2BA9I-G1wireless mouse

3 5 2.4GHz Wireless Arc Touch Mouse IMPORTANT: 1. The mouse needs a new 1.5V AAA battery, otherwise the touch bar may become insensitive or unresponsive as the touch bar requires a higher voltage to operate. 2. When the mouse cursor and touch bar are unstable or do not work, it is time to replace the battery with a new one. 退换货原因 UM ON OFF 1 2 3 4 5 Requires 2 pcs 1.5V AAA batteries (not included) Bend the mouse to turn on power. Flatten to turn off. Specifications -Compatible systems: Windows 7/8/10/XP/Vista, Mac OS, Chrome OS, Android, Linux -Application: PC, Laptop, Other devices with USB port -Scrolling Type: Touch Scroll -Connection style: 2.4GHz Wireless -DPI: 1600 -Hand Orientation: Left and Right -Mouse Size: 126.5*56.5*16.5 mm -Power Supply: 2*AAA battery (not included) -Weight: 50g -Wireless transmi ssion distance: 10m -Current: 8-15MA@3V -The strength of button: 60-70±10g -Buttons life: 3 million times. Ultra-Slim | Lightweight | Portable | Plug and Play Flick your finger up or down to scroll quickly. Tap at the top or bottom to page up or page down. WUDEMWWFE 1. Put into the battery, bend the mouse. 2. Insert the USB Receiver into a USB port on your computer. Plug and Play. USB Receiver Storage: Stow the USB Receiver in the magnetic holder underneath the mouse. Packing List: 1x Arc Wireless Mouse, 1x USB Receiver, 1x User Manual. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

-DongguanshiShunjinrunDianzikejiYouxiangongsi- TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB986446D01. Anexpirationdateforthisletterdoesnotexist.IncasetheU.S.agentchanges,thegranteeisobligatedtonotifytheFCCwithin30daysvia thegrantingTCB. FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 5/29/23 U.S.AgentDesignation [DongguanshiShunjinrunDianzikejiYouxiangongsi]acknowledgestheirconsentforthefollowing contactlocatedintheUnitedStatestoactastheiragentforserviceofprocessfortheequipmentfor whichauthorizationissought(FCCID:[2BA9I-G1]): NameandcompanyofU.S.agent:LinkwldLLC PhysicalU.S.addressofagent:1942BroadwaySt.STE314C,Boulder,CO,80302,US FRNofU.S.agent:0033625682 EmailaddressofU.S.agent:[email protected] TelephoneNoofU.Sagent:+1-716-963-4572 [LinkwldLLC]acknowledgestheirobligationtoacceptserviceofprocessonbehalfof[Dongguanshi ShunjinrunDianzikejiYouxiangongsi]. [DongguanshiShunjinrunDianzikejiYouxiangongsi]withtheFRN[0033790072]acceptsitsobligation tomaintainanagentforserviceofprocessintheUnitedStatesfornolessthanoneyearaftereither thegranteehaspermanentlyterminatedallmarketingandimportationoftheapplicableequipment withintheU.S.,ortheconclusionofanyCommission-relatedadministrativeorjudicialproceeding involvingtheequipment,whicheverislater. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirements listedunder§2.911(d)(7). Sincerely, Signature FangSong corporation DongguanshiShunjinrunDianzikejiYouxiangongsi 4 8 _ [ m o d e l ] U S _ A g e n t _ 2 . 9 1 1 ( d ) ( 7 ) - U , V 0 4 -DongguanshiShunjinrunDianzikejiYouxiangongsi- TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB986446D01. Anexpirationdateforthisletterdoesnotexist.IncasetheU.S.agentchanges,thegranteeisobligatedtonotifytheFCCwithin30daysvia thegrantingTCB. Signature TimothyZhu Manager LinkwldLLC

