2BARRPWS2044-in-1 Magnetic Wireless Charger

FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna. IC Caution: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:This device may not cause interference.This device must accept any interference, including interference that may cause undesired operation of the device.This equipment should be installed and operated with minimum distance between 10cm the radiator your body L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :L’appareil ne doit pas produire de brouillage;L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.Cet équipement doit être installé et utilisé avec une distance minimale de 1 0 cm entre le radiateur et votre corps ,12V-1.5A ,12V-1.5A

1/1 US Agent for Service of ProcessLETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process : Company Name: THREE STONES MEDIA LLC FRN: 0033401761 Contact Name: Sijie Zhang Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Telephone No: +1 267 909 3692 Email: [email protected] Applicant: Company name: Shanghai YIYU Trading Co., Ltd Product Description: 4-in-1 Magnetic Wireless Charger Grantee code: 2BARR FCC ID: 2BARRPWS204 Contact Name: 4-in-1 Magnetic Wireless Charger Address: Rm.201, Bldg.2, 528 Mingxing Rd., Xinqiao Town, Songjiang Dist., Shanghai Telephone No: 13788987335 Email: [email protected] [Shanghai YIYU Trading Co., Ltd] certifies that, as of the date of this filing of the application with the TCB, [THREE STONES MEDIA LLC] is our designated US agent for service of process for the above referenced FCC ID. [Shanghai YIYU Trading Co., Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [THREE STONES MEDIA LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicantis aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. 1/1 Da te: 25/06/2023 Applicant’s Name: buyu Xu US Agent’s Name: Sijie Zhang Tit le:manager Title: President Signa ture Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shanghai YIYU Trading Co., Ltd Grantee code: 2BARR FCC ID: 2BARRPWS204 Contact Name: buyu Xu Address: Rm.201, Bldg.2, 528 Mingxing Rd., Xinqiao Town, Songjiang Dist., Shanghai Telephone No: 13788987335 Fax No: N/A Email: [email protected] i. [ Shanghai YIYU Trading Co., Ltd ] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [ Shanghai YIYU Trading Co., Ltd ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Shanghai YIYU Trading Co., Ltd certifies that, as of the date of the filing of theapplication, the applicant is not identified on the Covered List as an entity producing “covered”equipment. Date: 09/05/2023 Applicant’s Name: buyu Xu Title:General Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shanghai YIYU Trading Co., Ltd Family models declaration letter. 6/25/2023 We Company: Shanghai YIYU Trading Co., Ltd Address: Rm.201, Bldg.2, 528 Mingxing Rd., Xinqiao Town, Songjiang Dist., Shanghai Product: 4-in-1 Magnetic Wireless Charger Model Name: PWS-2041 Family Model: PWS-2042 All models are the same circuit and RF module, except the colour. We (Shanghai YIYU Trading Co., Ltd) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.), same mechanical structure and design (including product enclosure, materials, etc.), the only difference is the model colour. Thanks Sincerely, Signature [Name] buyu Xu [Title] Gernal manager [email protected]

C5266091_X8_Ed.1 1/1 Letter of Authorization < Shanghai YIYU Trading Co., Ltd > Company: Shanghai YIYU Trading Co., Ltd Address: Rm.201, Bldg.2, 528 Mingxing Rd., Xinqiao Town, Songjiang Dist., Shanghai Product Name: 4-in-1 Magnetic Wireless Charger Model Number: PWS-2041, PWS-2042 FCC Identifier: 2BARRPWS204 We authorize LGAI Technological Center S.A., Ronda de la Font delCarme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: buyu Xu Date: 25/06/2023 Title: General Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 < Shanghai YIYU Trading Co., Ltd > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046Date:25/06/2023 Subject: Request for Confidentiality FCC ID: 2BARRPWS204 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location Attestation Statement External Photos Block Diagram Schematics Test Report Test Setup Photos User’s Manual NOTE 1 Internal Photos NOTE 1 Parts List / Tune Up / BOM List RF Exposure Info Operational Description Cover Letter(s) FCC Software Security Requirements for UNII devices NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of _180_ days from the date of the Grant of Equipment Authorization and prior to marketing. C5266091_X10_Ed.2 1/1 It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: buyu Xu Title: General Manager

