2BAIX-DED500Electronic drum

Rev 1/26/2023 (NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: March‐13‐2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BAIX‐DED500 NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Li Li Rev 1/26/2023 (NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: March‐13‐2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BAIX‐DED500 NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Li Li

NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. Room 602, Main Building, No.531 Ninghe Road, Qiuai Town,Yinzhou District Ningbo, zhejiang, 315101 China Date: 2023.3.13 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BAIX-DED500 US Agent – Attestation Statement / Part 2.911(d)(7) NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. certifies, that as of February 28, 2023, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2BAIX-DED500 NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. for FCC ID: 2BAIX-DED500 Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. Designated Agent: FCC US Agent, LLC Company Representative: Li li Designated Agent Representative: Tim Payne Signature: Signature:

( NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD.) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2BAIX-DED500 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram .pdf, Schematics .pdf , Operation Description .pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Short-term confidentiality requested: 180 days Exhibit Type File Name Internal Photos, Test Setup Photos, Manual, External Photos Internal Photos .pdf, Test Setup Photos .pdf, User Manual .pdf, External Photos.pdf Sincerely, Li li/head engineer NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD.

Difference Statement Model：DED-500, DED-500P, ACE-500, ACE-510, ACE-530 The PCB schematic diagram, PCB Layout and appearance are the same for all models. The only difference is the way the products are named. March 30, 2023 Name: Lili Title: head engineer NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD.

NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: March 13, 2023 SUBJECT: FCC Application for FCC ID: 2BAIX-DED500 To Whom It May Concern: We, the undersigned, hereby authorize Tony Wei at EMTEK(NINGBO) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK(NINGBO) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Lili / head engineer NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD.

NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. Date: 2023-03-13 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2BAIX-DED500 To Whom It May Concern: This letter is to ascertain that NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. EUT : Electronic drum Model Name : DED-500, DED-500P, ACE-500, ACE-510, ACE-530 We will apply for FCC SDOC. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature ： Client’s name / title ： Li li/head engineer Contact information / address: NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. /Room602, Main Building, No.531 Ninghe Road, Qiuai Town,

External photos: ---The End---

Label Location PEODUCT: Electronic drum Model：DED-500 FCC ID: 2BAIX-DED500

Internal photos: BT Antenna ---The End---

FCC ID: 2BAIX-DED500 Portable device According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz； Power and distance are rounded to the nearest mW and mm before calculation； The result is rounded to one decimal place for comparison； The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculate. Maximum measured transmitter power: Transmit Frequency (GHz) Mode Max Conducted Power (dBm) tune up maximum power(dBm) Result calculation 1-g SAR 2.402 GFSK -1.56 -1 0.25 3 2.441 GFSK -0.50 0 0.31 3 2.480 GFSK 0.94 1 0.40 3 2.402 PI/4 DQPSK -2.99 -2 0.20 3 2.441 PI/4 DQPSK -1.65 -1 0.25 3 2.480 PI/4 DQPSK -0.33 0 0.31 3 2.402 8DPSK -2.65 -2 0.20 3 2.441 8DPSK -1.33 -1 0.25 3 2.480 8DPSK 0.21 0 0.31 3 Conclusion: For the max result : 0.31≤ 3.0 for 1-g SAR extremity SAR, No SAR is required.

