2BASYAD-13HALO Wireless Charge Pad

FOR ALL QUESTIONS ABOUT THE WARRANTY OR EXCHANGE REQUESTS, CONTACT US. 1-800-255-6061 — 01 — WARNING • • • • • • • • • • — 02 —— 03 — — 04 — TROUBLESHOOTING IssueCauseSolutions Device is not charging. The device might not be on the charging pad properly. The case on the device might be too thick, preventing the device from charging. Remove the device and replace it onto the charging pad properly. Remove the case from the device before trying to charge again. The LED indicator is not lighting up. The charging pad is not getting power. Disconnect the charging pad from the power source. Make sure the cable and wall adapter are connected properly. Connect the charging pad to another power source. Flashing LED indicator Foreign Object Detection (FOD) is triggered. A metal object is detected by the charging pad. Remove the metal object between your device and the charging pad. If your device case contains metal, then remove your case. times. — 06 —— 07 — TECHNICAL SPECIFICATIONS INPUT DC QC 5V/2A, 9V/1.67A, 12V/1.5A PD 5V/3A, 9V/2.2A OUTPUT Wireless5W/7.5W/10W/15W Transmission Distance Earbuds: 0.12 inches (3mm) Phone: 0.2 inches (5mm) Working Frequency110-205KHz PRODUCT Dimensions4.35 x 4.35 x 0.40 inches (11.05 x 11.05 x 1.02cm) Weight0.15lb (66g) Warning： — 05 — The FCC certification of this device refers to RF exposure testing performed in typical operating conditions, where a person is no closer than 20 centimeters from the device surface at all times, except for non-repetitive patterns with transient time intervals in the order of a second. Only in the stated conditions, the device is shown to fully comply with the FCC RF Exposure requirements of KDB 447498.

Alliance Sports Group., LP 700 Henrietta Creek Rd. Roanoke, TX 76262 Roanoke Texas United States Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-3-19 To whom it may concern: We, Alliance Sports Group., LP, hereby certify that the equipment for which authorization is sought (FCC ID: 2BASYAD-13) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Kelsey McCoy Vice President - Engineering Alliance Sports Group., LP 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

-AllianceSportsGroup.,LP- FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 3/19/24 U.S.AgentDesignation AllianceSportsGroup.,LPacknowledgestheirconsentforthefollowingcontactlocatedintheUnitedStates toactastheiragentforserviceofprocessfortheequipmentforwhichauthorizationissought(FCC ID:2BASYAD-13): NameandcompanyofU.S.agent: REPAmericaLLC PhysicalU.S.addressofagent:BenXU,6510SAcademyBlvd,SteA#523,ColoradoSprings,CO 80906 FRNofU.S.agent: 0034192500 EmailaddressofU.S.agent: [email protected] REPAmericaLLCacknowledgestheirobligationtoacceptserviceofprocessonbehalfofAllianceSports Group.,LP. AllianceSportsGroup.,LPwiththeFRN0033635236acceptsitsobligationtomaintainanagentforservice ofprocessintheUnitedStatesfornolessthanoneyearaftereitherthegranteehaspermanentlyterminatedall marketingandimportationoftheapplicableequipmentwithintheU.S.,ortheconclusionofanyCommission- relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheverislater. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirementslistedunder§ 2.911(d)(7). TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB 986446D01. Anexpirationdateforthisletterdoesnotexist.IncasetheU.S.agentchanges,thegranteeisobligatedtonotify theFCCwithin30daysviathegrantingTCB. Sincerely, Signature KelseyMcCoy generalmanager AllianceSportsGroup.,LP Signature BenXU Manager REPAmericaLLC 4 8 _ [ m o d e l ] U S _ A g e n t _ 2 . 9 1 1 ( d ) ( 7 ) - U , V 0 5

Alliance Sports Group., LP Add: 700 Henrietta Creek Rd. Roanoke, TX 76262 Roanoke Texas United States Date: 2024-3-19 FCC ID: 2BASYAD-13 Dear Sir/Madam, We, Alliance Sports Group., LP Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: HALO Wireless Charge Pad Model no.: AD-13, C-13,C30,C35,F1,F2,F2B,F4,F7 Sincerely, Name/Title： Kelsey McCoy/Vice President - Engineering Company: Alliance Sports Group., LP Address: 700 Henrietta Creek Rd. Roanoke, TX 76262 Roanoke Texas United States Phone: (972) 343-1014 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-3-19> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2BASYAD-13 AD-13 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Kelsey McCoy/Vice President - Engineering Company: Alliance Sports Group., LP Address: 700 Henrietta Creek Rd. Roanoke, TX 76262 Roanoke Texas United States Phone: (972) 343-1014 Fax: N/A E-Mail: [email protected]

