2BAO6-NF-U351Wireless Adapter

Fabricante:Shenzhen Sihaijialan Electronic Technology Co., Ltd. Model/HVIN: NF-U351, C F-970AX, WL-NA1605 Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device complies with Innovation, Science, and Economic Development Canad licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d' Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil nedoit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. L'appareil destiné à fonctionner dans la bande 5150–5250 MHz est uniquement destiné à une utilisation en intérieur afin de réduire le risque d'interférence nuisible aux systèmes mobiles par satellite utilisant le même canal. The device has been tested and comply with FCC/ISED SAR limits. Users can obtain FCC/ISED information on RF exposure and compliance, this equipment should be installed and operated with minimum distance 5mm between the radiator& your body. Cet appareil a été testé et est conforme aux limites SAR de la FCC/ISED. Les utilisateurs peuvent consulter les renseignements de la FCC/ISED concernant l'exposition aux radiofréquences et la conformité. Cet équipement doit être installé et utilisé à une distance minimale de 5 mm entre l'émetteur et le corps. Produttore Shenzhen Sihaijialan Electronic Technology Co., Ltd.

USB WiFi Dongle USB WiFi Dongle Model/HVIN: NF-U351, CF-970AX,WL-NA1605 Manufacture:Shenzhen Sihaijialan Electronic Technology Co., Ltd. Hersteller:Shenzhen Sihaijialan Electronic Technology Co., Ltd. Fabricant:Shenzhen Sihaijialan Electronic Technology Co., Ltd.

Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-SA Page 1 of 5 APPENDIX D RETURN LOSS&IMPEDANCE MEASUREMENT D2450V2 - SN:751 Extended Dipole Calibrations Per FCC KDB 865664 D01, calibration intervals of up to 3 years may be considered for reference dipoles when it is demonstrated that the SAR target, impedance and return loss of a dipole have remained stable according to the following requirements. 1. The measured SAR does not deviate more than 10% from the target on the calibration certificate. 2. The return-loss does not deviate more than 20% from the previous measurement and meets the required 20 dB minimum return-loss requirement. 3. The measurement of real or imaginary parts of impedance does not deviate more than 5Ω from the previous measurement. The following dipole was checked to pass the above 3 requirements to have 3-year calibration period from calibration date. Calibrated Equipment: Verification Date Equipment Model S/N Calibration Date Calibration Due Date 2024/09/25 Simulated Tissue Liquid Head HBBL600-10000V6 220406-1 Each Time SAM Twin Phantom SAM-Twin V5.0 1744 NCR NCR Network Analyzer E5071B MY42403851 2024/01/12 2025/01/11 Network Analyzer Calibration Kit 85033E MY53402696 NCR NCR 2025/09/24 Simulated Tissue Liquid Head HBBL600-10000V6 220406-1 Each Time SAM Twin Phantom SAM-Twin V5.0 1744 NCR NCR Network Analyzer E5071B MY42403851 2024/10/08 2025/10/07 Network Analyzer Calibration Kit 85033E MY53402696 NCR NCR Test Data: D2450V2 - SN:751 2450MHz Head Date of Measurement Return Loss (dB) Delta (%) Real Impedence(Ω) Delta (Ω) Imaginary Impedence(Ω) Delta (Ω) 2023/09/26 -25.2 / 53.9 / 4.18 / 2024/09/25 -27.5 9.1 50.2 