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

PWS-2042

Photo 8 PWS-2041 Photo 9 Photo 10 Induction coil (Phone) Induction coil (Headphone) Induction coil (Watch) Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 Photo 17 Photo 18 Photo 19 Photo 20 Photo 21 Photo 29 PWS-2042 Photo 30 Photo 31 Induction coil (Watch) Induction coil (Phone) Induction coil (Headphone) Photo 32 Photo 33 Photo 34 Photo 35 Photo 36 Photo 37 Photo 38 Photo 39 Photo 40 Photo 41 Photo 42

FCC ID: 2BARRPWS204 1.Measuring Standard FCC Part 1(1.1310) and Part 2(2.1091), KDB 680106 D01v03r01 RF Exposure Wireless Charging App v03 1.2. Requiments Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These categories are fixed installation, mobile, and portable and are defined as follows: o Fixed Installations: fixed location means that the device, including its antenna, is physically secured at a permanent location and is not able to be easily moved to another location. Additionally, distance to humans from the antenna is maintained to at least 2 meters. o Mobile Devices: a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structures and the body of the user or nearby persons. Transmitters designed to be used by consumers or workers that can be easily re-located, such as a wireless modem operating in a laptop computer, are considered mobile devices if they meet the 20 centimeter separation requirement. The FCC rules for evaluating mobile devices for RF compliance are found in 47 CFR §2.1091. o Portable Devices: a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable device requirements are found in Section 2.1093 of the FCC's Rules (47 CFR§2.1093). The FCC also categorizes the use of the device as based upon the user’s awareness and ability to exercise control over his or her exposure. The two categories defined are Occupational/ Controlled Exposure and General Population/Uncontrolled Exposure. These two categories are defined as follows: Occupational/Controlled Exposure: In general, occupational/controlled exposure limits are applicable to situations in which persons are exposed as a consequence of their employment, who have been made fully aware of the potential for exposure and can exercise control over their exposure. This exposure category is also applicable when the exposure is of a transient nature due to incidental passage through a location where the exposure levels may be higher than the general population/uncontrolled limits, but the exposed person is fully aware of the potential for exposure and can exercise control over his or her exposure by leaving the area or by some other appropriate means. Awareness of the potential for RF exposure in a workplace or similar environment can be provided through specific training as part of a RF safety program. If appropriate, warning signs and labels can also be used to establish such awareness by providing prominent information on the risk of potential exposure and instructions on methods to minimize such exposure risks. General Population/Uncontrolled Exposure: The general population / uncontrolled exposure limits are applicable to situations in which the general public may be exposed or in which persons who are exposed as a consequence of their employment may not be made fully aware of the potential for exposure or cannot exercise control over their exposure. Members of the general public would come under this category when exposure is not employment-related; for example, in the case of a wireless transmitter that exposes persons in its vicinity. Warning labels placed on low-power consumer devices such as cellular telephones are not considered sufficient to allow the device to be considered under the occupational/controlled category, and the general population/uncontrolled exposure limits apply to these devices. 1.3 Test configuration 1, The field strength of both E-field was measured at 15cm, H-field was measured at 15cm surrounding the device, and 20 cm away from the surface from all coils using the equipment list above for determining compliance with the MPE requirements of FCC Part 1.1310. 2, The RF power density was measured at Under maximum load test 3, Maximum E-field measurements was made 15cm from each side of the EUT and H-field measurements was made 15cm from surrounding the EUT and 20 cm away from the surface from all coils. Along the side of the EUT and still 20cm away from the edge of the EUT, the field probes were positioned at the location where there is maximum field strength. The maximum E-field and H-field is reported below. 4, This device uses a wireless charging circuit for power transfer operating at the frequency of 111–205kHz. Thus, the 300kHz limits were used: E-field Limit = 614 (V/m); H-field limit = 1.63 (A/m). 1.4 Test Setup 2. Limits 3. MEASURING DEVICE AND TEST EQUIPMENT 3.1 Test Instruments Item Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Due day 1 Exposure Level Tester narda ELT-400 N-0231 2022.08.30 2023.08.29 2 Magnetic field probe 100cm2 narda ELT probe 100cm2 M0675 2022.08.30 2023.08.29 3 Isotropic Electric Field Probe narda EP-601 511WX60706 2022.08.30 2023.08.29 3.2 Measurement Uncertainty (95% confidence levels, k=2) No. Item Uncertainty 1 Uncertainty for H-Field 2.39dB 2 Uncertainty for E-Field 2.45dB 4. Measuring Results EUT: 4-in-1 Magnetic Wireless Charger Model Name. : PWS-2041 Temperature: 24 °C Relative Humidity: 56% Pressure: 1010hPa Test Date: 2023-6-01 Test Voltage: DC 5V/9V/12V from adapter Mobile phone 15W, Watch 2.5W and Earphone mode 3W: 111~205KHz, 326KHz. For Full load mode: E-Field Strength at 15 cm for position A, B, C, D. 20cm for position E from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limit (50%) (V/m) Limits Test (V/m) 0.111-0.205, 0.326 6.45 6.19 6.45 6.75 6.35 307 614 H-Filed Strength at 15 cm for position A, B, C, D. 20cm for position E from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limit (50%) (A/m) …

