Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
VALEO RESERVEDFebruary 2024 | Manual How to run the sensor in normal operation 15.02.2024 VALEO RESERVEDFebruary 2024 | 2 Introduction This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s) and complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation of the device Changes or modifications made to this equipment not expressly approved by Valeo North America Inc. may void the FCC authorization to operate this equipment This equipment complies with FCC and ISED radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. VALEO RESERVEDFebruary 2024 | 3 Setup CPD002 product and operational description Connect Power-supply 14V DC USB - Connect to PC PCAN Can interface between CPD002 and computer DUT CPD002 Wire harness CAN + Vbat VALEO RESERVEDFebruary 2024 | 4 Get PCAN running CPD002 product and operational description Install PCAN driver ●Download and install the latest version of the PCAN driver from Peak website: https://www.peak-system.com/quick/DrvSetup VALEO RESERVEDFebruary 2024 | 5 Start LPD_Testing_Tool CPD002 product and operational description Open LPD_Testing_Tool_V06.00_x64.exe ●Unzip “LPD_Testing_Tool_V08.5.1.zip” ●Connect the DUT via Peak-CAN-interface with the computer ●Open exe VALEO RESERVEDFebruary 2024 | 6 Sensing activation CPD Sensor product and operational description Description ●Load settings as shown in the left picture ●Press connect (right picture) VALEO RESERVEDFebruary 2024 | 7 Sensing activation CPD Sensor product and operational description Description ●Switch to the LPD Test tab on the left and press “Standalone Test” ●Press “play” VALEO RESERVEDFebruary 2024 | 8 Sensing activation CPD Sensor product and operational description Description A pointcloud will be displayed, showing the target position and the confidence ratio for life presence detection on the left Example: Baby in the region of the left seat Example: An empty vehicle, showing no pointcloud VALEO RESERVEDFebruary 2024 |
APPLICANT Valeo North America 150 Stephenson Highway 48083, Troy, Ml, USA to Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA June 10, 2024 Attestation Statement according to 2.911(d)(7) FCC ID: 2BAHD-EC31105 TO WHOM IT MAY CONCERN: Valeo North America Inc., with FCC Registration Number (FRN) 0033496571 has appointed The Corporation Trust Company, 40600 Ann Arbor Road E., Suite 201, Plymouth, Ml 48170- 4675, USA, to act as U.S. agent for service of process. Valeo North America Inc. with FCC Registration Number (FRN) 0033496571 hereby acknowledges the obligation of the U.S. agent for service of process. Further Valeo North America Inc. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Sincerely {signature & company stamp) Valeo North America Inc. 150 Stephenson Highway 48083, Troy, Ml, USA Dirk Schulte Mobile: +1248 217 7975 [email protected] (signature & company stamp) CT Corporation System 28 Liberty Street, New York, NY 10 005 Denise Bell Mobile: +1 (404) 965 3814 CTSOPRecipient@woltersk luwer.com
Document Version 1.1 2020-10-30 LONG-TERM CONFIDENTIALITY REQUEST for Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 TO WHOM IT M AY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request Long-Term Confidentiality for the following product: For the product stated above, we request Long-Term Confidentiality for exhibits which contain Block Diagram, Operational Description, Parts List/Tune Up Info, Schematics, SDR Software/Security Info. The above exhibits contain ou r trade secrets and proprietary information that could be of benefit to o ur competitors. This information will not be publicly available. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Company Name: Phone: Company Address: Fax: E-mail: Contact Name: Signature: Signature Date: Check your GC here. Click Grantee Search. FCC I D: Grantee Code Equipment Product Code
Annex A101 - Photographs No.1-7260/23-01-02_TR1-A101-R01 May 13, 2024 DescriptionExternal photographs of EUT This document is electronically signed and valid without handwritten signature. Public keys for verification of the electronic signatures can be requested at the testing laboratory. Authorized Frank Heussner Lab Manager Radio Labs cetecom advanced GmbH UntertĂĽrkheimer Str. 6-10, 66117 SaarbrĂĽcken Document No. 1-7260/23-01-02_TR1-A101-R01 Release 1 - Page 1 of 5 Photo 1 Photo 2 cetecom advanced GmbH UntertĂĽrkheimer Str. 6-10, 66117 SaarbrĂĽcken Document No. 1-7260/23-01-02_TR1-A101-R01 Release 1 - Page 2 of 5 Photo 3 Photo 4 cetecom advanced GmbH UntertĂĽrkheimer Str. 6-10, 66117 SaarbrĂĽcken Document No. 1-7260/23-01-02_TR1-A101-R01 Release 1 - Page 3 of 5 Photo 5 Photo 6 cetecom advanced GmbH UntertĂĽrkheimer Str. 6-10, 66117 SaarbrĂĽcken Document No. 1-7260/23-01-02_TR1-A101-R01 Release 1 - Page 4 of 5 Photo 7 Photo 8 - END OF DOCUMENT - cetecom advanced GmbH UntertĂĽrkheimer Str. 6-10, 66117 SaarbrĂĽcken Document No. 1-7260/23-01-02_TR1-A101-R01 Release 1 - Page 5 of 5
