2BAL3-MAYASM59181Desk Lamp w/Charger

Desk Lamp w/ Charger Manual Switch LED Lamp Flexible lamp-post Charging Area Instructions Attention 1.Please keep the charger away from water or other liquid. 2.If you need to lean the charger, please make sure it is power off. Specifications Input voltage:5V2A Output power:5W Charging efficiency:70%-80% Printed in China 1. Connect wireless charger with power source by USB cable, wireless charger turn on,the red indicator indicates the standby state 2. Put your phones onto the wireless charging area, the blue indicator indicates the charging state after placing the phone. Red and blue cross flashing indicates indicates that unsuitable device please adjust the position of you phone. 3. Light touch lamp switch,the lamp will be lighting on, the lamp has 3 types of lighting mode, cold light,warm light,warm white light then touch switch to turn it off. Indicator This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received,in- cluding interference that may cause undesired operation. “CAUTION: Changes or modifcations not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment." Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. (1)Product Name:Desk Lamp w/Charger, SM-59181 (2)Supplier:CVS Health Corporate Headquarters This equipment should be installed and operated with minimum distance 20cm between the radiator&your body. Address:One CVS Drive, Woonsocket, RI02895.Tel:(401)765-1500 Instruction Manual

(HENGYE INTL. DEVELOPMENT CO.,LTD.) (2023.07.24) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2BAL3‐ MAYASM59181) [HENGYE INTL. DEVELOPMENT CO.,LTD. ] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Jin liu (HENGYE INTL. DEVELOPMENT CO.,LTD.) (2023.07.24) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2BAL3‐ MAYASM59181) [HENGYE INTL. DEVELOPMENT CO.,LTD. ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Jin liu

HENGYE INTL. DEVELOPMENT CO.,LTD. Agent Authorization Letter 2023-07-24 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen Most Technology Service Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Jin liu Position: Manager Company Name: HENGYE INTL. DEVELOPMENT CO.,LTD. Address: ROOM 1011-1016,10 /F, QILIN BLDG,No.1501 NORTH TIANTONG RD,NINGBO,CHINA Tel / Fax 0754-28878211 / 0754-28878211 E-Mail: [email protected]

HENGYE INTL. DEVELOPMENT CO.,LTD. Long Term Confidentiality Request Letter 2023-07-24 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR (FCC ID: 2BAL3-MAYASM59181) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - e.g. Block diagram - e.g. SCH - e.g. Operational Description required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Name: Jin liu Position: Manager Company Name: HENGYE INTL. DEVELOPMENT CO.,LTD. Address: ROOM 1011-1016,10 /F, QILIN BLDG,No.1501 NORTH TIANTONG RD,NINGBO,CHINA Tel / Fax 0754-28878211 / 0754-28878211 E-Mail: [email protected]

Model No.: SM-59181 FRONT VIEW OF SAMPLE BACK VIEW OF SAMPLE Model No.: SM-59181 LEFT VIEW OF SAMPLE RIGHT VIEW OF SAMPLE Model No.: SM-59181 TOP VIEW OF SAMPLE FRONT VIEW OF SAMPLE Model No.: SM-59181 Overall photo

Label: Product name: Desk Lamp w/Charger Product model: SM-59181 FCC ID: 2BAL3-MAYASM59181 Manufacturer: HENGYE INTL. DEVELOPMENT CO.,LTD. Label location Size:40mm*20mm

Model No.: SM-59181 Page 1 of 2 INTERNAL PHOTO OF SAMPLE INTERNAL PHOTO OF SAMPLE Model No.: SM-59181 Page 2 of 2 INTERNAL PHOTO OF SAMPLE PCB ANT Location

