2BAUB-C1curtain bot

Smart Curtain Robot 1 Drive wheel 2 hook 4 setting button 6 Type-C charging port 3 hook tightening adjustment knob 5 light sensor indicator SMARAIN' Smart curtain robot is an intelligent curtain remote controller, with a solid Bluetooth wireless connection by "Tuya" app, the opening and closing state of the curtain can be easily controlled from distances. It is designed to be weight-light and compatible with various shape of curtain tracks for easy installation. This is an electric powered machine and a wide range of customized battery capacity you can choose. More additional, as for the customized functions, the closing and opening percentage of the curtain can be set through the controller and attached with a voice control function. Product Introduction 1. Drive wheel: the main control that drives the operation of the curtain machine. It can adjust the three gears, large, medium and small, according to the demand. 2. Hook: directly installed to the track, or with the Roman pole pendant. 3. Hook holding adjustment knob: turn right to hold the hook, and turn left to release the hook. The drive wheel of the curtain robot is tightly attached to the curtain rod through the mechanism inside the curtain robot to ensure that the curtain partner can operate normally on the curtain rod. Key operation Explanation Open, close or stop the curtain according to the current status The blue light is on for a long time, waiting for the remote control to check the code Hold for 3 seconds Single click 4. Setting key 5. Description of indicator light 6. Charging App Interface Introduction Buzzer Description Reset； Set travel limit points Buzzer Status Explanation 1 long beep 3 long beeps Low battery reminder Curtain-Bot bat：100% low power System settings Power mode Window opening animation Close the curtains More setup features Pause Battery level Open the curtains There will be 3 short beeps in sequence when the battery is low. When the low battery is reminded (the buzzer beeps 3 short times), please charge the curtain robot in time. The charging steps are as follows: Using a USB charging cable, insert one end of the Type-C plug into the charging port on the curtain robot, and plug the other end into the adapter to charge. Tip: When the red light goes out, it means the charging is complete. Please fully charge the battery before installing the product. The blue light flashes quickly, and the Bluetooth signal enters the status of waiting to connect with the APP The blue light goes out and the factory setting is restored Press and hold for 5 seconds Hold for 10 seconds Parts List Basic Parameter Model No:C1 Product Size：145.8 x 78 x 42mm Rated Current：1.0A Rated Voltage：5V Rated Torque：0.2N·m Input Power：5.0W Work Schedule：S2 4min Output Speed：60r/min Insulation Class：Class A Moving Speed：12cm/s Wireless Connection：Bluetooth Protection Class：IP20 Roman pole version： 0-95%RH,no condensation Working Humidity： Executive Standard Operating Temperature：0°C-45°C ：Q/QLML030-2021 Robot Robot I-rail version： manual strap USB charging cable USB charging cable hanging ring * 2 fixing clip* 24 traction belt (3 meters) Roman pole hanger manual Product Installation Video Please scan the QR code to watch the installation video. Tip: In order to ensure the installation effect of the product, please wipe the clean the curtain rod before installation. Product User Guide When using this product for the first time, please follow the guide steps below to use the device. 一、Connect to Tuya APP Open the Tuya APP homepage, click "+" in the upper right corner of the page, and select "Add Device". Press and hold the product setting button for 5 seconds to turn on the product (the blue light of the host flashes quickly), wait for "discovery device", confirm "add" and wait for the blue light of the automatically added "complete" host to stop flashing, that is, the connection with the APP is completed. Robot U-shaped rail version： USB charging cable hanging ring * 2 manual track guide cover Scan the QR code, download and install Tuya APP. This product has been connected to Tuya ecology and can be controlled through Tuya APP. Product installation requirements Pass-through curtain fabric Description of Roman Rod Curtain Types >64mm >4mm If used for pass-through curtain fabric, the shortest distance between two adjacent Roman circles should be greater than 64mm. Hang-through cord fabric If used for hang-through cord fabric, the thickness of the hanging ring should be greater than 4mm If you have purchased two or more curtain robots, please connect all curtain robots to Tuya APP before proceeding to the next step of installation. Notes for multi-device users 1.Click "+" in the upper right corner of the page 3.for "Discover Device" 4."add" 2."Add Device" Discovering devices... Add Add a device Adding Curtain robot Done 5.Wait for the auto-add "done" Add a device Add a device Added successfully Curtain robot Done Note: Please set the travel after the product is accurately installed on the curtain rod. Tip: Due to the upgrade and update of Tuya APP, the actual operation may be slightly different from the above description. Please follow the instructions in the current APP. Rail version curtain type description The diameter of the Roman rod should be between 22-35mm, or the circumference should be between 69-110mm, whichever satisfies one of the two. diameter：22-35mm circumference：69-110mm Requires tight fitting trim heads on both sides of the roman rod Roman poles need to have fitted decorative heads on both sides U-shaped trackI-shaped track The bottom surface of the U-shaped track should be flat and smooth, and there should be no protrusions. There should be heads on both sides of the track and keep it tight. The bottom surface of the industrial safety rail should be flat and smooth, and the width of the bottom surface should be greater than 10MM. U-rail installation requirements I-rail installation requirements width>10mm 二、Product Installa…

