2BASH-PAITAB1010Tablet

POSBANK CO.,LTD

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Jul 30, 2026
Application Purpose: Original Equipment
Equipment Note: Tablet
Frequency Range: 5180.00000000 - 5240.00000000
Company: POSBANK CO.,LTD
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party. Responsible for compliance could void the users authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Specific Absorption Rate (SAR) information: This device meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodicand thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persor regardless of age or health. FCC RF Exposure Information and Statement the SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue Device types: device has also been tested against this SAR limit. This device was tested for typical body-worn operations with the back of the Tablet kept Omm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain an Omm separation distance between the user's body and the back of the phone. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided.

Test Report

深圳市顺达成科技有限公司 SHUN DACHENG TECHNOLOGY CO., LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 承认书 SPECIFICATION FOR APPROVAL 审批/ Approval客户批准/Customer Approval 制作 Prepared By 审核 Checked By 批准 Approval By 审核 Checked By 批准 Approval By 签章 Sign at ure 李瑶娜符学荣日期 Dat 陈华明 e 2024.02.212024.02.212024.02.21 修订履历/Change Log 版本 Version 修订内容 Change Description 责任人 Person in Charge 核准 Approval By 日期 Date 客户名称 Customer Name 客户项目名 Customer Project Nam 普耐尔 SHENZHEN PUNAIER ELECTRONIC CO., LTD e M50 PRO 顺达成项目名 SDC Project Name M50 PRO 客户编码 Customer P/N 顺达成料号 SDC P/N WG4617B-0813R-25 频段 Band WiFi2.4G/5G/GPS/BT 版本号 Version A0 设计人信息/Designer Information 射频工程师 RF Engineer 杨永辉研发主管 R&D Dir etor 符学荣结构工程师 ME Engineer 李瑶娜 2024.02.22 2024.02.22 Company Address: 4th Floor, Building B5, Xinfu Industrial Park, Chongqing Road, Fuyong Town, Bao'an District, Shenzhen 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 目录/Catalogue 序号 No. 项目 Item 页码 PageNo. 1 图纸或实物图片 DrawingorProductImage 3/5 2 尺寸测量报告 DimensionsTestReport 4/6 3 射频性能测试报告 RFPerformanceTestReport 7-9 4 可靠性测试报告 ReliabilityTestReport1 10 5 包装文件 PackageDocument 11 6 环境有害物质管控一览表 RoHSControllistforSample 12 7 安装事宜或其它 InstallWizard orOther 12 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 产品图纸或实物图片 DrawingorProductImage 李瑶娜 W G 4 6 1 7 B - 0 8 1 3 R - 2 5 M 5 0 P R O X . X ± 0 . 5 X . X X ± 0 . 2 X X X . ± 1 0 . 0 X X . ± 5 . 0 X . ± 2 . 0 1 注： 6 0 m m 以内的线材，若无客户要求则默认端子头朝下 ? 0 . 