Alliance Sports Group., LP 700 Henrietta Creek Rd. Roanoke, TX 76262 Roanoke Texas United States Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-3-19 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BASYAD-13 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Kelsey McCoy/Vice President - Engineering Company: Alliance Sports Group., LP Address: 700 Henrietta Creek Rd. Roanoke, TX 76262 Roanoke Texas United States Phone: (972) 343-1014 Fax: N/A E-Mail: [email protected]

Page1of5FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. EUTConstructionalDetails ExternalEUTPhoto Photo1 Photo2 Page2of5FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. Photo3 Photo4 Page3of5FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. Photo5 Photo6 Page4of5FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. Photo7 Photo8 Page5of5FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. Photo9 ---TheEnd---

FCCLabel FCCID: 2BASYAD-13

Page1of5FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. EUTConstructionalDetails InternalEUTPhoto Photo1 Photo2 Page2of5FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. Photo3 Photo4 Page3of5FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. Photo5 Photo6 Phone Antenna Page4of5FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. Photo7 Photo8 Page5of5FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. Photo9 ------End------

Page 1 of 7 FCCID:2BASYAD-13 RFExposureEvaluation 1MeasuringStandard Accordingto§1.1307(b)(1),systemsoperatingundertheprovisionsofthissectionshallbeoperatedina mannerthatensuresthatthepublicisnotexposedtoradiofrequencyenergylevelinexcessofthe Commission’sguidelines.Accordingto§1.1310and§2.1091RFexposureiscalculated.According KDB680106D01:KDB680106D01WirelessPowerTransferv04. 2Requirements Accordingtotheitem3ofKDB680106D01v04: Inductivewirelesspowertransferapplicationsthatmeetallofthefollowingrequirementsareexcluded fromsubmittinganRFexposureevaluation. (1)MobileDeviceandPortableDeviceConfigurations (2)EquipmentAuthorizationProceduresforDevicesOperatingatFrequenciesBelow4MHz (3)TheaggregateH-fieldstrengthsanywhereatorbeyond15cmsurroundingthedevice,and20cm awayfromthetopsurface. Limits Thecriterialistedinthefollowingtableshallbeusedtoevaluatetheenvironmentimpactofhumanexposure toradiofrequency(RF)radiationasspecifiedin1.1307(b) LimitsforMaximumPermissibleExposure(MPE) Page 2 of 7 FCCID:2BASYAD-13 3TestSetup 4TestProcedure 1)TheRFexposuretestwasperformedinanechoicchamber. 2)Themeasurementprobewasplacedattestdistance(15cmfromallsidesand20cmfromthetop)whichis betweentheedgeofthechargerandthegeometriccenterofprobe. 3)Thehighestemissionlevelwasrecordedandcomparedwithlimitassoonasmeasurementofeachpoints (A,B,C,D,E)werecompleted. 4)TheEUTwasmeasuredaccordingtothedictatesofKDB680106D01WirelessPowerTransferv04. Remark：TheEUT’stestpositionA,B,C,DandEisvalidfortheEandHfieldmeasurements. 5EquipmentApprovalConsiderations TheEUTdoescomplywithKDB680106D01asfollowtable. RequirementsofKDB680106D01 Yes/No Description MobileDeviceandPortableDevice Configurations YesMobileDevice EquipmentAuthorizationProceduresfor DevicesOperatingatFrequenciesBelow4MHz Yes Thedeviceoperateinthefrequencyrange 113kHz-205kHz RFExposurecompliancemaybeensuredonly foraminimumseparationdistancethatisgreater than20cm,whileuseconditionsatsmaller distancescanstillbeconsideredunlikely. Yes TheEUTH-fieldstrengthsat15cm surroundingthedeviceand20cmabovethe topsurface. Page 3 of 7 FCCID:2BASYAD-13 6Descriptionofthetestmode Equipmentundertestwasoperatedduringthemeasurementunderthefollowing conditions: Test Mode Description Mode1 ACAdapter+EUT+Mobilephone Record Mode2 TesttheEUTinidlemode. Pre-tested Note:1.Alltestmodeswerepre-tested,butweonlyrecordedtheworstcaseinthisreport. 2.Unfoldedandfoldedmodeweretested,butweonlyrecordedtheworstcase. 7PeripheralList 8TestInstrumentslist TestEquipmentManufacturerModelNo.SN. Cal.Date (mm-dd-yy) Cal.Duedate (mm-dd-yy) ElectricandMagnetic FieldAnalyzer NardaEHP-200A180ZX1050521.06.202220.06.2024 N o. EquipmentManufacturerModelNo. Serial No. Powercordsignalcable 1Adapter HNTHNT-QC530N/AN/A N/A 2 Wireless charger receiver SLY15WN/AN/AN/A Page 4 of 7 FCCID:2BASYAD-13 9TestResult E-FiledStrengthat15cmfromtheedgessurroundingtheEUT(V/m) UnitTestmode TM1 Test Position A Test Position B Test Position C Test Position D Test Position E 50% Limits (V/m) Limits (V/m) V/mPhoneport92.56100.43101.2598.3387.98307614 H-FiledStrengthat15cmfromtheedgessurroundingtheEUT(A/m) UnitTestmode TM1 Test Position A Test Position B Test Position C Test Position D Test Position E 50% Limits (A/m) Limits (A/m) A/mPhoneport0.2160.2100.2010.1870.2150.8151.63 H-FiledStrengthat20cmfromthetopoftheEUT(A/m) UnitTestmode TM1 Test PositionE 50%Limits (A/m) Limits (A/m) A/mPhoneport0.2100.8151.63 Note:Alltestmodeswerepre-tested,butweonlyrecordedtheworstcaseinthisreport. Page 5 of 7 FCCID:2BASYAD-13 10TestSetupphoto TestPositionA-15cmfromtheedgeofEUTtothegeometriccenteroftheprobe TestPositionB-15cmfromtheedgeofEUTtothegeometriccenteroftheprobe Page 6 of 7 FCCID:2BASYAD-13 TestPositionC-15cmfromtheedgeofEUTtothegeometriccenteroftheprobe TestPositionD-15cmfromtheedgeofEUTtothegeometriccenteroftheprobe Page 7 of 7 FCCID:2BASYAD-13 TestPositionE-15cmfromtheedgeofEUTtothegeometriccenteroftheprobe TestPositionE-20cmfromtheedgeofEUTtothegeometriccenteroftheprobe ***Endofreport***