ReportNo.:RFI-LAB-RF-202303-CC17 QP030-E41 Page1of9 TestingReport CustomerName:NINGBOKINLINELECTRONICTECHNOLOGY CO.,LTD. ProductName:Electronicdrum SampleModel:DED-500/DED-500P/ACE-500/ACE-510/ACE-530 ReferenceStandard:GB/T9410-2008;ANSI/IEEEStd149-1979 IssueDate:2023.4.4 Engineer:Date: Auditor:Date: Approver:Date: ReportNo.:RFI-LAB-RF-202303-CC17 QP030-E41 Page2of9 Version VersionNo.DateDescriptionFormulateApproval A02023.4.4Forthefirsttime,formulateJeacksonEason Contents 1.GeneralInformation.........................................................................................................................3 1.1Generalinformationoftestinginstitutions...........................................................................3 1.2Testingprinciple...................................................................................................................3 1.3Testequipment......................................................................................................................4 1.4Testenvironment...................................................................................................................4 1.5Statement..............................................................................................................................4 2.SampleInformation.........................................................................................................................5 2.1Clientinformation.................................................................................................................5 2.2DescriptionofEUT(S)..........................................................................................................5 2.3EUTappearance....................................................................................................................6 2.4EUTsetupphotooffreespaceOTAtesting.........................................................................6 3.TestResults......................................................................................................................................7 3.1Teststandard.........................................................................................................................7 3.2Testuncertainty.....................................................................................................................7 3.3Testdata................................................................................................................................7 3.3.1Typicalfreespaceefficiencyandgain......................................................................7 3.3.2Typicalfreespaceradiationpattern...........................................................................8 （Thefollowingisblank）................................................................................................................9 ReportNo.:RFI-LAB-RF-202303-CC17 QP030-E41 Page3of9 1.GeneralInformation 1.1Generalinformationoftestinginstitutions Name ShenzhenRFI-LABCommunicationTechnologyCo.,Ltd. Address 10/FA,LingyunBld,LiufangRd,BaoanDistrict,SZ Tel 13682621346 E-mail [email protected] Equipment AlltheequipmentusedinthereportisfixedinZoneB,WestSideof1/F,Building1, TingweiIndustrialPark,No.6LiufangRoad,Bao'anDistrict,Shenzhen 1.2Testingprinciple ReportNo.:RFI-LAB-RF-202303-CC17 QP030-E41 Page4of9 1.3Testequipment EquipmentModelNo.SerialNo.Manufacturer Calibration date Next calibration date OTATest System RayZone-5000 RFI-LAB-RF -D00 GTS2023.3.142025.3.13 Network Analyzer E5071C RFI-LAB-RF -D01 KEYSIGHT2022.5.132023.5.12 1.4Testenvironment Temperature 23.6°C Humidity 59%RH Pressure 100.13kPa 1.5Statement (1)Thetestresultsinthereportareonlyapplicabletothetestedsamplesandthetestedsamples workundertheenvironmentdescribedinthereport. (2)OnlyShenzhenRFI-LABCommunicationTechnologyCo.,Ltd.havetherighttomodifythe report,andthemodificationinformationshallbeannotatedintherevisionform. (3)Anyobjectiontothisreportshallberaisedwithin30daysafterformalconfirmationofthe report. (4)Thisreportisinvalidifthereisanyevidencethatthesampleinformationprovidedisfalsified. (5)Thereportisinvalidwithoutthesignatureoftheauditorandapprover. ReportNo.:RFI-LAB-RF-202303-CC17 QP030-E41 Page5of9 2.SampleInformation 2.1Clientinformation Manufacturer NINGBOKINLINELECTRONICTECHNOLOGYCO.,LTD. Address Room602,MainBuilding,No.531NingheRoad,QiuaiTown, YinzhouDistrict,NingboCity,ZhejiangProvince Contacts / Tel / E-mail / Manufacturer NINGBOKINLINELECTRONICTECHNOLOGYCO.,LTD. 2.2DescriptionofEUT(S) ProductName Electronicdrum SampleModel DED-500/DED-500P/ACE-500/ACE-510/ACE-530 AntennaSize / SerialNo. / AntennaType PCBAntenna TestItem Antennagain;Efficiency;Radiationpattern FrequencyRange 2400-2500MHz ReceivedDate 2023.3.13 TestDate 2023.4.3 Remark / Report No.: RFI-LAB-RF-202303-CC17 QP030-E41 Page 6 of 9 2.3EUT appearance 2.4EUT setup photo of free space OTA testing Planform Front v iew ReportNo.:RFI-LAB-RF-202303-CC17 QP030-E41 Page7of9 3.TestResults 3.1Teststandard NameParameterMethodStandardno. Mobile communication antenna Antennagain Genericspecification forantennasusedinthe mobilecommunications GB/T 9410-2008 Radiationpattern Antenna Radiationefficiency IEEEStandardTest ProceduresforAntennas ANSI/IEEEStd 149-1979 Gainanddirectivity 3.2Testuncertainty TheuncertaintywascalculatedonthebasisoftheGUMpublishedbyISO,usingthe inclusionfactorofK=2andthe95%confidenceleveltoexpresstheextended uncertainty. ItemUncertainty Antennagain±0.72dB Radiationefficiency±0.72dB 3.3 Testdata 3.3.1Typicalfreespaceefficiencyandgain Frequency/MHz 24002410242024302440245024602470248024902500 PeakGain/dBi 1.671.301.051.010.890.640.610.590.260.01-0.10 Efficiency/% 47.5344.3841.6641.1139.9237.9838.2538.3835.6733.6831.80 ReportNo.:RFI-LAB-RF-202303-CC17 QP030-E41 Page8of9 3.3.2Typicalfreespaceradiationpattern (1)X-ZPlane(unit:dBi): (2)Y-ZPlane(unit:dBi): ReportNo.:RFI-LAB-RF-202303-CC17 QP030-E41 Page9of9 (3)X-YPlane(unit:dBi): (4)TypicalFreeSpace3DRadiationPatternat2.4GHz…