8 1 C a b l e B l a c k , 5 0 Ω I P E X 3 1 0 * 2 0 m m 导电布  S D C M 5 0 P R O W G 手撕位    深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 样品尺寸测量报告 SampleDimensionsTestReport 测试日期 TestDate 2024.02.21 样品数量 SampleQty. 3 测试人 Inspector 许燕芳尺寸编号 DimensionNo. 标准 Standard 样品1 Sample1 样品2 Sample2 样品3 Sample3 Pass/NG ①长度37.4±0.2mm37.437.537.4 Pass ②宽度20.16±0.2mm20.1620.2620.16 Pass ③厚度0.1±0.03mm0.10.10.1 Pass ④线长25±2mm252625 Pass 最终结论 Conclusion PASS 测试人&日期 Inspector&Date 许燕芳2024.02.21 批准&日期 Approval&Date 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 射频性能测量报告 RFPerformanceTestReport 天线测试设备简介 AntennaTestEquipmentIntroduction 测试天线输入特性使用AgilentE5071CandAgilent5062A矢量网络分析仪；辐射特性利用广屏三维近场暗室进行测试，并分别使用8960E5515和AgilentE4438C进行了分析。暗房的测试坐标如下: TestofantennainputcharacteristicsusingAgilentE5071CandAgilent5062Avectornetwork analyzer;Theradiationpatternoftheantennaaretestedusingtheguangping3DnearfieldAnechoicChamber, andtheinstrumentisusedtoagilent8960E5515andAgilentE4438C.Thetestcoordinatesofthedarkroom areasfollows: 1.S11参数测量/S11Parameter-VSWR 使用一根50Ω同轴电缆连接到天线，然后该电缆连接到网络分析仪测量S11参数，被测量产品远离金属至少 20厘米。 MeasuringMethodisa50Ωcoaxialcableisconnectedtotheantenna.Thenthiscableisconnectedtoanetworkanalyzer tomeasuretheS11parameter,Keepingthisfixtureawayfrommetalatleast20cm. S11Parameter-VSWR 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 2.天线匹配网络/ AntennaMatchingNetwork 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 3.Gain&Efficiency 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 4.WIFIOTAData 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 5.GPS实测图深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 可靠性测试报告 ReliabilityTestReport 测试日期 TestDate 2024.02.21 样品数量 SampleQty. 3 测试人 Inspector 许燕芳测试项目 TestItem 要求 Requirement 试验设备 testing equipment 样品1 Sample1 样品2 Sample2 样品3 Sample3 判定 PASS/NG 高温存储在+85°C条件下暴露 24H，恢复2H后进行测试恒温恒湿箱OKOKOKPass 低温存储在-40°C条件下暴露 24H，恢复2H后进行测试恒温恒湿箱OKOKOKPass 高温工作在+60°C条件下通电工作24H 恒温恒湿箱OKOKOKPass 低温工作在-20°C条件下通电工作24H 恒温恒湿箱OKOKOKPass 盐雾试验 (5士0．5)%氯化钠、 pH值为6.5～7.2，实验箱温度(35±2)°C □24H☑48H 盐雾试验机OKOKOKPass 连接器铆压拉拔力 1.13线径≥10N 0.81线径≥8N RG174≥60N RG178≥50N 推拉力计≥8N≥8N≥8NPass 最终结论 Conclusion Pass 测试人&日期 Inspector& Date 许燕芳2024.02.21 批准&日期 Approval&D ate 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 安装事宜或其它 InstallWizardorOther 安装过程：取1PCS产品，用手撕下FPC背面的离型纸，然后将FPC定位孔位置与外壳定位孔位置（定位筋位或定位线）对齐，平整的贴附与外壳上，具体位置如下图所示：安装过程注意事项： □粘贴天线后保证FPC完整贴附于外壳； □定位孔与外壳定位柱位置对齐； □FPC边缘与外壳边缘对齐； □带端子天线在将端子扣合到主板PCBA端时请首先对齐端子，然后垂直扣合； □拆卸天线端子时需使用工具（如专用撬棍）垂直翘起端子，不可直接拽线拆卸。深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750 产品ROHS证书深圳市顺达成科技有限公司 SHUNDACHENGTECHNOLOGYCO.,LTD 公司地址：深圳市宝安区福永镇重庆路新福工业园B5栋4楼电话:0755-27211658传真:0755-29485750

