2BAL6430LYAZ43 inch LCD display

Revision 2.0 Android Network Digital Signage (7.1 version) Content ....................................................................................................................................... ........................................................................................................... ................................................................................................ ............................................................................................ ..................................................................................... ........................................................................................... ......................................................................................... .................................................................................. ............................................................................................. Content Display Interface Description Remote Control Instructions Description Of Basic Operation Android 7.1 Operating System ( 3288) 1. Functional description 2. Introduction to system settings 3. Instructions for using the function Optional Storage Parameters 02 03 04 05 05 06 08 11 16 3 Machine Intace Description 21 3 4 5 7 6 1 2 3 4 5 6 7 Intaces Note: Please pull out the power plug before installing or disassembling the unit! DC 12V Audio OUT ports: This port is the audio signal output port. RJ45 Port: This is the grid interface Support connection to 100 mbit/g network. HDMI port: This port is used to connect HDMI signals. USB port: This port is for software upgrades and playback of audio and video files from USB sticks. TF Port : This is the TF card interface. SIM Port : This is the SIM card interface. 4 The remote control is shown below: Remote Control Instructions INPUT AUTO ENTER MENUEXIT VOL-VOL+ 1 2 5 6 8 10 3 7 9 4 Power on/off button 1 NC 2 Enter button 5 Vol- 8 Mute 10 Navigation button 4 Exit button 7 Vol+ 9 3 NC 6 Menu button  %ýŦóŢğşŮğŅĽdĒÖŦğódşýŢÖŮğŅĽ 3OD\6WRUH ĽùŢŅğù滼澳滶ŅşýŢÖŮğĽēŦƒŦŮýĻ瀀T滸滷滽滽瀁 6 Description Of Basic Operation 1. Functional description 1.1 In the navigation bar at the top of the machine, the following icons appear in erent situations. 1.2 The navigation bar at the bottom of the machine helps you to operate it more easily. Icons Description Connecting the network cable No 4G internet card inse ed Turn oight mode Connecting to WIFI Icons Description Home button Open uncleared background Exit button Volume down Volume up Screenshot function Hide the navigation bar  滶澳滸%ýŦóŢğşŮğŅĽŅĒŮěýÖşşĵğóÖŮğŅĽğóŅĽŦŮěÖŮóŅĻýƌğŮěŮěýŦƒŦŮýĻ澳 3OD\6WRUH 0XVLF &DPHUD&KURPH 'RZQORDGV ([SORUHU*DOOHU\ /LJKWQLQJ ;EK7LPHU9LGHR 6RXQG5HFRUGHU 6HWWLQJV 6HDUFK$SSV  %ýŦóŢğşŮğŅĽdĒÖŦğódşýŢÖŮğŅĽ dşýĽÖşşĵğóÖŮğŅĽòÖŢ澳 ~TDĽŦŮÖĵĵýŢ澵ŒěğŦĒýÖŮųŢýŦųşşŅDžŦùýŮýóŮğŅĽŅĒÖşşğĽŦŮÖĵĵýŢŦğĽŮěýùýƋğóý ŦŮŅŢÖēýÖĽùğĽŦŮÖĵĵÖŮğŅĽ澳 <ŅŅēĵý~ĵÖƒ…ŮŅŢý澳 