Shenzhen Most Technology Service Co., Ltd. No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. RF Exposure Evaluation Report Report Reference No. ..................... : FCC ID.. .......................................... : MTEB23070089-H 2BAL3-MAYASM59181 Compiled by ( position+printed name+signature) .. : File administrators Alisa Luo Supervised by ( position+printed name+signature) .. : Test Engineer Sunny Deng Approved by ( position+printed name+signature) .. : Manager Yvette Zhou Date of issue ..................................... : July 10, 2022 Representative Laboratory Name .: Shenzhen Most Technology Service Co., Ltd. Address ............................................ : No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. Applicant’s name ............................ : HENGYE INTL. DEVELOPMENT CO.,LTD. Address ............................................ : ROOM 1011-1016,10 /F, QILIN BLDG,No.1501 NORTH TIANTONG RD,NINGBO,CHINA Test specification/ Standard ..........: FCC CFR Title 47 Part 15 Subpart C FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 TRF Originator .................................. : Shenzhen Most Technology Service Co., Ltd. Shenzhen Most Technology Service Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Most Technology Service Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Most Technology Service Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Desk Lamp w/Charger Trade Mark ....................................... : N/A Manufacturer .................................... : SHENZHEN FANGXING TECHNOLOGY CO.,LTD Model/Type reference....................... : SM-59181 Modulation Type ............................... : FSK Operation Frequency ........................ : 110-205KHz Rating ............................................... : Input: DC 5V(by USB) output power:5W Hardware Version ............................ : N/A Software Version ............................ : N/A Result................................................ : PASS Report No.: MTEB22120269-H Page 2 of 7 T E S T R E P O R T Equipment under Test : Desk Lamp w/Charger Model /Type : SM-59181 Applicant : HENGYE INTL. DEVELOPMENT CO.,LTD. Address : ROOM 1011-1016,10 /F, QILIN BLDG,No.1501 NORTH TIANTONG RD,NINGBO,CHINA Manufacturer : HENGYE INTL. DEVELOPMENT CO.,LTD. Address : ROOM 1011-1016,10 /F, QILIN BLDG,No.1501 NORTH TIANTONG RD,NINGBO,CHINA Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: MTEB22120269-H Page 3 of 7 1. Revision History Revision Issue Date Revisions Revised By 00 2023.07.10 Initial Issue Alisa Luo Report No.: MTEB22120269-H Page 4 of 7 2. SAR Evaluation 2.1 RF Exposure Compliance Requirement 2.1.1 Standard Requirement According to FCC CFR Title 47 Part 15 Subpart C FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 2.1.2 Limits According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure is calculated. According KDB680106 D01v03r01: RF Exposure Wireless Charging. Test Setup: E to position is 20cm. 2.1.3 Test Procedure: 1: The RF exposure test was performed on 80cm insulated table in anechoic chamber. 2: The measurement probe was placed at test distance (15cm) which is between the edge of the charger and the geometric centre of probe. 3: The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. 4: The EUT were measured according to the dictates of KDB 680106D01v03r01. 2.1.4 Test Mode: Charging + Transmitting Mode Report No.: MTEB22120269-H Page 5 of 7 2.1.5 Test Instruments Item Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Interval 1 Exposure Level Tester narda ELT-400 N-0231 2023.3.17 1 Year 2 Magnetic field probe 100cm2 narda ELT probe 100cm2 M0675 2023.3.17 1 Year 3 Isotropic Electric Field Probe narda EP-601 511WX607062023.3.17 1 Year The EUT does comply with section 5 b) of KDB 680106 D01 RF Exposure Wireless charging App V03r01. Conditions requirement Answers Power transfer frequency is less than 1 MHz. After measuring the product the transfer frequency is 0.110-0.205MHz Output power from each primary coil is less than or equal to 15 watts. After measuring the product the each primary coil power is 5 watts The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. The transfer system include signal primary. Client device is placed directly in contact with the transmitter. Client device is placed directly in contact with the transmitter. Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Mobile exposure conditions only. The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. After measuring the product the Max H-field Strength is 0.702 A/m Far less than 50% of the MPE limit. Report No.: MTEB22120269-H Page 6 of 7 2.1.6 Test data For Full load mode: H-Filed Strength at 15 cm for position A,B,C,D 20cm for position E from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B T…

Text truncated - open the document above for the full version.

