2BARM-LZT-10Outdoor battery camera 2K

Hangzhou Fanhan Technology Co.,Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Sep 25, 2023
Application Purpose: Original Equipment
Date of Application: Sep 25, 2023
Equipment Note: Outdoor battery camera 2K
Frequency Range: 2412.00000000 - 2462.00000000
Company: Hangzhou Fanhan Technology Co.,Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help.

Attestation Statements

HangzhouFanhanTechnologyCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 9/26/23 U.S.AgentDesignation HangzhouFanhanTechnologyCo.,Ltd.acknowledgestheirconsentforthefollowingcontactlocatedinthe UnitedStatestoactastheiragentforserviceofprocessfortheequipmentforwhichauthorizationissought(FCC ID:2BARM-LZT-10): NameandcompanyofU.S.agent:InlandProductsInc. PhysicalU.S.addressofagent:1410E.WalnutAvenueFullerton,CA92831UniedStates FRNofU.S.agent:0028849883 EmailaddressofU.S.agent:[email protected] InlandProductsInc.acknowledgestheirobligationtoacceptserviceofprocessonbehalfofHangzhouFanhan TechnologyCo.,Ltd. HangzhouFanhanTechnologyCo.,Ltd.withtheFRN0033617473acceptsitsobligationtomaintainanagent forserviceofprocessintheUnitedStatesfornolessthanoneyearaftereitherthegranteehaspermanently terminatedallmarketingandimportationoftheapplicableequipmentwithintheU.S.,ortheconclusionofany Commission-relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheverislater. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirementslistedunder§ 2.911(d)(7). TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB 986446D01. Anexpirationdateforthisletterdoesnotexist.IncasetheU.S.agentchanges,thegranteeisobligatedtonotify theFCCwithin30daysviathegrantingTCB. Sincerely, Signature JieLi President HangzhouFanhanTechnologyCo.,Ltd. Signature MrMichaelWang President InlandProductsInc. 4 8 _ [ m o d e l ] U S _ A g e n t _ 2 . 9 1 1 ( d ) ( 7 ) - U , V 0 5

External Photos

ID Label/Location Info

Page1of1FCCID:2BARM-LZT-10 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity LABELANDLOCATION (Size:L4.0cmx3.0cm) LabelLocation Outdoorbatterycamera2K Model:LZT-10 FCCID:2BARM-LZT-10

Internal Photos

RF Exposure Info

Page 1 of 5 FCCID:2BARM-LZT-10 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCCRFExposureEvaluation 1.ProductInformation FCCID2BARM-LZT-10 ProductnameOutdoorbatterycamera2K TestModelLZT-10 PowerSupply Input:5V1A ForACAdapterInput:100-240V~,50/60Hz,0.15A AdapterOutput:5.0V1.0A DC3.6VbyRechargeableLi-ionBattery,2200mAh HardwareVersionMB(V1.1)+IRLED(V1.0)+PIR(V1.2) SoftwareVersion5.20.28.P1 2.4GWIFIFrequencyRange2412MHz~2462MHz ChannelSpacing5MHz ChannelNumber11Channelsfor20MHzbandwidth(2412~2462MHz) ModulationTypeIEEE802.11b:DSSS(CCK,DQPSK,DBPSK) IEEE802.11g:OFDM(64QAM,16QAM,QPSK,BPSK) IEEE802.11n:OFDM(64QAM,16QAM,QPSK,BPSK) AntennaDescriptionFPCAntenna,1.86dBi(Max.) ExposurecategoryGeneralpopulation/uncontrolledenvironment EUTTypeProductionUnit DeviceTypeMobileDevices Page 2 of 5 FCCID:2BARM-LZT-10 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 2.EvaluationMethod SystemsoperatingundertheprovisionsofFCC47CFRsectionshallbeoperatedinamannerthatensures thatthepublicisnotexposedtoradiofrequencyenergylevelinexcessoftheCommission’sguidelines. Inaccordancewith47CFRFCCPart2SubpartJ,section2.1091thisdevicehasbeendefinedasmobile devicewherebyadistanceof0.2mnormallycanbemaintainedbetweentheuserandthedevice,andbelow RFPermissibleExposurelimitshallcomplywith. InaccordancewithKDB447498D01forSimultaneoustransmissionMPEtestexclusionapplieswhenthesum oftheMPEratiosforallsimultaneoustransmittingantennasincorporatedinahostdevice,basedonthe calculated/estimated,numericallymodelledormeasuredfieldstrengthsorpowerdensity,is≤1.0.TheMPE ratioofeachantennaisdeterminedattheminimumtestseparationdistancerequiredbytheoperating configurationsandexposureconditionsofthehostdevice,accordingtotheratiooffieldstrengthsorpower densitytoMPElimit,atthetestfrequency.Eitherthemaximumpeakorspatiallyaveragedresultsfrom measurementsornumericalsimulationsmaybeusedtodeterminetheMPEratios.Spatialaveragingdoesnot applywhenMPEisestimatedusingsimplecalculationsbasedonfar-fieldplane-waveequivalentconditions. Theantennainstallationandoperatingrequirementsforthehostdevicemustmeettheminimumtest separationdistancesrequiredbyallantennas,inbothstandaloneandsimultaneoustransmissionoperations, tosatisfycompliance. 3.Limit 3.1ReferEvaluationMethod ANSIC95.1–1999:IEEEStandardforSafetyLevelswithRespecttoHumanExposuretoRadioFrequency ElectromagneticFields,3kHzto300GHz. FCCKDBpublication447498D01General1RFExposureGuidancev06:MobileandPortableDevicesRF ExposureProceduresandEquipmentAuthorizationPolicies. FCCCFR47part11.1310:Radiofrequencyradiationexposurelimits. FCCCFR47part22.1091:Radiofrequencyradiationexposureevaluation:mobiledevices 3.2Limit LimitsforMaximumPermissibleExposure(MPE)/ControlledExposure Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) PowerDensity (mW/cm²) AveragingTime (minute) LimitsforOccupational/ControlledExposure 0.3–3.0 3.0–30 30–300 300–1500 1500–100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100)* (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 LimitsforMaximumPermissibleExposure(MPE)/UncontrolledExposure Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) PowerDensity (mW/cm²) AveragingTime (minute) LimitsforOccupational/ControlledExposure 0.3–3.0 3.0–30 30–300 300–1500 1500–100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100)* (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequencyinMHz *=Plane-waveequivalentpowerdensity Page 3 of 5 FCCID:2BARM-LZT-10 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 4.MPECalculationMethod PredicationofMPElimitatagivendistance Equationfrompage18ofOETBulletin65,Edition97-01 S=PG/4πR² Where:S=powerdensity P=powerinputtoantenna G=powergainoftheantennainthedirectionofinterestrelativetoanisotropicradiator R=distancetothecenterofradiationoftheantenna 5.AntennaInformation EUTcanonlyuseantennascertificatedasfollowsprovidedbymanufacturer; Internal/ ExternalIdentification Antennatypeand antennanumber Operatefrequency band Maximumantenna gain Note InternalFPCAntenna2412MHz-2462MHz1.86dBi(Max.)WIFIAntenna Page 4 of 5 FCCID:2BARM-LZT-10 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6.ConductedPower <2.4GWIFI> ModeChannelFrequency(MHz) MaxConductedPower (dBm) IEEE802.11b 1241214.39 6243714.68 11246214.84 IEEE802.11g 1241214.07 6243714.48 11246215.37 IEEE802.11n HT20 1241214.06 6243714.91 11246215.21 7.ManufacturingTolerance <2.4GWIFI> 11B(Peak) ChannelChannel1Channel6Channel11 Target(dBm)14.014.014.0 Tolerance±(dB) 1.01.01.0 11G(Peak) ChannelChannel1Channel6Channel11 Target(dBm)14.0 14.015.0 Tolerance±(dB)1.01.01.0 11N20SISO(Peak) ChannelChannel1Channel6Channel11 Target(dBm) 14.014.015.0 Tolerance±(dB)1.01.01.0 Page 5 of 5 FCCID:2BARM-LZT-10 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 8.MeasurementResults 8.1StandaloneMPE AsdeclaredbytheApplicant,theEUTisawirelessdeviceusedinafixapplication,atleast20cmfromany bodypartoftheuserornearbypersons;fromthemaximumEUTRFoutputpower,theminimumseparation distance,r=20cm,aswellasthegainoftheusedantennare…

Text truncated - open the document above for the full version.