© cetecom advanced GmbH Page 1 of 13 TEST REPORT Test report no.: 1-7260-23-01-21_TR1-R01 Testing laboratory Applicant cetecom advanced GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: https://cetecomadvanced.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2018-03) by the Deutsche Akkreditierungsstelle GmbH (DAkkS). The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12047-01-00. ISED Testing Laboratory Recognized Listing Number: DE0001 FCC designation number: DE0002 Valeo Klimasysteme GmbH Werner-von-Siemens-Strasse 6 96476 Bad Rodach/GERMANY Contact: Christian Eibl e-mail: [email protected] Phone: +49 (0) 176 3000 1082 Manufacturer Valeo Klimasysteme GmbH Werner-von-Siemens-Strasse 6 96476 Bad Rodach/GERMANY Test Item Kind of test item: interior radar Model name: CPD002 FCC ID: 2BAHD-EC31105 Frequency: 57-64 GHz Technology tested: Radar This test report is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report authorized: Test performed: Alexander Hnatovskiy Eric Tuettmann Lab Manager Testing Manager Radio Labs Radio Labs Test report no.: 1-7260-23-01-21_TR1-R01 © cetecom advanced GmbH Page 2 of 13 1 Table of contents 1 Table of contents ............................................................................................................................................. 2 2 General Information ......................................................................................................................................... 3 2.1 Notes and Disclaimer ............................................................................................................................ 3 2.2 References ............................................................................................................................................ 3 2.3 Structure of this Document ................................................................................................................... 3 3 General RF Exposure Test Exemptions ............................................................................................................ 4 3.1 1 mW Test Exemption ........................................................................................................................... 5 3.2 MPE-Based Test Exemption ................................................................................................................. 5 3.3 SAR-Based Test Exemption .................................................................................................................. 5 3.4 Simultaneous Transmission ............................................................................................................... 6 4 1 mW Test Exemption ...................................................................................................................................... 7 4.1 Detailed Description .............................................................................................................................. 7 4.2 Results ................................................................................................................................................... 7 5 MPE-Based Test Exemption ............................................................................................................................ 8 5.1 Detailed Description .............................................................................................................................. 8 5.2 Results ................................................................................................................................................... 9 6 SAR-Based Test Exemption ........................................................................................................................... 10 6.1 Detailed Description ............................................................................................................................ 10 6.2 Results ................................................................................................................................................. 11 7 Simultaneous Transmission .......................................................................................................................... 12 7.1 Detailed Description ............................................................................................................................ 12 7.2 Result................................................................................................................................................... 12 8 Conclusion ...................................................................................................................................................... 13 Test report no.: 1-7260-23-01-21_TR1-R01 © cetecom advanced GmbH Page 3 of 13 2 General Information 2.1 Notes and Disclaimer The test results of this test report relate exclusively to the test item specified in this test report. cetecom advanced GmbH does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of cetecom advanced GmbH. The testing service provided by cetecom advanced GmbH has been rendered under the current "General Terms and Conditions for cetecom advanced GmbH". cetecom advanced GmbH will not be liable for any loss or damage resulting from false, inaccurate, inapprop…
Text truncated - open the document above for the full version.