Test Setup Photos

FCCID:2A8EM-HIBREAKPLUSReportNumber:BTF260609R00201 ANNEXDSARTestSetupPhotos ReferencePhoto:simulationliquiddepth15cm ReferencePhotos Right(dist.0mm)Back(dist.0mm)

Test Setup Photos

FCC ID: 2BASH-PAITAB1010 www.cotecna-toby.com TB-RF-073-3.1 Appendix V EUT Test Photographs Photo of Setup for Conducted Emission Photo of Setup for Radiated Emission (Below 1 GHz) FCC ID: 2BASH-PAITAB1010 www.cotecna-toby.com TB-RF-073-3.1 Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for RF Conducted FCC ID: 2BASH-PAITAB1010 www.cotecna-toby.com TB-RF-073-3.1 Photo of Setup for RF Conducted Photo of Setup for DFS -----END OF THE REPORT-----

Test Report

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202603-0143-14 Page: 1 of 21 TB-RF-073-3.1 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com DFS Test Report FCC ID: 2BASH-PAITAB1010 Original Grant Report No. : TBR-C-202603-0143-14 Applicant : POSBANK CO., LTD Equipment Under Test (EUT) EUT Name : Tablet Model No. : PAI TAB-1010 Series Model No. : PAI TABN-1010, PAI TAB ORDER, PAI TABN ORDER Brand Name : POSBANK Sample ID : HC-C-202603-0143-09-01 Receipt Date : 2026-05-09 Test Date : 2026-05-09 to 2026-07-07 Issue Date : 2026-07-07 Standards : FCC Part 15 Subpart E 15.407 KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02 KDB 905462 D03 UNII Clients Without Radar Detection New Rules v01r02 Test Method : ANSI C63.10: 2020+Cor.1:2023+C63.10a: 2024+Errata to C63.10a: 2024 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above Test By : Kael LI Reviewed By : Lucase Yang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202603-0143-14 Page: 2 of 21 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ...................................................................................................................................... 2 1. GENERAL INFORMATION ABOUT EUT....................................................................... 4 1.1 Client Information .......................................................................................................... 4 1.2 General Description of EUT (Equipment Under Test) ............................................ 4 1.3 Test Facility .................................................................................................................... 6 2. TEST SOFTWARE .............................................................................................................. 7 3. TEST EQUIPMENT AND TEST SITE .............................................................................. 7 4. U-NII DFS RULE REQUIREMENTS ................................................................................ 8 4.1. Applicability of DFS requirements ....................................................................... 8 4.2. Test Limits and Radar Signal Parameters ......................................................... 9 5. CALIBRATION OF RADAR WAVEFORM ................................................................... 14 5.1. Test Procedure ..................................................................................................... 14 5.2. Conducted Calibration Test Setup .................................................................... 15 5.3. Deviation from Test Standard ............................................................................ 15 5.4. Radar Waveform Calibration Result ................................................................. 15 6. U-NII DFS TESTING ......................................................................................................... 16 6.1. Test Procedure ..................................................................................................... 16 6.2. Test Setup ............................................................................................................. 16 7. TESTING RESULTS ......................................................................................................... 17 7.1. Summary of Test Results ................................................................................... 17 7.2. DFS Detection Threshold ................................................................................... 17 7.3. Channel Closing Transmission Time ................................................................ 18 7.4. Non-occupancy Period ....................................................................................... 21 Report No.: TBR-C-202603-0143-14 Page: 3 of 21 www.cotecna-toby.com TB-RF-073-3.1 Revision History Report No. Version Description Issued Date TBR-C-202603-0143-14 Rev.01 Initial issue of report 2026-07-07 Report No.: TBR-C-202603-0143-14 Page: 4 of 21 www.cotecna-toby.com TB-RF-073-3.1 1. General Information about EUT 1.1 Client Information Applicant : POSBANK CO., LTD Address : #805-808, 108, Gasan digital 2-ro ,Geumcheon-gu Seoul South Korea Manufacturer : POSBANK CO., LTD Address : #805-808, 108, Gasan digital 2-ro ,Geumcheon-gu Seoul South Korea 1.2 General Description of EUT (Equipment Under Test) EUT Name : Tablet Models No. : PAI TAB-1010, PAI TABN-1010, PAI TAB ORDER, PAI TABN ORDER Model Different : Sales areas have different names Operating Frequency Band : 5250-5350MHz 5470-5725MHz TPC : No Yes Power Rating : INPUT: DC 5.0V/2.0A DC 3.85V 6000mAh 23.1Wh Rechargeable Li-ion battery Software Version : V1.12_20260203 Hardware Version : F89-V2.0 Note : This device was functioned as a Master Slave device with radar detection Slave device without radar detection Note: (1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Report No.: TBR-C-202603-0143-14 Page: 5 of 21 www.cotecna-toby.com TB-RF-073-3.1 (2) Antenna information provided by the manufacturer. Antenna FPC Antenna Model: / Max. Gain: U-NII-1:2.27dBi U-NII-2A: 2.27dBi U-NII-2C: 2.27dBi U-NII-3: 2.27dBi (3) Channel List: Frequency Band Channel No. Frequency Channel No. Frequency 5260~5320 MHz (U-NII-2A) 52 5260 MHz 60 5300 MHz 54 5270 MHz 62 5310MHz 56 5280MHz 64 5320 MHz For 20 MHz Bandwidth, use channel 52, 56, 60, 64. For 40 MHz Bandwidth, use channel 54, 62. For 80 MHz Bandwidth, use channel 58. Frequency Band Channel No. Frequency Chann…

Text truncated - open the document above for the full version.

