2BAP9-HDA000007Electric Bike

Shenzhen winfeng Intelligent Manufacturing Co. , Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: May 26, 2023
Application Purpose: Original Equipment
Date of Application: May 25, 2023
Equipment Note: Electric Bike
Frequency Range: 2402.00000000 - 2480.00000000
Company: Shenzhen winfeng Intelligent Manufacturing Co. , Ltd.
Country: China
