2BAJ4SFI-10BOptical Fiber Identifier

Fiberfox Inc.

Click to zoom

Application Details

Equipment Class: JAB - Part 15 Class B Digital Device
Date of Grant: Mar 28, 2023
Application Purpose: Original Equipment
Date of Application: Mar 28, 2023
Equipment Note: Optical Fiber Identifier
Company: Fiberfox Inc.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Operating Manual The FiberFox OFI Model SFI-10B Probe is a rugged, hand-held, easy- to-use maintenance and installation instrument that identifies optical fibers by detecting the optical signals that are transmitted through a singlemode fiber. The SFI-10B utilizes non-destructive macro-bend detection, which eliminates the need to identify a fiber by opening it at the splice point. Thus, the probability of interrupting service is eliminated. Signals that the SFI-10B detect include continuous wave live optical transmission, and low frequency modulated tones at 270, 1000, and 2000 Hz. When the SFI-10B detects traffic on a fiber being tested, LCD display on the SFI-10B illuminates to indicate the presence and direction of transmission. The presence of tone is indicated in LCD display (Figure 1). The relative level of core power within the fiber is also displayed on the LCD display. Introduction Operating the SFI-10B Operation of the SFI-10B is simple, as outlined in the following steps: 1. Choose an adapter head for the type of fiber to be tested. The SFI-10B is supplied with two adapters (as shown in Figure 2): (A) foam-covered, to accommodate 250 μm bare fiber and 900 μm buffered fiber; (B) foam-covered, for 3 mm and 2 mm jacketed fiber (i.e., pigtails and jumpers) or loose tube fiber. 2. Push adaptor cover, as shown in Figure 3. 3. Select the appropriate adapter and slide it into the mating slotted channel of the body with slight downward pressure, as shown in Figure 4. 4. Pull adaptor cover Figure 1 Figure 2 A B Figure 3 Figure 4 Presence of Traffic. Arrow of either Traffic Right/Left indicates the detection and direction of traffic. This is useful in determining whether the fiber is transmitting or receiving at equipment terminal locations. (refer to Figure 6) Test Tone Detection. Display of any one of the 2 kHz, 1 kHz, or 270 Hz indicates that a test tone is being detected, which ensures accurate identification of the fiber that is under test. (refer to Figure 6) Relative Power Level. The relative core power in the fiber is displayed as a minus dB value between 0 and -40 dBm. Low Battery Indication. When the battery voltage becomes low, low gage is displayed after the self test. The unit will continue to operate for some time, but the battery should be replaced with a fresh 1.5 -volt alkaline battery x 2ea as soon as possible. (refer to Figure 6) Maintenance. It is important that the optical ports remain clean and free of dust, dirt, grease, or other foreign matter. Cleaning with lint-free swabs and isopropyl alcohol is recommended for optimum performance Figure 5 Figure 6 Test Tone Traffic Battery 5. Insert the fiber to be tested between the adapter and the top of the clamp (refer to Figure 5). Ensure that the fiber is installed properly in the alignment groove and pull the thumb switch downward. Warnings and Cautions The SFI-10B has been designed for discriminating signals in optical fibers. Do not attempt to use this instrument for other applications. Misuse of the instrument may result in electric shock and/or serious personal injury. •Read this instruction manual carefully before operating this instrument. •Store this instruction manual in a safe place. •Contents of this instruction manual may change without announcement. Warnings and Cautions Components Components SFI-10B Front Side a . R ule Part 15.19(a)(3): This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. b . R ule Part 15.21: The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. N ote: This equipment has been tested and found to comply with the limits for a Class B digital N OTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help Description SFI-10B Back Surface SFI-10B Bottom Side Power Supply Battery Operation 1.By using a driver remove the battery cover on the reverse side of the SFI-10 B. 2.Place batteries into the battery compartment on the orientation imprinted side of the compartment. 3.Put on the battery cover. * Caution: Risk of fire or explosion if the battery is replaced by incorrect type. Use AA Batteries (Voltage: 1.2 to 1.5 V). SPEC