Text truncated - open the document above for the full version.

Dongguan Xinwang Coil Technology Co., Ltd. 地址（ Add ） : : Room 306, Building 7, No. 8, Buge Road, Tianxin Industrial Zone, Tangxia Town, Dongguan City 电话（ Tel ） : 13662722286 传真（ Fax ） : 产品规格承认书 SPECIFICATON APPROVAL 客户名称： CUSTOMERShenzhen Mingxinfu Electronics Co., Ltd. 客户品名： Product Name ofCustomer Coil Module 我方产品名（材质）： Product Mame ofOurs(Matenial) Coil Module 承认： APPROVED 核准：制表：日期： APPROVEDDRAWN王兴旺DATE 2022-12-15 页码 1 of 4 Specification 规格内容 CISTOMEP/N: 客户品名 Coil Module PARTNUMBER： 制造商料号 1.DIMENSIONS(外形尺寸）：mm A 5.3±0.5 B 17.6±1 C 40±1 D 45MAX E 25±2 F 2-5 G Total thickness 2.8MAX H Disk thickness 0.8 ±0.1 I J k L M N O R Q P APPROVED BY 承认 CHECKED BY 审查 PREPARED BY 制作 DATE 日期 PACE 页码 王兴旺 2022-12-15 2 of 4 Specifcation 规格内容 CUSTOMERP/N: 客户品名 Coil Module PARTNUMBER： 制造商料号 5.WINDING DETAILS(绕线详细说明）： Wdy.NO. 绕组 Start 开始 Finish 结束 Turns 圈数 Wire Dia 线径 Wdg.TyepeSprad/lose 绕线方法疏/密绕 Wdg.Direction 绕线方向 Turns/Layer 层数/每层圈数 S F 11TS 0.08*105P lose countercloc kwise 1Layer/11TS 6.ELECTRICAL CHARACTERISTICS(电气特性）： PARAMETERS UNIN LIMTI Inductance ls@100KHz/1v UH 6.3UH±10％ Q @100KHz/1v 80MIN DCR @100KHz/1v mΩ 90MAX APPROVED BY 承认 CHECKED BY 审查 PREPARED BY 制作 DATE 日期 PAGE 页码 王兴旺 2022-12-15 3 of 4

Dongguan Xinwang Coil Technology Co., Ltd. 地址（ Add ） : : Room 306, Building 7, No. 8, Buge Road, Tianxin Industrial Zone, Tangxia Town, Dongguan City 电话（ Tel ） : 13662722286 传真（ Fax ） : 产品规格承认书 SPECIFICATON APPROVAL 客户名称： CUSTOMERShenzhen Mingxinfu Electronics Co., Ltd. 客户品名： Product Name ofCustomerCoil Module 我方产品名（材质）： Product Mame ofOurs(Matenial) Coil Module 承认： APPROVED 核准：制表：日期： APPROVEDDRAWN王兴旺DATE 2022-12-15 页码 1 of 4 Specification 规格内容 CISTOMEP/N: 客户品名 Coil Module PARTNUMBER： 制造商料号 1.DIMENSIONS(外形尺寸）：mm A 5.3±0.5 B 20.5±1 C 45MAX D 41.5±1 E 200±5 F 2-5 G Total thickness 2.8MAX H Disk thickness 0.8 ±0.1 I J k L M N O R Q P APPROVED BY 承认 CHECKED BY 审查 PREPARED BY 制作 DATE 日期 PACE 页码 王兴旺 2022-12-15 2 of 4 Specifcation 规格内容 CUSTOMERP/N: 客户品名 Coil Module PARTNUMBER： 制造商料号 5.WINDING DETAILS(绕线详细说明）： Wdy.NO. 绕组 Start 开始 Finish 结束 Turns 圈数 Wire Dia 线径 Wdg.TyepeSprad/lose 绕线方法疏/密绕 Wdg.Directio n 绕线方向 Turns/Layer 层数/每层圈数 S F 10TS 0.08*105P lose counterclo ckwise 1Layer/10TS 6.ELECTRICAL CHARACTERISTICS(电气特性）： PARAMETERS UNIN LIMTI Inductance ls@100KHz/1v UH 6.3UH±10％ Q @100KHz/1v 65MIN DCR @100KHz/1v mΩ 90MAX APPROVED BY 承认 CHECKED BY 审查 PREPARED BY 制作 DATE 日期 PAGE 页码 王兴旺 2022-12-15 3 of 4

