Shenzhen Hengyifangli Technology Co., Ltd. East and West 01 of 2nd floor,BLDG 2, Hongye IND Park Hangcheng Str., Bao'an, Shenzhen, China The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023-04-12 U.S. Agent Designation Shenzhen Hengyifangli Technology Co., Ltd. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BAPR-M100): Name and company of U.S. agent: Fotoprous LLC Physical U.S. address of agent: 492C Cedar Lane #545, Teaneck, NJ 7666 United States FRN of U.S. agent: Email address of U.S. agent: 0033523242 [email protected] Fotoprous LLC acknowledges their obligation to accept service of process on behalf of Shenzhen Hengyifangli Technology Co., Ltd. Shenzhen Hengyifangli Technology Co., Ltd. accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). Sincerely, Signature Applicant Name: Xiaojie Song Title: Manager Applicant Company: Shenzhen Hengyifangli Technology Co., Ltd. Signature U.S. Name: NC Li Title: PM U.S. Company: Fotoprous LLC 48_[mo del] US_Agent_2.911(d)(7) - U, V02

Sincerely, Name/Title： Xiaojie Song /Manager Company: Shenzhen Hengyifangli Technology Co., Ltd. Address: East and West 01 of 2nd floor, BLDG 2, Hongye IND Park Hangcheng Str., Bao'an, Shenzhen China Phone: 15361488636 Fax: N/A E-Mail: [email protected]

FCC ID: 2BAPR-M100 External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BAPR-M100 Photo 4 Photo 5 Photo 6 FCC ID: 2BAPR-M100 Photo 7

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location FCC ID : 2BAPR-M100

FCC ID: 2BAPR-M100 Internal Photos of the EUT Photo 1 Photo 2 Photo 3 433 Built-in spring antenna FCC ID: 2BAPR-M100 Photo 4 Photo 5

1. Antenna Description: Antenna type Built-in spring antenna Model M100 Frequency range 433.137MHz Manufacturer Shenzhen Hengyifangli Technology Co., Ltd. Gain 0.00 dBi 2. Antenna Photo: Length:17.95mm diameter:3.99mm
