2BAG8-MAYTONAP3AutoPro Dual

USER MANUAL AutoPro Dual CONTENTGetting To Know Before Using ...................... 4How To Check A Car Has CarPlay Or Not ....... 5What's In The Box ......................................... 6Specifications ............................................... 7Connectors ................................................... 8User Interface ............................................... 9Quick Settings ............................................ 11Firmware Update........................................ 14 WarningTo protect the driving safety of yourself and other road users, and to avoid breaking the traffic law in your respective country; please DO NOT watch videos while driving. Due to the product's continuous updating, some contents of this manual may differ from the product you actually purchased.TIPS! To adapt to the factory display, the Android system will automatically restart once when the first time connecting to the car. This AI box is designed for the factory car stereo with built-in wired Apple CarPlay, which can convert wired CarPlay into a full Android system. Besides, it integrates wireless Apple CarPlay/Android Auto functions.Getting to know before using 5 1. Plug an iPhone (running iOS 10 or newer) into the car USB ports with genuine factory lightning cable. If there is a notification pop up on iPhone like below, that your car has built-in Apple CarPlay.2. If there is a CarPlay icon in the car stereo menu, that your car has built-in Apple CarPlay.3. Contact your car dealer for help. or How to check a car has CarPlay or not 4 6 What's in the box• Android AI box *1• Bypass power cable *1• USB cable (type-C to A) *1• USB cable (type-C to C) *1• User manual *1• Installation guide *1• Ejection pin *1 7 OS Processor RAM+ROM Expandable Memory SIM Card Wi-Fi Bluetooth GNSS Power Input Operating Temperature Dimensions Weight Android 10Qualcomm Snapdragon 665 Octa-core,64 bit 11 nm, up to 2.0 GHz4GB + 64GBMicro SD card, up to 128GB3G/4G LTE Nano SIM cardDual-band Wi-Fi 802.11 a/b/g/n/ac 2.4 GHz+5 GHzBuilt-in GPS/GLONASS/BeidouUSB 5V~1A-30~75 ȭ SSMBT 5.0, for iPhone/Android smartphone hands-freecalling & audio streaming, external BT mouse, remote controller, etc. Specifications 8 NOTE! Power off before inserting or removing the nano SIM card. Nano SIM card and Micro SD card are not included in the package. For how to insert the cards please refer to this diagram. USB-C port Mini HDMI out Nano SIM card Micro SD card Connectors User Interface 9 Common apps, press & hold the icon to replace installed app. Music playback widget WiFi / BT / SIM cardnetwork status barRecent running appsGoogle Assistant by default. Select another app in Settings > CAR > Voice assistant.Tap: Back Press & hold: all recent apps Tap: Home Press & hold: enable split screen (only available in 3rd party app) Up to 1080P HDMI a/v output 10 Weather & clock widgetAdd your location by tapping the weather icon.Long press: delete all favorite contact shortcutsTap: call this contact Long press: replace the contact Tap to add favorite contact shortcut (please pair to Bluetooth first) Quick settings 11 • Pairing your iPhone/Android phone with Bluetooth• Setting up wireless Apple CarPlay/Android Auto• Opening notification barTIPS! Disable [wireless auto connect] in MultiPlay app settings if you don't want to automatically start wireless CP/AA every time you pair to Bluetooth. Swipe down twice from the top Enable your mobile phone's Bluetooth, next open Bluetooth app on AI box Pair your iPhone/ Android smartphone to AI box's Bluetooth first. Open MultiPlay app. Tap confirm if there are pop-up notifications on your phone. NOTE! Using wireless CarPlay or Android Auto will disable the AI box's WiFi function. Enter pair code 0000 on your mobile phone to finish pairing 0000 13 2 You could choose it as PIP navigation or a shortcut for any app.Shortcut: Open [PIP Widget] app > [Quick launch setting for any app] > [Select the quick launch app].PIP navigation: Open [PIP Widget] app> [PIP Navi setting] > [Select the navigation app on PIP widget].NOTE! The selected PIP maps will only display on the homepage with PIP mode instead of full-screen mode. 12 • Casting different contents to HDMI monitor• Enable split-screen mode Preview Preview How to How to Preview USB cable In video-playback app Open the notification bar by twice swiping down from the top, next tap [Cast to HDMI] icon to start casting. Tap this icon again will disable casting. Open any app supporting split-screen mode Press and hold home button Select another app. Press and hold the home button again to exit split mode. HDMI cable AI box 13 • Setting nav bar to the right side• Software version Go to Settings > CAR > Driving settings > Right Rudder, enable.Go to Settings > About machine > Build number How to center console monitor headrest monitor 14 Format micro SD card into FAT32 Insert the micro SD card into the AI box then power on. Tick [Wipe data and format flash], next tap install. The blue light flashes rapidly while updating. After the update is finished, the system will restart. Delete the update. zip file or remove the micro SD card. Copy update.zip to the root folder of micro SD card update.zip FAT32 1345 2 Root folder update.zip Firmware update Google, Google Play, Android, Android Auto, are trademarks of Google Inc., registered in the U.S. and other countries.Apple, iPhone, iPad, and CarPlay are trademarks of Apple Inc., registered in the U.S. and other countries.We are not affiliated with Google Inc. or Apple Inc. All other product and service names mentioned are the trademarks of their respective companies. FCC Caution:Any changes or modifications not expressly approved by the party responsible for compliance could voidthe user's authority to operate the equipment.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept a…

Text truncated - open the document above for the full version.

MAYTON Add: 2F, 32, Bupyeong-daero 313beon-gil, Bupyeong-gu, incheon, Republic of Korea, Incheon, South Korea Tel: 13926598677 Fax: 13926598677 F ederal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA D ate: 08-24-2023 FCC ID: 2BAG8-MAYTONAP3 R ef. #1: Attestation Statements Part 2.911(d)(5)(i) Filing M AYTON certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. R ef. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing M AYTON certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates)as an entity producing “covered” equipment. A pplicant: MAYTON Address: 2F, 32, Bupyeong-daero 313beon-gil, Bupyeong-gu, incheon, Republic of Korea, Incheon, South Korea Contact Person: Wang yicheng Tel.: 13926598677 Email: [email protected] S incerely, S ignature:

U.S. AGENT LETTER OF ATTESTATION Date: 2023-08-23 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7)Filing FCC ID: 2BAG8-MAYTONAP3 MAYTON certifies that, as of the date of the filing of the application,USA MEIHUA TRADING INC is our designated U.S. agent for service of process for the above referenced FCC ID. MAYTON accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. USA MEIHUA TRADING INC accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: USA MEIHUA TRADING INC Address:5379 Pine Valley Ct Boulder CO 80301 United States FRN:0033406166 Tel.: (312) 363-9424 Email:[email protected] Signed by (printed name): Harley Quinn Signature: Applicant: MAYTON Address:2F, 32, Bupyeong-daero 313beon-gil, Bupyeong-gu, incheon, Republic of Korea Incheon, South Korea FRN: 0033495136 Tel: 13926598677 Email: [email protected] Signed by (printed name):Wang yicheng Signature:

Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City 客户名称 -1 -/ 21 customer name 项目名称 project name 供方料号Supplier material number XBY220378 日期date：2023年6月9日 深圳祥博一科技有限公司 Shenzhen Xiangboyi Technology Co. Ltd Specification Acknowledgement MAYTON-AP3 ShenZhen Bijiasuo Electronic Co..Ltd Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City 目录 -2 -/ 21 Catalogue 一. 测试系统及设备Test System and Equipment ........ - 4 - 二. 产品细节描述 Product Description ........................ - 5 - 三. 设备描述 Device Description ................................. - 7 - 四. 匹配电路 Matching Circuits ................................. - 8 - 五. 测试数据Active Test Tata ...................................... - 9 - 六. 工程图 EngineeringDrawing ................................ - 22 - Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -3 -/ 21 一. 测试系统及设备Te s t System and Equipment 测试项目Test item 设备equipment 1：S参数S parameter 网络分析仪Network analyzer: A338/A333 HP8753D 2：有源测试 Active test 1. TRP 2. TIS 综合测试仪Comprehensive tester: Agilent 8960/ CMW500 3：无源测试 Passive test 1. 效率efficiency 2. 增益gain 1. 暗室darkroom： 5x3x3 m (ETS-3D) 2. 网络分析仪Network analyzer：HP 8753D Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -4 -/ 21 二. 产品细节描述 Product Description 技术要求 Technical requirements 技术指标 Technical index 备注remarks 工作频段 Band LTE:B1/B3/B5/B7/B8/B18/B19 /B20/B26/B28/B38/B40/B41 /B71 WIFI/BT 频率范围 Range Of Frequency 620-960Mhz;1710-2690Mhz 2400-2500Mhz;5150-5850Mhz 驻波比 VSWR 620-960Mhz<3.0 1710-2690Mhz<3.0 2400-2500Mhz<3.0 5150-5850Mhz<3.0 中心频率 Center Frequency Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City 输出阻抗 -5 -/ 21 Impendance 50Ω 极化方式 Polarization 线极化 Linear polarization 工作温度 operating temperature -20°C / +55°C 存储温度 storage temperature -25°C / +65°C 盐雾 Salt Fog 24小时（24小时干湿交替） 24h(24h alterning wet & dry) 无铅认证 RoHS Compliant 是 yes Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -6 -/ 21 三. 设备描述 Device Description EUT Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -7 -/ 21 四. 匹配电路 Matching Circuits 匹配电路matching circuit Element Value Vender E1(0201) NA E2(0201) 0Ω E3(0201) NA E4(0201) 0Ω 天线匹配没有做改动The antenna match was not changed 。 Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -8 -/ 21 五. 有源测试数据Active Test Data dBm dBm dBm dBm dBm dBm dBm dBm dBm dBm Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -9 -/ 21 LTE主天线无源效率，增益 LTE main antenna with passive efficiency, gain dBm dBm dBm dBm dBm dBm Model:MAYTON-AP3-LTE-ANT Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -10 -/ 21 Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -11 -/ 21 LTE主天线方向图 main antenna Model:MAYTON-AP3-LTE-ANT Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -12-/ 21 Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -13 -/ 21 FJ天线无源效率，增益 FJ antenna with passive efficiency, gain Model:MAYTON-AP3-FJ-ANT Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -14 -/ 21 FJ天线方向图 FJ antenna pattern Model:MAYTON-AP3-FJ-ANT Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -15 -/ 21 WIFI天线无源效率，增益 WIFI antenna has passive efficiency, ga Model:MAYTON-AP3-WIFI-ANT Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -16 -/ 21 WIFI天线方向图 WIFI antenna orientation diagram Model:MAYTON-AP3-WIFI-ANT Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -17 -/ 21 Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -18 -/ 21 Shenzhen Xiangboyi Technology Co. Ltd Te l：0755-29369912 Fax：0755-61624200 Address: 5F, Building B, Huazhi Chuanggu, No.7 Yuhua Street, 138 Industrial Zone, Tangxia Town, Dongguan City -1 9 -/ 21 BT天线无源效率，增益 BT antenna with passive efficiency, gain BT天线方向图 BT antenna pattern Model:MAYTON-AP3-BT-ANT Shenzhen Xiangboyi …

Text truncated - open the document above for the full version.