Dongguan CityXinwang Coil Technology Co., Ltd Add: Room 601, Building 2, No. 92, Xinxing Road, Hengtang Industrial Zone, Tangxia Town, Dongguan City Tel: 13662722286 Fax: SPECIFICATON APPROVAL CUSTOMERShenzhen MingXinFu Electronics Co.,Ltd Product Name ofCustomerWatch coil Product Mame ofOurs(Matenial)Watch coil APPROVED APPROVEDDRAWNWang XingwangDATE 2023-6-30 Page 1 of 4 Specification CISTOMEP/N: Watch coil PARTNUMBER： 1.DIMENSIONS：mm A 7.6±0.5 B 13.5±1 C 21MAX D 8-10 E 2MAX F 25±1 G Total thickness: 2.8MAX H Release paper : 0.15MAX I J k L M N O R Q P APPROVED BY CHECKED BY PREPARED BY DATE PACE Wang Xingwang 2023-6-30 2 of 4 Specifcation CUSTOMERP/N: Watch coil PARTNUMBER： 5.WINDING DETAILS： Wdy.NO. Start Finish Turns Wire Dia Wdg.TyepeSprad/Close Wdg.Directio n Turns/Layer S F 12TS 0.08*24P Close Anticlockwise 1 layer/12TS 6.ELECTRICAL CHARACTERISTICS PARAMETERS UNIN LIMTI Inductance ls@100KHz/1v UH 6.5UH±10％ Q @100KHz/1v 25MIN DCR @100KHz/1v mΩ 200MAX APPROVED BY CHECKED BY PREPARED BY DATE PAGE Wang Xingwang 2023-6-30 3 of 4 MATERIAL LIST CUSTOMER P/N: Watch coil PARTNUMBER： NO. Material name Description Manufacturer Material 1 Hot air stranded wire 0.08*24P 99.95% copper 2 Solder Bar high temperature 3 Glue silica gel 4 Soft magnetic disc G25*7.6*2.6H 5 Double-sided tape 19*0.15H (without holes and ears) 6 Magnetic core 7.5*2.2(3200Gs±5%) 7 Packaging materials Pearl cotton 8 APPROVED BY CHECKED BY PREPARED BY DATE PAGE Wang Xingwang 2023-6-30 4 of 4

