2BARN-RZ1-403remote control

FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For Treadmill This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. For remote control This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

Zhejiang Dapao Technology Co., Ltd No. 65, Kaifa Avenue, Baiyang Street, Wuyi County, Jinhua City, Zhejiang Province China The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023-4-4 To whom it may concern: We, Zhejiang Dapao Technology Co., Ltd , hereby certify that the equipment for which authorization is sought (FCC ID: 2BARN-RZ1-403) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). Sincerely, Signature Zhibo Lin PM Zhejiang Dapao Technology Co., Ltd 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V02

2BARN-RZ1-403

Zhejiang Dapao Technology Co., Ltd Add: No. 65, Kaifa Avenue, Baiyang Street, Wuyi County, Jinhua City, Zhejiang Province China Date: 2023-4-4 FCC ID: 2BARN-RZ1-403 Dear Sir/Madam, We, Zhejiang Dapao Technology Co., Ltd Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: remote control Model no.: Z1-403, Z2, Z3, Z4, Z5, Z6, Z7, Z8, Z9, B1, B2, B3, B4, B5, B6, B7, B8, B9 A1, A2, A3, A4, A5, A6, A7, A8, A9, A10, C1, C2, C3, C4, C5, C6, C7, C8, C9, X1, X2, X3, X4, X5, X6, X7, X8, X9 Sincerely, Name/Title： Zhibo Lin/PM Company: Zhejiang Dapao Technology Co., Ltd Address: No. 65, Kaifa Avenue, Baiyang Street, Wuyi County, Jinhua City, Zhejiang Province China Phone: 13620214161 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2023-4-4> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BARN-RZ1-403 Z1-403 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Zhibo Lin/PM Company: Zhejiang Dapao Technology Co., Ltd Address: No. 65, Kaifa Avenue, Baiyang Street, Wuyi County, Jinhua City, Zhejiang Province China Phone: 13620214161 Fax: N/A E-Mail: [email protected]

Zhejiang Dapao Technology Co., Ltd No. 65, Kaifa Avenue, Baiyang Street, Wuyi County, Jinhua City, Zhejiang Province China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023-4-4 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BARN-RZ1-403 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Zhibo Lin/PM Company: Zhejiang Dapao Technology Co., Ltd Address: No. 65, Kaifa Avenue, Baiyang Street, Wuyi County, Jinhua City, Zhejiang Province China Phone: 13620214161 Fax: N/A E-Mail: [email protected]

FCC ID: 2BARN-RZ1-403 External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BARN-RZ1-403 Photo 4 Photo 5 Photo 6 FCC ID: 2BARN-RZ1-403 Photo 7

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location FCC ID : 2BARN-RZ1-403

FCC ID: 2BARN-RZ1-403 Internal Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BARN-RZ1-403 Photo 4 433 PCB Antenna

Summary Inverted Antenna Specification ITEM ANT SPEC Model Name 433.92M ANT MAX. Gain -0.7dBi Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50 Ohm Antenna Length 98.08mm Manufacture Zhejiang Dapao Technology Co., Ltd Antenna Photo & Length (mm)

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China FCC PART 15 SUBPART C TEST REPORT FCC PART 15.231 Report Reference No. ..................... : FCC ID. ............................................ : CTA23022100701 2BARN-RZ1-403 Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Amy Wen Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Mar. 03, 2023 Testing Laboratory Name .............: Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : Zhejiang Dapao Technology Co., Ltd Address ............................................ : No. 65, Kaifa Avenue, Baiyang Street, Wuyi County, Jinhua City, Zhejiang Province, China Test specification ...........................: Standard ........................................... : FCC Part 15.231 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: remote control Trade Mark ....................................... : N/A Manufacturer .................................... : Zhejiang Dapao Technology Co., Ltd Model/Type reference....................... : Z1-403 Listed Models .................................. : Z2, Z3, Z4, Z5, Z6, Z7, Z8, Z9, B1, B2, B3, B4, B5, B6, B7, B8, B9 A1, A2, A3, A4, A5, A6, A7, A8, A9, A10, C1, C2, C3, C4, C5, C6, C7, C8, C9, X1, X2, X3, X4, X5, X6, X7, X8, X9 Modulation ....................................... : ASK Frequency .......................................... 433.92MHz Ratings ............................................. : DC 3.0V From Battery Result................................................ : PASS Report No.: CTA23022100701 Page 2 of 23 T E S T R E P O R T Equipment under Test : remote control Model /Type : Z1-403 Listed Models : Z2, Z3, Z4, Z5, Z6, Z7, Z8, Z9, B1, B2, B3, B4, B5, B6, B7, B8, B9 A1, A2, A3, A4, A5, A6, A7, A8, A9, A10, C1, C2, C3, C4, C5, C6, C7, C8, C9 Applicant : Zhejiang Dapao Technology Co., Ltd Address : No. 65, Kaifa Avenue, Baiyang Street, Wuyi County, Jinhua City, Zhejiang Province, China Manufacturer : Zhejiang Dapao Technology Co., Ltd Address : No. 65, Kaifa Avenue, Baiyang Street, Wuyi County, Jinhua City, Zhejiang Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA23022100701 Page 3 of 23 Contents 1 TES T ST A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 Block Diagram of Test Setup 5 2.6 Special Accessories 5 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 11 4.3 20dB Bandwidth 15 4.4 Deactivation Time 16 4.5 Antenna Requirement 17 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 18 6 P H O T O S O F T H E E U T ........................................................... 19 Report No.: CTA23022100701 Page 4 of 23 1 T E ST S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.231:Periodic operation in the band 40.66-40.70 MHz and above 70 MHz. ANSI C63.10:2013 : American National Standard for Testing Unlicensed Wireless Devices Report No.: CTA23022100701 Page 5 of 23 2 S U MM A R Y 2.1 General Remarks Date of receipt of test sample : Feb. 21, 2023 Testing commenced on : Feb. 21, 2023 Testing concluded on : Mar. 03, 2023 2.2 Product Description Product Name: remote control Model/Type reference: Z1-403 Testing sample ID： CTA230221007-1# (Engineer sample), CTA230221007-2#(Normal sample) Power supply: DC 3.0V From Battery Modulation: ASK Operation frequency: 433.92MHz Channel number: 1 Antenna type: PCB antenna Antenna gain: -0.7 dBi 2.3 Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 3.0V From Battery 2.4 Short description of the Equipment under Test (EUT) This is a remote control. For more details, refer to the user’s manual of the EUT. 2.5 Block Diagram of Test Setup 2.6 Special Accessories Follow auxiliary equipment(s) test with EUT that provided by the manufacturer or laboratory is listed as follow: Description Manufacturer Model Technical Parameters Certificate Provided by / / / / / / / / / / / / EUT DC 3.0V From Battery Report No.: CTA23022100701 Page 6 of 23 2.7 Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for the device filing…

Text truncated - open the document above for the full version.

FCC ID: 2BARN-RZ1-403 Test Setup Photos of the EUT