3.7 4.23 0.05 2025/09/24 -26.5 5.2 49.7 4.2 4.7 0.52 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-SA Page 2 of 5 Calibrated By: Lance Li Calibrated By: Lance Li Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-SA Page 3 of 5 D5GHzV2 - SN:1301 Extended Dipole Calibrations Per FCC KDB 865664 D01, calibration intervals of up to 3 years may be considered for reference dipoles when it is demonstrated that the SAR target, impedance and return loss of a dipole have remained stable according to the following requirements. 1. The measured SAR does not deviate more than 10% from the target on the calibrationcertificate. 2. The return-loss does not deviate more than 20% from the previous measurement and meets the required 20 dB minimum return-loss requirement. 3. The measurement of real or imaginary parts of impedance does not deviate more than 5Ω from the previous measurement. The following dipole was checked to pass the above 3 requirements to have 3-year calibration period from calibration date. Calibrated Equipment: Verification Date Equipment Model S/N Calibration Date Calibration Due Date 2024/02/05 Simulated Tissue Liquid Head HBBL600-10000V6 220406-1 Each Time SAM Twin Phantom SAM-Twin V5.0 1744 NCR NCR Network Analyzer E5071B MY42403851 2024/01/12 2025/01/11 Network Analyzer Calibration Kit 85033E MY53402696 NCR NCR 2025/01/27 Simulated Tissue Liquid Head HBBL600-10000V6 2200808-2 Each Time SAM Twin Phantom SAM-Twin V5.0 1744 NCR NCR Network Analyzer E5071B MY42403851 2024/10/08 2025/10/07 Network Analyzer Calibration Kit 85033E MY53402696 NCR NCR Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-SA Page 4 of 5 Test Data: D5GHzV2-SN:1301 5250MHz Head Date of Measurement Return Loss (dB) Delta (%) Real Impedence(Ω) Delta (Ω) Imaginary Impedence(Ω) Delta (Ω) 2023/02/16 -32.6 / 48.1 / -1.23 / 2024/02/05 -29.1 10.7 53.1 5.00 -1.95 0.72 2025/01/27 -32.3 0.92 52.3 4.2 -0.90 0.33 5600MHz Head Date of Measurement Return Loss (dB) Delta (%) Real Impedence(Ω) Delta (Ω) Imaginary Impedence(Ω) Delta (Ω) 2023/02/16 -29.5 / 52.4 / 2.45 / 2024/02/05 -32.3 9.5 51.5 0.9 1.97 0.48 2025/01/27 -32.8 11.2 50.4 2 2.26 0.19 5750MHz Head Date of Measurement Return Loss (dB) Delta (%) Real Impedence(Ω) Delta (Ω) Imaginary Impedence(Ω) Delta (Ω) 2023/02/16 -30.1 / 51.4 / 2.84 / 2024/02/05 -30.6 1.7 49.0 2.40 2.76 0.08 2025/01/27 -32.6 8.3 50.2 1.20 2.33 0.51 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-SA Page 5 of 5 Calibrated By: Lance Li Calibrated By: Lance Li

Shenzhen Accurate Technology Co., Ltd. No.: 2504Z84275E-RF Test Photos Test Photos Page 1 / 3 Photo of Power Line Conducted Emission Measurement Shenzhen Accurate Technology Co., Ltd. No.: 2504Z84275E-RF Test Photos Test Photos Page 2 / 3 Radiated Spurious Emissions Test View (9kHz-30MHz) Radiated Spurious Emissions Test View (30MHz- 1GHz) Shenzhen Accurate Technology Co., Ltd. No.: 2504Z84275E-RF Test Photos Test Photos Page 3 / 3 Radiated Spurious Emissions Test View (1GH - 18GHz) Radiated Spurious Emissions Test View (Above 18GHz) ***** END *****

TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-R ProductName:Antenna SpecificationForApproval Date:2023.11.8 Version:1.0 客户名称 Customer： 客户料号 CustomerP/N： 腾祥料号 TXP/N：AN2457-SNA27664-R 规格描述 Description: TengxiangCheckedBy: 腾祥审核 CustomerApprovedBy: 客户审核 DRAWN 制作 TESTEDBY 检测 CHECKEDBY 审核 CHECKEDBY 审核 Q.C.DEPT. 品管 Q.C.DEPT. 品管 APPROVEDBY 核准 APPROVEDBY 核准 NO.53ShatouShaChongRoad,ChangAnTown,Guangdongprovince,China 中国广东省东莞市长安镇沙头区沙涌路53号 TEL:86-769-81873082FAX:86-769-82663788 http://www.tenxiang.cn TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-R ProductName:Antenna 1.Specification SamplePhoto A.ElectricalCharacteristics Frequency频率2400-2500MHz/5150-5850MHz/6000-7125MHz S.W.R.驻波比<=2.0/<=2.5 AntennaGain增益0.72dBi/2.83dBi/1.92dBi Polarization 极化方式Linear Impedance 阻抗50Ohm B.Material&MechanicalCharacteristics Material材质 C.Environmental StorageTemperature 存储温度 -40 ̊C~+80 ̊C OperationTemperature 工作温度 -40 ̊C~+80 ̊C AntennaColorStoragelife 天线颜色存储寿命 <2year White copper TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-R ProductName:Antenna 3.Antenna-SParameterTestData TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-R ProductName:Antenna 4.Antenna-RadiationPatternTestData 2400MHz 2450MHz 2500MHz TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-R ProductName:Antenna 5150MHz 5550MHz 5850MHz 6000MHz TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-R ProductName:Antenna 7125MHz 5.MechanicalDrawingSeeattachedfiles 22.08±0.3 5.50 *1.20 2.00 1.40 4.00 90° 3.50 0.30 B C D AN2457-SNA27664-R / 金属片右天线 1/1 A HC 2023.11.02 APPROVER DATE SIGN DESCRIPTION SCALE: APP BY Tolerance X.XX X.X X° TITLE: PART NO.: CUSTOMER P/N: CHK BY DES BY RF BY UNITS: mm REVISION: HFREACHRoHS CONFIDENTIAL *1.70 5.50 WJ 2023.11.02 DWF 2023.11.02 YCX 2023.11.02 50pcs/ PE bag 2000pcs/Carton 3. SEALING 。 2.PACKING 1 . Enter PE bag 。 AN2457-SNA27664-R 2023.11.02

Tengxiang Technology.Inc 东莞市腾祥电子有限公司 Product Number: AN2457-SNA27664-L Product Name: Antenna Page 1 Specification For Approval Date: 2023.11.8 Version: 1.0 客 户 名 称 Customer： 客 户 料 号 Customer P/N： 腾 祥 料 号 T X P/N：AN2457-SNA27664-L 规 格 描 述 Description : 2.4G/5G/6G 三频金属片天线 2.4G/5G/6G tri-band metal sheet antenna Tengxiang Checked By: 腾 祥 审 核 CustomerApproved By: 客 户 审 核 DRAWN 制 作 TESTED BY 检 测 CHECKED BY 审 核 CHECKED BY 审 核 Q.C.DEPT. 品 管 Q.C.DEPT. 品 管 APPROVED BY 核 准 APPROVEDBY 核 准 NO.53 Shatou ShaChong Road, ChangAn Town, Guangdong province, China 中国广东省东莞市长安镇沙头区沙涌路53号 TEL:86-769-81873082 FAX:86-769-82663788 http://www.tenxiang.cn Tengxiang Technology.Inc 东莞市腾祥电子有限公司 Product Number: AN2457-SNA27664-L Product Name: Antenna Page 2 Index: 1. Specification (规格) 2. Characteristics and Reliability Test (产品特性和可靠性测试标准) 3. Antenna - S Parameter Test Data (样品测试数据) 4. Antenna - Radiation Pattern Test Data (辐射模式测试数据) 5. Mechanical and Packing Drawing (图纸包装规范) Revision History（变更履历） RevisionDateChange NotificationDescription 1.02023.11.8 First Edition TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-L ProductName:Antenna Page 3 1. Specification SamplePhoto A. ElectricalCharacteristics Frequency频率2400-2500MHz/5150-5850MHz/6000-7125MHz S.W.R.驻波比<= 2. 0/<= 2. 