Page1of23ReportNo.:AIT23121503FW1 DongguanYaxu(AiT)TechnologyLimited No.22,JinqianlingThirdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. FCCTESTREPORT ClientInformation: Applicant: AllianceSportsGroup.,LP Applicantadd.:700HENRIETTACREEKROADROANOKE,TX76262 ProductInformation: ProductName:HALOWirelessChargePad ModelNo.:AD-13,C-13,C30,C35,F1,F2,F2B,F4,F7 BrandName:N/A FCCID:2BASYAD-13 Applicablestandards : FCCCFRTitle47Part15SubpartC PreparedBy: DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang,Huangjiang,Dongguan, Guangdong,China Tel.:+86-769-82020499Fax.:+86-769-82020495 DateofReceipt:Dec.15,2023DateofTest:Dec.15,2023~Dec.21,2023 DateofIssue:Dec.22,2023TestResult:Pass ThisdevicedescribedabovehasbeentestedbyDongguanYaxu(AiT)TechnologyLimitedandthe testresultsshowthattheequipmentundertest(EUT)isincompliancewiththeFCCrequirements. Anditisapplicableonlytothetestedsampleidentifiedinthereport. Note:Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofDongguan Yaxu(AiT)TechnologyLimited,thisdocumentmaybealteredorrevisedbyDongguanYaxu(AiT) TechnologyLimited,personalonly,andshallbenotedintherevisionofthedocument.Thistest reportmustnotbeusedbytheclienttoclaimproductendorsement. Reviewedby:Approvedby: SimbaHuangSeal.chen Page2of23ReportNo.:AIT23121503FW1 DongguanYaxu(AiT)TechnologyLimited No.22,JinqianlingThirdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. 1Contents Page COVERPAGE 1CONTENTS..................................................................................................................................................................2 2TESTSUMMARY........................................................................................................................................................5 2.1STATEMENTOFTHEMEASUREMENTUNCERTAINTY..................................................................................................5 2.2MEASUREMENTUNCERTAINTY.................................................................................................................................5 3TESTFACILITY...........................................................................................................................................................6 3.1DEVIATIONFROMSTANDARD...................................................................................................................................6 3.2ABNORMALITIESFROMSTANDARDCONDITIONS........................................................................................................6 3.3TESTLOCATION......................................................................................................................................................6 4GENERALINFORMATION.........................................................................................................................................7 4.1EUTTESTMODE....................................................................................................................................................8 4.2DESCRIPTIONOFTESTSETUP.................................................................................................................................8 4.3PERIPHERALLIST....................................................................................................................................................9 4.4EUTPERIPHERALLIST...........................................................................................................................................9 5EQUIPMENTSLISTFORALLTESTITEMS...........................................................................................................10 6CONDUCTEDEMISSIONTEST...............................................................................................................................11 6.1CONDUCTEDEMISSIONMEASUREMENT.....................................................................................................11 6.2POWERLINECONDUCTEDEMISSIONLIMITS................................................................................................11 6.3TESTPROCEDURE...........................................................................................................................................11 6.4DEVIATIONFROMTESTSTANDARD..............................................................................................................12 6.5TESTSETUP......................................................................................................................................................12 6.6EUTOPERATINGCONDITIONS.......................................................................................................................12 6.7TESTRESULT.......................................................................................................................................................13 7RADIATEDEMISSIONMEASUREMENT................................................................................................................15 7.1RADIATEDEMISSIONLIMITS..................................................................................................................................15 7.2ANECHOICCHAMBERTESTSETUPDIAGRAM.........................................................................................................16 7.3TESTPROCEDURE................................................................................................................................................16 7.4DEVIATIONFROMTESTSTANDARD..............................................................................................................16 7.5TESTRESULT.......................................................................................................................................................17 8BANDWIDTHTEST...................................................................................................................................................20 8.1TESTPROCEDURE............................................…