Page 1 of 2 Version 0.5 © CTC advanced GmbH Declaration Antenna gain declaration We VALEO Klimasysteme GmbH hereby declare under our sole responsibility, that the indicated antenna gain of 6.67 dBi of the product CPD002 (202-JCE096) corresponds to the antenna gain activated / operated during the conformity measurement scenario, including a duty cycle of 5.27%. The indicated antenna gain results of the simulation: Page 2 of 2 Version 0.5 © CTC advanced GmbH The simulation was performed by: Dr.-Ing. Frank Sickinger Valeo Schalter und Sensoren GmbH Laiernstrasse 12 74321 Bietigheim-Bissingen ------------------------------- Signature Company VALEO Klimasysteme GmbH Address Werner-von-Siemens-Strasse 6, 96476 BAD RODACH, GERMANY Name Christian Eibl Phone +49 (0) 176 3000 1082 Email [email protected] Datum August 2, 2024
TEST REPORT Test report no.: 1-7260-23-01-18_TR1-R01 Testing laboratory Applicant cetecom advanced GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: https://www.cetecomadvanced.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2018-03) by the Deutsche Akkreditierungsstelle GmbH (DAkkS). The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12047-01-00. ISED Testing Laboratory Recognized Listing Number: DE0001 FCC designation number: DE0002 VALEO North America 150 Stephenson Highway Troy, MI 48083 / USA Contact: Dr.-Ing. Dirk SCHULTE e-mail: [email protected] Phone: +1 248 619-8566 Manufacturer Valeo Klimasysteme GmbH Werner-von-Siemens-Strasse 6 96476 Bad Rodach / GERMANY Test standard/s FCC - Title 47 CFR Part 15 FCC - Title 47 of the Code of Federal Regulations; Chapter I; Part 15 - Radio frequency devices For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: interior radar Model name: CPD002 FCC ID: 2BAHD-EC31105 Frequency: 57 GHz to 64 GHz Technology tested: FMCW Antenna: Integrated patch antenna Power supply: 9 V to 18 V DC by external power supply (battery) Temperature range: -40°C to +90°C This test report is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report authorized: Test performed: Thomas Vogler Frank Heussner Lab Manager Lab Manager Radio Labs Radio Labs Test report no.: 1-7260-23-01-18_TR1-R01 © cetecom advanced GmbH Page 2 of 49 1 Table of contents 1 Table of contents .................................................................................................................................... 2 2 General information ................................................................................................................................ 3 2.1 Notes and disclaimer .................................................................................................................... 3 2.2 Application details ........................................................................................................................ 3 2.3 Test laboratories sub-contracted .................................................................................................. 3 3 Test standard/s, references and accreditations ....................................................................................... 4 4 Reporting statements of conformity – decision rule ................................................................................ 5 5 Test environment.................................................................................................................................... 6 6 Test item ................................................................................................................................................ 6 6.1 General description ...................................................................................................................... 6 6.2 Additional information .................................................................................................................. 7 7 Description of the test setup ................................................................................................................... 8 7.1 Shielded semi anechoic chamber .................................................................................................. 9 7.2 Shielded fully anechoic chamber ................................................................................................ 11 7.3 Radiated measurements > 18 GHz .............................................................................................. 13 7.4 Radiated measurements > 50/85 GHz ......................................................................................... 13 8 Sequence of testing .............................................................................................................................. 15 8.1 Sequence of testing radiated spurious 9 kHz to 30 MHz .............................................................. 15 8.2 Sequence of testing radiated spurious 30 MHz to 1 GHz ............................................................. 16 8.3 Sequence of testing radiated spurious 1 GHz to 18 GHz .............................................................. 17 8.4 Sequence of testing radiated spurious above 18 GHz .................................................................. 18 8.5 Sequence of testing radiated spurious above 50 GHz with external mixers .................................. 19 9 Measurement uncertainty ..................................................................................................................... 20 10 Summary of measurement results ..................................................................................................... 21 11 Additional comments ........................................................................................................................ 21 12 Basic information of the DUT & selection of applicable rule parts ....................................................... 22 13 Measurement results ........................................................................................................................ 27 13.1 Occupied bandwidth & emission bandwidth & Frequency stability ............................................ 27 13.2 Radiated power (EIRP) ............................................................................................................ 30 13.3 Peak transmitter conducted output power ............................................................................... 3…
Text truncated - open the document above for the full version.
