FCC RF Exposure EUT Description: Portable Multifunctional Radio Model No.: XLN-486SW FCC ID: 2BAWH-XLN-486SW 1. Limits According to KDB 447498 D01 General RF Exposure Guidance v06 The 1‐g and 10‐g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤50 mm are determined by: [(max power of channel, including tune‐up tolerance, mW)/(min. test separation distance, mm)]ꞏ[√f(GHz)]≤3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR, Where: Result=P/D*√F F= the RF channel transmit frequency in GHz P=Maximum turn‐up power in mw D=Min. test separation distance in mm 2. Test Result of RF Exposure Evaluation Frequency (MHz) Output power (dBm) Tune Up Power (dBm) Max Tune Up power mW Min test separati on distance mm Result Limit SAR Test Exclusion 2480 -3.34 -3±1(-2) 0.631 5 0.199 3.0 Pass Note: PK Output power= conducted power. Conducted power see the test report HK2510105561-E, antenna gain=-0.58dBi Per KDB 447498 D01, when the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. The test exclusion threshold is 0.199 which is<= 3, SAR testing is not required. Note: Exclusion Thresholds Results=[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ꞏ[√f(GHz)] f(GHz) is the RF channel transmit frequency in GHz Distance=5mm

Page 1 of 48 Report No.: HK2510105561-E FCC Test Report Test Report On Behalf of SHENZHEN XINLINGNAN ELECTRONIC TECHNOLOGY CO., LTD. For Portable Multifunctional Radio Model No.: XLN-486SW, XLN-486WB, XLN-486SW-BT, XLN-486WB-BT FCC ID: 2BAWH-XLN-486SW Prepared For: SHENZHEN XINLINGNAN ELECTRONIC TECHNOLOGY CO., LTD. Room 201, Building 3, Shifeng Industrial park, NO.3 Lixin St., Liyuanxia Village, Pinghu Town, Longgang District, Shenzhen, 518111, China Prepared By: Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Oct. 10, 2025 ~ Oct. 16, 2025 Date of Report: Oct. 16, 2025 Report Number: HK2510105561-E Page 2 of 48 Report No.: HK2510105561-E Test Result Certification Applicant’s Name .................. : SHENZHEN XINLINGNAN ELECTRONIC TECHNOLOGY CO., LTD. Address .................................. : Room 201, Building 3, Shifeng Industrial park, NO.3 Lixin St., Liyuanxia Village, Pinghu Town, Longgang District, Shenzhen, 518111, China Manufacturer's Name ........... : SHENZHEN XINLINGNAN ELECTRONIC TECHNOLOGY CO., LTD. Address .................................. : Room 201, Building 3, Shifeng Industrial park, NO.3 Lixin St., Liyuanxia Village, Pinghu Town, Longgang District, Shenzhen, 518111, China Product Description Trade Mark ............................. : N/A Product Name ......................... : Portable Multifunctional Radio Model and/or Type Reference : XLN-486SW, XLN-486WB, XLN-486SW-BT, XLN-486WB-BT Standards .............................. : 47 CFR FCC Part 15 Subpart C 15.247 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of Performance of Tests ............ : Oct. 10, 2025 ~ Oct. 16, 2025 Date of Issue ........................................... : Oct. 16, 2025 Test Result ............................................... : Pass Testing Engineer Len Liao Technical Manager Sliver Wan Authorized Signatory Jason Zhou Page 3 of 48 Report No.: HK2510105561-E Table of Contents Page 1. Summary ................................................................................................... 5 1.1. Test Standards ............................................................................................................ 5 1.2. Test Procedures and Results ...................................................................................... 5 1.3. Information of the Test Laboratory .............................................................................. 6 1.4. Statement of the Measurement Uncertainty ................................................................ 6 2. General Information ................................................................................. 7 2.1. Environmental Conditions ........................................................................................... 7 2.2. General Description of EUT ........................................................................................ 7 2.3. Description of Test Modes and Test Frequency .......................................................... 8 2.4. Equipments Used during the Test ............................................................................... 9 2.5. Related Submittal(s) / Grant (s) ................................................................................ 10 2.6. Modifications ............................................................................................................. 10 2.7. Description of Test Setup .......................................................................................... 10 2.8. Description of Support Units ..................................................................................... 11 3. Test Conditions and Results ................................................................. 12 3.1. AC Conducted Emissions Test .................................................................................. 12 3.2. Radiated Emissions and Band Edge ........................................................................ 15 3.3. Maximum Peak Conducted Output Power ................................................................ 26 3.4. 20dB Bandwidth ........................................................................................................ 27 3.5. Frequency Separation .............................................................................................. 30 3.6. Number of Hopping Frequency ................................................................................. 32 3.7. Time of Occupancy (Dwell Time) .............................................................................. 34 3.8. Out-of-Band Emissions ............................................................................................. 37 3.9. Pseudorandom Frequency Hopping Sequence ........................................................ 44 3.10. Antenna Requirement ........................................................................................... 45 4. Test Setup Photos of the EUT ............................................................... 46 5. Photos of the EUT .................................................................................. 48 Page 4 of 48 Report No.: HK2510105561-E ** Modified History ** Revision Description Issued Date Remark Revision 1.0 Initial Test Report Release Oct. 16, 2025 Jason Zhou Page 5 of 48 Report No.: HK2510105561-E 1. Summary 1.1. Test Standards The tests were performed according to following standards: FCC Rules Part 15.247: Frequ…

Text truncated - open the document above for the full version.

