说明书制作要求 此页不印刷 印刷内容：H1200 I / H1200Pro I 说明书 中性 美规 产品规格：25.6V, 42Ah/1075.2Wh 产品版本：H1200ProIM V1.0.00 物料编码：3.06.03.0307 —— 成品尺寸：142x210mm 展开尺寸：284x210mm 钉装：骑马钉 20P 材质：128g/157g 双铜纸 1 H1200 USER MANUAL Thank you for purchasing H1200 Series high quality power station To ensure your personal safety, Property safety and good user experience, Please read this User Manual carefully before operation and keep it for future reference. Charging instructions Before using your new Power Station H1200 Series, plug it into a suitable power outlet until it is fully charged. Then you can start your exciting journey with it. — 01 — WARNING Please read the following instructions for safety before use. Improper use may result in fire, property damage or personal injury or death. DO NOT use the product with incompatible components or alter the product in any way. WARNINGWARNING Improper use may result in fire, property damage, or personal injury. Make sure to use the product according to the following safety rules and guidelines. Do not expose the product to any liquid or submerge in water. If the battery comes into contact with water, it may cause chemical decomposition of the battery. This may cause the battery to catch fire or explode. SAFETY INSTRUCTIONS Read the following instructions to ensure safe usage: Carefully read the instructions for the electric devices that you intend to connect to your power. Product Maintenance: 1. Battery life may be reduced or become nonfunctional if not properly maintained. 2. Fully charge and discharge at least every 3 months to ensure battery life. 3. Do not store battery with less than 50% charge. DANGER Noncompliance may very likely lead to serious injury*or death. • DO NOT disassemble, repair or modify the unit or the battery. • DO NOT place the unit close to or in a fire or expose it to heat. Keep out of direct sunlight. • DO NOT charge, use or store the unit in a bathroom or in an area exposed to rain or moisture. Only use the output socket to power external devices. • Never connect the output to mains power under any circumstances. • DO NOT touch the unit or the plug in points if your hands are wet. • DO NOT connect any metallic objects to the AC input or output. • DO NOT rub your eyes if fluid from inside the unit should get in your eyes. • DO NOT dispose the unit together with household waste. • DO NOT use any inappropriate power cords. • DO NOT operate the unit above the specified input voltage. • DO NOT use the unit if it is not functioning correct. • DO NOT move the unit if it is recharging or in use. WARNING Noncompliance may lead to serious injury** or death. • Use and store the unit only in a clean and dry environment. Do not use and store in dusty and wet environment. • Check the unit prior to every use. Do not use the unit if it is damaged, broken. • DO not use the unit if the power cord is damaged or broken. Keep the unit away from children. • DO NOT let children use the power supply unit. Keep this product away from pets. • DO NOT use or store the unit in an area or environment with high temperature. • Should fluid from inside of the unit come in contact with your skin or clothing, wash the affected areas with tap water. In a storm, unplug the power cord from the socket. • DO NOT charge the device through a power system other than the rated voltage. • DO NOT place the unit on its side or upside down while in use or storage. • DO NOT use accessories for other usage. CAUTION Noncompliance may lead to injuries and/or property damage** • If rust peculiar odors. overheating or other abnormal circumstances are observed, stop using the unit immediately and contact the dealer or our customer service center. • The unit complies with all legal requirements for transport of dangerous goods. • Make sure that the unit is properly secured when transporting it in a motor vehicle. • Only charge, use and store the unit within an ambient temperature of 0 to 40°C (32 ~104 °F ). • Switch the unit off immediately if it has accidentally fallen, was dropped or was exposed to vibrations. • Once the unit is fully charged, unplug the AC charging cable. We is not liable for any damage caused by using different brand charging cables. • Use of different cables will void the products warranty and may cause damage or serious bodily injury. — 02 — PRODUCT INTRODUCTION H1200 Series with high capacity and high safety battery pack. It is very convenient for emergency off-grid demand such as sudden power failure, snowstorm or hurricane, outdoor tourism, outdoor operation, RV power supply, etc. There is perfect performance with great power output up to 1200W, fast charging, high capacity and long cycle life. Dual-machine parallel output 2400W Max, support more high-power equipment, more durable. LOAD CAPACITY The data reference conversion efficiency is 85%, because the environment and usage methods will fluctuate, and the data is for reference only. PACKING LIST Principal machine / User manual / AC charging cable / MC4 to Anderson cable (optional accessory) / Car charger to Anderson cable (optional accessory) / H1200Pro Parallel Cable (optional accessory). It is recommended to use 120W/200W/300W/400W Solar Panels. Principal machine User ManualAC charging cable MC4-Anderson connector cable (optional accessory) 12V Car Anderson cable (optional accessory) H1200Pro Parallel Cable (optional accessory) Laptops (41.4Wh) Around 22 Recharges Mini Fridge (40W) Around 22 hours 32" TV (60W) Around 15 hours DJ Drone (89.2Wh) Around 10 Recharges CPAP without heated humidifier (15W) 60 hours Smartphone (10Wh) Around 91 Recharges GoPro (5.9Wh) Around 154 Recharges Switch (16Wh) Around 57 Recharges Floodlight (5W) Around 182 hours +MORE — 03 — CONTENTS SAFETY INSTRUCTIONS ·······························01 PRODUCT INTRODUCTION ····························02 LOAD CAPACITY ·····································02 PACKING LIST ·······································02 PRODUCT FUNCTION DESCRIPTION ··············…