MAYTON Add: 2F, 32, Bupyeong-daero 313beon-gil, Bupyeong-gu, incheon, Republic of Korea, Incheon, South Korea Tel: 13926598677 Fax: 13926598677 Attestation Letter Date: 2023-08-24 To: FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: Our product AutoPro Dual, model: MAYTON-AP3, MAYTONAP3.5, FCC ID: 2BAG8-MAYTONAP3, for marketing purpose, this product only supports BDR,EDR,BLE(BLE 1M&BLE 2M), 2.4G WIFI(2412~2462MHz), 5G WIFI(5150~5250 MHz, 5250~5350 MHz, 5470~5725 MHz, 5725~5850 MHz), WCDMA Band 2/4/5, LTE Band 2/4/5/17/25/41/66/71. The other functions, bands and modes were disabled to use by manufacturer with the software, the end user has no capability to activate it. Sincerely, Printed Name: Wang yicheng Title: Manager

MAYTON Add:2F, 32, Bupyeong-daero 313beon-gil, Bupyeong-gu, incheon, Republic of Korea, Incheon, South Korea Tel: 13926598677 Fax: 13926598677 Declaration of Frequency Stability To: FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: We, MAYTON ensure that the product (FCC ID: 2BAG8-MAYTONAP3) meets e-CFR Title 47 section 15.407(g) and KDB 789033 D02v02r01 frequency stability such that the emissions are maintained within the band of operation under all conditions of normal operation as specified in the user's manual. Sincerely, Printed Name: Wang yicheng Title: Manager Date: 2023-08-24

MAYTON Add: 2F, 32, Bupyeong-daero 313beon-gil, Bupyeong-gu, incheon, Republic of Korea, Incheon, South Korea Tel: 13926598677 Fax: 13926598677 Date ：2023-08-24 Product Model Number: MAYTON-AP3, MAYTONAP3.5 FCC ID：2BAG8-MAYTONAP3 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that ORGANIZATION. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by ORGANIZATION. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: 13926598677 On behalf of: MA YTON

MAYTON Add: 2F, 32, Bupyeong-daero 313beon-gil, Bupyeong-gu, incheon, Republic of Korea, Incheon, South Korea Tel: 13926598677 Fax: 13926598677 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 24, 2023 Subject; Request for Confidentiality FCC ID: 2BAG8-MAYTONAP3 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Wang yicheng Title: Manager

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-EXP Page 1 of 5 EUT EXTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-EXP Page 2 of 5 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-EXP Page 3 of 5 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-EXP Page 4 of 5 port China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-EXP Page 5 of 5 port

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-RF EXHIBITA-FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the time purchase (Labeling requirements per 2.295)

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 1 of 16 EUT INTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 2 of 16 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 3 of 16 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 4 of 16 GNSS Antenna China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 5 of 16 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 6 of 16 MAIN Antenna AUX Antenna China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 7 of 16 Wi-Fi Antenna China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 8 of 16 chip chip China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 9 of 16 chip chip China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 10 of 16 chip chip China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 11 of 16 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 12 of 16 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 13 of 16 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 14 of 16 chip China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 15 of 16 chip chip China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-INP Page 16 of 16 BT Antenna

