2BAT6-A011WI-FI CAMERA

1 of 20 PL-C390-921 Rev. 2.2 2022-04 A-390 WI-FI CAMERA For Software version 2.00 and posteriors For Serial Numbers higher than M-20000uctions Instructions For Use English The Instructions for Use may be updated without further notice. The latest version is available on www.airtraq.com. To check for latest software versions available connect A-390 to “Airtraq Cam” application on PC or visit www.airtraq.com 2 of 20 INDEX 1. A-390 Intended Use and Basic information 2. A-390 Components 3. A-390 Switches, indicators and connectors 4. A-390 Battery charge & charge status checking 5. Mounting the A-390 onto the Airtraq 6. Turn On/Off 7. Touch Panel & Menus 8. Airtraq Cam app for PC and Mobile devices 9. Initial Set Up 10. Paediatric Mode 11. Image Rotation 12. Record, Auto-Record and Snapshot 13. Play recorded videos and view Snapshots on A-390 14. Download videos and snapshots to a PC/MAC. Delete videos and snapshots. 15. Connecting Wi-Fi and recording with Tablet / Phone / PC 16. View System Information 17. Updating A-390 Internal Software 18. Troubleshooting 19. Cleaning Instructions 20. Operating, Storage And Transport Conditions 21. Technical Data 22. Regulatory 23. Disposal Instructions 24. Manufacturer’s Warranty 25. Important Safety Instructions 26. User Assistance Information 27. Glossary of Symbols 3 of 20 1. A-390 INTENDED USE AND BASIC INFORMATION Code: A-390 Description: Airtraq Wi-Fi Camera The A-390 is an accessory for the Airtraq Video Laryngoscope. It is compatible with all Airtraq Video laryngoscopes models. Intended Use: The A-390 shall be attached to an Airtraq Video Laryngoscope and its intended purpose is to provide full colour, real-time images on its 2.8 inch integrated touch screen. A-390 is powered by an internal rechargeable 3.7 V Li-Po battery. A-390 does not work while connected to a battery charger. A-390 battery shall be charged at least 1.8 m. away from the patient. In case A390 is not operative by any cause (battery not charged, etc) the user can still intubate looking directly through the eyecup of the Airtraq Video Laryngoscope. Auxiliary Functions: The A390 provides the following additional functions that are not included in its intended purpose: sending real time images via Wi-Fi to a mobile device; video playback on A390 ́s screen; wire connection to a PC for video downloading or software update. A temporary failure of any of these functions, due to an abnormal circumstance, will not increase the patient ́s risk and will not compromise A390 ́s intended use, therefore it would be acceptable. 2. A-390 COMPONENTS 2.1. A-390 Camera CMOS video camera with integrated touch screen and rechargeable Li-Po Battery. 2.2. USB-C cable To be used to connect the A-390 to a PC for video downloading or for camera’s settings administration. May also be used to charge the A390 directly from a USB power source. 2.3. Silicon protective case Provides additional protection against shocks. It can be easily installed onto or removed from the camera. 2.4. Battery charger Must be connected to mains supply to charge the 3.7 volts, Li-Po Battery. 2.5. Docking station Accessory to facilitate charge of A-390. Docking Station can also be used to charge the A-360 Airtraq Wi-Fi Camera. 4 of 20 The mains power supply is connected to the Docking Station through its micro USB-C connector. 2.6. Neoprene pouch Can be used to store some of the A390 accessories. 2.7. Storage case (two sizes) Can be used to store all or some of the above items. It is recommended that the A-390 be stored and transported inside the storage case to protect the camera while not in use. A-390 can be charged when it is inside the storage case by connecting the USB-C cable directly to the camera and zipping the case partially closed allowing room for the cable to exit the case and plugged into power. 3. A-390 SWITCHES, INDICATORS AND CONNECTORS A. Automatic power button: This button is automatically pushed when the A-390 is inserted onto any Airtraq. It can also be pushed manually to turn on the A-390. To turn off the A-390 press the corresponding icon on the menu. B. Battery charge connector: Brass surface connectors that connect to docking station for battery charge. C. USB-C female connector connector: to connect to PC or to battery charger. D. Battery charge connector: Brass surface connectors that connect to Camera for battery charge. E. USB-C female connector: to connect to mains power supply. 4. A-390 BATTERY CHARGE AND CHARGE STATUS CHECKING The A-390 DOES NOT WORK WHEN IT IS BEING CHARGED. 5 of 20 IT SHOULD BE CHARGED AT LEAST 1.8 M AWAY FROM THE PATIENT It is recommended to perform a full charge/discharge cycle of the battery before starting to use the A-390 for clinical purposes. After a full charge, the A-390 can operate for around 120 minutes when Wi-Fi is deactivated and for around 90 minutes when Wi-Fi is activated. Recharging takes approximately 110 minutes. Without use, the battery will discharge at a rate of around 1% per day. If the A-390 can be turned on, then a minimum of 10 minutes of operating time is guaranteed. When the A-390 is turned on, a battery charge status icon and available minutes of operating time appear on the screen. To charge battery: 1. Connect the battery charger to Docking station and to mains electrical supply. 2. Place A-390 onto docking station. 3. A-390 can also be charged connecting directly the battery charger provided to the USB-C connector of the A390. Upon starting to charge battery the A-390 will automatically turn Off. Also, touching the screen while charging or when fully charged will show available minutes of operating time and a battery icon. When in use, the battery charge indicator on the header of the screen will show available minutes of operating time and a battery icon in different colours. Service life for the rechargeable battery depends upon the number of charge-discharge cycles performed. Battery can be expected to lose around 25% of its capacity after 500 …