Test Report

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202603-0143-13 Page: 1 of 53 TB-RF-073-3.1 1/F., Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Email: [email protected] www.cotecna-toby.com RF Test Report FCC ID: 2BASH-PAITAB1010 Report No. : TBR-C-202603-0143-13 Applicant : POSBANK CO., LTD Equipment Under Test (EUT) EUT Name : Tablet Model No. : PAI TAB-1010 Series Model No. : PAI TABN-1010, PAI TAB ORDER, PAI TABN ORDER Brand Name : POSBANK Sample ID : HC-C-202603-0143-09-01 Receipt Date : 2026-05-09 Test Date : 2026-05-09 to 2026-07-03 Issue Date : 2026-07-03 Standards : FCC Part 15 Subpart E 15.407 Test Method : ANSI C63.10:2020+Cor.1:2023 KDB 789033 D02 General UNII Test Procedures New Rules v02r01 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above. Tested By : Kael LI Reviewed By : Lucase Yang Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202603-0143-13 Page: 2 of 53 www.cotecna-toby.com TB-RF-073-3.1 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 7 1.4 Description of Support Units .............................................................................................. 7 1.5 Description of Test Mode .................................................................................................... 8 1.6 Description of Test Software Setting .............................................................................. 10 1.7 Measurement Uncertainty ................................................................................................ 12 1.8 Test Facility ......................................................................................................................... 13 2. TEST SUMMARY ..................................................................................................................... 14 3. TEST SOFTWARE ................................................................................................................... 14 4. TEST EQUIPMENT AND TEST SITE ................................................................................... 15 5. CONDUCTED EMISSION TEST ........................................................................................... 17 5.1 Test Standard and Limit .................................................................................................... 17 5.2 Test Setup ........................................................................................................................... 17 5.3 Test Procedure ................................................................................................................... 17 5.4 Deviation From Test Standard ......................................................................................... 18 5.5 EUT Operating Mode ........................................................................................................ 18 5.6 Test Data ............................................................................................................................. 18 6. RADIATED AND CONDUCTED UNWANTED EMISSIONS ............................................ 19 6.1 Test Standard and Limit .................................................................................................... 19 6.2 Test Setup ........................................................................................................................... 20 6.3 Test Procedure ................................................................................................................... 21 6.4 Deviation From Test Standard ......................................................................................... 22 6.5 EUT Operating Mode ........................................................................................................ 23 6.6 Test Data ............................................................................................................................. 23 7. RESTRICTED BANDS REQUIREMENT ............................................................................. 24 7.1 Test Standard and Limit .................................................................................................... 24 7.2 Test Setup ........................................................................................................................... 25 7.3 Test Procedure ................................................................................................................... 25 7.4 Deviation From Test Standard ......................................................................................... 26 7.5 EUT Operating Mode ........................................................................................................ 26 Report No.: TBR-C-202603-0143-13 Page: 3 of 53 www.cotecna-toby.com TB-RF-073-3.1 7.6 Test Data ............................................................................................................................. 26 8. BANDWIDTH TEST ................................................................................................................. …

Text truncated - open the document above for the full version.