Text truncated - open the document above for the full version.

Fine Page 1 of 3 FINE ELECTRONICS INDUSTRIAL (HK) LIMITED 泛亞電子實業(香港)有限公司 TEL：0769-22490287 FAX：0769-22499451 FY-GZ001 承認書 SPECIFICATION FOR APPROVAL 客戶： CUSTOMER: 澳德鸿 客戶料號： CUST P/N: 泛亞料號： FINE P/N: 産品型號： DESC: φ20.5x43-10Ts-0.08x105-50mm-50C 日期： DATE: 2018/01/20 版本： Version: A.0 擬制 PREPARED BY 審核 CHECKED BY 批准 APPROVED BY 客戶承認 CUSTOMER APPROVE 郭洋洋 蔡纪雨 倪星 泛亞電子實業（HK）有限公司 FINE ELECTRONICS INDUSTRIAL （HK）LIMITED 工廠地址：東莞市石碣鎮四甲工業區 TEL：0769-22490287 / 22452492 FAX：0769-22499451 E-mail：[email protected] Fine Page 2 of 3 FINE ELECTRONICS INDUSTRIAL (HK) LIMITED 泛亞電子實業(香港)有限公司 TEL：0769-22490287 FAX：0769-22499451 FY-GZ001 版本變更履歷 Version Change History 版本 Rev. 變 更 前 Before Change 變 更 後 After Change 更 改 日 期 Change Date 批 准 Approved By A.0 新发行 ---- 2018/01/20 倪星 Fine Page 3 of 3 FINE ELECTRONICS INDUSTRIAL (HK) LIMITED 泛亞電子實業(香港)有限公司 TEL：0769-22490287 FAX：0769-22499451 FY-GZ001 SPECIFICATION 産品型號： DESC φ20.5x43-10Ts-0.08x105-50mm-50C 版本 Rev：A.0 客戶CUST: 澳德鸿 泛亚料号 Fine P/N： 客户料号CUST P/N: 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATIC DIAGRAM: A 43±1.5 B 20.5±0.5 C 1.2±0.2 D 50±3 E 2-5 F 30±1 G 8.0 ref H 3.2max I 1.0±0.2 Note: 1. Cross outlet; 2. The coil is attached to a circular hard disk, the disk size is 50±1mm, and the thickness is 1.0±0.2mm..; 3. Coil with 8mm wide high temperature adhesive paper; 4. Tape the back of the magnetic disc with hand-torn double-sided tape； 三、绕线参数Winding Specification: 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 1 S F silk-covered wire 0.08*105P10Ts CCW 四、电气特性ELECTRICAL CHARACTERISTICS: 温度TEMPERATURE:25±10°C, 湿度RELATIVE HUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 IND. S-F 3.8 u H ±30% 单独线圈 100KHz/1.0V LCZ METER 1062B 2 IND. S-F 6.5 u H ±10% 加磁片 100KHz/1.0V LCZ METER 1062B 3 DCR S-F 擬制/日期PREPARED BY/DATE 審核/日期CHECKED BY/DATE 郭洋洋2018/01/20 蔡纪雨2018/01/20 113kHz-205kHz

Page1of2FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. TestSetupPhoto RadiatedEmission Page2of2FCCID: 2BASYAD-13 DongguanYaxu(AiT)TechnologyLimited No.22,Jinqianling3rdStreet,Jitigang, Huangjiang,Dongguan,Guangdong,China. ConductedEmission ------End------