5 AntennaGain增益-0.94 dBi/4.85 dBi/ 2.67 dBi Polarization 极化方式Linear Impedance 阻抗50 Ohm B. Material& MechanicalCharacteristics Material材质 洋白铜 White copper C. Environmental StorageTemperature 存储温度 - 40 ̊C ~ +80 ̊C OperationTemperature 工作温度 - 40 ̊C ~ +80 ̊C AntennaColor Storagelife 天线颜色存储寿命 < 2year TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-L ProductName:Antenna Page4 2.CharacteristicsandReliabilityTest TestItems 测试 项目 TestConditionandProcedure 测试方法 Requirements 要求Result 结果 1V.S.W.R. 电压驻波比 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 2Insertion Loss插入损 失 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 3Antenna Gain 天线增益 SetDUTonAntennaChamber;makeindividual calibrationtotest设置天线暗室参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 4Solderability 可焊性 GB/T2423.28-2005 Temp:260±5°C;Duration:5seconds温度260± 5°C;持续5秒 Tinevenlyonfull 上锡均匀饱满 PASS 5PullTest 拉力 Holdingwithindividualspecification;force appliedtoaxisofterminal.单独定义产品端子拉力 1.DirectiveDUTspecification 2.FrequencyTol.≤5% 符合待测物规范;频率偏移≤5% PASS 6Dimension 尺寸 Inspectionofdimension,color,material,package, surfaceprocess.检查尺寸,颜色,材料,包装,表面处理 DirectiveDUTspecification 符合待测物规范 PASS 7 SaltSpray盐 雾 GB/T2423.17-2008 Temp:35°C;RH:≥95%;NaClsolution:≥ 5%;Time:24H 温度35°C；湿度≥95%;盐水浓度≥5%；测试24H 1.NoVisualDamage 2.FrequencyTol.≤5% 无明显外观不良;频率偏移≤5% PASS 8RoHSWithReferencetoIEC62321:2008withflowchart 参考IEC62321测试流程 DirectiveRoHS2015/863/EU 符合RoHS2015/863/EU标准 PASS TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-L ProductName:Antenna Page5 3.Antenna-SParameterTestData TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-L ProductName:Antenna Page6 4.Antenna-RadiationPatternTestData 2400MHz 2450MHz 2500MHz TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-L ProductName:Antenna Page7 5150MHz 5550MHz 5850MHz 6000MHz TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2457-SNA27664-L ProductName:Antenna Page8 7125MHz 5.MechanicalDrawingSeeattachedfiles B C D AN2457-SNA27664-L / 金属片左天线 1/1 A HC 2023.11.02 APPROVER DATE SIGN DESCRIPTION SCALE: APP BY Tolerance X.XX X.X X° TITLE: PART NO.: CUSTOMER P/N: CHK BY DES BY RF BY UNITS: mm REVISION: HFREACHRoHS CONFIDENTIAL 22.08±0.3 5.50 *1.20 *1.70 2.00 1.40 4.00 90° 3.50 0.30 5.50 YCX 2023.11.02 DWF 2023.11.02 WJ 2023.11.02 50pcs/ PE bag 2000pcs/Carton 3. SEALING 。 2.PACKING 1 . Enter PE bag 。 AN2457-SNA27664-L 2023.11.02

Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 141 of 163 TR-4-E-R016 Chain 0 802.11ax20_2412MHz_RU_Full_Chain 0 802.11ax20_2437MHz_RU_Full_Chain 0 Chain 1 802.11ax20_2462MHz_RU_Full_Chain 0 802.11ax20_2412MHz_RU_Full_Chain 1 802.11ax20_2437MHz_RU_Full_Chain 1 802.11ax20_2462MHz_RU_Full_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 142 of 163 TR-4-E-R016 Chain 0 802.11ax40_2422MHz_RU_Full_Chain 0 802.11ax40_2437MHz_RU_Full_Chain 0 Chain 1 802.11ax40_2452MHz_RU_Full_Chain 0 802.11ax40_2422MHz_RU_Full_Chain 1 802.11ax40_2437MHz_RU_Full_Chain 1 802.11ax40_2452MHz_RU_Full_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 143 of 163 TR-4-E-R016 Duty Cycle Mode Antenna Test Frequency (MHz) Ton (ms) Ton+Toff (ms) Duty Cycle (%) Duty Cycle Factor(dB) 1/Ton (Hz) VBW Setting (kHz) 802.11b Chain 0 2437 8.179 8.440 96.91 0.14 122 0.200 Chain 1 2437 8.172 8.433 96.91 0.14 122 0.200 802.11g Chain 0 2437 1.346 1.598 84.23 0.75 743 1 Chain 1 2437 1.346 1.598 84.23 0.75 743 1 802.11n20 Chain 0 2437 1.142 1.395 81.86 0.87 876 1 Chain 1 2437 