2BASI-WY200AUTOMATIC SWIMMING POOL CLEANER

ROBOTIC POOL CLEANER USER MANUAL WY200 EN Safety Instructions.............................................................................. I. lntroduction ............................................................................. II. lmportant Precautions.............................................................. III. Specifications.......................................................................... IV. Instructions............................................................................ 4.1 LED lndicator.......................................................................... 4.2 Charge the robot.................................................................... 4.2.2 Charger indicator................................................................. 4.3 Clean the filter cartridge.......................................................... V. WYBOT APP Connection............................................................ VI. Installation of floating blocks (optional)................................... VII. Packing list............................................................................. WARRANTY................................................................................... 3 6 6 7 8 8 9 9 9 11 12 13 14 Contents 03 Safety Instructions 1.It is strictly forbidden to use this machine beyond its use conditions. Please read this user manual carefully before use. Please use the product according to the instructions in the user manual. Our company is not responsible for any loss and injury caused by improper use. 2.Only accessories recommended or sold by the manufacturer can be used for the machine. 3.The product shall not be used by children under 8 years old or people with mental disabilities. If necessary, the product shall be used under the supervision and guidance of guardian. Please don't let children ride on the product or play with the product as a toy. 4.To prevent accidents, the machine must be taken out from the swimming pool before charging, and the charger and the machine must be placed indoors or in a splash-resistant facility for charging. Before charging, ensure that the charging port is dry. 5.Please use the original charger to charge the machine. 6.Please confirm that the charging port is dry after the machine is taken out from swimming pool, then connect it with the charger, and confirm that the machine has been turned off (the indicator lights of the machine go off completely), otherwise it cannot be charged normally. 7.The charger must be plugged into a socket with leakage protection. Please ensure that the ground wire on the socket is grounded in a standard and reliable way. 8.It is strictly forbidden to use other chargers to charge the machine. Please do not charge this charger to other equipment, avoid damage to the charger or the machine. 9.No one is allowed to enter the swimming pool when the cleaner is working, so as to avoid danger and injury. 10.When the cleaner is placed on the shore, please do not turn it on, otherwise it will affect the normal use of the cleaner. 04 11.Clean the filter basket in time after each use, so as not to affect the work of the cleaner due to excessive dirt in the filter basket. 12.When the cleaner is not in use, please store the cleaner in a cool and ventilated place indoors to avoid direct sunlight. 13.It is forbidden for non-professional personnel to disassemble the sealing box of the main machine and the sealing box assembly of the sensor, so as to avoid danger or avoid damage to the cleaner. 14.Charge the machine before the battery is completely exhausted. When the yellow light of the machine is on, please charge the machine in time. 15.Do not charge the machine when the battery is full. Overcharging will reduce the life of the battery. 16.Engine oil seal contains grease. If grease leaks, it may cause slight pollution to water body. 17.The machine should be charged under 5°C-35°C environment. When the battery is overheated, it shall be cooled before charging. 18.When the machine is stored for a long time, it shall be charged every three months. Please use the original charger to charge the machine, so as to ensure that the power of the machine is kept at 40%-60%. If the machine is not charged for a long time, the battery voltage will be lower than the overdischarge protection voltage due to the self-discharge of the battery, and when the time is too long, fatal damage will be caused to the battery, so please pay attention to this. 19.It is forbidden to pierce the shell of the machine with nails or other sharp objects, and it is forbidden to hammer, hit or throw the machine. 20.Do not charge the machine under fire or extremely hot conditions! Do not use or store the machine near heat sources. 21.During the operation of the machine underwater, slight "lifting" of the machine may occasionally occur, it is a normal operation procedure of the machine, not a failure. Caution 1.When putting the cleaner into the swimming pool, the bottom of the cleaner shall face the pool wall, hold the handle and press the cleaner into the water. At the same time, turn on the switch, and the cleaner will slowly discharge the gas, and after 30s, it starts to work (The gas in the cleaner must be completely discharged, otherwise gas will affect the normal work of the machine). Make the machine naturally sinks to the bottom of the pool. 2. When the cleaner completes the cleaning, it will automatically lean against the pool wall. Take out the machine with hook. 05 WY200 robotic pool cleaner is a new and efficient robotic pool cleaning equipment. It can automatically clean the swimming pool without discharge of the pool water. At the same time, through the filtration system, it collects the suspended solids and sediments in the water. The main machine body is powered by 25.2V/6.4AH lithium ion battery pack, so it has high safety. 1.Requirements for machine position during charging: See Article 4 of "Safety Instructions" on page 1. 2.Ple…