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 2 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name PRODOL MEDITEC, S.A. Address Muelle Tomas Olavarri 5, 3 drcha (Vizcaya), Las Arenas, Spain, 48930 Grantee Code 2BAT6 FCC ID 2BAT6-A011 Authorized Contact Name Luis Ruiz-Ozaita Contact Email [email protected] Contact Phone +34944804690 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List PRODOL MEDITEC, S.A. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. PRODOL MEDITEC, S.A. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 2 of 2 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Signature: Date: 2023/5/29 Print Name: Luis Ruiz-Ozaita Title: General Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

PRODOL MEDITEC, S.A. U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) T O: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 A TTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: United Consulting Technology Services Co., Ltd. FRN: 0033495714 Contact Name: David Wu Street Address: 17800 CASTLETON ST STE 665 CITY OF INDUSTRY CA 91748 United States Telephone No: (626) 217-4022 Email: [email protected] T his letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U .S. Agent Signature: D ate: 2023/5/29 Signed by (Printed Name/Title): David Wu/CEO T he Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. A pplicant Company name: PRODOL MEDITEC, S.A. G rantee Code: 2 BAT6 FCC ID: 2 BAT 6-A0 11 Contact Name: Luis Ruiz-Ozaita Street Address: Muelle Tomas Olavarri 5, 3 drcha (Vizcaya) City/Province/Zip: Las Arenas/-/ 48930 Telephone No: +34944804690 Email: [email protected] Applicant Signature: Date: 2023/5/29 Signed by (Printed Name/Title): Luis Ruiz-Ozaita / General Manager

PRODOL MEDITEC, S.A. Authority letter FCC Date: 2023/5/29 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2BAT6-A011 To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Guangzhou branch and Bonnie Liao in SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Guangzhou branch to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with applicant company FCC. This authorization is valid until further written notice from the applicant. Name (Printed): Luis Ruiz-Ozaita Title: General Manager Signature: On behalf of Company: PRODOL MEDITEC, S.A.

PRODOL MEDITEC, S.A. Confidential letter FCC To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: PRODOL MEDITEC, S.A. Muelle Tomas Olavarri 5, 3 drcha (Vizcaya) Las Arenas, 48930, Spain Regarding: Confidentiality Request regarding application for FCC ID: 2BAT6-A011 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Name (Printed): Luis Ruiz-Ozaita Title: General Manager Signature: On behalf of Company: PRODOL MEDITEC, S.A.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 1 of 4 Appendix External Photos for GZCR2210001338HS SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 2 of 4 EUT Constructional Details (EUT Photos) There is no RF in this part SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 4 of 4

label Location:

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 1 of 7 Appendix Internal Photos for GZCR2210001338HS SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 2 of 7 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 3 of 7 RF ANT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 4 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 5 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 6 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 7 of 7

