperature: 23.5 C Relative Humidity: 52.2% ATM Pressure: 100.0 kPa Test Engineer: Nick Peng Supervised by: Ling Zhu Page 2 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.1 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 1M 2402 Ant1 0.68 >=0.5 Pass NVNT BLE 1M 2440 Ant1 0.658 >=0.5 Pass NVNT BLE 1M 2480 Ant1 0.656 >=0.5 Pass Page 3 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs -6dB Bandwidth NVNT BLE 1M 2402MHz Ant1 -6dB Bandwidth NVNT BLE 1M 2440MHz Ant1 Page 4 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT BLE 1M 2480MHz Ant1 Page 5 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.2 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT BLE 1M 2402 Ant1 1.049 NVNT BLE 1M 2440 Ant1 1.04 NVNT BLE 1M 2480 Ant1 1.042 Page 6 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs OBW NVNT BLE 1M 2402MHz Ant1 OBW NVNT BLE 1M 2440MHz Ant1 Page 7 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity OBW NVNT BLE 1M 2480MHz Ant1 Page 8 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.3 Maximum Conducted Output Power and e.i.r.p. Condition Mode Frequency (MHz) Antenna Total Power (dBm) Limit (dBm) Antenna Gain Report EIRP Power(dBm) Limit (dBm) Verdict NVNT BLE 1M 2402 Ant1 -4.59 30 2 -2.59 36 Pass NVNT BLE 1M 2440 Ant1 -3.68 30 2 -1.68 36 Pass NVNT BLE 1M 2480 Ant1 -3.28 30 2 -1.28 36 Pass Page 9 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs Power NVNT BLE 1M 2402MHz Ant1 Power NVNT BLE 1M 2440MHz Ant1 Page 10 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Power NVNT BLE 1M 2480MHz Ant1 Page 11 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.4 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Total PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT BLE 1M 2402 Ant1 -21 8 Pass NVNT BLE 1M 2440 Ant1 -20.25 8 Pass NVNT BLE 1M 2480 Ant1 -19.91 8 Pass Page 12 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs PSD NVNT BLE 1M 2402MHz Ant1 PSD NVNT BLE 1M 2440MHz Ant1 Page 13 of 26 FCC ID: 2BA8A-TEDPROHOME IC: 9994A-TEDPROHOME Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shaj…
