2BALY-HS6HS6 BLE Sensor

Efento Bluetooth Low Energy Loggers User manual V 1.5 13.01.2023 Efento Sp. z o.o Ul.Krupnicza 14/5 31-123 Kraków Product overview Product description EfentoBluetoothLowEnergyloggerstransmitthedataoverBluetoothLowEnergy interface,whatallowsquickandeasyconfigurationanddataaccesswithasmartphone. Moreover,devicescanworkwithEfentoGateway,whichsendsthedatatoEfentoCloud or any other cloud platform. Loggersarebatterypoweredandcanoperate(dependingonthesettings)upto5years without any maintenance. Technical data Battery1 x AA, 3.6V batteries, 2400 mAh Batteries lifetime up to 5 years Measured valuesEach logger can have up to three slots Each slot can measure: temperature (internal logger or probe), humidity (internal logger or probe), air pressure, VOC, open/close, pulse counter, leakage Measurement intervalConfigurable by user Measurement interval: 1 second – 10 days Memory60 000 measurements Communication protocolsBluetoothLowEnergy(forcommunicationwith smartphones or Efento Gateway) Indicators (troubleshooting) Alllogger’sinformationcanbeaccessedwithEfento mobile application MechanicsEnclosure material: ABS Size: 23.75 x 46.84 x 84.13 mm, 60 g Probeslength(forloggerwithprobesonly):bydefault 1 meter, other lengths are available on request Operating range: -35°C to +70°C Mounting:doublesideadhesivetapewithacrylicglue or 2 x M3 screws Certifications- Efento Sp. z o.o Ul.Krupnicza 14/5 31-123 Kraków Physical dimensions Logger types Efentologgersmeasurevariousphysicalvalues/environmentalconditions.Oneloggercan haveuptothreechannelswithaprobe/sensorassignedtoit.Themeasuredvalues include:temperature,humidity,airpressure,differentialpressure,open/close,pulse counters,VOC,waterleakage.Thefullanduptodatelistofsensortypescanbefoundat getefento.com.Thesettingsbelowarecommonforalltypesofsensors.IfEfentoLoggeris usedasapulsecounter,therearesomesettingsthataredifferent.Thisisdescribedin “Pulse counters” chapter. Efento Sp. z o.o Ul.Krupnicza 14/5 31-123 Kraków Table of contents Product overview2 Product description2 Physical dimensions3 Logger types3 Table of contents4 Operating modes5 Efento Gateway5 Efento mobile application5 Application installation5 Searching for loggers and displaying the data6 Warnings6 Application configuration7 Logger configuration7 Encryption8 Reading data from the logger memory9 Charts9 Exporting the data10 Statistics10 Pluse counters11 Connecting pulse counters11 Conversion ratio12 Pulse duration control13 Qualification and approvals13 European Union regulatory compliance13 Compliance with the RoHS directive13 NCC Taiwan compliance13 KCC South Korea compliance14 Efento Sp. z o.o Ul.Krupnicza 14/5 31-123 Kraków Operating modes Dependingonyourneeds,EfentoBluetoothloggerscanworkwithEfentogatewayorwith Efento mobile application. Efento Gateway EfentoGatewayisanetworkdevicethatsendsthedatafromEfentologgerstoEfento Cloudoranyothercloudplatform/server.EfentoGatewaycanreceiveandforwardtoa cloudplatformdatafromupto128wirelessloggers.Deviceisequippedwithalarge memorywhichstoresupto500000measurementsfromtheassignedloggers.Ifthere are any connectivity issues, it will automatically resend the missing data. EfentoGatewaysupportsmanysecurityfeatures,includingcommunicationencryption: bothbetweenloggersandgateway(AES128)andgatewayandserver(TLS/SSL), proxy server and custom HTTP headers authorisation. ThedevicemaybepoweredbyUSBpowersupply(5V,1A)orbyPoE(802.3af).Efento GatewaysendstheloggerdataoverRESTprotocol(HTTPSorHTTP).Therangeof EfentoGatewayisupto100metersintheopenspaceand20–30minthebuildings, depending on the building type (thickness and material of the walls, etc.). TolearnhowtoconfigureEfentoGatewaytosendthedatatoEfentoCloud,pleaserefer to our support section:getefento.com/support Efento mobile application EfentomobileapplicationallowsuserstointeractwithallEfentologgers(configuration, readingthemeasurements)andEfentoCloudplatform(accesstotheloggers measurementsandallcloudfunctionsthroughamobiledevice).Applicationisavailable freeofchargeinGooglePlay.Userscanswitchbetweentheapplicationmodes(nearby andcloud)atanytime.ApplicationworkswithmobiledevicesequippedwithAndroid5.0 or newer and Bluetooth Low Energy interface. Application installation DownloadandinstallEfentomobileapplicationfromGooglePlay.Theapplicationisfreeand availablefordevicesequippedwithBluetooth4.0andAndroid5.0ornewer.Afterlaunching the application, please set it to “Nearby devices” mode. Efento Sp. z o.o Ul.Krupnicza 14/5 31-123 Kraków Searching for loggers and displaying the data Removeprotectivetapefromthelogger'sbatteryholder. Opentheapplication,afterafewsecondstheapplication willautomaticallydetectallloggerswithinrangeofyour phone/tablet.Thelistshowsthenamesoftheloggers, theirserialnumbersandtheircurrentmeasurement values. Thepadlockiconontheleftsideofthelogger’sserial numbermeansthatcommunicationbetweenloggerand mobiledevicesisencrypted.Thepadlockicondisplayed insteadofthemeasurementvaluemeansthelogger communicationisencryptedandthemobiledeviceisnot abletodecryptthedata(loggercommunicationencryption is described in further parts of this user manual). Warnings The application notifies user of: ●Lowbatterylevel-aredbatteryiconnexttothelogger’sname.Aftertheicon appears,youhaveapproximately30daystoreplacethebattery.Intheeventof batterydischarge,datathathasalreadybeensavedintheloggermemorywillnotbe lost. After replacing the battery you will be able to read them from the logger memory ●Measurementproblem-exclamationmarkiconnexttothelogger’sname.Loggeris damagedandcan’ttakepropermeasurements(measurementsareoutofscale,or thedeviceisnotabletotakemeasurementsatall).Ifyouseethiswarning,contact Efento’s support team at help.efento.io. ●Loggerhasnotbeenrestarted-duringthefirststartup,werecommendresetting theloggertosetthemeasurementperiodandtime.Iftheloggerhasnotbeenreset, all measurements data will be lost after removing the battery. ●Softwareupdate-ifanewversionofthesoftwareisavailable,informationaboutit willappearundertheloggernameand…