Attestation Statements

FiberFox FIBERFOX Inc Yi B/D 2F, 80, Dongseo-daero 179beon-gil, Yuseong-gu, Daejeon, Republic of Korea Tel +82-70-4820-6991, Fax +82-42-716-7223 www.fiberfox.co.kr Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03-16-2023 Ref: Attestation Statements Part 2.911(d)( 7) Filing FCC ID: 2BAJ4SFI-10B FIBERFOX Inc. (“the applicant”) certifies that, as of the date of the filing of the application, TianHeng Consulting, LLC is our designated U.S. agent for service of process for the above referenced FCC ID. FIBERFOX Inc. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. TianHeng Consulting, LLC accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Sincerely, Designated U.S. Agent Information: Name: TianHeng Consulting, LLC FRN: 0033401258 Contact Person: Hualing Dong Address: 392 Andover Street, Wilmington, MA 01887, United States Tel.: +1 617-997-4010 Email: [email protected] U.S. Agent Signature: Applicant: Company Name: FIBERFOX Inc. Grantee Code: 2BAJ4 Contact Name: ChangHo Kang Address: Yi B/D 2F, 80, Dongseo-daero 179beon-gil, Yuseong-gu, Daejeon, Republic of Korea Tel.: +82-70-4820-6991 Email: [email protected] Applicant Signature: Hualing Dong, President

Attestation Statements

Fiberfox Inc. Kwang Yi B/D 2F, 80, Dongseo-daero 179beon-gil, Yuseong-gu, Daejeon, Republic of Korea Tel. +82-10-4595-7309 Fax +82-70-4820-6991 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: March 16, 2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BAJ4SFI-10B Fiberfox Inc. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Best Regards, ChangHo Kang / Senior Researcher Fiberfox Inc. Rev 1/26/2023 Fiberfox Inc. C-509, 744, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03-14-2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BAJ4SFI-10B Fiberfox Inc. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Best Regards, ChangHo Kang / Senior Researcher Fiberfox Inc. Rev 1/26/2023

Cover Letter(s)

Fiberfox Inc. Kwang Yi B/D 2F, 80, Dongseo-daero 179beon-gil, Yuseong-gu, Daejeon, Republic of Korea Te l . + 8 2-10-4595-7309 Fax +82-70-4820-6991 March 16, 2023 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : Fiberfox Inc. FCC ID : 2BAJ4SFI-10B Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), Fiberfox Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Fiberfox Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name CONFIDENTIAL Schematics CONF APPENDIX 2BAJ4SFI-10B SCH DIA.pdf Parts list CONF APPENDIX 2BAJ4SFI-10B PL.pdf Block diagram CONF APPENDIX 2BAJ4SFI-10B BLK DIA.pdf Operational description CONF APPENDIX 2BAJ4SFI-10B OpDes.pdf SHORT-TERM CONFIDENTIAL External Photos SHORT-TERM CONF 2BAJ4SFI-10BEXT Photo.pdf Internal Photos SHORT-TERM CONF 2BAJ4SFI-10B INT Photo.pdf Te s t-Setup Photos SHORT-TERM CONF 2BAJ4SFI-10B Test Photo.pdf User’s Manual SHORT-TERM CONF 2BAJ4SFI-10B Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Best Regards, ChangHo Kang / Senior Researcher Fiberfox Inc.

Cover Letter(s)

External Photos

FCC ID: 2BAJ4SFI-10B Front Rear Copyright ○ c 2023, LTA Co., Ltd .Page 1 of 5 FCC ID: 2BAJ4SFI-10B Side Side Copyright ○ c 2023, LTA Co., Ltd .Page 2 of 5 FCC ID: 2BAJ4SFI-10B Side Side Copyright ○ c 2023, LTA Co., Ltd .Page 3 of 5 FCC ID: 2BAJ4SFI-10B ANTENNA(2.4 GHz) Copyright ○ c 2023, LTA Co., Ltd .Page 4 of 5 FCC ID: 2BAJ4SFI-10B Label Position Copyright ○ c 2023, LTA Co., Ltd .Page 5 of 5