Report No.: S23052401401001 Version.1.1Page 1 of 27 FCC Test Report FCC ID: 2BARRPWS204 Product: 4-in-1 Magnetic Wireless Charger Trade Name: INGOX Model Number: PWS-2041 Family Model: PWS-2042 Report No.: S23052401401001 Prepared for Shanghai YIYU Trading Co., Ltd Rm.201, Bldg.2, 528 Mingxing Rd., Xinqiao Town, Songjiang Dist., Shanghai Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, SanweiCommunity,Xixiang Street, Bao’an District, Shenzhen P.R. China Tel:400-800-6106,0755-2320 0050 / 2320 0090 Website:http://www.ntek.org.cn Report No.: S23052401401001 Version.1.1Page 2 of 27 TEST RESULTCERTIFICATION Applicant’s name ................. : Shanghai YIYU Trading Co., Ltd Address ................................. : Rm.201, Bldg.2, 528 Mingxing Rd., Xinqiao Town, Songjiang Dist., Shanghai Manufacturer's Name .......... : Shenzhen yuxuan wireless technology co.,ltd Address ................................. : 301, Building A, lane 4, Shaxin Road, ShaYing Community，Maluan street, Pingshan District, Shenzhen, Guangdong Product Name: 4-in-1 Magnetic Wireless Charger Model and/or type reference : PWS-2041 Family Model: PWS-2042 Standards ............................. : FCC part 15C ANSI C63.10:2013 KDB 680106 D01 RF Exposure Wireless Charging App v03r01 This device described above has been tested by ShenzhenNTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ShenzhenNTEK Testing Technology Co., Ltd., this document may be altered or revised by Shenzhen NTEK Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. The test results of this report relate only to the tested sample identified in this report. Date of Test ............................................ : TestSampleNumber............................: S230524014002 Date (s) of performance of tests ............. : May 24. 2023 ~ Jun 12. 2023 Date of Issue ........................................... : Jun 12. 2023 Test Result ............................................... : Pass Testing Engineer : (Gavan Zhang) Authorized Signatory : (Alex Li) Report No.: S23052401401001 Version.1.1Page 3 of 27 Table of Contents Page 1 . TEST SUMMARY 4 1.1 FACILITIES AND ACCREDITATIONS 5 1.2 LABORATORY ACCREDITATIONS AND LISTINGS 5 1.3 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST SETUP 9 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 11 2.4 MEASUREMENT INSTRUMENTS LIST 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION 13 3.1.2 TEST PROCEDURE 14 3.1.3 TEST SETUP 14 3.1.4 EUT OPERATING CONDITIONS 14 3.1.5 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 17 3.2.2 TEST PROCEDURE 18 3.2.3 TEST SETUP 19 3.2.4 TEST RESULTS 20 4. BANDWIDTH TEST 23 4.1TEST PROCEDURE 23 4.2TEST SETUP 23 4.3 TEST RESULT 24 5. ANTENNA APPLICATION 27 5.1 Antenna Requirement 27 5.2 Result 27 Report No.: S23052401401001 Version.1.1Page 4 of 27 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item FCC Rules Limit Judgment Remark FCC part 15C ANSI C63.10:2013 Conducted Emission §15.207 / PASS Radiated Emission §15.209 / PASS ANTENNA APPLICATION §15.203 / PASS 20dB BANDWIDTH §15.215 / PASS NOTE: (1)’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Report No.: S23052401401001 Version.1.1Page 5 of 27 1.1 FACILITIES AND ACCREDITATIONS All measurement facilities used to collect the measurement data are located at 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.10 and CISPR Publication 22. 1.2 LABORATORY ACCREDITATIONS AND LISTINGS Site Description CNAS-Lab. : The Certificate Registration Number is L5516. IC-Registration : The Certificate Registration Number is 9270A-1. FCC- Accredited : Test Firm Registration Number:463705. Designation Number: CN1184 A2LA-Lab. : The Certificate Registration Number is 4298.01 This laboratory is accredited in accordance with the recognized International Standard ISO/IEC 17025:2005General requirements for the competence of testing and calibration laboratories. This accreditation demonstratestechnical competence for a defined scope and the operation of a laboratory quality management system (refer to joint ISO-ILAC-IAF Communiqué dated 8 January 2009). Name of Firm : Shenzhen NTEK Testing Technology Co., Ltd. Site Location : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKC01 ANSI 150 KHz ~ 30MHz 2.8 B. Radiated Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKA01 ANSI 9KHz ~1000MHz 2.64 1GHz ~12.4GHz 2.40 C. Occupied Bandwidth: Uncertainty ±3.7dB Report No.: S23052401401001 Version.1.1Page 6 of 27 Revision History Report No. Version Description Issued Date S23052401401001 Rev.01 Initial issue of report Jun 12. 2023 Report No.: S23052401401001 Version.1.1Page 7 of 27 2. GENERAL INFORMATION 2.1GENERAL DESCRIPTION OF EUT Product Feature and Specification Equipment 4-in-1 Magnetic Wireless Charger Trade Name INGOX FCC ID 2BARRPWS204 Model No. PWS-2041 Family Model PWS-2042 Model Difference …

Text truncated - open the document above for the full version.

Radiated Measurement Photos AC Conducted Measurement Photos