Test Report

Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0143-13 Page: 56 of 81 FCC ID: 2BASH-PAITAB1010 TB-RF-073-3.1 11AC20SISO-Ant1-5745-PASS 11AC20SISO-Ant1-5825-PASS 11AC40SISO-Ant1-5755-PASS 11AC40SISO-Ant1-5795-PASS 11AC80SISO-Ant1-5775-PASS 11AC80SISO-Ant1-5775-PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0143-13 Page: 57 of 81 FCC ID: 2BASH-PAITAB1010 TB-RF-073-3.1 8: Frequency Stability 8.1 Test Result TestMode Antenna Frequency [MHz] Voltage [Vdc] Temperature (°C) Deviation (Hz) Deviation (ppm) Limit (ppm) Verdict 11A Ant1 5180 NV NT -82000.00 -15.830116 20 PASS 11A Ant1 5180 LV NT -82000.00 -15.830116 20 PASS 11A Ant1 5180 HV NT -84000.00 -16.216216 20 PASS 11A Ant1 5200 NV NT -84000.00 -16.153846 20 PASS 11A Ant1 5200 LV NT -84000.00 -16.153846 20 PASS 11A Ant1 5200 HV NT -84000.00 -16.153846 20 PASS 11A Ant1 5240 NV NT -84000.00 -16.030534 20 PASS 11A Ant1 5240 LV NT -84000.00 -16.030534 20 PASS 11A Ant1 5240 HV NT -84000.00 -16.030534 20 PASS 11A Ant1 5260 NV NT -84000.00 -15.969582 20 PASS 11A Ant1 5260 LV NT -86000.00 -16.349810 20 PASS 11A Ant1 5260 HV NT -86000.00 -16.349810 20 PASS 11A Ant1 5280 NV NT -86000.00 -16.287879 20 PASS 11A Ant1 5280 LV NT -86000.00 -16.287879 20 PASS 11A Ant1 5280 HV NT -86000.00 -16.287879 20 PASS 11A Ant1 5320 NV NT -86000.00 -16.165414 20 PASS 11A Ant1 5320 LV NT -86000.00 -16.165414 20 PASS 11A Ant1 5320 HV NT -86000.00 -16.165414 20 PASS 11A Ant1 5500 HV NT -90000.00 -16.363636 20 PASS 11A Ant1 5500 NV NT -88000.00 -16.000000 20 PASS 11A Ant1 5500 LV NT -90000.00 -16.363636 20 PASS 11A Ant1 5580 NV NT -90000.00 -16.129032 20 PASS 11A Ant1 5580 LV NT -90000.00 -16.129032 20 PASS 11A Ant1 5580 HV NT -90000.00 -16.129032 20 PASS 11A Ant1 5700 NV NT -92000.00 -16.140351 20 PASS 11A Ant1 5700 LV NT -92000.00 -16.140351 20 PASS 11A Ant1 5700 HV NT -92000.00 -16.140351 20 PASS 11A Ant1 5745 NV NT -94000.00 -16.362054 20 PASS 11A Ant1 5745 LV NT -94000.00 -16.362054 20 PASS 11A Ant1 5745 HV NT -94000.00 -16.362054 20 PASS 11A Ant1 5785 NV NT -94000.00 -16.248920 20 PASS 11A Ant1 5785 LV NT -94000.00 -16.248920 20 PASS 11A Ant1 5785 HV NT -94000.00 -16.248920 20 PASS 11A Ant1 5825 NV NT -94000.00 -16.137339 20 PASS 11A Ant1 5825 LV NT -94000.00 -16.137339 20 PASS 11A Ant1 5825 HV NT -94000.00 -16.137339 20 PASS 11N20SISO Ant1 5180 NV NT -80000.00 -15.444015 20 PASS 11N20SISO Ant1 5180 LV NT -100000.00 -19.305019 20 PASS 11N20SISO Ant1 5180 HV NT -40000.00 -7.722008 20 PASS 11N20SISO Ant1 5200 NV NT -60000.00 -11.538462 20 PASS 11N20SISO Ant1 5200 LV NT -60000.00 -11.538462 20 PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0143-13 Page: 58 of 81 FCC ID: 2BASH-PAITAB1010 TB-RF-073-3.1 11N20SISO Ant1 5200 HV NT -80000.00 -15.384615 20 PASS 11N20SISO Ant1 5240 NV NT -60000.00 -11.450382 20 PASS 11N20SISO Ant1 5240 LV NT -80000.00 -15.267176 20 PASS 11N20SISO Ant1 5240 HV NT -80000.00 -15.267176 20 PASS 11N20SISO Ant1 5260 NV NT -80000.00 -15.209125 20 PASS 11N20SISO Ant1 5260 LV NT -60000.00 -11.406844 20 PASS 11N20SISO Ant1 5260 HV NT -80000.00 -15.209125 20 PASS 11N20SISO Ant1 5280 NV NT -60000.00 -11.363636 20 PASS 11N20SISO Ant1 5280 LV NT -80000.00 -15.151515 20 PASS 11N20SISO