ID Label/Location Info

Internal Photos

FCC ID: 2BAJ4SFI-10B Main Board Front Main Board Rear Copyright ○ c 2023, LTA Co., Ltd. Page 1 of 4 FCC ID: 2BAJ4SFI-10B Board Front Board Rear Copyright ○ c 2023, LTA Co., Ltd. Page 2 of 4 FCC ID: 2BAJ4SFI-10B Board Front Board Rear Copyright ○ c 2023, LTA Co., Ltd. Page 3 of 4 FCC ID: 2BAJ4SFI-10B ANTENNA(2.4 GHz) Internal Copyright ○ c 2023, LTA Co., Ltd. Page 4 of 4

RF Exposure Info

FCC ID: 2BAJ4SFI-10B ATTACHMENT RF EXPOSURE EVULATION 1.1 Limit According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength Magnetic field Strength Power density Averaging time 1.34 - 30....................................... 824/f 2.19/f *(180/ f²) 30 30 - 300....................................... 27.5 0.073 0.2 30 300 - 1500.................................... ............... ............... f/1500 30 1500 - 100.000................................. ............... ............... 1.0 30 F = frequency in MHz * = Plane-wave equivalent power density 1.2 MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance Power density at the specific separation: S = PG/(4R 2 π) Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20 cm = limit for MPE) S = (0.66 * 0.89) / (4 * 5 2 * π) S = 0.19 mW/cm 2 FCC ID: 2BAJ4SFI-10B ATTACHMENT 1.3 MAXIMUM PERMISSIBLE EXPOSURE Prediction - Calculated under the worst-case conditions of each mode. (Measured power -2.0 dBm ± 0.5dB) 3-1. 2.4 GHz Mode Max Peak output Power at antenna input terminal -1.83 dBm Max Peak output Power at antenna input terminal 0.66 mW Prediction distance 5 mm Prediction frequency 2,402 MHz Antenna Gain(typical) -0.52 dBi Antenna Gain(numeric) 0.89 - Power density at prediction frequency( S) 0.03 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.012 mW/cm 2 SAR Test exclusion thresholds for 100MHz to 6GHz at test separation distance ≤ 50 mm = Used [(max.power of channel, including tune-up torelance, mW)/(min. test separation distance, mm)] * [√f(GHz)] = [0.66 / 5 ] * [ √2.402 ] = 0.02 ≤ 3.0, for 1g SAR Thus, SAR for this device is not required.