Test Report

DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 1/8 APPROVALSHEET CUSTOMERNAME:PUWELL PRODUCTNAME: 2.4G Inner Antenna L=95mm+terminal / Small camera CUSTOMERP/N: UB01C95F3D1800Model:A PRODUCERNAME：Youbi DongguanYoubiElectronicsCo.,LTD，Room101,Building2,No.9, PRODUCERADDRESS：XinfaRoad,LinVillage,TangxiaTown，Guangdongprovince MANUFACTURER SIGNATURE CUSTOMER SIGNATURE CHECKEDBY: APPROVEDBY: DATE: 2023/06/15 DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 2/8 1．Specificationtable: ElectricalSpecification DesignSpecifications Types AntennaTypeInnerantenna OperatingFrequency2400-2500MHz PeakGain 1.86 AverageEfficiency 39.77% VSWR ＜ 3 PolarizationLinear AxialRatio ＼ RadiationpatternOmnidirectional Impedance 50ohm Powerhandling1W InterfaceCable+terminal Overalldimensions20*13.9*0.2mm OperatingTemp.-20°C~+70°C StorageTemp.-20°C~+70°C DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 3/8 3.MechanicalSpecification DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 4/8 3.2：Darkroom2D、3DRaditationPattern DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 5/8 3.2.1Efficiencyandgain Frequency/MHzEfficiency/%Gain/dBi 240040.551.35 241040.931.53 242039.171.32 243042.761.84 244041.881.86 245040.741.66 246040.461.83 247037.51.14 248037.411.18 249038.550.87 250037.580.78 DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 6/8 3.2.2.1Darkroom2D 、 3DRaditationPattern DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 7/8 2400MHz2450MHz 2500MHzPhi0 Phi90Theta90 DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 8/8 4:Antennaposition ANT1 TIS：Theloweredgeoftheantennashould beasflushaspossiblewiththeupperedge ofthebatterytopreventinterferencefrom theinstallationoftheupperstructure

Test Report

Page1of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity AppendixA RFTestDatafor2.4GWIFI(ConductedMeasurement) ProductName:Outdoorbatterycamera2K TestModel:LZT-10 EnvironmentalConditions Temperature: 23.8C RelativeHumidity:52.1% ATMPressure:100.0kPa TestEngineer:PaddiChen Supervisedby:LingZhu Page2of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.1DTSBandwidth TestResult TestModeAntennaFreq(MHz) DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11BAnt1 24129.6002407.4402417.0400.5PASS 24379.6002431.9602441.5600.5PASS 24629.1602457.4002466.5600.5PASS 11GAnt1 241216.3202403.8402420.1600.5PASS 243716.3202428.8402445.1600.5PASS 246216.3202453.8402470.1600.5PASS 11N20SISOAnt1 241216.8802403.6402420.5200.5PASS 243716.6802428.6402445.3200.5PASS 246216.6802453.6802470.3600.5PASS Page3of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 Page4of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11G_Ant1_2412 11G_Ant1_2437 Page5of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11G_Ant1_2462 11N20SISO_Ant1_2412 Page6of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 Page7of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Page8of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.2Maximumconductedoutputpower TestResultPeak TestModeAntennaFreq(MHz)PeakPower[dBm] Conducted Limit[dBm] Verdict 11BAnt1 241214.39≤30.00PASS 243714.68≤30.00PASS 246214.84≤30.00PASS 11GAnt1 241214.07≤30.00PASS 243714.48≤30.00PASS 246215.37≤30.00PASS 11N20SISOAnt1 241214.06≤30.00PASS 243714.91≤30.00PASS 246215.21≤30.00PASS Page9of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.3Maximumpowerspectraldensity TestResult TestModeAntennaFreq(MHz) Result [dBm/3kHz] Limit [dBm/3kHz] Verdict 11BAnt1 2412-11.36≤8.00PASS 2437-8.4≤8.00PASS 2462-8.35≤8.00PASS 11GAnt1 2412-17.76≤8.00PASS 2437-17.56≤8.00PASS 2462-17.24≤8.00PASS 11N20SISOAnt1 2412-17.4≤8.00PASS 2437-17.16≤8.00PASS 2462-16.38≤8.00PASS Page10of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 Page11of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11G_Ant1_2412 11G_Ant1_2437 Page12of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11G_Ant1_2462 11N20SISO_Ant1_2412 Page13of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 Page14of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Page15of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSC…

Text truncated - open the document above for the full version.