2.45 GHz SMD Chip AntennaP/N 2450AT43A100 Detail Specification: Page 1 of 6 Part NumberInput Power Frequency RangeImpedance Peak GainOperating Temperature Average GainReel Quanity Return Loss Part Number Explanation BulkSuffix = S T & RSuffix = E 100% Tin Suffix = None Tin / LeadPlease Consult Factory Mechanical Dimensions ±± ±± ++ ±± Mounting Considerations - Vertical Mounting Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.12012 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 2450AT43A100 1/11/2013 2W max. 50 Ω2400 - 2500 Mhz General Specifications - Vertical Mounting T No. Function 1 Signal Feed Terminal NC (To be used as Anchoring to PCB)0.20 0.1/-0.2 2 7.00L 0.008 P/N Suffix Terminal Configuration -40 to +85°C 1,000 eg. 2450AT43A100S eg. 2450AT43A100E eg. 2450AT43A100 (E or S) 2.0 dBi typ. (XZ-V) 0.5 dBi typ. (XZ-V) 9.5 dB min. Packing Style Termination style 0.50 0.276 W a mm 0.008 1.20 2.00 In 0.079 0.047 0.020 0.20 0.300.012 .004/-.008 1 2 L W a T * GND Plane GND Plane 2.0 5.5 8.0 1.0 0 Note: Matching components may be needed when designing into a PCB so, make sure to leave a shunt-series- shunt or "pi" network available space/footprint when laying out. More info: http://johansontechnology.com/tuning Mount these devices with brown mark facing up. Units: mm * Line width should be designed to provide 50 Ω impedance matching characteristics. 2.45 GHz SMD Chip AntennaP/N 2450AT43A100 Detail Specification: Page 2 of 6 Test Board of Vertical Mounting style, p/n: 2450AT43A100-EB1SMA * This 50ohm trace to the antenna can be shorten (considerably) to suit your PCB space constraints Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.12012 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 1/11/2013 Typical Electrical Characteristics (T=25°C) ) ) ) 40mm Return Loss Antenna No Ground Ground 20mm 19mm 40mm 9.5m 50Ω Feed Line 0Ω 2.45 GHz SMD Chip AntennaP/N 2450AT43A100 Detail Specification: Page 3 or 6 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.12012 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 1/11/2013 Typical Electrical Characteristics (T=25°C) Typical Radiation Patterns on Test Board of Vertical Mounting p/n: 2450AT43A100-EB1SMA ) XY-V/XY-H 180° 270° 0° 90° X Z Y XY-cut scanning direction XY cut @2.45GHz Vertical Horizontal XZ-V/XZ-H YZ-V/YZ-H 180° 270° 0° 90° X Z Y XZ-cut scanning direction 180° 270° 0° 90° X Z Y YZ-cut scanning direction XZ cut @2.45GHz Vertical Horizontal YZ cut @2.45GHz Vertical Horizontal 2.45 GHz SMD Chip AntennaP/N 2450AT43A100 Detail Specification: Page 4 of 6 Part NumberInput Power Frequency RangeImpedance Peak GainOperating Temperature Average GainReel Quanity Return Loss Mounting Considerations - Horizontal Mounting Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.12012 Johanson Technology, Inc. All Rights Reserved 2400 - 2500 Mhz50 Ω High Frequency Ceramic Solutions 1/11/2013 General Specifications - Horizontal Mounting 2450AT43A1002W max. 2.0 dBi typ. (XZ-V)-40 to +85°C 1.0 dBi typ. (XZ-V)1,000 9.5 dB min. Note: Matching components might be needed when design into a PCB so, make sure to leave a shunt-series- shunt or "pi" network available space/footprint when laying out. More info: http://johansontechnology.com/tuning Mount these devices with brown mark facing up. Units: mm * Line width should be designed to provide 50 Ω impedance matching characteristics. 5.5 8.0 1.0 2.0 0 Ohm GND * GND 6.8 2.45 GHz SMD Chip AntennaP/N 2450AT43A100 Detail Specification: Page 5 of 6 Test Board of Horizontal Mounting style, p/n: 2450AT43A100-EB2SMA * This 50ohm trace to the antenna can be shorten (considerably) to suit your PCB space constraints Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.12012 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 1/11/2013 Typical Electrical Characteristics (T=25°C) ) Return Loss 9.5mm Ground 20mm 40mm No Ground 50Ω Feed Trace (CPWG) 40mm 5mm 9mm Matching Circuit 2.5mm 2.45 GHz SMD Chip AntennaP/N 2450AT43A100 Detail Specification: Page 6 or 6 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.12012 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 1/11/2013 Typical Electrical Characteristics (T=25°C) Typical Radiation Patterns on Test Board of Vertical Mounting p/n: 2450AT43A100-EB2SMA ) XY-V/XY-H 180° 270° 0° 90° X Z Y XY-cut scanning direction XY cut @2.45GHz Vertical Horizontal XZ-V/XZ-H YZ-V/YZ-H 180° 270° 0° 90° X Z Y XZ-cut scanning direction 180° 270° 0° 90° X Z Y YZ-cut scanning direction XZ cut @2.45GHz Vertical Horizontal YZ cut @2.45GHz Vertical Horizontal