Test Report

Test Report No. : LR500112301C Copyright © 2023, LTA Co., Ltd. Page 1 of 21 TEST REPORT Test Report No. : LR500112301C Issue Date : January 13, 2023 Applied Standard : FCC Part 15, Subpart B Trade Name : Fiberfox Inc. Equipment Name : Optical Fiber Identifier Model Name : SFI-10B Additional Model name : - Serial Number : Identification FCC ID : 2BAJ4SFI-10B This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. This test report is not related to KS Q ISO/IEC 17025 and KOLAS accreditation. This laboratory is accredited by National Radio Research Agency Laboratory and National Voluntary Laboratory Accreditation Program. The tests reported herein have been performed in accordance with its terms of accreditation. Test Report No. : LR500112301C Copyright © 2023, LTA Co., Ltd. Page 2 of 21 Revision history Revision Date of issue Test report No. Description 0 13.01.2023 LR500112301C Initial Test Report No. : LR500112301C Copyright © 2023, LTA Co., Ltd. Page 3 of 21 >>TABLE OF CONTENTS<< LTA Certification .................................................................................................................................. 4 General information’s .......................................................................................................................... 6 1- Brief Information ............................................................................................................................. 7 2- Test Site Description ........................................................................................................................ 9 3- Test Procedure ................................................................................................................................ 11 4- List of Equipment Used For the Tests ........................................................................................... 14 5- EMISSION .................................................................................................................................... 15 5-1 Conducted Emissions ..................................................................................................... 15 5-2 Radiated Emissions ........................................................................................................ 16 Conclusions ........................................................................................................................................ 18 Photograph of the measurements ....................................................................................................... 19 Test Report No. : LR500112301C Copyright © 2023, LTA Co., Ltd. Page 4 of 21 LTA Certification Applicant / Manufacturer Company name : Fiberfox Inc. Address : Kwang Yi B/D 2F, 80, Dongseo-daero 179beon-gil, Yuseong-gu, Daejeon, Republic of Korea Telephone / Facsimile : +82-10-4595-7309 / +82-70-4820-6991 Factory Company name : Fiberfox Inc. Address : Kwang Yi B/D 2F, 80, Dongseo-daero 179beon-gil, Yuseong-gu, Daejeon, Republic of Korea Equipment Under Test (EUT) Equipment Name : Optical Fiber Identifier Model name : SFI-10B Additional Model name : - Serial number : Identification Intended environment : Industrial area Date of receipt : December 23, 2022 EUT condition : Pre-production, not damaged Test Mode : Operating mode, Bluetooth mode Interface ports : - Power rating : 3 V Test Voltage : 3 V Model Description - NONE Model Specification - NONE *** To be continued next page *** Test Report No. : LR500112301C Copyright © 2023, LTA Co., Ltd. Page 6 of 21 General information’s Purpose This document is based on the Electromagnetic Interference (EMI) tests performed on the “SFI-10B”. The measurements were performed according to the measurement procedure described in ANSI C 63.4-2014.The tests were carried out in order to confirm whether the electromagnetic emissions from the EUT( Equipment Under Test), are within the Class B limits defined in FCC Part 15, Subpart B- “Section 15.107- Conducted limits” and “Section 15.109-Radiated emission limits”. Test Performed Company name : LTA Co., Ltd. Address : 34, Songju-ro 236Beon-gil, Yangji-myeon, Cheoin-gu Yongin-si, Gyeonggi-do 449-822, Korea Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Measurement uncertainty Conducted Emissions (0.15 to 30 MHz) : ±2.80 [dB] (k=2) Radiated Emissions (30 to 1,000 MHz) : H : ±4.42 [dB] (k=2) V : ±4.70 [dB] (k=2) (1 GHz to 6 GHz) : H : ±5.88 [dB] (k=2) V : ±5.91 [dB] (k=2) (6 GHz to 18 GHz) : H : ±6.13 [dB] (k=2) V : ±6.16 [dB] (k=2) The coverage factor k=2 yields approx. a 95% level of confidence for near-normal distribution typical of most measurement results. Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2023-09-30 ECT accredited Lab. RRA KOREA U.S.A CANADA KR0049 - 2023-04-08 2024-08-15 RRA accredited Lab. VCCI JAPAN C-14948 T-12416 R-14483 G-10847 2023-09-10 2023-09-10 2023-10-15 2024-12-13 VCCI registration KOLAS KOREA KT551 2025-10-12 KOLAS accredited Lab. Test Report No. : LR500112301C Copyright © 2023, LTA Co., Ltd. Page 7 of 21 1- Brief Information 1-1 Test Summary Parameter Applied Standard Status (note 1) I. Emission Conducted Emissions FCC Part 15.107 NA Radiated Emissions FCC Part 15.109 C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable * The data in this test report are traceable to the national or international standards. Frequency range to be scanned: 0.15 MHz - 30 MHz as conducted measurement 30 MHz to 5 th harmonic of the highest frequency or 40 GHz, whichever is lower as radiated measurement. Bandwidth: Measured by the CISPR quasi-peak function Bandwidth is 9 kHz in the frequency …

Text truncated - open the document above for the full version.