Text truncated - open the document above for the full version.

Report No. EDG2302140053E00301R Page 1 of 62 Ver.1.0 TEST REPORT $二维码$ Product Name : Electronic drum Model Number : DED-500, DED-500P, ACE-500, ACE-510, ACE-530 FCC ID : 2BAIX-DED500 Prepared for : NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. Address : Room602, Main Building, No. 531 Ninghe Road, Qiuai Town, Yinzhou District, Ningbo City, Zhejiang Province Prepared by : EMTEK (DONGGUAN) CO., LTD. Address : -1&2F., Building 2, Zone A, Zhongda Marine Biotechnology Research and Development Base, No. 9, Xincheng Avenue, Songshanhu High-technology Industrial Development Zone, Dongguan, Guangdong, China Tel : +86-0769-22807078 Fax: +86-0769-22807079 Report Number : EDG2302140053E00301R Date(s) of Tests : February 14, 2023 to March 20, 2023 Date of issue : March 21, 2023 Report No. EDG2302140053E00301R Page 2 of 62 Ver.1.0 Table of Contents 1 TEST RESULT CERTIFICATION ............................................................................................................ 3 2 EUT TECHNICAL DESCRIPTION .......................................................................................................... 4 3 SUMMARY OF TEST RESULT ............................................................................................................... 5 4 TEST METHODOLOGY .......................................................................................................................... 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................................................... 6 4.2 MEASUREMENT EQUIPMENT USED .................................................................................................. 6 4.3 DESCRIPTION OF TEST MODES ........................................................................................................ 7 4.4 TEST SOFTWARE ................................................................................................................................ 7 5 FACILITIES AND ACCREDITATIONS ................................................................................................... 8 5.1 FACILITIES ............................................................................................................................................ 8 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ............................................................................. 8 6 TEST SYSTEM UNCERTAINTY ............................................................................................................. 9 7 SETUP OF EQUIPMENT UNDER TEST ............................................................................................... 10 7.1 RADIO FREQUENCY TEST SETUP 1 ................................................................................................ 10 7.2 RADIO FREQUENCY TEST SETUP 2 ................................................................................................ 10 7.3 CONDUCTED EMISSION TEST SETUP ............................................................................................ 11 7.4 SUPPORT EQUIPMENT ..................................................................................................................... 12 8 FREQUENCY HOPPING SYSTEM REQUIREMENTS ......................................................................... 13 8.1 STANDARD APPLICABLE .......................................................................................................................... 13 8.2 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ........................................................................ 13 8.3 EQUAL HOPPING FREQUENCY USE ......................................................................................................... 14 8.4 FREQUENCY HOPPING SYSTEM .............................................................................................................. 14 9 TEST REQUIREMENTS ........................................................................................................................ 15 9.1 20DB BANDWIDTH ............................................................................................................................. 15 9.2 CARRIER FREQUENCY SEPARATION ............................................................................................. 21 9.3 NUMBER OF HOPPING FREQUENCIES ........................................................................................... 27 9.4 AVERAGE TIME OF OCCUPANCY (DWELL TIME) ............................................................................ 29 9.5 MAXIMUM PEAK CONDUCTED OUTPUT POWER ........................................................................... 32 9.6 CONDUCTED SUPRIOUS EMISSION ............................................................................................... 38 9.7 RADIATED SPURIOUS EMISSION ..................................................................................................... 45 9.8 CONDUCTED EMISSION TEST ......................................................................................................... 58 9.9 ANTENNA APPLICATION ................................................................................................................... 61 Report No. EDG2302140053E00301R Page 3 of 62 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. Address : Room602, Main Building, No. 531 Ninghe Road, Qiuai Town, Yinzhou District, Ningbo City, Zhejiang Province Manufacturer : NINGBO KINLIN ELECTRONIC TECHNOLOGY CO., LTD. Address : Room602, Main Building, No. 531 Ninghe Road, Qiuai Town, Yinzhou District, Ningbo City, Zhejiang Province EUT : Electronic drum Model Name : DED-500, DED-500P, ACE-500, ACE-510, ACE-530 Trademark : NA Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(DONGGUAN) CO., LTD.The test data, data evaluation, test procedures, and equipment configurations shown in this report…