-DongguanshiShunjinrunDianzikejiYouxiangongsi- TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB986446D01. FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 5/29/23 Towhomitmayconcern: We,[DongguanshiShunjinrunDianzikejiYouxiangongsi],herebycertifythattheequipmentforwhich authorizationissought(FCCID:[2BA9I-G1])isnot“covered”equipmentprohibitedfromreceivingan equipmentauthorizationpursuantto§2.903oftheFCCrules. Wealsocertifythat,asofthedateofthefilingoftheapplication,wearenotidentifiedontheCovered List(https://www.fcc.gov/supplychain/coveredlist)asanentityproducing“covered”equipment. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirements listedunder§2.911(b)and(d)(5)and(6). Sincerely, Signature FangSong corporation DongguanshiShunjinrunDianzikejiYouxiangongsi 6 2 _ [ m o d e l ] C o v e r e d E q u _ 2 . 9 1 1 ( d ) ( 5 ) ( i ) a n d ( i i ) - U , V 0 2

Code:AB-RF-05-b ExternalPhotograph Code:AB-RF-05-b Code:AB-RF-05-b

LabelLocationOnEUT Label ProductName:wirelessmouse ModelNo.:G1 FCCID:2BA9I-G1 ThisdevicecomplieswithPart15oftheFCCRules.Operationis subjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation.

Code:AB-RF-05-b InternalPhotograph Code:AB-RF-05-b ANT Code:AB-RF-05-b

RFEXPOSUREEVALUATION FCCID:2BA9I-G1 AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeused toevaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF) Radiationasspecifiedin§1.1307(b): RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,using measurementsorcomputersimulation.WhenroutineSARevaluationisnot required,portabletransmitterswithoutputpowergreaterthantheapplicable lowthresholdrequireSARevaluationtoqualifyforTCBapproval. Channel (MHz) Maximum output power (dBm) Tuneup tolerance (dBm) MaxTuneUp Power(dBm) Distance (mm) Calculation results Limit Operating Mode 24052.072.07 ±1 3.0750.6293 2.4G24301.981.98 ±1 2.9850.6213 24700.460.46±11.4650.4413 Result:NoStandaloneSARtestisrequired.