Shenzhen Most Technology Service Co., Ltd. No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. TEST REPORT FCC PART 15.209 Report Reference No. ..................... : FCC ID.. .......................................... : MTEB23070089-R 2BAL3-MAYASM59181 Compiled by ( position+printed name+signature) .. : File administrators Alisa Luo Supervised by ( position+printed name+signature) .. : Test Engineer Sunny Deng Approved by ( position+printed name+signature) .. : Manager Yvette Zhou Date of issue ..................................... : July 10, 2022 Representative Laboratory Name .: Shenzhen Most Technology Service Co., Ltd. Address ............................................ : No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China. Applicant’s name ............................ : HENGYE INTL. DEVELOPMENT CO.,LTD. Address ............................................ : ROOM 1011-1016,10 /F, QILIN BLDG,No.1501 NORTH TIANTONG RD,NINGBO,CHINA Test specification/ Standard ..........: FCC Rules and Regulations Part 15 Subpart C (Section 15.209), ANSI C63.10: 2013 TRF Originator .................................. : Shenzhen Most Technology Service Co., Ltd. Shenzhen Most Technology Service Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Most Technology Service Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Most Technology Service Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Desk Lamp w/Charger Trade Mark ....................................... : N/A Manufacturer .................................... : HENGYE INTL. DEVELOPMENT CO.,LTD. Model/Type reference....................... : SM-59181 Modulation Type ............................... : FSK Operation Frequency ........................ : 110-205KHz Rating ............................................... : Input: DC 5V(by USB) output power:5W Hardware Version ............................ : N/A Software Version ............................ : N/A Result................................................ : PASS Report No.: MTEB23070089-R Page 2 of 23 T E S T R E P O R T Equipment under Test : Desk Lamp w/Charger Model /Type : SM-59181 Applicant : HENGYE INTL. DEVELOPMENT CO.,LTD. Address : ROOM 1011-1016,10 /F, QILIN BLDG,No.1501 NORTH TIANTONG RD,NINGBO,CHINA Manufacturer : HENGYE INTL. DEVELOPMENT CO.,LTD. Address : ROOM 1011-1016,10 /F, QILIN BLDG,No.1501 NORTH TIANTONG RD,NINGBO,CHINA Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: MTEB23070089-R Page 3 of 23 Contents 1. REVISION HISTORY ................................................................ 4 2. TEST STANDARDS .................................................................. 5 3. SUMMARY ............................................................................. 6 3.1. General Remarks 6 3.2. Product Description 6 3.3. Equipment Under Test 6 3.4. Short description of the Equipment under Test (EUT) 6 3.5. EUT operation mode 6 3.6. Block Diagram of Test Setup 7 3.7. Test Item (Equipment Under Test) Description* 7 3.8. Auxiliary Equipment (AE) Description 7 3.9. Antenna Information* 7 3.10. EUT configuration 7 3.11. Modifications 7 4. TEST ENVIRONMENT ............................................................... 8 4.1. Address of the test laboratory 8 4.2. Environmental conditions 8 4.3. Test Description 9 4.4. Statement of the measurement uncertainty 9 4.5. Equipments Used during the Test 10 5. TEST CONDITIONS AND RESULTS ............................................ 11 5.1. AC Power Conducted Emission ................................................................................... 11 5.2. Radiated Emission ........................................................................................................ 14 5.3. 20dB Bandwidth ........................................................................................................... 20 5.4. Antenna Requirement ................................................................................................... 21 6. TEST SETUP PHOTOS OF THE EUT .......................................... 22 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 23 Report No.: MTEB23070089-R Page 4 of 23 1. Revision History Revision Issue Date Revisions Revised By 00 2023.07.10 Initial Issue Alisa Luo Report No.: MTEB23070089-R Page 5 of 23 2. TEST STANDARDS The tests were performed according to following standards: The tests were performed according to following standards: ANSI C63.10:2013 : American National Standard for Testing Unlicensed Wireless Devices FCC Rules and Regulations Part 15 Subpart C (Section 15.207): Conducted limits. FCC Rules and Regulations Part 15 Subpart C (Section 15.209): Radiated emission limits; general requirements. Report No.: MTEB23070089-R Page 6 of 23 3. SUMMARY 3.1. General Remarks Date of receipt of test sample : 2023.06.30 Testing commenced on : 2023.07.01 Testing concluded on : 2023.07.08 3.2. Product Description Product Name: Desk Lamp w/Charger Model/Type reference: SM-59181 Power Supply： Input: DC 5V(by USB) Testing sample ID： MTYP01983 Modulation: Induction Operation frequency: 110-205KHz Antenna type: Coil Antenna Antenna gain: 0 dBi 3.3. Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 5V(by USB) 3.4. Short description of the Equipment under Test (EUT) This is a Desk Lamp w/Charger For more details, refer to the user’s manual of the EUT. 3…

Text truncated - open the document above for the full version.

Antenna manufacturer: HENGYE INTL. DEVELOPMENT CO.,LTD. Antenna size: R1:40mm/R2:20mm antenna gain: 0 dBi Coil turns: 10 laps R2:20mm R1:40mm

Model No.: SM-59181 RE TEST SETUP RE TEST SETUP Model No.: SM-59181 CE TEST SETUP