Test Report

2017.05.31 RA-N0501-01 APPROVAL SHEET MODEL :BCM-LN100AS Antenna layout Review Consent Approval Messrs. BnCOM Co.,Ltd RadiNa Co. ,Ltd TEL:+82-2-463-0373 FAX:+82-2-463-0374 PRODUCT APPROVAL SHEET GRBll001001 MODEL NAME BCM-LN100AS REV. 1.0 Page 2 / 10 RADINA. Co., LTD / CONFIDENTIAL This Document contains confidential and proprietary information, cannot discourse to third party without the prior written Authorization. Table of contents 1. Revision History 2. Product Information 2.1 General Features 2.2 Electrical Specifications 3. Pattern Specifications 4. Matching Network 5. Electrical Characteristics 5.1 VSWR 5.2 Smith Chart 5.3 3D-PLOT 5.4 2D-GAIN 6. Passive Measurement 7. Measurement Process PRODUCT APPROVAL SHEET GRBll001001 MODEL NAME BCM-LN100AS REV. 1.0 Page 3 / 10 RADINA. Co., LTD / CONFIDENTIAL This Document contains confidential and proprietary information, cannot discourse to third party without the prior written Authorization. 1. Revision History NO. Before After Reason Date 1 2 3 4 5 6 7 8 9 10 11 12 13 PRODUCT APPROVAL SHEET GRBll001001 MODEL NAME BCM-LN100AS REV. 1.0 Page 4 / 10 RADINA. Co., LTD / CONFIDENTIAL This Document contains confidential and proprietary information, cannot discourse to third party without the prior written Authorization. 2. Product Information 2.1 General Features PART NUMBER GradiANT ANTENNA TYPE PCB Pattern Antenna APPLICATIONS Beacon 2.2 Electrical Specifications Frequency Range1 (TX) 2400MHz~2485MHz Frequency Range1 (RX) 2400MHz~2485MHz IMPEDANCE 50  V.S.W.R TX 2400MHz 2485MHz 5↓ 5↓ RX 2400MHz 2485MHz 5↓ 5↓ RADIATION PATTERN Omni-directional POLARIZATION Linear PRODUCT APPROVAL SHEET GRBll001001 MODEL NAME BCM-LN100AS REV. 1.0 Page 5 / 10 RADINA. Co., LTD / CONFIDENTIAL This Document contains confidential and proprietary information, cannot discourse to third party without the prior written Authorization. 3. Pattern Specifications 4. Matching Network Capacitor value can be changed depending on different situation PRODUCT APPROVAL SHEET GRBll001001 MODEL NAME BCM-LN100AS REV. 1.0 Page 6 / 10 RADINA. Co., LTD / CONFIDENTIAL This Document contains confidential and proprietary information, cannot discourse to third party without the prior written Authorization. 5. Electrical Characteristics 5.1 VSWR 5.2 SMITH CHART PRODUCT APPROVAL SHEET GRBll001001 MODEL NAME BCM-LN100AS REV. 1.0 Page 7 / 10 RADINA. Co., LTD / CONFIDENTIAL This Document contains confidential and proprietary information, cannot discourse to third party without the prior written Authorization. 5.3 3D-PLOTs 5.4 2D-GAIN PRODUCT APPROVAL SHEET GRBll001001 MODEL NAME BCM-LN100AS REV. 1.0 Page 8 / 10 RADINA. Co., LTD / CONFIDENTIAL This Document contains confidential and proprietary information, cannot discourse to third party without the prior written Authorization. 