ÖĻýŢÖ瀀ŮěýùýƋğóýĽýýùŦŮŅòýóŅĽĽýóŮýùŮŅÖóÖĻýŢÖğĽŅŢùýŢŮŅųŦýğŮ瀁澵ųŦý ŮěýóÖĻýŢÖŮŅŮÖıýşğóŮųŢýŦ澴ŢýóŅŢùƋğùýŅŦÖĽùÖùĭųŦŮŮěýşěŅŮŅŢÖŮğŅğĽŮěý óÖĻýŢÖŦýŮŮğĽēŦ澳 <ŅŅēĵýěŢŅĻý澵ŮěğŦòŢŅƌŦýŢóÖĽòýųŦýùŮŅÖóóýŦŦŮěýƌýòƌěýĽóŅĽĽýóŮýù ŮŅŮěýğĽŮýŢĽýŮ澳 ;ğĵý\ÖĽÖēýŢ澳 ŒğĻýùŅĽ濗ŅƺĒųĽóŮğŅĽ瀀ŦýŮŅĽ濗ŅƺğĽŮýdžÖĵŅƋýŢ滺ĻğĽųŮýŦ瀁澳 …ýŮŮğĽēŦ瀀ēŅŮŅĻýĽųŮŅŦýŮÖŦŢýšųğŢýù瀁澳 ýóŅŢùýŢ澵瀀ŢýšųğŢýŦĻÖóěğĽýƌğŮěĻğóŢŅşěŅĽý瀁ŮŅŢýóŅŢùÖųùğŅǁĵýŦ澳 ©ğùýŅşĵÖƒýŢ澵óÖĽŦųşşŅDžÖųŮŅĻÖŮğóŢýÖùğĽēÖĽùşĵÖƒòÖóıŅĒƋğùýŅŦĒŢŅĻ ĻýĻŅLj澳 DóŅĽŦ %ýŦóŢğşŮğŅĽ 8 2.Introduction to system settings Description Of Basic Operation Wireless & networks Device Personal System Date & time GMT-04:00 Eastern Daylight time Accessibility Data usage O B of data used More USB DEBUG Display Adaptiv All apps allowed to send Sound Apps Ring voluma at 71% 21 apps installed Storage 335 MB of 4.39 GB used Av Users Signed in as owner ON / Device only Location Security Accounts Google languages & input English(ZH) Backup & reset Wi-Fi Disabled Settings 9 Description Of Basic Operation Click on the icon ttion and connect to the detect 2.1 WiFi Disconnected 2.2.1 Adjusting the backlight brightness (the light-sensing function needs to be switched o or the adjusted brightness parameter to be valid). Brightness level 2.2.2 Light-sensitive functions. Light sensor Optimize Brightness Level For Available Light By clicking on the icon, the following function options can be set. 2.2 Display Adaptive brightness is OFF 2.2.3 Wallpaper settings. Wallpaper 2.2.4 Screen sleep. Sleep Never 2.2.5 Screen savers. Screen saver 2.2.6 Font size. Font size Default 2.2.7 Display size. Display size Default 2.2.8 Screen rotation. Rotate the main Screen Rotate direction 0 2.2.9 HDMI output settings. HDMI 2.2.10 Top navigation bar hide switch. Hide the statusbar 2.2.11 Bottom navigation bar hide switch. Hide navigation bar 10 Description Of Basic Operation 2.3 Click on the icon to set the app' permissions. Notications All apps allowed to send 2.4 Click on the icon to set the system volume and one. Notications All apps allowed to send 2.5 Click on the icon to set app permissions and to uninstall the app. Apps 15 apps installed 2.6 Click on the icon to set the screenshot storage path and the screenshot function switch. Screenshot Setting 2.7 Click on the icon to set up the conversion of one of the o an OT. USB DEBUG 2.8 Click on the icon t to set the input method keyboard. Languages & input English(United States) 2.9 Click on the icon to restore the system to fact settings and back up data. Backup & reset 2.10 Click on the icons to change the time, date and time zone. Date & time GMT + 08:00 China Standard Time 2.11 Click on the icon to view information about the system. About device Android 7.1.2  滸澳DĽŦŮŢųóŮğŅĽŦĒŅŢųŦğĽēŮěýĒųĽóŮğŅĽ 滸澳滶‘…ŦƌğŮóědŒ<ĒųĽóŮğŅĽ 滸澳滶澳滶óóýŦŦğĽēŮěýŦýŮųşŦóŢýýĽ澳 滸澳滶澳滷dşýĽŮěý‘…%)‘<ĻýĽųòÖŢÖĽùŮğóı‘…ŅĽ澴ŅĽýŅĒŮěý‘…şŅDžŦƌğĵĵòýóŅĻýÖĽ dŒ<şŅDž澳 %ýŦóŢğşŮğŅĽdĒÖŦğódşýŢÖŮğŅĽ %ýƋğóý ~ýŢŦŅĽÖĵ %ÖŮÖųŦÖēý dŅĒùÖŮÖųŦ…

