2BAPD-CK98Bluetooth mechanical keyboard

132.00 mm 90.00 mm Manufacturer: Dieyun Innovation Technology Co., LTD., No. 20, Sanjiang Industrial Zone, Hengli Town, Dongguan city List of Contents: Transparent mechanical keyboard ×1 Air spring data cable x 1 Instruction Manual x 1 CK 98 Transparent mechanical keyboard Double head key extractor×1 Case of ammunition x 1 12 Quick Start Guide If you are a MAC user, flip the switch to switch to a MAC system （After the conversion is successful, the MAC is displayed in the lower left corner of the default screen） If you are a WIN user, please flip the system conversion switch to WIN （After the conversion is successful, the lower left corner of the screen is WIN by default） WIN MAC 1 2 1 Power switch (built-in lithium battery) 2 System transfer switch 13 1.Connect to Bluetooth Press fn+1/2/3 and then hold down fn+1/2/3 Put the keyboard into pairing mode, The keyboard pairing name is CK98 5.0/CK98 3.0 Long press 1/2/3 button and the white light will flash.After the match is successful, the 1/2/3 button will keep on for 2 seconds and restore the backlight(By default, the Bluetooth identifier is at the lower right corner of the screen.) MAC 2.Connecting wire Long press fn+5 to put the keyboard into wired mode Long press the back 5 button and the white light will flash. After the pairing is successful, the 5 keys will be on for 2 seconds and the backlight will be restoredBy default, the lower right corner of the screen is WIN 14 4.Changing lamp effect fn+INS Adjust the lighting mode fn+DEL Switching monochrome colors fn+PGUP Turn the backlight off/on 15 7.Storage and use environment 1.Storage temperature: -20°C~+70°C 2.Operating temperature: -20°C~+60°C 3.Storage humidity: The relative humidity in the non-condense state is 30%-95%RH 8.Compatible system: Supported operating system: ANDROID/ISO/Win XP/Win7/Win8/Win10/MAC (default WIN system) 16 5.Charging Charging status The charging indicator animation is displayed in the upper right corner of the default screen *1,Lamp working current 250MA Sustainable time about 15 hours (working all the time) *2,Off working current 40MA Sustainable time about 80 hours (always working) *3,Standby current 0.5MA Standby time about 180 days *4,Enter standby mode. Press any key to start the keyboard and enter working mode. 6.Back to the 1.Keyboard startup defaults to the last connected device 2.fn+1 (fn+2, fn+3) White slow flash connection *To do this, the keyboard must have been paired with the device WIN 17 Fn Combined Function Keys (MAC) Reset function F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 Press Bluetooth 1 to connect back, Long press Bluetooth 1 to pair Short press Bluetooth 2 to connect back,Long press Bluetooth 2 to pair Tap Bluetooth 3 to connect back, Long press Bluetooth 3 to pair Short press 2.4G to connect back, Long press 2.4G to pair Wired mode Querying Electricity Quantity Main backlight effect switch 18 Fn Combined Function Keys (MAC) END Backlight brightness + Backlight brightness - Backlight speed - Backlight speed + Backlight speed + Querying the Display Information The home screen goes to the Custom screen HOME PAUSE 19 Fn Combination key (WIN system) Press and hold for 3s to restore factory Settings Multimedia Reduction in volume Volume plus mute The last song Next song Pause play stop mail Web page The computer calculator Press Bluetooth 1 to connect back, Long press Bluetooth 1 to pair Short press Bluetooth 2 to connect back,Long press Bluetooth 2 to pair Tap Bluetooth 3 to connect back, Long press Bluetooth 3 to pair Short press 2.4G to connect back, Long press 2.4G to pair Wired mode Querying Electricity Quantity Main backlight effect switch 20 END HOME PAUSE Backlight brightness + Backlight brightness - Backlight speed - Backlight speed + Backlight speed + Querying the Display Information The home screen goes to the Custom screen Fn Combination key (WIN system) 21 FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

Shenzhen Diyun Interlligent Co.,LTD 309-10，Building 512,Bagualing Industrial Zone,No.33 Bagualing Road ,Hualin Community,Yuanling Street,Futian District,Shenzhen The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 04/20/2023 U.S. Agent Designation Shenzhen Diyun Interlligent Co.,LTD acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BAPD-CK98): Name and company of U.S. agent: GSS SERVICE INC Physical U.S. address of agent: 6547 N Academy Blvd #2266 Colorado Springs Co 80918 USA FRN of U.S. agent: 0033402082 Email address of U.S. agent: [email protected] GSS SERVICE INC acknowledges their obligation to accept service of process on behalf of Shenzhen Diyun Interlligent Co.,LTD Shenzhen Diyun Interlligent Co.,LTD with the FRN 0033589656 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). Sincerely, Signature Signature [Name]: Jianya Sun [Name of U.S. agent]: Michoux Logan [Title]: Manager [Title of U.S. agent]: PM [Company]: Shenzhen Diyun Interlligent Co.,LTD [Company of U.S. agent]: GSS SERVICE INC 48_[mo del] US_Agent_2.911(d)(7) - U, V04

Sincerely, Name/Title： Jianya Sun/Manager Company: Shenzhen Diyun Interlligent Co.,LTD Address: 309-10, Building 512, Bagualing Industrial Zone, No.33 Bagualing Road, Hualin Community, Yuanling Street, Futian District, Shenzhen China Phone: 13861717578 Fax: N/A E-Mail: [email protected]

FCC ID: 2BAPD-CK98 External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BAPD-CK98 Photo 4 Photo 5 Photo 6 FCC ID: 2BAPD-CK98 Photo 7

Label and Location Size: L: 4.0cm*W: 3.0cm Label and Location Model No.: CK98 FCC ID : 2BAPD-CK98 Caution : This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2BAPD-CK98 Internal Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BAPD-CK98 Photo 4 Photo 5 Photo 6 BLE PCB antenna

RF Exposure evaluation FCC ID: 2BAPD-CK98 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) 0.0 -2.0 -2.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.450 5 1.0 1.2589 0.3941<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

1. Antenna Description: Antenna type PCB antenna Model CK98 Frequency range 2400-2500MHz Manufacturer Shark Wisdom (Shenzhen) Technology Co., LTD ANT Peak Gain 1.58 dBi 2. Antenna Photo: 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern
