2BACC-ID67PLUSMechanical keyboard

Instructions for ID67 PLUS Specifications： Model: ID67 PLUS Bluetooth: IDOBAO - C1 / C2 /C3 / C4 / Back light: RGB - LED Material: Body case - Aluminum; Keycaps - ABS; Battery capacity: 4000mAh Connection mode: Wired / Bluetooth 5.2 Keys: 67keys Switch support: MX Switches (3pins & 5pins) Interface: USB Type-C Size: 121.19mm*323.06mm*42.61mm Weight: 1360g Switching of connection modes Packing List: Keyboard kit, cable, Keycap puller, Switchpuller, Instruction manual Other key combination: Restart the Keyboard: Wired mode: FN + ESC switch to wired mode Bluetooth mode: FN + number keys (as the picture below) As corresponding number key turns on blue light, switch on to Bluetooth mode Search Bluetooth “IDOBAO” and connect with your device; This keyboard support 6 Bluetooth channel, with the key combination of: FN + 1 switch to Bluetooth device 1 FN + 2 switch to Bluetooth device 2 FN + 3 switch to Bluetooth device 3 FN + 4 switch to Bluetooth device 4 FN + 5 switch to Bluetooth device 5 FN + 6 switch to Bluetooth device 6 FN + L Turn On/Off RGB lights FN + ←/→ Switch the RGB effects FN + ↑ Increase the RGB brightness FN + ↓ Decrease the RGB brightness FN + Q Reset Bluetooth connection record FN + G Switch to gaming mode (Lock up WIN key) Product warranty Customers can obtain after-sales service using IDOBAO mechanical keyboard products to: In the time of 8-30 days (Starts from the second day of delivered time), If this product has initiative performance failure, and confirmed by IDOBAO after -sales team, we will provide repair and replacement service. In the time of 1 year (Starts from the second day of delivered time), If this product has initiative performance failure, and confirmed by IDOBAO after -sales team, we will provide repair service. Non -warranty regulations Unauthorized repair, bump, oversight, misuse, water seepage,accident, tear, paint alter; Out of warranty time; Other damages. Contact us Official website: www.idobao.net Customer service: [email protected] Discord channel: In the case of keyboard in no response state, Pull off the keycap of CAPS key, Turn off and on the power switch beside the key, to restart the keyboard. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. *RF warning for Portable device: The device has been evaluated to meet general RF exposure requirement.The device can be used in portable exposure condition without restriction.

Sincerely, Name/Title： Wei Liu/General Manager Company: Shenzhen Kool-Aid Duobao E-commerce Co., LTD Address: 118, Building 9, Hongshan 69792, Daling Community, Minzhi Street, Longhua District, Shenzhen, China Phone: 86-13686468936 Fax: 86-075582521355 E-Mail: [email protected]

FCCID:2BACC-ID67PLUS FCCID:2BACC-ID67PLUS FCCID:2BACC-ID67PLUS

FCCID:2BACC-ID67PLUS FCCID:2BACC-ID67PLUS FCCID:2BACC-ID67PLUS FCCID:2BACC-ID67PLUS FCCID:2BACC-ID67PLUS FCCID:2BACC-ID67PLUS FCCID:2BACC-ID67PLUS ANT

Page1of2 RFEXPOSUREEVALUATION FCCID:2BACC-ID67PLUS ProductName: Mechanicalkeyboard ModelName: ID67Plus BluetoothVersion:BLE Operatingfrequency:2402-2480MHz NumbersofChannel:40channelsForDTS AntennaType:IntegralAntenna AntennaGain:2.16dBi TypeofModulation:GFSK Powersupply:DC:5V1A HardwareVersion:N/A SoftwareVersion:N/A Page2of2 StandardRequirement Accordingto§15.247(i)and§1.1307b(1),systemsoperatingundertheprovisionsofthis sectionshallbeoperatedinamannerthatensuresthatthepublicisnotexposedtoradio frequencyenergylevelsinexcessoftheCommission’sguidelines.SeeKDB447498D01 GeneralRFExposureGuidancev06,section4.3.1. The1-gand10-gSARtestexclusionthresholdsfor100MHzto6GHzattestseparation distances≤50mmaredeterminedby: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]*[√f(GHz)]≤3.0for1-gSARand≤7.5for10-gSARextremitySAR,where f(GHz)istheRFchanneltransmitfrequencyinGHz PoweranddistanceareroundedtothenearestmWandmmbeforecalculation Theresultisroundedtoonedecimalplaceforcomparison. Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis≤ 50mmandfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmisappliedtodetermineSARtestexclusion. RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,usingmeasurements orcomputersimulation.WhenroutineSARevaluationisnotrequired,portabletransmitters withoutputpowergreaterthantheapplicablelowthresholdrequireSARevaluationtoquality forTCBapproval. Channel (MHz) Maximum output power (dBm) Tuneup tolerance (dBm) MaxTune UpPower (mW) Distance (mm) Calculation results Limit Operating Mode 2480 0.83 0.83 ± 11.52405350.4800163BLE AccordingtoKDB447498,nostand-alonerequiredforBTantenna,andnosimultaneousSAR measurementisrequired. Signature RonnieLiu EMCManager Date:2023-03-30