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000133803 Page: 1 of 9 FCC ID: 2BAT6-A011 Ricky Liu Manager RF EXPOSURE EVALUATION REPORT Application No.: GZCR2210001338HS Applicant:PRODOL MEDITEC, S.A. Address of Applicant:Muelle Tomás Olavarri 5, 3 o drcha 48930 Las Arenas (Vizcaya) SPAIN Manufacturer:PRODOL MEDITEC LIMITED Address of Manufacturer:1/F,4/F Block C, NO.18, 7th Science Ave. Zhuhai Guangdong 519085 China. Factory:PRODOL MEDITEC LIMITED Address of Factory:1/F,4/F Block C, NO.18, 7th Science Ave. Zhuhai Guangdong 519085 China. Equipment Under Test (EUT): EUT Name:WI-FI CAMERA Model No.: A-390 Trade Mark: Standard(s) : KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2022-10-21 Date of Evaluation: 2022-12-06 to 2022-12-27 Date of Issue: 2023-06-07 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000133803 Page: 2 of 9 Revision Record VersionReport No.DateRemark 01GZCR2210001338032023-06-07Original Authorized for issue by: Curry Wu/Project Engineer Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000133803 Page: 3 of 9 2Evaluation Summary ItemStandardMethodRequirementResult RF Exposure KDB447498D01 General RF Exposure Guidance v06 KDB447498D01 General RF Exposure Guidance v06 KDB447498D01 General RF Exposure Guidance v06 Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000133803 Page: 4 of 9 3Contents Page 1Cover Page...............................................................................................................................................1 2Evaluation Summary................................................................................................................................3 3Contents....................................................................................................................................................4 4General Information.................................................................................................................................5 4.1Details of E.U.T.................................................................................................................................5 4.2Evaluating Location...........................................................................................................................5 4.3Facility...............................................................................................................................................6 4.4Deviation from Standards..................................................................................................................6 4.5Abnormalities from Standard Conditions...........................................................................................6 5Technical Requirements Specification..................................................................................................7 5.1RF Exposure Evaluation....................................................................................................................7 5.1.1Limit & Test Method......................................................................................................................7 5.1.2Conclusion....................................................................................................................................8 6EUT Constructional Details (EUT Photos).............................................................................................9 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000133803 Page: 5 of 9 4General Information 4.1Details of E.U.T. Power supply:DC 5 V powered by AC/DC adaptor for charging: Model: RHD10W050200 Input: AC 100-240V 50/60Hz, 0.7 A Output: DC 5.0V 2.0 A 10W DC 3.7V supply by rechargeable battery for normal working Model: LP803450 Rated: DC 3.7 V, 1400mAh, 5.2WH Cable(s):about 1m USB type C cable Operation Frequency:802.11b: 2412MHz to 2462MHz Modulation Type:802.11b: DSSS (CCK, DQPSK, DBPSK) Number of Channels:802.11b:11 Channel Spacing:5MHz Antenna Type:Chip Antenna Antenna Gain:2 dBi 4.2Evaluating Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Guangzhou Branch EMC Laboratory, 198 Kezhu Road, Scientech Park, Guangzhou Economic & Technology Development District, Guangzhou, China 510663 Tel: +86 20 82155555Fax: +86 20 82075059 No tests were sub-contracted. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR221000133803 Page: 6 of 9 4.3Facility The facility is recognized, certified, or accredited by the following organizations: ● ACMA SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory can also perform testing for the Australian/New Zealand Regulatory Compliance Mark (RCM). ● SGS UK(Certificate No.: 32), SGS-TUV SAARLAND and SGS-FIMKO Have approved SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory as a supplier of EMC TESTING SERVICES and SAFETY TESTING SERVICES. ● FCC Recognized Accredited Test Firm(Registration No.: 486818) SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory has been accredited and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. Designation Number: CN5016, Test Firm Registration Number: 486818. ● ISED (Registration No.: 4620B, CAB identifier: CN0052) SGS-CSTC Standards Technical Services Co., Ltd., has been registered by Innovation Science…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000133802 Page: 1 of 56 FCC ID: 2BAT6-A011 Ricky Liu Manager TEST REPORT Application No.: GZCR2210001338HS Applicant:PRODOL MEDITEC, S.A. Address of Applicant:Muelle Tomás Olavarri 5, 3 o drcha 48930 Las Arenas (Vizcaya) SPAIN Manufacturer:PRODOL MEDITEC LIMITED Address of Manufacturer:1/F,4/F Block C, NO.18, 7th Science Ave. Zhuhai Guangdong 519085 China. Factory:PRODOL MEDITEC LIMITED Address of Factory:1/F,4/F Block C, NO.18, 7th Science Ave. Zhuhai Guangdong 519085 China. Equipment Under Test (EUT): EUT Name:WI-FI CAMERA Model No.: A-390 Trade Mark: Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2022-10-21 Date of Test: 2022-12-06 to 2022-12-27 Date of Issue: 2023-06-07 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000133802 Page: 2 of 56 Revision Record VersionReport No.DateRemark 01GZCR2210001338022023-06-07Original Authorized for issue by: Curry Wu/Project Engineer Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR221000133802 Page: 3 of 56 2Test Summary Radio Spectrum Technical Requirement ItemStandardMethodRequirementResult Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part ItemStandardMethodRequirementResult Conducted Emissions at AC Power Line (150kHz-30MHz) ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-…