Text truncated - open the document above for the full version.

Rcstars Industrial (Shenzhen) Co., LTD 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Rcstars Industrial (Shenzhen) Co., LTD Address: 7/F, 2ND Bldg, Senyang High-Tech Park, N0.7 Road, Guangming High-Tech Park District, Shenzhen, China, 518106 Product Name: 43 inch LCD display FCC ID: 2BAL6430LYAZ Model(s): RCS-430LYAZ, RCS-430ODLYAZ 2.911(d)(5)(i) Equipment Type We, [Rcstars Industrial (Shenzhen) Co., LTD] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Fiona Xing Date: Apr. 03, 2023 Title and Company name: Manager; Rcstars Industrial (Shenzhen) Co., LTD. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Rcstars Industrial (Shenzhen) Co., LTD 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Rcstars Industrial (Shenzhen) Co., LTD Address: 7/F, 2ND Bldg, Senyang High-Tech Park, N0.7 Road, Guangming High-Tech Park District, Shenzhen, China, 518106 Product Name: 43 inch LCD display FCC ID: 2BAL6430LYAZ Model(s): RCS-430LYAZ, RCS-430ODLYAZ 2.911(d)(5)(ii) Applicant filing We, [Rcstars Industrial (Shenzhen) Co., LTD] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Fiona Xing Date: Apr. 03, 2023 Title and Company name: Manager; Rcstars Industrial (Shenzhen) Co., LTD. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Rcstars Industrial (Shenzhen) Co., LTD Section 2.911(d)(7) USAAgent for Service of Process Company name: Rcstars Industrial (Shenzhen) Co., LTD Address: 7/F, 2ND Bldg, Senyang High-Tech Park, N0.7 Road, Guangming High-Tech Park District, Shenzhen, China, 518106 Product Name: 43 inch LCD display FCC ID: 2BAL6430LYAZ Model(s): RCS『430LVAZ, RCS-430ODLYAZ 2.911(d)(7) USA Designated Agent for Service 。f Process We, [Rcstars Industrial (Shenzhen) C 。 .，LTD] （ “ the applicant ” ） designate [AOCE Corporation Inc.] NOTE1 f。r the purpose of accepting service of process on behalf of the applicant. Applicant c。nsent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent 。bligation: We Acknowledge our obligation to accept service 。f process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: AOCE Corporation Inc. Address: 6547 N Academy Bivd #2266, Springs, 80918, COLORADO FRN: 0033401381 Contact Name: Johnson Wang Teleph。ne N。：346 582 5234 Email: ww同[email protected] Applicant Company name: Rcstars Industrial (Shenzhen) Co., LTD Address: 7/F, 2ND Bldg, Senyang High-Tech Park, N0.7 Road, Guangming High-Tech Park District, Shenzhen, China, 518106 FCC Gr antee Code: 2BAL6 C ontact Name: Fiona Xing Telephone No: 18682108065 2.911 {d)(7)USA Agent vl.3 Rcstars Industrial (Shenzhen) Co., LTD Signature: Title: PM Date: 2023/4/3 Email: [email protected] Sign ature ：「帆布。 Title: Manager Date: 2023/4/3 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register docume叫2022-28263published on 02/06/23 h忧os://www.federalreoister.oov/documents/2023/02/06/2022-28263/orotectina-aaainst-nat1on al-security”threats-to-the-communications-suoolv-chain-throuoh-the 2.911 {d)(7}USA Agent vl.3

< Rcstars Industrial (Shenzhen) Co., LTD> Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD21046 Date: Apr. 03, 2023 Subject; Request for Long Term Confidentiality FCC ID: 2BAL6430LYAZ To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Fiona Xing Title: Manager

Rcstars Industrial (Shenzhen) Co., LTD Letter of Authorization Company: Rcstars Industrial (Shenzhen) Co., LTD Address: 7/F, 2ND Bldg, Senyang High-Tech Park, N0.7 Road, Guangming High-Tech Park District, Shenzhen, China, 518106 Product name: 43 inch LCD display Trade name: Rcstars Model name: RCS-430LYAZ, RCS-430ODLYAZ FCC Identifier: 2BAL6430LYAZ We authorize MiCOM LabsInc, 575 Boulder Court, Pleasanton, California94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM LabsInc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Fiona Xing Date: Apr. 03, 2023 Title: Manager Signature of applicant:

Model Difference Declaration To Whom It May Concern, We, Rcstars Industrial (Shenzhen) Co., LTD Product Name: 43 inch LCD display Trade Mark: Rcstars Model Name: RCS-430LYAZ, RCS-430ODLYAZ All model’s the function, software and electric circuit are the same, only with a product color and model named different. Test sample model: RCS-430LYAZ. Please contact me if you have any question. Name: Fiona Xing Date: Apr. 03, 2023 Title: Manager Signature of applicant:

Model: RCS-430LYAZ

FCC ID LABEL: Label Location:

Model: RCS-430LYAZ 2.4G Antenna

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product 43 inch LCD display Main Model RCS-430LYAZ FCC ID 2BAL6430LYAZ 2. EVALUATION METHOD AND LIMIT Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE Frequency Range (MHz) E-field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Time |E| 2 , |H| 2 or S (Minutes) 0.3 -- 1.34 614 1.63 (100)* 30 1.34 -- 30 824/f 2.19/f (180/f 2 )* 30 30 -- 300 27.5 0.073 0.2 30 300 -- 1500 -- -- f/1500 30 1500 -- 100,000 -- -- 1.0 30 *Note: 1. f= Frequency in MHz * Plane-wave Equivalent Power Density 2. The averaging time for General Population/Uncontrolled exposure to fixed transmitters is not applicable for mobile and portable transmitters. See 47 CFR §§2.1091 and 2.1093 on source-based time-averaging requirement for mobile and portable transmitters. S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna CALCULATION A minimum test separation distance ≥ 20 cm is required between the antenna and radiating structures of the device and nearby persons to apply mobile device exposure limits. The distance must be at least 20 cm and fully supported by the operating and installation configurations of the transmitter and its antenna(s), according to the source-based time-averaged maximum power requirements of § 2.1091(d)(2). In cases where cable losses or other attenuations are applied to determine compliance, the most conservative operating configurations and exposure conditions must be evaluated. Mode Max PK Output Power (dBm) Tune Up Power (dBm) Max Tune Up Power (mW) Power Density (mW/cm 2 ) Power Density Limit (mW/cm²) 11b 15.25 15±1(16) 39.811 0.029713 1 11g 16.68 17±1(18) 63.096 0.047092 1 11n/HT20 16.32 16±1(17) 50.119 0.037407 1 11n/HT40 15.70 16±1(17) 50.119 0.037407 1 Note: The estimation distance is 20cm. 2.4G WIFI: Antenna Gain=5.74dBi (linear: 3.7497), π=3.14 Note: PK Output power=conducted power. Conducted power see the test report UNIA23030812ER-61, antenna gain=5.74dBi. ------The End------