Text truncated - open the document above for the full version.

Efento Sp. z o.o. To: Federal Communications Commission Date: 2023/04/12 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section 2.911(d)(5)(i) and Section 2.911(d)(5)(ii) (KDB 986446 D01 Covered Equipment) Section 2.911(d)(5)(i) Efento Sp. z o.o. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Section 2.911(d)(5)(ii) Efento Sp. z o.o. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Type of Equipment subject to FCC Certification: FCC ID: 2BALY-HS6 If you have any questions, please feel free to contact me. Contact Person: Piotr Szydlowski Position in the Company: CEO Date of Signature: 2023/04/12 ___________________________ Signatory (signature of the applicant)

EFENTO SP. Z O.O. Ul.Krupnicza 14/5 31-123 Kraków, POLAND Date: 04/12/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BALY-HS6 US Agent – Attestation Statement / Part 2.911(d)(7) EFENTO SP. Z O.O. certifies, that as of 04/12/2023, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2BALY-HS6. EFENTO SP. Z O.O., accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of EFENTO SP. Z O.O. for FCC ID: 2BALY-HS6. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: EFENTO SP. Z O.O. Designated Agent: FCC US Agent, LLC Company Representative: Piotr Szydlowski Designated Agent Representative: Tim Payne Signature: Signature:

Efento Sp. z o.o. Long/Short-term Confidentiality Request PHOENIX TESTLAB GmbH Date: 12 April 2023 Product Certification Königswinkel 10 D 32825 Blomberg FCC ID: 2BALY-HS6 To Whom It May Concerns, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we hereby request long-term confidential treatment of information accompanying this application as outlined below: ☒ Schematics ☐ Parts List ☒ Block Diagram ☐ Tune-Up Info ☒ Operational Description In addition we hereby request the following exhibits contained in this application to be temporarily (short-term confidentiality) withheld from the public disclosure ☒ for an initial period of 180 days ☐ until: ☐ not applicable ☐ External Photos ☐ Test Setup Photos ☐ Internal Photos ☐ Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. If you have any questions, please feel free to contact me. Yours sincerely, Signatory Printed Name: Piotr Szydlowski Position: Manager

Page 1 of 3 FCC ID: 2BALY-HS6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 3 FCC ID: 2BALY-HS6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 3 FCC ID: 2BALY-HS6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6

Page 1 of 1 FCC ID: 2BALY-HS6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L6.0cm x 2.0cm) Label Location HS6 BLE Sensor Model: HS6 FCC ID: 2BALY-HS6

Page 1 of 4 FCC ID: 2BALY-HS6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Page 2 of 4 FCC ID: 2BALY-HS6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Antenna Page 3 of 4 FCC ID: 2BALY-HS6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 4 FCC ID: 2BALY-HS6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7