Page1of23 AppendixTestData ReportNo.:18220WC30085201TestSampleNo.:1-2-2 StartTestDate:2023.05.11FinishTestDate:2023.05.15 TestEngineer:Auditor: Temperature:25.3 °C RelativeHumidity:57% Pressure:1012hPa AppendixA:DTSBandwidth TestResult TestModeAntennaFrequency[MHz] DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 2.4GAnt1 24050.9722404.5242405.4960.5PASS 24300.8842429.5962430.4800.5PASS 24700.8642469.6122470.4760.5PASS Page2of23 TestGraphs 2.4G_Ant1_2405 2.4G_Ant1_2430 2.4G_Ant1_2470 Page3of23 Page4of23 AppendixB:OccupiedChannelBandwidth TestResult TestModeAntennaFrequency[MHz] OCB[MHz] FL[MHz]FH[MHz] 2.4GAnt1 24051.18302404.41212405.5951 24301.21022429.39712430.6073 24701.19722469.40752470.6047 Page5of23 TestGraphs 2.4G_Ant1_2405 2.4G_Ant1_2430 2.4G_Ant1_2470 Page6of23 Page7of23 AppendixC:Maximumconductedoutputpower TestResultPeak TestModeAntennaFrequency[MHz] ConductedPeak Power[dBm] Conducted Limit[dBm] Verdict 2.4GAnt1 24052.07≤30PASS 24301.98≤30PASS 24700.46≤30PASS Page8of23 TestGraphsPeak 2.4G_Ant1_2405 2.4G_Ant1_2430 2.4G_Ant1_2470 Page9of23 Page10of23 AppendixD:Maximumpowerspectraldensity TestResult TestModeAntennaFrequency[MHz]Result[dBm/3kHz]Limit[dBm/3kHz]Verdict 2.4GAnt1 2405-13.92≤8.00PASS 2430-13.98≤8.00PASS 2470-15.48≤8.00PASS Page11of23 TestGraphs 2.4G_Ant1_2405 2.4G_Ant1_2430 2.4G_Ant1_2470 Page12of23 Page13of23 AppendixE:Bandedgemeasurements TestResult TestMod e Antenn a ChNam e Frequency[MHz ] RefLevel[dBm ] Result[dBm ] Limit[dBm ] Verdic t 2.4GAnt1 Low2405-0.42-57.24≤-20.42PASS High2470-3.26-56.74≤-23.26PASS Page14of23 TestGraphs 2.4G_Ant1_Low_2405 2.4G_Ant1_High_2470 Page15of23 AppendixF:ConductedSpuriousEmission TestResult TestMod e Antenn a Frequency[MHz ] FreqRange [MHz] RefLeve l [dBm] Result[dBm ] Limit[dBm ] Verdic t 2.4GAnt1 2405 Reference-0.41-0.41---PASS 30~1000-0.41-70.25≤-20.41PASS 1000~2650 0 -0.41-53.33≤-20.41PASS 2430 Reference-3.05-3.05---PASS 30~1000-3.05-70.16≤-23.05PASS 1000~2650 0 -3.05-53.25≤-23.05PASS 2470 Reference-3.69-3.69---PASS 30~1000-3.69-69.12≤-23.69PASS 1000~2650 0 -3.69-52.52≤-23.69PASS Page16of23 TestGraphs 2.4G_Ant1_2405_0~Reference 2.4G_Ant1_2405_30~1000 2.4G_Ant1_2405_1000~26500 Page17of23 2.4G_Ant1_2430_0~Reference 2.4G_Ant1_2430_30~1000 Page18of23 2.4G_Ant1_2430_1000~26500 2.4G_Ant1_2470_0~Reference Page19of23 2.4G_Ant1_2470_30~1000 2.4G_Ant1_2470_1000~26500 Page20of23 Page21of23 AppendixG:DutyCycle TestResult TestModeAntennaFrequency[MHz] ONTime [ms] Period [ms] DutyCycle [%] DutyCycle Factor[dB] 2.4GAnt1 24052.883.7477.011.13 24302.893.7577.071.13 24702.893.7577.071.13 Page22of23 TestGraphs 2.4G_Ant1_2405 2.4G_Ant1_2430 2.4G_Ant1_2470 Page23of23 ---End---

ReportNo.:18220WC30085201FCCID:2BA9I-G1Page1of28 Code:AB-RF-05-b FCCTestReport Applicant: DongguanshiShunjinrunDianzikeji Youxiangongsi Address: jiumingcunlu22hao101fangzhangmutou zhendongguancityguangdong523617, China ProductName:wirelessmouse ReportDate:May29,2023 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC30085201FCCID:2BA9I-G1Page2of28 Code:AB-RF-05-b Contents 1.GeneralInformation............................................................................................................................................6 1.1.ClientInformation.....................................................................................................................................6 1.2.DescriptionofDevice(EUT)..................................................................................................................6 1.3.AuxiliaryEquipmentUsedDuringTest.................................................................................................7 1.4.DescriptionofTestConfiguration..........................................................................................................7 1.5.DescriptionOfTestSetup.......................................................................................................................8 1.6.TestEquipmentList.................................................................................................................................9 1.7.MeasurementUncertainty....................................................................................................................10 1.8.DescriptionofTestFacility....................................................................................................................10 2.SummaryofTestResults.................................................................................................................................11 3.ConductedEmissionTest................................................................................................................................12 3.1.TestStandardandLimit........................................................................................................................12 3.2.TestSetup...............................................................................................................................................12 3.3.TestProcedure.......................................................................................................................................12 3.4.TestData.................................................................................................................................................12 4.RadiationSpuriousEmissionandBandEdge.............................................................................................13 4.1.TestStandardandLimit........................................................................................................................13 4.2.TestSetup...............................................................................................................................................13 4.3.TestProcedure.......................................................................................................................................14 4.4.TestData.................................................................................................................................................15 5.MaximumPeakOutputPowerTest................................................................................................................23 5.1.TestStandardandLimit........................................................................................................................23 5.2.TestSetup...............................................................................................................................................23 5.3.TestProcedure.......................................................................................................................................23 5.4.TestData.................................................................................................................................................23 6.6DBOccupyBandwidthTest...........................................................................................................................24 6.1.TestStandardandLimit........................................................................................................................24 6.2.TestSetup...............................................................................................................................................24 6.3.TestProcedure.......................................................................................................................................24 6.4.TestData.................................................................................................................................................24 7.PowerSpectralDensityTest...........................................................................................................................25 7.1.TestStandardandLimit........................................................................................................................25 7.2.TestSetup...............................................................................................................................................25 7.3.TestProcedure.......................................................................................................................................25 7.4.TestData.................................................................................................................................................25 8.100kHzBandwidthofFrequencyBandEdgeRequirement......................................................................26 8.1.TestStandardandLimit........................................................................................................................26 8.2.TestSetup.............…