Occupied bandwidth & Frequency stability No.1-7260/23-01-18_TR1-A201-R1 May 17, 2024 Test Standard(s)Systems FCC.ISED - NI This document is electronically signed and valid without handwritten signature. Public keys for verification of the electronic signatures can be requested at the testing laboratory. Authorized Frank Heussner Lab Manager Radio Labs cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-7260/23-01-18_TR1-A201-R1 Release 1 - Page 1 of 13 Systems FCC.ISED # Frequency stability over temperature & voltage ~ TID045_FCC,ISED_FrequencyStability 57000-64000 MHz References TC start05.04.2024 08:51:01 Ambit temp [°C] | humidity [rel%] not enabled | not enabled System version5.0.3.7 Standard | Version Systems FCC.ISED | NI Method DescriptionSystems FCC ISED Freq stability over temp/volt Information Equipment Signal analyzer,Rohde&Schwarz,FSW-50,1331.5003K50/101332,5.30SP1 Power supply,Agilent Technologies,N5767A,US14J1569P,B.00.06,REV:F Climatic box,CTS T40/50,,NI Test Parameter EUT port Temperaturevar Voltagevar Auto control enabled power supply | Climatic Box Yes | Yes Full path type Full path name Switch bits Test for temperature[°C]: 20 | voltage [V]: 14 READ SA SETTINGS: RefLevel [dBm] | RefLevelOffset [dB] | InpAtt [dB]20.00 | 39 | 0 Start [MHz] | Stop [MHz]59000.000 | 65000.000 RBW [MHz] | VBW [MHz]50.000000 | 80.000000 Detector | TraceModePOS | MAXH Sweep: time [ms] | count | points per Section | type330000 | 1 | 1001 | SWE cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-7260/23-01-18_TR1-A201-R1 Release 1 - Page 2 of 13 59000.0059500.0060000.0060500.0061000.0061500.0062000.0062500.0063000.0063500.0064000.0064500.0065000.00 MHz Frequency 20.0 15.0 10.0 5.0 0.0 -5.0 -10.0 -15.0 -20.0 -25.0 -30.0 dBm Magnitude BW RESULT DESCRIPTIONLOWER LIMITUPPER LIMITMEASUREDUNITVERDICT Bandwidth 99%------3526.906MHzINFO T1 99%57000---59991.3711MHzPASS T2 99%---6400063518.2771MHzPASS RESULT DESCRIPTIONLOWER LIMITUPPER LIMITMEASUREDUNITVERDICT Bandwidth 20dB------3660MHzINFO Reference freq.------62042MHzINFO T1 20dB57000---59930.0000MHzPASS T2 20dB---6400063590.0000MHzPASS Test for temperature[°C]: 20 | voltage [V]: 11.9 READ SA SETTINGS: RefLevel [dBm] | RefLevelOffset [dB] | InpAtt [dB]20.00 | 39 | 0 Start [MHz] | Stop [MHz]59000.000 | 65000.000 RBW [MHz] | VBW [MHz]50.000000 | 80.000000 Detector | TraceModePOS | MAXH Sweep: time [ms] | count | points per Section | type330000 | 1 | 1001 | SWE cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-7260/23-01-18_TR1-A201-R1 Release 1 - Page 3 of 13 59000.0059500.0060000.0060500.0061000.0061500.0062000.0062500.0063000.0063500.0064000.0064500.0065000.00 MHz Frequency 20.0 15.0 10.0 5.0 0.0 -5.0 -10.0 -15.0 -20.0 -25.0 -30.0 dBm Magnitude BW RESULT DESCRIPTIONLOWER LIMITUPPER LIMITMEASUREDUNITVERDICT Bandwidth 99%------3525.906MHzINFO T1 99%57000---59991.4440MHzPASS T2 99%---6400063517.3499MHzPASS RESULT DESCRIPTIONLOWER LIMITUPPER LIMITMEASUREDUNITVERDICT Bandwidth 20dB------3666MHzINFO Reference freq.------62048MHzINFO T1 20dB57000---59930.0000MHzPASS T2 20dB---6400063596.0000MHzPASS Test for temperature[°C]: 20 | voltage [V]: 16.1 READ SA SETTINGS: RefLevel [dBm] | RefLevelOffset [dB] | InpAtt [dB]20.00 | 39 | 0 Start [MHz] | Stop [MHz]59000.000 | 65000.000 RBW [MHz] | VBW [MHz]50.000000 | 80.000000 Detector | TraceModePOS | MAXH Sweep: time [ms] | count | points per Section | type330000 | 1 | 1001 | SWE cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-7260/23-01-18_TR1-A201-R1 Release 1 - Page 4 of 13 59000.0059500.0060000.0060500.0061000.0061500.0062000.0062500.0063000.0063500.0064000.0064500.0065000.00 MHz Frequency 20.0 15.0 10.0 5.0 0.0 -5.0 -10.0 -15.0 -20.0 -25.0 -30.0 dBm Magnitude BW RESULT DESCRIPTIONLOWER LIMITUPPER LIMITMEASUREDUNITVERDICT Bandwidth 99%------3524.396MHzINFO T1 99%57000---59994.1074MHzPASS T2 99%---6400063518.5031MHzPASS RESULT DESCRIPTIONLOWER LIMITUPPER LIMITMEASUREDUNITVERDICT Bandwidth 20dB------3666MHzINFO Reference freq.