1.269 1.524 83.27 0.80 788 1 802.11n40 Chain 0 2437 0.572 0.826 69.25 1.60 1748 2 Chain 1 2437 0.631 0.884 71.38 1.46 1585 2 802.11ax20_RU_FULL Chain 0 2437 0.978 1.230 79.51 1.00 1022 2 Chain 1 2437 1.154 1.406 82.08 0.86 867 1 802.11ax40_RU_FULL Chain 0 2437 0.519 0.773 67.14 1.73 1927 2 Chain 1 2437 0.605 0.855 70.76 1.50 1653 2 Duty Cycle = Ton/(Ton+Toff)*100% Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 144 of 163 TR-4-E-R016 Chain 0 Chain 1 802.11b_2437MHz_Chain 0 802.11b_2437MHz_Chain 1 Chain 0 Chain 1 802.11g_2437MHz_Chain 0 802.11g_2437MHz_Chain 1 Chain 0 Chain 1 802.11n20_2437MHz_Chain 0 802.11n20_2437MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 145 of 163 TR-4-E-R016 Chain 0 Chain 1 802.11n40_2437MHz_Chain 0 802.11n40_2437MHz_Chain 1 Chain 0 Chain 1 802.11ax20_2437MHz_RU_FULL_Chain 0 802.11ax20_2437MHz_RU_FULL_Chain 1 Chain 0 Chain 1 802.11ax40_2437MHz_RU_FULL_Chain 0 802.11ax40_2437MHz_RU_FULL_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 146 of 163 TR-4-E-R016 Conducted Spurious Emission Chain 0 802.11b_2412MHz_Chain 0 802.11b_2412MHz_Chain 0 802.11b_2412MHz_Chain 0 802.11b_2437MHz_Chain 0 802.11b_2437MHz_Chain 0 802.11b_2462MHz_Chain 0 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 147 of 163 TR-4-E-R016 802.11b_2462MHz_Chain 0 802.11b_2462MHz_Chain 0 Chain 1 802.11b_2412MHz_Chain 1 802.11b_2412MHz_Chain 1 802.11b_2412MHz_Chain 1 802.11b_2437MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 148 of 163 TR-4-E-R016 802.11b_2437MHz_Chain 1 802.11b_2462MHz_Chain 1 802.11b_2462MHz_Chain 1 802.11b_2462MHz_Chain 1 Chain 0 802.11g_2412MHz_Chain 0 802.11g_2412MHz_Chain 0 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 149 of 163 TR-4-E-R016 802.11g_2412MHz_Chain 0 802.11g_2437MHz_Chain 0 802.11g_2437MHz_Chain 0 802.11g_2462MHz_Chain 0 802.11g_2462MHz_Chain 0 802.11g_2462MHz_Chain 0 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 150 of 163 TR-4-E-R016 Chain 1 802.11g_2412MHz_Chain 1 802.11g_2412MHz_Chain 1 802.11g_2412MHz_Chain 1 802.11g_2437MHz_Chain 1 802.11g_2437MHz_Chain 1 802.11g_2462MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 151 of 163 TR-4-E-R016 802.11g_2462MHz_Chain 1 802.11g_2462MHz_Chain 1 Chain 0 802.11n20_2412MHz_Chain 0 802.11n20_2412MHz_Chain 0 802.11n20_2412MHz_Chain 0 802.11n20_2437MHz_Chain 0 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 152 of 163 TR-4-E-R016 802.11n20_2437MHz_Chain 0 802.11n20_2462MHz_Chain 0 802.11n20_2462MHz_Chain 0 802.11n20_2462MHz_Chain 0 Chain 1 802.11n20_2412MHz_Chain 1 802.11n20_2412MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 153 of 163 TR-4-E-R016 802.11n20_2412MHz_Chain 1 802.11n20_2437MHz_Chain 1 802.11n20_2437MHz_Chain 1 802.11n20_2462MHz_Chain 1 802.11n20_2462MHz_Chain 1 802.11n20_2462MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 154 of 163 TR-4-E-R016 Chain 0 802.11n40_2422MHz_Chain 0 802.11n40_2422MHz_Chain 0 802.11n40_2422MHz_Chain 0 802.11n40_2437MHz_Chain 0 802.11n40_2437MHz_Chain 0 802.11n40_2452MHz_Chain 0 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 155 of 163 TR-4-E-R016 802.11n40_2452MHz_Chain 0 802.11n40_2452MHz_Chain 0 Chain 1 802.11n40_2422MHz_Chain 1 802.11n40_2422MHz_Chain 1 802.11n40_2422MHz_Chain 