Text truncated - open the document above for the full version.

Locksion Co., Ltd 17E, Quanzhi Technology Park, Houting, Shajing Town, Baoan District Shenzhen, China The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023-04-12 U.S. Agent Designation Locksion Co., Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BAUB-C1): Name and company of U.S. agent: GSS SERVICE INC Physical U.S. address of agent: 6547 N Academy Blvd #2266 Colorado Springs Co 80918 USA FRN of U.S. agent: Email address of U.S. agent: 0033402082 [email protected] GSS SERVICE INC acknowledges their obligation to accept service of process on behalf of Locksion Co., Ltd Locksion Co., Ltd accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). Sincerely, Signature Applicant Name: Tiefang Cheng Title: Manager Applicant Company: Locksion Co., Ltd Signature U.S. Name: Michoux Logan Title: PM U.S. Company: GSS SERVICE INC 48_[mo del] US_Agent_2.911(d)(7) - U, V02

Sincerely, Name/Title： Tiefang Cheng/Manager Company: Locksion Co., Ltd Address: 17E, Quanzhi Technology Park, Houting, Shajing Town, Baoan District Shenzhen China Phone: 13424344345 Fax: N/A E-Mail: [email protected]

FCC ID: 2BAUB-C1 External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BAUB-C1 Photo 4 Photo 5 Photo 6 FCC ID: 2BAUB-C1 Photo 7

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location FCC ID : 2BAUB-C1

FCC ID: 2BAUB-C1 Internal Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2BAUB-C1 Photo 4 Photo 5 Photo 6 FCC ID: 2BAUB-C1 Photo 7 Photo 8 Photo 9 BLE PCB Antenna FCC ID: 2BAUB-C1 Photo 10 Photo 11 Photo 12 433 Internal Antenna FCC ID: 2BAUB-C1 Photo 13 Photo 14 Photo 15 BLE PCB Antenna FCC ID: 2BAUB-C1 Photo 16

RF Exposure evaluation FCC ID: 2BAUB-C1 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information C1 can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: BLE CSR8250 / PCB Antenna 1.49dBi for 2400-2500MHz; BLE LEM5010 / PCB Antenna 1.20dBi for 2400-2500MHz 5. Manufacturing Tolerance BLE GFSK(Peak) CSR8250 Channel Channel 00 Channel 19 Channel 39 Target (dBm) 3.0 3.0 3.0 Tolerance ±(dB) 1.0 1.0 1.0 BLE GFSK(Peak) LEM5010 Channel Channel 00 Channel 19 Channel 39 Target (dBm) 3.0 3.0 3.0 Tolerance ±(dB) 1.0 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna refer to section 4, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW BLE CSR8250 4.0 2.5119 1.49 1.4093 0.0007 1.0000 BLE LEM5010 4.0 2.5119 1.20 1.3183 0.0007 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. simultaneous MPE Result BLE CSR8250 MPE (Ratio) BLE LEM5010 MPE (Ratio) simultaneous MPE (Ratio) MPE Limits (Ratio) 0.0007 0.0007 0.0014 1.0000 8. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