------62042MHzINFO T1 20dB57000---59930.0000MHzPASS T2 20dB---6400063596.0000MHzPASS Test for temperature[°C]: -20 | voltage [V]: 14 READ SA SETTINGS: RefLevel [dBm] | RefLevelOffset [dB] | InpAtt [dB]20.00 | 39 | 0 Start [MHz] | Stop [MHz]59000.000 | 65000.000 RBW [MHz] | VBW [MHz]50.000000 | 80.000000 Detector | TraceModePOS | MAXH Sweep: time [ms] | count | points per Section | type330000 | 1 | 1001 | SWE cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-7260/23-01-18_TR1-A201-R1 Release 1 - Page 5 of 13 59000.0059500.0060000.0060500.0061000.0061500.0062000.0062500.0063000.0063500.0064000.0064500.0065000.00 MHz Frequency 20.0 15.0 10.0 5.0 0.0 -5.0 -10.0 -15.0 -20.0 -25.0 -30.0 dBm Magnitude BW RESULT DESCRIPTIONLOWER LIMITUPPER LIMITMEASUREDUNITVERDICT Bandwidth 99%------3521.181MHzINFO T1 99%57000---59998.0944MHzPASS T2 99%---6400063519.2749MHzPASS RESULT DESCRIPTIONLOWER LIMITUPPER LIMITMEASUREDUNITVERDICT Bandwidth 20dB------3660MHzINFO Reference freq.------62042MHzINFO T1 20dB57000---59936.0000MHzPASS T2 20dB---6400063596.0000MHzPASS Test for temperature[°C]: -10 | voltage [V]: 14 READ SA SETTINGS: RefLevel [dBm] | RefLevelOffset [dB] | InpAtt [dB]20.00 | 39 | 0 Start [MHz] | Stop [MHz]59000.000 | 65000.000 RBW [MHz] | VBW [MHz]50.000000 | 80.000000 Detector | TraceModePOS | MAXH Sweep: time [ms] | count | points per Section | type330000 | 1 | 1001 | SWE cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-7260/23-01-18_TR1-A201-R1 Release 1 - Page 6 of 13 59000.0059500.0060000.0060500.0061000.0061500.0062000.0062500.0063000.0063500.0064000.0064500.0065000.00 MHz Frequency 20.0 15.0 10.0 5.0 0.0 -5.0 -10.0 -15.0 -20.0 -25.0 -30.0 dBm Magnitude BW RESULT DESCRIPTIONLOWER LIMITUPPER LIMITMEASUREDUNITVERDICT Bandwidth 99%------3523.002MHzINFO T1 99%57000---59993.7834MHzPASS T2 99%---6400…
Text truncated - open the document above for the full version.
Annex A103 - Photographs FCC No.1-7260/23-01-18_TR1-A103-R01 May 17, 2024 DescriptionTest set-up photographs This document is electronically signed and valid without handwritten signature. Public keys for verification of the electronic signatures can be requested at the testing laboratory. Authorized Frank Heussner Lab Manager Radio Labs cetecom advanced GmbH UntertĂĽrkheimer Str. 6-10, 66117 SaarbrĂĽcken Document No. 1-7260/23-01-18_TR1-A103-R01 Release 1 - Page 1 of 6 Photo 1 Photo 2 cetecom advanced GmbH UntertĂĽrkheimer Str. 6-10, 66117 SaarbrĂĽcken Document No. 1-7260/23-01-18_TR1-A103-R01 Release 1 - Page 2 of 6 Photo 3 Photo 4 cetecom advanced GmbH UntertĂĽrkheimer Str. 6-10, 66117 SaarbrĂĽcken Document No. 1-7260/23-01-18_TR1-A103-R01 Release 1 - Page 3 of 6 Photo 5 Photo 6 cetecom advanced GmbH UntertĂĽrkheimer Str. 6-10, 66117 SaarbrĂĽcken Document No. 1-7260/23-01-18_TR1-A103-R01 Release 1 - Page 4 of 6 Photo 7 Photo 8 cetecom advanced GmbH UntertĂĽrkheimer Str. 6-10, 66117 SaarbrĂĽcken Document No. 1-7260/23-01-18_TR1-A103-R01 Release 1 - Page 5 of 6 Photo 9 Photo 10 - END OF DOCUMENT - cetecom advanced GmbH UntertĂĽrkheimer Str. 6-10, 66117 SaarbrĂĽcken Document No. 1-7260/23-01-18_TR1-A103-R01 Release 1 - Page 6 of 6
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15.255 | 57.00 GHz - 64.00 GHz | 17.78 mW |