1 802.11n40_2437MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 156 of 163 TR-4-E-R016 802.11n40_2437MHz_Chain 1 802.11n40_2452MHz_Chain 1 802.11n40_2452MHz_Chain 1 802.11n40_2452MHz_Chain 1 Chain 0 802.11ax20_2412MHz_RU_Full_Chain 0 802.11ax20_2412MHz_RU_Full_Chain 0 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 157 of 163 TR-4-E-R016 802.11ax20_2412MHz_RU_Full_Chain 0 802.11ax20_2437MHz_RU_Full_Chain 0 802.11ax20_2437MHz_RU_Full_Chain 0 802.11ax20_2462MHz_RU_Full_Chain 0 802.11ax20_2462MHz_RU_Full_Chain 0 802.11ax20_2462MHz_RU_Full_Chain 0 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 158 of 163 TR-4-E-R016 Chain 1 802.11ax20_2412MHz_RU_Full_Chain 1 802.11ax20_2412MHz_RU_Full_Chain 1 802.11ax20_2412MHz_RU_Full_Chain 1 802.11ax20_2437MHz_RU_Full_Chain 1 802.11ax20_2437MHz_RU_Full_Chain 1 802.11ax20_2462MHz_RU_Full_Chai…

Text truncated - open the document above for the full version.

Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 117 of 163 TR-4-E-R016 APPENDIX Test Information: Sample No.: 3CBL-2 Test Date: 2026/01/19~2026/01/20 Test Site: RF Test Mode: Transmitting Tester: Cayde Hou Test Result: Pass Environmental Conditions: Temperature: (°C) 19.6~20.2 Relative Humidity: (%) 42~52 ATM Pressure: (kPa) 101.8 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 118 of 163 TR-4-E-R016 6dB Emission Bandwidth Mode Antenna Test Frequency (MHz) Result (MHz) Limit (MHz) Verdict 802.11b Chain 0 2412 11.251 ≥0.5 Pass 2437 11.251 ≥0.5 Pass 2462 10.250 ≥0.5 Pass Chain 1 2412 11.251 ≥0.5 Pass 2437 11.251 ≥0.5 Pass 2462 11.251 ≥0.5 Pass 802.11g Chain 0 2412 16.457 ≥0.5 Pass 2437 16.457 ≥0.5 Pass 2462 16.457 ≥0.5 Pass Chain 1 2412 16.497 ≥0.5 Pass 2437 16.497 ≥0.5 Pass 2462 16.457 ≥0.5 Pass 802.11n20 Chain 0 2412 17.698 ≥0.5 Pass 2437 17.698 ≥0.5 Pass 2462 17.658 ≥0.5 Pass Chain 1 2412 17.698 ≥0.5 Pass 2437 17.658 ≥0.5 Pass 2462 17.738 ≥0.5 Pass 802.11n40 Chain 0 2422 36.837 ≥0.5 Pass 2437 36.757 ≥0.5 Pass 2452 36.837 ≥0.5 Pass Chain 1 2422 36.757 ≥0.5 Pass 2437 36.757 ≥0.5 Pass 2452 36.757 ≥0.5 Pass 802.11ax20_RU_Full Chain 0 2412 19.099 ≥0.5 Pass 2437 19.099 ≥0.5 Pass 2462 19.099 ≥0.5 Pass Chain 1 2412 19.179 ≥0.5 Pass 2437 19.179 ≥0.5 Pass 2462 19.099 ≥0.5 Pass 802.11ax40_RU_Full Chain 0 2422 38.198 ≥0.5 Pass 2437 38.198 ≥0.5 Pass 2452 38.198 ≥0.5 Pass Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 119 of 163 TR-4-E-R016 Mode Antenna Test Frequency (MHz) Result (MHz) Limit (MHz) Verdict 802.11ax40_RU_Full Chain 1 2422 38.118 ≥0.5 Pass 2437 38.198 ≥0.5 Pass 2452 38.198 ≥0.5 Pass Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 120 of 163 TR-4-E-R016 Chain 0 802.11b_2412MHz_Chain 0 802.11b_2437MHz_Chain 0 Chain 1 802.11b_2462MHz_Chain 0 802.11b_2412MHz_Chain 1 802.11b_2437MHz_Chain 1 802.11b_2462MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 121 of 163 TR-4-E-R016 Chain 0 802.11g_2412MHz_Chain 0 802.11g_2437MHz_Chain 0 Chain 1 802.11g_2462MHz_Chain 0 802.11g_2412MHz_Chain 1 802.11g_2437MHz_Chain 1 802.11g_2462MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 122 of 163 TR-4-E-R016 Chain 0 802.11n20_2412MHz_Chain 0 802.11n20_2437MHz_Chain 0 Chain 1 802.11n20_2462MHz_Chain 0 802.11n20_2412MHz_Chain 1 