Shenzhen Qisen Technology Co., Ltd. address：4th Floor, No. 22 Anye Road, Henggang Street, Longgang District, Shenzhen telephone：0755-84864089 / 15989305086 website：www.qskjgf.com SPECIFICATION FOR APPROVAL COMPANY NAME Shenzhen Qisen Technology Co., Ltd. PRODUCT P/N QS20121101 PRODU CT NAME Built-in SMA male pin 5DB antenna Confirmed by The Company Shenzhen Qisen Technology Co., Ltd. catalogue 1...............................Product Acknowledgment Cover........................ 2...............................Product catalogue........................... 3...............................Product Recognition........................ 4...............................Product Specification Sheet........................ 5...............................Product drawings........................... 6...............................Product Test Report..................... 7...............................Product Summary........................... address：4th Floor, No. 22 Anye Road, Henggang Street, Longgang District, Shenzhen telephone：0755-84864089 / 15989305086 website：www.qskjgf.com 3.Customer confirmation: CUSTOMER NAME Rcstars Industrial (Shenzhen) Co., LTD. Confirmed by Customer Sample submission date 2020-03-31 Product Item No. QS20121101 Customer No. QisenQ0715 Customer Item No. Product name Built-in SMA male pin 5DB antenna Product specifications 178wire300MM attachment ■Product drawing ■Performance test ■Product RoHS ■Sample quantity Supporting document □CE □FCC■RoHS □3C □others： remarks Shenzhen Qisen Technology Co., Ltd. address：4th Floor, No. 22 Anye Road, Henggang Street, Longgang District, Shenzhen telephone：0755-84864089 / 15989305086 website：www.qskjgf.com 4.Specification sheet: Frequency Range (MHZ) 2400-2483.5MHz Impedance(Ω)50±10 Peak Gain(dBi) 5±0.5 ≤1.92 Admitted Power10W PolarizationLinear,Vertical Connector TypeSMA Physical Properties Antenna BaseNaked copper Operating Temp -20°C~+65°C Storage Temp-30°C~+75°C Antenna length 488MM Shenzhen Qisen Technology Co., Ltd. Main technical specifications VSWR address：4th Floor, No. 22 Anye Road, Henggang Street, Longgang District, Shenzhen telephone：0755-84864089 / 15989305086 website：www.qskjgf.com 5.Product drawing address：4th Floor, No. 22 Anye Road, Henggang Street, Longgang District, Shenzhen telephone：0755-84864089 / 15989305086 website：www.qskjgf.com Shenzhen Qisen Technology Co., Ltd. Shenzhen Qisen Technology Co., Ltd. 6.Test report 6.1、Microwave darkroom test schematic 2、Matching circuit No matching circuit was added. Shenzhen Qisen Technology Co., Ltd. address：4th Floor, No. 22 Anye Road, Henggang Street, Longgang District, Shenzhen telephone：0755-84864089 / 15989305086 website：www.qskjgf.com 6.2、Actual environment S11 test result Antenna standing wave ratio and return loss： Frequency （MHz） 240024502500 VSWR1.621.071.7 Return Loss-12.51-28.51-11.67 Shenzhen Qisen Technology Co., Ltd. address：4th Floor, No. 22 Anye Road, Henggang Street, Longgang District, Shenzhen telephone：0755-84864089 / 15989305086 website：www.qskjgf.com 6.3、Antenna matching test data FrequencyGainEffective （MHz）dBi（%） 2400 5.2459.8 2410 5.5464.1 2420 5.7467.24 2430 5.6866.61 2440 5.6366.84 2450 5.5667.28 2460 5.2264.31 2470 5.3764.58 2480 5.5266.09 2490 5.8171.13 2500 5.5769.35 Shenzhen Qisen Technology Co., Ltd. address：4th Floor, No. 22 Anye Road, Henggang Street, Longgang District, Shenzhen telephone：0755-84864089 / 15989305086 website：www.qskjgf.com 6.4、Antenna test 3D image 7.Product summary According to current antenna data, the matched antenna exhibits good electrical performance Shenzhen Qisen Technology Co., Ltd. address：4th Floor, No. 22 Anye Road, Henggang Street, Longgang District, Shenzhen telephone：0755-84864089 / 15989305086 website：www.qskjgf.com