6. Passive Measurement 1 2 3 4 5 6 7 8 9 10 Frequency(MHz) 2400 2405 2410 2415 2420 2425 2430 2435 2440 2445 Efficiency(dB) -5.37 -5.09 -4.80 -4.34 -3.81 -3.42 -3.27 -3.87 -3.58 -3.42 Efficiency(%) 29.01 30.99 33.14 36.85 41.55 45.45 47.07 40.99 43.84 45.52 TRG(dB) -5.37 -5.09 -4.80 -4.34 -3.81 -3.42 -3.27 -3.87 -3.58 -3.42 TRG Theta (dB) -5.82 -5.51 -5.23 -4.79 -4.25 -3.88 -3.47 -4.31 -4.03 -3.85 TRG Phi (dB) -15.49 -15.44 -15.02 -14.37 -14.03 -13.49 -16.81 -14.06 -13.68 -13.64 UHRG(dB) -8.36 -8.08 -7.82 -7.28 -6.83 -6.38 -6.20 -6.80 -6.45 -6.31 UHRG/TRG(%) 50.30 50.17 49.85 50.74 49.91 50.64 50.92 50.99 51.61 51.44 H-Plane -4.74 -4.45 -4.09 -3.57 -3.06 -2.71 -2.21 -3.03 -2.71 -2.56 E1-Plane, AVG(dB) -7.83 -7.64 -7.39 -6.80 -6.30 -6.04 -5.58 -6.36 -6.06 -5.92 E2-Plane, AVG(dB) -5.75 -5.40 -5.06 -4.76 -4.04 -3.78 -3.28 -4.11 -3.84 -3.76 Peak Gain(dB) -2.97 -2.47 -2.31 -1.65 -1.21 -0.80 -0.52 -1.23 -0.89 -0.76 Directivity(dB) 2.40 2.62 2.49 2.68 2.61 2.63 2.75 2.64 2.69 2.66 Minimum Gain(dB) -10.52 -10.56 -10.26 -10.10 -10.02 -9.43 -12.17 -9.66 -9.74 -9.32 11 12 13 14 15 16 17 18 19 20 Frequency(MHz) 2450 2455 2460 2465 2470 2475 2480 2485 2490 2497 Efficiency(dB) -3.53 -3.47 -3.61 -3.90 -4.20 -4.35 -3.67 -3.93 -4.32 -4.75 Efficiency(%) 44.36 44.96 43.54 40.78 38.05 36.70 42.95 40.47 36.95 33.48 TRG(dB) -3.53 -3.47 -3.61 -3.90 -4.20 -4.35 -3.67 -3.93 -4.32 -4.75 TRG Theta (dB) -3.97 -3.92 -4.05 -4.34 -4.65 -4.81 -4.12 -4.39 -4.79 -5.23 TRG Phi (dB) -13.70 -13.57 -13.83 -13.98 -14.24 -14.37 -13.74 -13.87 -14.22 -14.55 UHRG(dB) -6.37 -6.33 -6.47 -6.75 -7.06 -7.19 -6.47 -6.71 -7.14 -7.64 UHRG/TRG(%) 52.03 51.84 51.73 51.85 51.75 52.02 52.48 52.71 52.25 51.49 H-Plane -2.78 -2.51 -2.79 -2.91 -3.35 -3.32 -2.81 -3.00 -3.49 -3.90 E1-Plane, AVG(dB) -6.00 -5.92 -6.09 -6.42 -6.64 -6.87 -6.02 -6.37 -6.85 -7.24 E2-Plane, AVG(dB) -3.86 -3.72 -3.81 -4.17 -4.49 -4.45 -3.85 -4.19 -4.64 -5.14 Peak Gain(dB) -1.01 -0.75 -0.94 -0.82 -1.40 -1.54 -0.96 -1.47 -1.43 -2.10 Directivity(dB) 2.52 2.72 2.68 3.08 2.80 2.81 2.71 2.45 2.90 2.66 Minimum Gain(dB) -9.75 -9.04 -9.48 -9.81 -9.44 -9.57 -9.40 -9.58 -10.59 -10.33 Average Efficiency -4.00dBi, 39.83% Peak Gain -0.75dBi 7. Measurement Process PRODUCT APPROVAL SHEET GRBll001001 MODEL NAME BCM-LN100AS REV. 1.0 Page 9 / 10 RADINA. Co., LTD / CONFIDENTIAL This Document contains confidential and proprietary information, cannot discourse to third party without the prior written Authorization. 7.1 SWR / Return loss Set Condition Network Analyzer Agilent 8753ES Cable Semi-ridid (40mm, 60mm) Test condition 7.2 Gain Antenna gain is measured in the anechoic chamber of this company. Anechoic Chamber for Antenna Gain Measurement 7.3 Gain test block diagram PRODUCT APPROVAL SHEET GRBll001001 MODEL NAME BCM-LN100AS REV. 1.0 Page 10 / 10 RADINA. Co., LTD / CONFIDENTIAL This Document contains confidential and proprietary information, cannot discourse to third party without the prior written Authorization. Active test Sysetm - TRP, NHPRP,UHRP - TIS, NHPIS, UHIS - Relative Sensitivity Passiver test Sysetm - Efficiency - Peak Gain, Avg, Gain - Min, Max PWR

Test Setup Photos