802.11n20_2437MHz_Chain 1 802.11n20_2462MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 123 of 163 TR-4-E-R016 Chain 0 802.11n40_2422MHz_Chain 0 802.11n40_2437MHz_Chain 0 Chain 1 802.11n40_2452MHz_Chain 0 802.11n40_2422MHz_Chain 1 802.11n40_2437MHz_Chain 1 802.11n40_2452MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 124 of 163 TR-4-E-R016 Chain 0 802.11ax20_2412MHz_RU_Full_Chain 0 802.11ax20_2437MHz_RU_Full_Chain 0 Chain 1 802.11ax20_2462MHz_RU_Full_Chain 0 802.11ax20_2412MHz_RU_Full_Chain 1 802.11ax20_2437MHz_RU_Full_Chain 1 802.11ax20_2462MHz_RU_Full_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 125 of 163 TR-4-E-R016 Chain 0 802.11ax40_2422MHz_RU_Full_Chain 0 802.11ax40_2437MHz_RU_Full_Chain 0 Chain 1 802.11ax40_2452MHz_RU_Full_Chain 0 802.11ax40_2422MHz_RU_Full_Chain 1 802.11ax40_2437MHz_RU_Full_Chain 1 802.11ax40_2452MHz_RU_Full_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 126 of 163 TR-4-E-R016 99% Occupied Bandwidth Mode Antenna Test Frequency (MHz) 99% OBW (MHz) 802.11b Chain 0 2412 14.920 2437 14.880 2462 13.920 Chain 1 2412 14.880 2437 14.880 2462 14.920 802.11g Chain 0 2412 16.640 2437 16.640 2462 16.600 Chain 1 2412 16.640 2437 16.640 2462 16.640 802.11n20 Chain 0 2412 17.800 2437 17.720 2462 17.760 Chain 1 2412 17.720 2437 17.760 2462 17.760 802.11n40 Chain 0 2422 36.720 2437 36.640 2452 36.640 Chain 1 2422 36.640 2437 36.640 2452 36.720 802.11ax20_RU_Full Chain 0 2412 18.920 2437 18.960 2462 18.960 Chain 1 2412 19 2437 19 2462 19 802.11ax40_RU_Full Chain 0 2422 38.080 2437 37.920 2452 37.920 Chain 1 2422 38 2437 38 2452 38 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 127 of 163 TR-4-E-R016 Chain 0 802.11b_2412MHz_Chain 0 802.11b_2437MHz_Chain 0 Chain 1 802.11b_2462MHz_Chain 0 802.11b_2412MHz_Chain 1 802.11b_2437MHz_Chain 1 802.11b_2462MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 128 of 163 TR-4-E-R016 Chain 0 802.11g_2412MHz_Chain 0 802.11g_2437MHz_Chain 0 Chain 1 802.11g_2462MHz_Chain 0 802.11g_2412MHz_Chain 1 802.11g_2437MHz_Chain 1 802.11g_2462MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 129 of 163 TR-4-E-R016 Chain 0 802.11n20_2412MHz_Chain 0 802.11n20_2437MHz_Chain 0 Chain 1 802.11n20_2462MHz_Chain 0 802.11n20_2412MHz_Chain 1 802.11n20_2437MHz_Chain 1 802.11n20_2462MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 130 of 163 TR-4-E-R016 Chain 0 802.11n40_2422MHz_Chain 0 802.11n40_2437MHz_Chain 0 Chain 1 802.11n40_2452MHz_Chain 0 802.11n40_2422MHz_Chain 1 802.11n40_2437MHz_Chain 1 802.11n40_2452MHz_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 131 of 163 TR-4-E-R016 Chain 0 802.11ax20_2412MHz_RU_Full_Chain 0 802.11ax20_2437MHz_RU_Full_Chain 0 Chain 1 802.11ax20_2462MHz_RU_Full_Chain 0 802.11ax20_2412MHz_RU_Full_Chain 1 802.11ax20_2437MHz_RU_Full_Chain 1 802.11ax20_2462MHz_RU_Full_Chain 1 Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 132 of 163 TR-4-E-R016 Chain 0 802.11ax40_2422MH…

Text truncated - open the document above for the full version.

Note: This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA, or any agency of the Federal Government. The information marked “#” is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Customer model name, addresses, names, trademarks etc. are included but no need marked. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. Shenzhen Accurate Technology Co., Ltd. Floor 1, KuMaKe Building, Dongzhou Community, Guangming Street, Guangming District, Shenzhen, Guangdong, China. Tel: +86 755-26503290 Web: www.atc-lab.com Rev:A/4.0(2024/11/01) Page 1 of 163 TR-4-E-R016 TEST REPORT Applicant Name: Shenzhen Sihaijialan Electronic Technology Co., Ltd. Address: 301, Building 2, Hongxin Industrial Park, No. 1303, Guanguang Road, Xinlan Community,Guanlan Street, Longhua District, Shenzhen 518000 China Report Number: 2504Z84275E-RF-00A FCC ID: 2BAO6-NF-U351 Test Standard (s) FCC PART 15.247 Sample Description Product Name: Wireless Adapter Model No.: NF-U351 Trade Mark: N/A Date Received: 2025-11-04 Report Date: 2026-03-09 Test Result: The EUT complied with the standards above. Prepared and Checked By: Approved By: Roger.Ling Bob. Liao EMC Engineer EMC Engineer Shenzhen Accurate Technology Co., Ltd. Report No.: 2504Z84275E-RF-00A Rev:A/4.0(2024/11/01) Page 2 of 163 TR-4-E-R016 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ................................................................................................................ 4 GENERAL INFORMATION ............................................................................................................................ 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ........................................................................ 5 OBJECTIVE ................................................................................................................................................... 6 TEST METHODOLOGY .................................................................................................................................... 6 TEST FACILITY .............................................................................................................................................. 6 MEASUREMENT UNCERTAINTY ....................................................................................................................... 6 SYSTEM TEST CONFIGURATION ............................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ......................................................................................................... 7 EUT EXERCISE SOFTWARE AND POWER LEVEL # ............................................................................................ 7 SPECIAL ACCESSORIES AND EQUIPMENT MODIFICATIONS ............................................................................... 7 SUPPORT EQUIPMENT LIST AND DETAILS ....................................................................................................... 7 EXTERNAL I/O CABLE .................................................................................................................................... 8 BLOCK DIAGRAM OF TEST SETUP .................................................................................................................. 8 SUMMARY OF TEST RESULTS ...........................................................................…

Text truncated - open the document above for the full version.