Page 34 of 48 Report No.: HK2510105561-E 3.7. Time of Occupancy (Dwell Time) Limit The average time of occupancy on any channel shall not be greater than 0.4 seconds within a period of 0.4 seconds multiplied by the number of hopping channels employed. Test Procedure The transmitter output was connected to the spectrum analyzer through an attenuator. Set center frequency of spectrum analyzer=operating frequency with 1MHz RBW and 3MHz VBW, Span 0Hz. Test Configuration EUT SPECTRUM ANALYZER Test Results Modulation Packet Pulse time (ms) Number of transmission in 31.6s (79 Hopping*0.4) = Burst Count Dwell time (second) Limit (second) Result GFSK DH1 0.374 32 (pulses) * 10 = 320 0.120 0.40 Pass DH3 1.630 17 (pulses) * 10 = 170 0.277 DH5 2.878 11 (pulses) * 10 = 110 0.317 π/4DQPSK 2-DH1 0.384 31 (pulses) * 10 = 310 0.119 0.40 Pass 2-DH3 1.637 16 (pulses) * 10 = 160 0.262 2-DH5 2.884 11 (pulses) * 10 = 110 0.317 Note: 1. We have tested all mode at high,middle and low channel,and recoreded worst case at middle channel. 2. Dwell time = [Pulse time (ms) / 1000] × Burst Count Test plot as follows: Page 35 of 48 Report No.: HK2510105561-E GFSK Modulation DH1 DH3 DH5 Page 36 of 48 Report No.: HK2510105561-E π/4DQPSK Modulation 2-DH1 2-DH3 2-DH5 Page 37 of 48 Report No.: HK2510105561-E 3.8. Out-of-Band Emissions Limit In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF con-ducted or a radiated measurement, pro-vided the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter com-plies with the conducted power limits based on the use of RMS averaging over a time interval, as permitted under paragraph (b)(3) of this section, the attenuation required under this paragraph shall be 30 dB instead of 20 dB. Attenuation below the general limits specified in §15.209(a) is not required. Test Procedure Connect the transmitter output to spectrum analyzer using a low loss RF cable, and set the spectrum analyzer to RBW=100 kHz, VBW= 300 kHz, peak detector , and max hold. Measurements utilizing these setting are made of the in-band reference level, band edge and out-of-band emissions. Test Configuration EUT SPECTRUM ANALYZER Test Results Remark: The measurement frequency range is from 30MHz to the 10th harmonic of the fundamental frequency. The lowest, middle and highest channels are tested to verify the spurious emissions and bandage measurement data. We measured all conditions (DH1, DH3, DH5) and recorded worst case at DH5 and 2DH5 Test plot as follows: Page 38 of 48 Report No.: HK2510105561-E GFSK CH00 CH39 Page 39 of 48 Report No.: HK2510105561-E CH78 Page 40 of 48 Report No.: HK2510105561-E Left Band edge hoping off Right Band edge hoping off Left Band edge hoping on Right Band edge hoping on Page 41 of 48 Report No.: HK2510105561-E π/4DQPSK CH00 CH39 Page 42 of 48 Report No.: HK2510105561-E CH78 Page 43 of 48 Report No.: HK2510105561-E Left Band edge hoping off Right Band edge hoping off Left Band edge hoping on Right Band edge hoping on Page 44 of 48 Report No.: HK2510105561-E 3.9. Pseudorandom Frequency Hopping Sequence Test Applicable For 47 CFR Part 15C section 15.247 (a) (1): Frequency hopping systems shall have hopping channel carrier frequencies separated by a minimum of 25 kHz or the 20 dB bandwidth of the hop-ping channel, whichever is greater. Alternatively, frequency hopping systems operating in the 2400–2483.5 MHz band may have hopping channel carrier frequencies that are separated by 25 kHz or two-thirds of the 20 dB bandwidth of the hopping channel, whichever is greater, provided the systems operate with an output power no greater than 125 mW. The system shall hop to channel frequencies that are selected at the system hopping rate from a pseudo randomly ordered list of hopping frequencies. Each frequency must be used equally on the average by each transmitter. The system receivers shall have input bandwidths that match the hop-ping channel bandwidths of their corresponding transmitters and shall shift frequencies in synchronization with the transmitted signals. EUT Pseudorandom Frequency Hopping Sequence Requirement The pseudorandom frequency hopping sequence may be generated in a nice-stage shift register whose 5 th and 9 th stage outputs are added in a modulo-two addition stage. And the result is fed back to the input of the first stage. The sequence begins with the first one of 9 consecutive ones, for example: the shift register is initialized with nine ones. ● Number of shift register stages:9 ● Length of pseudo-random sequence:2 9 -1=511 bits ● Longest sequence of zeros:8(non-inverted signal) An example of pseudorandom frequency hopping sequence as follows: Each frequency used equally one the average by each transmitter. The system receiver have input bandwidths that match the hopping channel bandwidths of their corresponding transmitter and shift frequencies in synchronization with the transmitted signals. Page 45 of 48 Report No.: HK2510105561-E 3.10. Antenna Requirement Standard Applicable For intentional device, according to FCC 47 CFR Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. And according to FCC 47 CFR Section 15.247, if transmitting antennas of directional gain greater than 6dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6dBi. Refer to Statement below for Compliance The manufacturer may design the unit so that the user can replace a broken antenna, but the use of a standard antenna jack or electrical connector is prohibited. Further, this requirement does not a…

Text truncated - open the document above for the full version.

                      Horiz ontal:2400 MHz 2450 MHz 2500 MHz Power ( dBm) Max: 0 Min: -40 Scale: 5/div Gain(d B) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical:2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(d B) Frequency (MHz) Max Min Avg 2400 -5.2537 -22.1424 -12.4294 2450 -2.4652 -24.5837 -10.4702 2500 -1.86120 -29.5214 -9.20432 ANT Test LabsAttestation of Global Compliance Co., Ltd.

Test Model: XLN-486SW Radiated Emission AC Conducted Emission RF Conducted Emission