Text truncated - open the document above for the full version.

Report No. EDG2302140053E00301R Page 38 of 62 Ver.1.0 9.6 CONDUCTED SUPRIOUS EMISSION Applicable Standard According to FCC Part 15.247(d) and 558074 D01 15.247 Meas Guidance V05r02 Conformance Limit According to FCC Part 15.247(d): In any 100 kHz bandwidth outside the frequency band in which the spread spectrum intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted, provided the transmitter demonstrates compliance with the peak conducted power limits. Test Configuration Test according to clause 7.1 radio frequency test setup 1 Test Procedure The transmitter output (antenna port) was connected to the spectrum analyzer  Reference level measurement Establish a reference level by using the following procedure: Set instrument center frequency to DSS channel center frequency. Set Span = approximately 5 times the 20 dB bandwidth, centered on a hopping channel. Set the RBW = 100 kHz. Set the VBW ≥ 3 x RBW. Set Detector = peak. Set Sweep time = auto couple. Set Trace mode = max hold. Allow trace to fully stabilize. Use the peak marker function to determine the maximum Maximumconducetedlevel. Note that the channel found to contain the maximum conduceted level can be used to establish the reference level.  Band-edge Compliance of RF Conducted Emissions Use the following spectrum analyzer settings: Span = wide enough to capture the peak level of the emission operating on the channel closest to the band-edge, as well as any modulation products which fall outside of the authorized band of operation Set RBW  1% of the span=100kHzSet VBW  RBW Set Sweep = autoSetDetector function = peakSetTrace = max hold Allow the trace to stabilize. Set the marker on the emission at the bandedge, or on the highest modulation product outside of the band, if this level is greater than that at the bandedge. Enable the marker-delta function, then use the marker-to-peak function to move the marker to the peak of the in-band emission. The marker-delta value now displayed must comply with the limit specified in this Section. Now, using the same instrument settings, enable the hopping function of the EUT. Allow the trace to stabilize. Follow the same procedure listed above to determine if any spurious emissions caused by the hopping function also comply with the specified limit.  ConducetedSpurious RF Conducted Emission Use the following spectrum analyzer settings: Span = wide enough to capture the peak level of the in-band emission and all spurious emissions (e.g., harmonics) from the lowest frequency generated in the EUT up through the 10th harmonic.