1. Antenna Description: Antenna type Internal Antenna Model C1 Frequency range 433MHz Manufacturer Locksion Co., Ltd Gain 0.00 dBi 2. Antenna Photo: Length:171.50mm Width:3.00mm

1. Antenna Description: Antenna type PCB antenna Model C1 Frequency range 2400-2500MHz Manufacturer Locksion Co., Ltd ANT Peak Gain 1.20 dBi 2. Antenna Photo: Length :9.29mm Width:3.42mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

1. Antenna Description: Antenna type PCB antenna Model C1 Frequency range 2400-2500MHz Manufacturer Locksion Co., Ltd ANT Peak Gain 1.49 dBi 2. Antenna Photo: Length :15.01mm Width:.3.19mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : CTA23032800201 2BAUB-C1 Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Amy Wen Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Mar. 31, 2023 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : Locksion Co., Ltd Address ............................................ : 17E, Quanzhi Technology Park, Houting, Shajing Town, Baoan District Shenzhen, China Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: curtain bot Trade Mark ....................................... : smatain Manufacturer .................................... : Locksion Co., Ltd Model/Type reference....................... : C1 Listed Models .................................. : C2, C3, C4, C5, C6, C7, C8, C9, C10 Modulation ....................................... : GFSK Frequency .......................................... From 2402MHz to 2480MHz Ratings ............................................. : DC 3.7V From Battery and DC 5.0V From external circuit Result................................................ : PASS Report No.: CTA23032800201 Page 2 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : curtain bot Model /Type : C1 Listed Models : C2, C3, C4, C5, C6, C7, C8, C9, C10 Applicant : Locksion Co., Ltd Address : 17E, Quanzhi Technology Park, Houting, Shajing Town, Baoan District Shenzhen, China Manufacturer : Locksion Co., Ltd Address : 17E, Quanzhi Technology Park, Houting, Shajing Town, Baoan District Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA23032800201 Page 3 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emissions and Band Edge 13 4.3 Maximum Peak Output Power 20 4.4 Power Spectral Density 21 4.5 6dB Bandwidth 23 4.6 Out-of-band Emissions 25 4.7 Antenna Requirement 29 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 30 6 P H O T O S O F T H E E U T ........................................................... 31 Report No.: CTA23032800201 Page 4 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V05r02: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: CTA23032800201 Page 5 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Mar. 27, 2023 …

Text truncated - open the document above for the full version.

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : CTA23032800202 2BAUB-C1 Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Amy Wen Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Apr. 07, 2023 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : Locksion Co., Ltd Address ............................................ : 17E, Quanzhi Technology Park, Houting, Shajing Town, Baoan District Shenzhen, China Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: curtain bot Trade Mark ....................................... : smatain Manufacturer .................................... : Locksion Co., Ltd Model/Type reference....................... : C1 Listed Models .................................. : C2, C3, C4, C5, C6, C7, C8, C9, C10 Modulation ....................................... : GFSK Frequency .......................................... From 2402MHz to 2480MHz Ratings ............................................. : DC 3.7V From Battery and DC 5.0V From external circuit Result................................................ : PASS Report No.: CTA23032800202 Page 2 of 31 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : curtain bot Model /Type : C1 Listed Models : C2, C3, C4, C5, C6, C7, C8, C9, C10 Applicant : Locksion Co., Ltd Address : 17E, Quanzhi Technology Park, Houting, Shajing Town, Baoan District Shenzhen, China Manufacturer : Locksion Co., Ltd Address : 17E, Quanzhi Technology Park, Houting, Shajing Town, Baoan District Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA23032800202 Page 3 of 31 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emissions and Band Edge 13 4.3 Maximum Peak Output Power 20 4.4 Power Spectral Density 21 4.5 6dB Bandwidth 23 4.6 Out-of-band Emissions 25 4.7 Antenna Requirement 29 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 30 6 P H O T O S O F T H E E U T ........................................................... 31 Report No.: CTA23032800202 Page 4 of 31 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V05r02: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: CTA23032800202 Page 5 of 31 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Mar. 27, 2023 …

Text truncated - open the document above for the full version.

FCC ID: 2BAUB-C1 Test Setup Photos of the EUT