Page 1 of 3 FCC ID: 2BALY-HS6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC RF Exposure Evaluation 1. Product Information FCC ID : 2BALY-HS6 Product name : HS6 BLE Sensor Test Model : HS6 Power Supply : DC 3.6V By ER14505 Battery, 2700mAh Hardware Version : HS6 Software Version : 6.x.x Bluetooth : 2402MHz ~ 2480MHz Channel Number : 40 channels for Bluetooth V5.0 (DTS) Channel Spacing : 2MHz for Bluetooth V5.0(DTS) Modulation Type : GFSK for Bluetooth V5.0 (DTS) Bluetooth Version : V5.0 Antenna Type : SMD PIFA Antenna Antenna Gain : 3.0dBi Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Portable Device 2. Evaluation method and Limit According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.“ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test Page 2 of 3 FCC ID: 2BALY-HS6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. When one of the following test exclusion conditions is satisfied for all combinations of simultaneous transmission configurations, further equipment approval is not required to incorporate transmitter modules in host devices that operate in the mixed mobile and portable host platform exposure conditions. The grantee is responsible for documenting this according to Class I permissive change requirements. Antennas that qualify for standalone SAR test exclusion must apply the estimated standalone SAR to determine simultaneous transmission test exclusion. a) The [∑ of (the highest measured or estimated SAR for each standalone antenna configuration, adjusted for maximum tune-up tolerance) / 1.6 W/kg] + [∑ of MPE ratios] is ≤ 1.0. b)The SAR to peak location separation ratios of all simultaneously transmitting antenna pairs operating in portable device exposure conditions are all ≤ 0.04, and the [∑ of MPE ratios] is ≤ 1.0. 3. Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices 4. Conducted Power Results <BT LE> Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 -3.26 19 2440 -2.29 39 2480 -3.06 5. Manufacturing Tolerance <BT LE> GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) -3.0 -2.0 -3.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 3 of 3 FCC ID: 2BALY-HS6 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 6. Evaluation Results 6.1 Standalone Evaluation Band/Mode f (GHz) Antenna Distance (mm) RF output power SAR Test Exclusion Threshold SAR Test Exclus…

Text truncated - open the document above for the full version.

UBX-23005563 - R01 C1-Public www.u-blox.com NINA-B112 Antenna Datasheet Datasheet Abstract The document specifies NINA-B112 antenna performance. NINA-B112 Antenna Datasheet - Datasheet UBX-23005563 - R01 Document information Page 2 of 8 C1-Public Document information Title NINA-B112 Antenna Datasheet Document type Datasheet Document number UBX-23005563 Revision and date R01 5-Apr-2023 Disclosure restriction C1-Public NINA-B112 Antenna Datasheet - Datasheet UBX-23005563 - R01 Contents Page 3 of 8 C1-Public Contents Document information ................................................................................................................................ 2 Contents .......................................................................................................................................................... 3 1 Product description .............................................................................................................................. 4 1.1 Characteristics ............................................................................................................................................ 4 1.2 Impedance .................................................................................................................................................... 4 1.3 Radiation patterns ...................................................................................................................................... 5 Related documents ...................................................................................................................................... 8 Revision history ............................................................................................................................................. 8 Contact ............................................................................................................................................................. 8 NINA-B112 Antenna Datasheet - Datasheet UBX-23005563 - R01 Contents Page 4 of 8 C1-Public 1 Product description 1.1 Characteristics The NINA-B112 metal sheet antenna also called PIFA, has the following characteristics. NINA-B112 (u-blox LILY antenna) Manufacturer ProAnt Gain +3 dBi Impedance 50 Ω Size (HxWxL) 3.0 x 3.8 x 9.9 mm Type PIFA Operation Temperature -40°C ~ +85°C Comment SMD PIFA antenna on NINA-B112. Should not be mounted inside a metal enclosure. Approval FCC, IC, RED, MIC, NCC, KCC, ANATEL, ACMA and ICASA 1.2 Impedance Figure 1: Impedance of NINA-B112 antenna. NINA-B112 Antenna Datasheet - Datasheet UBX-23005563 - R01 Contents Page 5 of 8 C1-Public 1.3 Radiation patterns The below radiation patterns show the relative output power of an EVB-NINA-B112 transmitting at 0 dBm output power. Both horizontal and vertical antenna polarizations were used. The NINA-B112 module was rotated 360° around the azimuth axis while being kept at 0°, 90° and 180° elevation as shown in Figure 2. Figure 2: Azimuth and elevation rotation axes relative to the measurement antenna NINA-B112 Antenna Datasheet - Datasheet UBX-23005563 - R01 Contents Page 6 of 8 C1-Public Figure 3: Radiation pattern of NINA-B112 kept at 0° elevation Figure 4: Radiation pattern of NINA-B112 kept at 90° elevation -25 -22 -19 -16 -13 -10 -7 -4 -1 2 5 0 dBm @2440 MHz, 0°elevation Horizontal [dB] Vertical [dB] 180° 0° 135° 315° 225° 270° 180° 90° 45° -25 -22 -19 -16 -13 -10 -7 -4 -1 2 5 0 dBm @2440 MHz, 90°elevation Horizontal [dB] Vertical [dB] 180° 0° 135° 315° 225° 270° 180° 90° 45° NINA-B112 Antenna Datasheet - Datasheet UBX-23005563 - R01 Contents Page 7 of 8 C1-Public Figure 5: Radiation pattern of NINA-B112 kept at 180° elevation -25 -22 -19 -16 -13 -10 -7 -4 -1 2 5 0 dBm @2440 MHz, 180°elevation Horizontal [dB] Vertical [dB] 180° 0° 135° 315° 225° 270° 180° 90° 45° NINA-B112 Antenna Datasheet - Datasheet UBX-23005563 - R01 Related documents Page 8 of 8 C1-Public Related documents [1] NINA-B112 Data sheet, doc. no. UBX-15019243 [2] NINA-B1 series system integration manual, doc. no. UBX-15026175 For regular updates to u-blox documentation and to receive product change notifications, register on our homepage (www.u-blox.com). Revision history Revision Date Name Comments R01 2023-04-05 hekf Initial release Contact For further support and contact information, visit us at www.u-blox.com/support.