Page 1 of 75 Report No.: UNIA23030812ER-61 FCC RADIO TEST REPORT FCC ID: 2BAL6430LYAZ Sample : 43 inch LCD display Trade Name : Rcstars Main Model : RCS-430LYAZ Additional Model : RCS-430ODLYAZ Report No. : UNIA23030812ER-61 Prepared for Rcstars Industrial (Shenzhen) Co., LTD 7/F, 2ND Bldg, Senyang High-Tech Park, N0.7 Road, Guangming High-Tech Park District, Shenzhen, China Prepared by Shenzhen United Testing Technology Co., Ltd. 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China Page 2 of 75 Report No.: UNIA23030812ER-61 TEST RESULT CERTIFICATION Applicant .............................. : Rcstars Industrial (Shenzhen) Co., LTD Address ................................. : 7/F, 2ND Bldg, Senyang High-Tech Park, N0.7 Road, Guangming High-Tech Park District, Shenzhen, China Manufacturer ........................ : Rcstars Industrial (Shenzhen) Co., LTD Address ................................. : 7/F, 2ND Bldg, Senyang High-Tech Park, N0.7 Road, Guangming High-Tech Park District, Shenzhen, China Product description Product .................................. : 43 inch LCD display Trade Name ........................... : Rcstars Model Name .......................... : RCS-430LYAZ, RCS-430ODLYAZ Test Methods ........................ : FCC Rules and Regulations Part 15 Subpart C Section 15.247 ANSI C63.10: 2013 This device described above has been tested by Shenzhen United Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of UNI, this document may be altered or revised by Shenzhen United Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. Date of Test Date (s) of performance of tests ............. : Mar. 20, 2023 ~ Mar. 31, 2023 Date of Issue .......................................... : Mar. 31, 2023 Test Result.............................................. : Pass Prepared by: Jason Ye/Editor Reviewer: Kelly Cheng/Supervisor Approved & Authorized Signer: Liuze/Manager Page 3 of 75 Report No.: UNIA23030812ER-61 Table of Contents Page 1 TEST SUMMARY 5 1.1 TEST PROCEDURES AND RESULTS 5 1.2 TEST FACILITY 6 1.3 MEASUREMENT UNCERTAINTY 7 1.4 ENVIRONMENTAL CONDITIONS 7 2 GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 CARRIER FREQUENCY OF CHANNELS 9 2.3 TEST MODE 9 2.4 DESCRIPTION OF THE TEST MODES 9 2.5 TEST SETUP 10 2.6 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 10 2.7 MEASUREMENT INSTRUMENTS LIST 11 3 CONDUCTED EMISSION 12 3.1 TEST LIMIT 12 3.2 TEST SETUP 12 3.3 TEST PROCEDURE 13 3.4 TEST RESULT 13 4 RADIATED EMISSION 16 4.1 TEST LIMIT 16 4.2 TEST SETUP 17 4.3 TEST PROCEDURE 18 4.4 TEST RESULT 18 5 OCCUPIED BANDWIDTH 41 5.1 TEST LIMIT 41 5.2 TEST PROCEDURE 41 5.3 EQUIPMENT USED 41 5.4 TEST RESULT 41 6 POWER SPECTRAL DENSITY 50 6.1 TEST LIMIT 50 6.2 TEST PROCEDURE 50 6.3 EQUIPMENT USED 50 6.4 TEST RESULT 50 7 PEAK OUTPUT POWER 59 Page 4 of 75 Report No.: UNIA23030812ER-61 Table of Contents Page 7.1 TEST LIMIT 59 7.2 TEST PROCEDURE 59 7.3 EQUIPMENT USED 59 7.4 TEST RESULT 59 8 OUT OF BAND EMISSIONS 60 8.1 TEST LIMIT 60 8.2 TEST SETUP 60 8.3 TEST PROCEDURE 60 8.4 TEST RESULT 60 9 ANTENNA REQUIREMENT 73 10 PHOTO OF TEST 74 10.1 RADIATED EMISSION 74 10.2 CONDUCTED EMISSION 75 Page 5 of 75 Report No.: UNIA23030812ER-61 1 TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS 1.1.1 Item FCC Rules Description Of Test Result 1 FCC Part 15.207 Conducted Emission Pass 2 FCC Part 15.209(a) Radiated Emission Pass 3 FCC Part 15.247(a)(2) Occupied Bandwidth Pass 4 FCC Part 15.247(e) Power Spectral Density Pass 5 FCC Part 15.247(b) Peak Output Power Pass 6 FCC Part 15.247(d) Out Of Band Emissions Pass 7 FCC Part 15.247(d) Conducted Spurious Emission Pass 8 FCC Part 15.203 Antenna Requirement Pass Page 6 of 75 Report No.: UNIA23030812ER-61 1.2 TEST FACILITY Test Firm : Shenzhen United Testing Technology Co., Ltd. Address : 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd,Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19.The testing quality system of our laboratory meets with ISO/IEC-17025 requirements. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: A2LA Certificate Number: 4747.01 The EMC Laboratory has been accredited by A2LA, and in compliance with ISO/IEC 17025:2017 General Requirements for testing Laboratories. FCC Registration Number: 0027159896 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. IC Registration Number: 21947 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. Page 7 of 75 Report No.: UNIA23030812ER-61 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement: Test Site Method Measurement Frequency Range U, (dB) UNI ANSI 9kHz ~ 150kHz 2.96 150kHz ~ 30MHz 2.44 B. Radiated Measurement: Test Site Method Measurement Frequency Range U, (dB) UNI ANSI 9kHz ~ 30MHz 2.50 30MHz ~ 1000MHz 4.80 1000MHz ~ 18000MHz 4.13 C. RF Conducted Method: Item Measurement Uncertainty Uncertainty of total RF power, conducted U c = ±0.8 dB Uncertainty of RF power density, conducted U c = ±2.6 dB Uncertainty of spurious emissions, conducted U c = ±2 % Uncertainty of Occupied Channel Bandwidth U c = ±2 % 1.4 ENVIRONMENTAL CONDITIONS During the measurement the environmental conditions were within the listed ranges: Tempe…

Text truncated - open the document above for the full version.

Model: RCS-430LYAZ Radiated Emission test Model: RCS-430LYAZ Conducted Emission test