(30MHz to 25GHz).Set RBW = 100 kHzSetVBW RBW Set Sweep = autoSetDetector function = peakSetTrace = max hold Allow the trace to stabilize. Set the marker on the peak of an y spurious emission recorded. The level displayed must comply with the limit specified in this Section. Test Results Report No. EDG2302140053E00301R Page 39 of 62 Ver.1.0 Bluetooth (GFSK, pi/4-DQPSK,8DPSK) mode have been tested, and the worst result(GFSK)was report as below: Test Model Maximum Conduceted Level RBW=100kHz Channel 0: 2402MHz GFSK Test Model ConducetedSpurious RF Conducted Emission(30 MHz-25GHz) Channel 0: 2402MHz GFSK Report No. EDG2302140053E00301R Page 40 of 62 Ver.1.0 Test Model Band-edge Conducted Emissions Channel 0: 2402MHz GFSK Test Model Maximum Conduceted Level RBW=100kHz Channel 39: 2441MHz GFSK Report No. EDG2302140053E00301R Page 41 of 62 Ver.1.0 Test Model ConducetedSpurious RF Conducted Emission(30 MHz-25GHz) Channel 0: 2402MHz GFSK Test Model Maximum Conduceted Level RBW=100kHz Channel 78: 2480MHz GFSK Report No. EDG2302140053E00301R Page 42 of 62 Ver.1.0 Test Model ConducetedSpurious RF Conducted Emission(30 MHz-25 GHz) Channel 78: 2480MHz GFSK Test Model Band-edge Conducted Emissions Channel 78: 2480MHz GFSK Report No. EDG2302140053E00301R Page 43 of 62 Ver.1.0 Test Model Maximum Conduceted Level RBW=100kHz Hopping Mode GFSK Test Model ConducetedSpurious RF Conducted Emission(30 MHz-25GHz) Hopping Mode GFSK Report No. EDG2302140053E00301R Page 44 of 62 Ver.1.0 Test Model Band-edge Conducted Emissions Hopping Mode GFSK Report No. EDG2302140053E00301R Page 45 of 62 Ver.1.0 9.7 RADIATED SPURIOUS EMISSION Applicable Standard According to FCC Part 15.247(d) and 15.209 and 558074 D01 15.247 Meas Guidance V05r02 Conformance Limit According to FCC Part 15.247(d): radiated emissions which fall in the restricted bands, as defined in §15.205(a), must also comply with the radiated emission limits specified in §15.209(a) (see §15.205(c)). According to FCC Part15.205, Restricted bands MHz MHz MHz GHz 0.090-0.110 16.42-16.423 399.9-410 4.5-5.15 10.495-0.505 16.69475-16.69525 608-614 5.35-5.46 2.1735-2.1905 16.80425-16.80475 960-1240 7.25-7.75 4.125-4.128 25.5-25.67 1300-1427 8.025-8.5 4.17725-4.17775 37.5-38.25 1435-1626.5 9.0-9.2 4.20725-4.20775 73-74.6 1645.5-1646.5 9.3-9.5 6.215-6.218 74.8-75.2 1660-1710 10.6-12.7 6.26775-6.26825 123-138 2200-2300 14.47-14.5 8.291-8.294 149.9-150.05 2310-2390 15.35-16.2 8.362-8.366 156.52475-156.52525 2483.5-2500 17.7-21.4 8.37625-8.38675 156.7-156.9 2690-2900 22.01-23.12 8.41425-8.41475 162.0125-167.17 3260-3267 23.6-24.0 12.29-12.293 167.72-173.2 3332-3339 31.2-31.8 12.51975-12.52025 240-285 3345.8-3358 36.43-36.5 12.57675-12.57725 322-335.4 3600-4400 (2) 13.36-13.41 According to FCC Part15.209,the level of any transmitter spurious emission in Restricted bands shall not exceed the level of the emission specified in the following table Restricted Frequency(MHz) Field Strength ( μV/m) Field Strength (dB μV/m) Measurement Distance 0.009-0.490 2400/F(KHz) 20 log (uV/m) 300 0.490-1.705 24000/F(KHz) 20 log (uV/m) 30 1.705-30 30 29.5 30 30-88 100 40 3 88-216 150 43.5 3 216-960 200 46 3 Above 960 500 54 3 Test Configuration Test according to clause 7…

Text truncated - open the document above for the full version.

Radiated CONDUCTED EMISSION ---The End---