Page 1 of 32 FCC ID: 2BALY-HS6 Report No.: LCSA031723036EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT For EFENTO SP. Z O.O. HS6 BLE Sensor Test Model: HS6 Prepared for : EFENTO SP. Z O.O. Address : Ul.Krupnicza 14/5 31-123 Kraków, POLAND Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : March 17, 2023 Number of tested samples : 2 Sample No. : A031723036-1, A031723036-2 Serial number : Prototype Date of Test : March 17, 2023 ~ March 25, 2023 Date of Report : March 27, 2023 Page 2 of 32 FCC ID: 2BALY-HS6 Report No.: LCSA031723036EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FCC CFR 47 PART 15 C(15.247) Report Reference No. ................. : LCSA031723036EA Date of Issue ................................... : March 27, 2023 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ........................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ........... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .......................... : EFENTO SP. Z O.O. Address ........................................... : Ul.Krupnicza 14/5 31-123 Kraków, POLAND Test Specification Standard .......................................... : FCC CFR 47 PART 15 C(15.247) Test Report Form No. ................... : LCSEMC-1.0 TRF Originator ................................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. ........................... : HS6 BLE Sensor Trade Mark ...................................... : Efento Test Model ...................................... : HS6 Ratings ............................................ : DC 3.6V By ER14505 Battery, 2700mAh Result ........................................... : Positive Compiled by: Supervised by: Approved by: Vera Deng/ Administrator Cary Luo/ Technique principal Gavin Liang/ Manager Page 3 of 32 FCC ID: 2BALY-HS6 Report No.: LCSA031723036EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC -- TEST REPORT Test Model............................... : HS6 EUT......................................... : HS6 BLE Sensor Applicant............................... : EFENTO SP. Z O.O. Address.................................. : Ul.Krupnicza 14/5 31-123 Kraków, POLAND Telephone............................... : / Fax.......................................... : / Manufacturer........................ : EFENTO SP. Z O.O. Address................................... : Ul.Krupnicza 14/5 31-123 Kraków, POLAND Telephone............................... : / Fax.......................................... : / Factory................................... : EFENTO SP. Z O.O. Address................................... : Ul.Krupnicza 14/5 31-123 Kraków, POLAND Telephone............................... : / Fax.......................................... : / Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSA031723036EA March 27, 2023 Date of issue Page 4 of 32 FCC ID: 2BALY-HS6 Report No.: LCSA031723036EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Revision History Report Version Issue Date Revision Content Revised By 000 March 27, 2023 Initial Issue --- Page 5 of 32 FCC ID: 2BALY-HS6 Report No.: LCSA031723036EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 6 1.1. DESCRIPTION OF DEVICE (EUT) ........................................................................................................................ 6 1.2. HOST SYSTEM CONFIGUR…

Text truncated - open the document above for the full version.

Page 1 of 32 FCC ID: 2BALY-HS6 Report No.: LCSA031723036EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT For EFENTO SP. Z O.O. HS6 BLE Sensor Test Model: HS6 Prepared for : EFENTO SP. Z O.O. Address : Ul.Krupnicza 14/5 31-123 Kraków, POLAND Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : March 17, 2023 Number of tested samples : 2 Sample No. : A031723036-1, A031723036-2 Serial number : Prototype Date of Test : …

Text truncated - open the document above for the full version.