Ant1 5280 HV NT -80000.00 -15.151515 20 PASS 11N20SISO Ant1 5320 NV NT -80000.00 -15.037594 20 PASS 11N20SISO Ant1 5320 LV NT -100000.00 -18.796992 20 PASS 11N20SISO Ant1 5320 HV NT -80000.00 -15.037594 20 PASS 11N20SISO Ant1 5500 NV NT -80000.00 -14.545455 20 PASS 11N20SISO Ant1 5500 LV NT -80000.00 -14.545455 20 PASS 11N20SISO Ant1 5500 HV NT -80000.00 -14.545455 20 PASS 11N20SISO Ant1 5580 NV NT -100000.00 -17.921147 20 PASS 11N20SISO Ant1 5580 LV NT -100000.00 -17.921147 20 PASS 11N20SISO Ant1 5580 HV NT -100000.00 -17.921147 20 PASS 11N20SISO Ant1 5700 NV NT -80000.00 -14.035088 20 PASS 11N20SISO Ant1 5700 LV NT -80000.00 -14.035088 20 PASS 11N20SISO Ant1 5700 HV NT -100000.00 -17.543860 20 PASS 11N20SISO Ant1 5745 NV NT -80000.00 -13.925152 20 PASS 11N20SISO Ant1 5745 LV NT -80000.00 -13.925152 20 PASS 11N20SISO Ant1 5745 HV NT -80000.00 -13.925152 20 PASS 11N20SISO Ant1 5785 NV NT -80000.00 -13.828868 20 PASS 11N20SISO Ant1 5785 LV NT -100000.00 -17.286085 20 PASS 11N20SISO Ant1 5785 HV NT -80000.00 -13.828868 20 PASS 11N20SISO Ant1 5825 NV NT -80000.00 -13.733906 20 PASS 11N20SISO Ant1 5825 LV NT -60000.00 -10.300429 20 PASS 11N20SISO Ant1 5825 HV NT -80000.00 -13.733906 20 PASS 11N40SISO Ant1 5190 NV NT -82000.00 -15.799615 20 PASS 11N40SISO Ant1 5190 LV NT -82000.00 -15.799615 20 PASS 11N40SISO Ant1 5190 HV NT -82000.00 -15.799615 20 PASS 11N40SISO Ant1 5230 NV NT -82000.00 -15.678776 20 PASS 11N40SISO Ant1 5230 LV NT -84000.00 -16.061185 20 PASS 11N40SISO Ant1 5230 HV NT -84000.00 -16.061185 20 PASS 11AC20SISO Ant1 5180 NV NT -84000.00 -16.216216 20 PASS 11AC20SISO Ant1 5180 LV NT -84000.00 -16.216216 20 PASS 11AC20SISO Ant1 5180 HV NT -84000.00 -16.216216 20 PASS 11AC20SISO Ant1 5200 NV NT -84000.00 -16.153846 20 PASS 11AC20SISO Ant1 5200 LV NT -84000.00 -16.153846 20 PASS 11AC20SISO Ant1 5200 HV NT -84000.00 -16.153846 20 PASS 11AC20SISO Ant1 5240 NV NT -82000.00 -15.648855 20 PASS 11AC20SISO Ant1 5240 LV NT -84000.00 -16.030534 20 PASS 11AC20SISO Ant1 5240 HV NT -84000.00 -16.030534 20 PASS 11AC20SISO Ant1 5260 NV NT -84000.00 -15.969582 20 PASS Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202603-0143-13 Page: 59 of 81 FCC ID: 2BASH-PAITAB1010 TB-RF-07…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Yanggyu Kim(Manager)

[email protected]Fax: 0502-565-7722

Technical Contact

ACT Lab LLCScott Huber

[email protected]

3280 East 59th Street,Long Beach, · United States

Test Firm

Shenzhen Toby Technology Co., Ltd.Ray Lai

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15E	5.18 GHz - 5.24 GHz	33.30 mW
2	15E	5.26 GHz - 5.32 GHz	54.30 mW
3	15E	5.50 GHz - 5.70 GHz	22.10 mW
4	15E	5.75 GHz - 5.83 GHz	14.90 mW

Confidentiality

Long Term

Grant Notes

Output power listed is average conducted. This device supports 802.11a, 802.11n and 802.11ac with a 20 MHz, 40 MHz and 80 MHz bandwidth mode. For body worn operation, this device has been tested and meets FCC RF exposure guidelines when used at a minimum distance of 0 mm from the body. The highest reported SAR for body-worn is 0.97 W/kg. This device complies with the Dynamic Frequency Selection (DFS) requirements of KDB 905462 D03 as a Client only without Radar Detection.