Test Report

Page23of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11G_Ant1_2412_1000~26500 11G_Ant1_2437_30~1000 Page24of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11G_Ant1_2437_1000~26500 11G_Ant1_2462_30~1000 Page25of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11G_Ant1_2462_1000~26500 11N20SISO_Ant1_2412_30~1000 Page26of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11N20SISO_Ant1_2412_1000~26500 11N20SISO_Ant1_2437_30~1000 Page27of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11N20SISO_Ant1_2437_1000~26500 11N20SISO_Ant1_2462_30~1000 Page28of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11N20SISO_Ant1_2462_1000~26500 Page29of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.6DutyCycle TestResult TestModeAntennaFreq(MHz) Transmission Duration [ms] Transmission Period[ms] Duty Cycle [%] FactorVerdict1/T 11BAnt1 24128.198.3797.850.09---0.12 24378.188.4496.920.14---0.12 24628.188.4297.150.13---0.12 11GAnt1 24121.361.5388.890.51---0.74 24371.361.5488.310.54---0.74 24621.361.5587.740.57---0.74 11N20SISOAnt1 24121.151.3287.120.60---0.87 24371.151.3585.190.70---0.87 24621.151.1996.640.15---0.87 Page30of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 Page31of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11G_Ant1_2412 11G_Ant1_2437 Page32of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11G_Ant1_2462 11N20SISO_Ant1_2412 Page33of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 Page34of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Page35of42FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.7EmissionsinRestrictedBands TestResult TestModeAntenna ChNa me Freq (MHz) Detector Freq [MHz] Result [dBm] Limit [dBm] Result [dBuV/m] Limit [dBuV/m] Verdict 11BAnt1 Low2412 AV2310.000-48.26≤-41.2046.94≤54PASS AV2389.180-45.83≤-41.2049.37≤54PASS AV2390.000-46.51≤-41.2048.69≤54PASS Peak2310.000-43.17≤-21.2052.03≤74PASS Peak2381.510-37.98≤-21.2057.22≤74PASS Peak2390.000-40.86≤-21.2054.34≤74PASS High2462 AV2483.500-45.48≤-41.2049.72≤54PASS AV2483.560-45.61≤-41.2049.59≤54PASS AV2500.000-46.48≤-41.2048.72≤54PASS Peak2483.500-39.08≤-21.2056.12≤74PASS Peak2487.740-36.31≤-21.2058.89≤74PASS Peak2500.000-39.22≤-21.2055.98≤74PASS 11GAnt1 Low2412 AV2310.000-48.03≤-41.2047.17≤54PASS AV2389.960-45.55≤-41.2049.65≤54PASS AV2390.000-45.55≤-41.2049.65≤54PASS Peak2310.000-43.47≤-21.2051.73≤74PASS Peak2388.400-34.88≤-21.2060.32≤74PASS Peak2390.000-39.79≤-21.2055.41≤74PASS High2462 AV2483.500-44.17≤-41.2051.03≤54PASS AV2483.670-44.24≤-41.2050.96≤54PASS AV2500.000-46.93≤-41.2048.27≤54PASS Peak2483.500-39.83≤-21.2055.37≤74PASS Peak2483.890-34.89≤-21.2060.31≤74PASS Peak2500.000-41.53≤-21.2053.67≤74PASS 11N20SISOAn…

Text truncated - open the document above for the full version.

Test Report

Page1of36FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCCTESTREPORT For HangzhouFanhanTechnologyCo.,Ltd. Outdoorbatterycamera2K TestModel:LZT-10 Preparedfor:HangzhouFanhanTechnologyCo.,Ltd. Address:2-1002,No.6,lianhuistreet,binjiangdistrict,Hangzhou,Zhejiang China Preparedby:ShenzhenLCSComplianceTestingLaboratoryLtd. Address:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei, ShajingStreet,BaoanDistrict,Shenzhen,518000,China Tel:(+86)755-82591330 Fax:(+86)755-82591332 Web:www.LCS-cert.com Mail:[email protected] Dateofreceiptoftestsample:August03,2023 Numberoftestedsamples:2 Samplenumber:A072723035-1,A072723035-2 Serialnumber:Prototype DateofTest:August03,2023~August15,2023 DateofReport:August16,2023 Page2of36FCCID:2BARM-LZT-10ReportNo.:LCSA072723035EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity FCCTESTREPORT FCCCFR47PART15C(15.247) ReportReferenceNo......................:LCSA072723035EA DateofIssue.......................................:August16,2023 TestingLaboratoryName..............:ShenzhenLCSComplianceTestingLaboratoryLtd. Address................................................:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei, ShajingStreet,BaoanDistrict,Shenzhen,518000,China TestingLocation/Procedure............:FullapplicationofHarmonisedstandards■ PartialapplicationofHarmonisedstandards□ Otherstandardtestingmethod□ Applicant’sName.............................:HangzhouFanhanTechnologyCo.,Ltd. Address...…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jie Li

[email protected]0571-81955295Fax: 0571-81955295

Test Firm

Shenzhen LCS Compliance Testing Laboratory Ltd.Gavin Liang

[email protected]0755-82591330Fax: 0755-82591132

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	34.40 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is peak conducted. This device supports 802.11b, 802.11g and 802.11n with a 20 MHz bandwidth mode. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
