2BAP8TWPIR02tiiwee PIR sensor 02

Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever. tiiwee PIR sensor 02 User Manual Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever. USA - ENGLISH tiiwee PIR sensor 02 (For indoor use only) For Tiiwee Home Alarm System Introduction Congratulations with your Tiiwee passive infrared detector (PIR). It is compatible with the components of the Tiiwee Home Alarm System and can be wirelessly connected to all Tiiwee 433 MHz Alarm Units (available separately). This sensor applies digital dual-core fuzzy logic control processing technology and intelligent analysis algorithms to prevent false alarms. It also features various settings to adjust the PIR sensor to your personal situation. Important: This sensor has been programmed to respect a 5 second delay between 2 signals. This is intentional and will save battery power. contents 1 x tiiwee PIR sensor 02 3 x batteries, 1.5V AAA-type, alkaline 1 x ball-joint mount 2 x screws 1 x instructions for use Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever. Product Overview and activation Open the back panel to insert the batteries. Please respect the correct polarity. Now, close the back panel again. Slide the ball joint in place until it locks in place and attach the wall mount on the ball joint. Your PIR sensor is now ready to be installed on the mount. General installation guidelines Avoid positions that are close to a window, air conditioners, fluorescent lights, heaters, refrigerators, stoves, and direct sunlight and other places where temperature would change rapidly and air flow is high. If there are two detectors in the same detecting range, please adjust the position to avoid interference and false alarms. Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever. Attach the detector to the bracket, and change the detecting angle and distance by adjusting the installation height and the bracket. It is advised to install the device at a height of approximately 2 meters. IMPORTANT: The Infrared detector is sensitive to a human’s vertical movement. It is less sensitive to horizontal movements. Therefore, it is advised to aim the device at a 90 degrees’ angle to a person’s walking direction. Test 1. After the installation, turn the switch to ON. Now, walk or move in front of the PIR sensor at a distance between 3 and 6 meters. Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever. 2. The Indicator light should light up once. Note the 5 second delay between 2 signals. This is normal and intentional to save battery power. 3. If needed, adjust the detector angle to get the desired detection range. When the detector indicator flashes • LED flashes once: A signal is detected and the detector sends a signal to the Alarm unit. • LED continuously on: Low-voltage indication, please change the battery as soon as possible. Connecting the PIR Sensors to an Alarm Siren This PIR sensor is compatible with the Tiiwee Home Alarm System. Connect it wirelessly with one of the 433 MHz Alarm Units. IMPORTANT: The instructions for pairing the PIR sensor with the Tiiwee Home Alarm System are included with the Alarm units or can be consulted on our website www.tiiwee.com or one of our Youtube channels. Advanced features The Tiiwee PIR sensor is equipped with some additional features to allow you to adjust the device to your specific needs. In order to access these functions, remove the screw at the top of the sensor. Then separate the 2 parts (front and back part) by using an appropriate device (screw driver i.e.). Now you can see the circuit board with the 2 switches. Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever. 1. The Indicator light can be switched off to save battery power (“LED OFF position). Off course, in this mode an alarm signal will still be sent to the Alarm Unit or the PIR Motion Sensor Alarm. However, please note that the low battery indication is switched off in this setting. 2. A waiting time of 5 minutes between detections can be set saving battery power (“5 Min” vs “5s” switch). The 5-minute waiting period can be used when your PIR sensor is meant to result in a strong Siren alarm. This mode however is not advised when you selected a Chime sound setting on your Alarm unit. Mode Setting The factory settings are “5s” and “Led On”. This means that the sensor will respect a 5-seconds waiting time between 2 signals and that the LED Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever. indicator light will always flash if movement is detected. These are the most commonly used settings. 1. If both switches are set to the ON position as shown in picture 1, the LED will flash each time a movement is detected. After each signal, a 5 second waiting time is set as a standard to allow a person to pass without triggering a signal continuously. 2. If the top switch is set to Off the detector will respect a 5-minute delay before it will become active again. This is a power saving mode. This setting can perfectly be used with a loud alarm (which will sound continuously and loud). A Chime setting on the Alarm unit is not advised with this delay. 3. If the lower switch is set to Off, the Led light will not flash each time a signal is detected. This can be convenient for saving battery power. 4. If both switches are in the Off position as shown in Figure 2, the PIR sensor will respect a 5-minute interval between 2 different signals nor will the LED window flash. Low-voltage Reminder Function:…