RF EXPOSURE EVALUATION REPORT Applicant: MAYTON Address: 2F, 32, Bupyeong-daero 313beon-gil, Bupyeong-gu, incheon, Republic of Korea,Incheon, South Korea FCC ID: 2BAG8-MAYTONAP3 Product Name: AutoPro Dual Standard(s): 47 CFR §1.1307 The above device has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR230740691-00G Date Of Issue: 2023/9/14 Reviewed By: Calvin Chen Title: RF Engineer Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-00G Page 2 of 8 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-00G Page 3 of 8 CONTENTS DOCUMENT REVISION HISTORY .......................................................................................... 4 1. GENERAL INFORMATION .................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 5 2. RF EXPOSURE EVALUATION .............................................................................................. 6 2.1 Applicable Standard .......................................................................................................................................... 6 2.2 Measurement Result .......................................................................................................................................... 8 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-00G Page 4 of 8 DOCUMENT REVISION HISTORY Revision Number Report Number Description of Revision Date of Revision 1.0 CR230740691-00G Original Report 2023/9/14 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-00G Page 5 of 8 1. GENERAL INFORMATION 1.1 Product Description for Equipment under Test (EUT) EUT Type: Mayton AutoPro Dual EUT Model: MAYTON-AP3 Multiple Models: MAYTONAP3.5 Rated Input Voltage: DC 5V from USB Serial Number: 28K7-1 EUT Received Date: 2023/7/19 EUT Received Status: Good Note: The Multiple models are electrically identical with the test model. Please refer to the declaration letter for more detail, which was provided b y manufacturer. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-00G Page 6 of 8 2. RF EXPOSURE EVALUATION 2.1 Applicable Standard According to §1.1307(b)(3)(ii)(B) Simultaneous Transmission with both SAR-based and MPE-Based Test Exemptions This case is described in detail in § 1.1307(b)(3)(ii)(B) and covers the situations where both SAR-based and MPE-based exemption may be considered for test exemption in fixed, mobile, or portable device exposure conditions. For these cases, a device with multiple RF sources transmitting simultaneously will be considered an RF exempt device if the condition of Formula (1) is satisfied. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-00G Page 7 of 8 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-00G Page 8 of 8 2.2 Measurement Result Radio Frequency (MHz) Distance (mm) P th (mW) Maximum Conducted Power including Tune-up Tolerance (dBm) Antenna Gain (dBi) The Greater of Conducted Power or ERP dBm mW BDR/EDR 2402-2480 200 3060 5 -1.68 5 3.16 BLE 2402-2480 200 3060 1 -1.68 1 1.26 2.4G WLAN 2412-2462 200 3060 22 -0.85 22 158.49 5.2G WLAN 5180-5230 200 3060 14 1.85 14 25.12 5.3G WLAN 5260-5320 200 3060 14 1.85 14 25.12 5.6G WLAN 5500-5720 200 3060 14 1.85 14 25.12 5.8G WLAN 5745-5825 200 3060 15 1.85 15 31.62 WCDMA B2 1850-1910 200 3060 25 1.31 25 316.23 WCDMA B4 1710-1755 200 3060 25 -0.42 25 316.23 WCDMA B5 824-849 200 1681 25.5 -2.89 25.5 354.81 LTE B2 1850-1910 200 3060 24.5 1.31 24.5 281.84 LTE B4 1710-1755 200 3060 23 -0.42 23 199.53 LTE B5 824-849 200 1681 25.5 -2.89 25.5 354.81 LTE B17 704-716 200 1436 26.5 -1.36 26.5 446.68 LTE B25 1850-1915 200 3060 24 1.31 24 251.19 LTE B41 2496-2690 200 3060 20.5 -0.95 20.5 112.20 LTE B66 1710-1780 200 3060 23.5 -0.42 24 251.19 LTE B71 663-698 200 1353 26.5 -1.38 26.5 446.68 Note: The WWAN, WiFi and Bluetooth can transmit simultaneously. =P WWAN / P th + P WiFi / P th + P Bluetooth / P th = 446.68/1353 + 158.49/3060 + 3.16/3060 =0.383 < 1.0 Result: The device meet FCC MPE at 20 cm distance. ===== END OF REPORT =====

TEST REPORT Applicant: MAYTON Address: 2F, 32, Bupyeong-daero 313beon-gil, Bupyeong-gu, incheon, Republic of Korea,Incheon, South Korea FCC ID: 2BAG8-MAYTONAP3 Product Name: AutoPro Dual Standard(s): 47 CFR Part 2, 47 CFR Part 22, Subpart H 47 CFR Part 24, Subpart E 47 CFR Part 27 ANSI C63.26-2015 KDB 971168 D01 Power Meas License Digital Systems v03r01 The above device has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR230740691-00E Date Of Issue: 2023/12/27 Reviewed By: Calvin Chen Title: RF Engineer Approved By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-00E Page 2 of 240 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740691-00E Page 3 of 240 CONTENTS DOCUMENT REVISION HISTORY .......................................................................................... 4 1. GENERAL INFORMATION .................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 5 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 7 1.2.1 EUT Operation Condition: ............................................................................................................................. 7 1.2.2 Support Equipment List and Details ............................................................................................................ 11 1.2.3 Support Cable List and Details .........................................…

Text truncated - open the document above for the full version.