Text truncated - open the document above for the full version.

version01 DongguanshiShunjinrunDianzikejiYouxiangongsi DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:G1,G2,B100,B200,KB100,AT258,AT811,KM202,KM426,KM800 FCCID:2BA9I-G1 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsforinternalantennatype(s) describedbelow: ModelNo.ofantenna:G1 Typeofantenna:PCBantenna Gainoftheantenna:-1.6dBi Frequencyrange:2405-2470M Hz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:DongguanshiShunjinrunDianzikejiYouxiangongsi Address:jiumingcunlu22hao101fangzhangmutouzhendongguancityguangdong 523617,China City:dongguan ZIP/Postalcode:/ Country:China Place:dongguanDate:5/29/2023 Signature:

AntennaSpecification Specifications Summary ITEMSPEC. ModelName CenterFrequency 2405 MHz -1.60dBi 2450MHz 2470 MHz -3.00 dBi -2.7dBi MAX.GAIN -1.6dBi PolarizationHorizontal AzimuthBeamPatternOmni-directional Impedance 50 Ω AntennaPhoto & Length ( mm ) AntManufacturer:DongguanshiShunjinrunDianzikejiYouxiangongsi Address: jiumingcunlu22hao101fangzhangmutouzhendongguancityguangdong 523617,China 1.Mainantenna:2405MHz 1.1 Horizontal Frequency(MHZ):2405 MaximumValue(dBi):-1.6 AverageGain ( dBi ):-1.4 MinimumGain(dBi):-61.26 1.2Vertical AntennaPolarity :Horizontal Frequency(MHZ):2405AntennaPolarity:Vertical MaximumValue ( dBi ):-2.85 AverageGain(dBi):-12 MinimumGain(dBi):-64 2.Mainantenna:2450MHz 2.1Horizontal Frequency(MHZ):2450AntennaPolarity:Horizontal MaximumValue(dBi):-2.6 AverageGain(dBi):-5.4 MinimumGain(dBi):-60 2.2Vertical Frequency(MHZ):2450AntennaPolarity:Vertical MaximumValue ( dBi ):-2.6 AverageGain ( dBi ):-10.1 MinimumGain ( dBi ):-54 3.Mainantenna:2470MHz 2.1Horizontal Frequency(MHZ):2480AntennaPolarity:Horizontal MaximumValue ( dBi ):-3 AverageGain(dBi):-4.6 MinimumGain(dBi):-52 2.2Vertical Frequency ( MHZ ):2470 AntennaPolarity :Vertical MaximumValue(dBi):-3 AverageGain(dBi):-11 MinimumGain(dBi):-50

Code:AB-RF-05-b TestSetupPhotograph PhotoofRadiationEmissionTest
