2BAXL-CK24ATAtom Wireless Controller

FreemodeGoLLCdbaCRKD 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType Companyname:FreemodeGoLLCdbaCRKD Address:3142Constitutiondrive,Livermore,CA94551,USA ProductName:AtomWirelessController FCCID:2BAXL-CK24AT Model(s):24-AT-HP,24-AT-AP,24-AT-CG,24-AT-GB,24-AT-LG,24-AT-PG,24-AT-SB,24-AT-YY 2.911(d)(5)(i)EquipmentType We,[FreemodeGoLLCdbaCRKD](“theapplicant”)certifythattheequipmentforwhich authorizationissoughtthroughcertificationisnot:  Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules.  Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:StephenWithersDate:Aug.06,2024 Signature: TitleandCompanyname:ProductManager/FreemodeGoLLCdbaCRKD NOTE1 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

FreemodeGoLLCdbaCRKD 2.911(d)(5)(ii)ApplicantAttestationv1.3 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname:FreemodeGoLLCdbaCRKD Address:3142Constitutiondrive,Livermore,CA94551,USA ProductName:AtomWirelessController FCCID:2BAXL-CK24AT Model(s):24-AT-HP,24-AT-AP,24-AT-CG,24-AT-GB,24-AT-LG,24-AT-PG,24-AT-SB,24-AT-YY 2.911(d)(5)(ii)Applicantfiling We,[FreemodeGoLLCdbaCRKD](“theapplicant”)certifythat,asofthedateofthefilingofthe application,theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE2 ,establishedpursuantto §1.50002ofthischapter,asanentityproducingcoveredcommunicationsequipment. Yourssincerely, Name:StephenWithersDate:Aug.06,2024 Signature: TitleandCompanyname:ProductManager/FreemodeGoLLCdbaCRKD NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Freemode Go LLC dba CRKD 2.911 (d)(7)USA Agent v1.4 Section 2.911(d)(7) USA Agent for Service of Process Company name: Freemode Go LLC dba CRKD Address: 3142 Constitution drive, Livermore, CA 94551, USA Product Name: Atom Wireless Controller FCC ID: 2BAXL-CK24AT Model(s): 24- AT-HP, 24-AT-AP, 24 -AT-CG, 24-AT-GB, 24-AT-LG, 24-AT-PG, 24-AT- SB, 24-AT-YY 2.911(d)(7) USA Designated Agent for Service of Process We, [Freemode Go LLC dba CRKD] (“the applicant”) designate [Freemode Go LLC dba CRKD] NOTE1 for the purpose of ac cepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Freemode Go LLC dba CRKD USA Address: 3142 Constitution drive, Livermore, CA 94551, USA FRN Number: 0033681735 Contact Name: Stephen Withers Telephone No: +1 925 344 4045 Email: [email protected] Applicant Company name: Freemode Go LLC dba CRKD Address: 3142 Constitution drive, Livermore, CA 94551, USA FCC Grantee Code: 2BAXL FRN Number: 0033681735 Contact Name: Stephen Withers Telephone No: +1 925 344 4045 Email: [email protected] Signature: Title: Product Manager Signature: Title: Product Manager Date: Jul. 31, 2024 Date: Jul. 31, 2024 Freemode Go LLC dba CRKD 2.911 (d)(7)USA Agent v1.4 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against- national-security-threats-to-the-communications-supply-chain-through-the

FreemodeGoLLCdbaCRKD AgentAuthorization Company:FreemodeGoLLCdbaCRKD Address:3142Constitutiondrive,Livermore,CA94551,USA ProductName:AtomWirelessController ModelNumber(s):24-AT-HP,24-AT-AP,24-AT-CG,24-AT-GB,24-AT-LG,24-AT-PG,24- AT-SB,24-AT-YY ProductDescription:AtomWirelessController WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA,to actonourbehalfonallmattersconcerningthecertificationofabovenamedequipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtotheapproval andcertificationofequipmenttotheregulatoryagenciesasrequiredandtodiscussany issuesconcerningtheapprovalapplication.AnyandallactscarriedoutbyMiCOMLabson ourbehalfshallhavethesameeffectasactsofourown. Signature:Date:Aug.06,2024 Name:StephenWithers Title:ProductManager Company:FreemodeGoLLCdbaCRKD

FreemodeGoLLCdbaCRKD OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:Aug.06,2024 Subject;RequestforConfidentiality FCCID:2BAXL-CK24AT ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Softwaresecurityrequirement Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, FreemodeGoLLCdbaCRKD Signature: Name:StephenWithers Title:ProductManager

FreemodeGoLLCdbaCRKD ModelDifferenceDeclaration ToWhomItMayConcern, We,FreemodeGoLLCdbaCRKD(AtomWirelessController);TradeMark:CRKD,ModelNumber:24- AT-HP,24-AT-AP,24-AT-CG,24-AT-GB,24-AT-LG,24-AT-PG,24-AT-SB,24-AT-YY;Allmodel’sthe function,softwareandelectriccircuitarethesame,onlywiththematerialandcoloroftheshell,model nameddifferent.Testsamplemodel:24-AT-HP. Pleasecontactmeifyouhaveanyquestion. Signature:Date:Aug.06,2024 Name:StephenWithers Title:ProductManager

LABEL: Ca: 5mm x 20mm Label Location FCC ID: 2BAXL-CK24AT

FCC RF Exposure Product Name: Atom Wireless Controller FCC ID: 2BAXL‐CK24AT Model(s): 24‐AT‐HP 1. Limits According to KDB 447498 D01 General RF Exposure Guidance v06 The 1‐g and 10‐g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤50 mm are determined by: [(max power of channel, including tune‐up tolerance, mW)/(min. test separation distance, mm)]·[√ f(GHz)]≤3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR, Where: Result=P/D*√F F= the RF channel transmit frequency in GHz P=Maximum turn‐up power in mw D=Min. test separation distance in mm 2. Test Result of RF Exposure Evaluation Frequency (MHz) Output power (dBm) Tune Up Power (dBm) Max Tune Up power dBm/mW Min test separatio n distance mm Result Limit (mW/cm 2 ) SAR Test Exclusion 2402 1.33 1±1 2/1.58 5 0.49 3.0 Pass Note: PK Output power= conducted power. Conducted power see the test report HK2407184009‐E, antenna gain=0dBi Per KDB 447498 D01, when the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine RF Exposure test exclusion. The test exclusion threshold is 0.49 which is<= 3, RF Exposure testing is not required. Note: Exclusion Thresholds Results=[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f (GHz)] f(GHz) is the RF channel transmit frequency in GHz Distance=5mm

Page 1 of 43 Report No.: HK2407184009-E FCC Test Report Test Report On Behalf of Freemode Go LLC dba CRKD For Atom Wireless Controller Model No.: 24-AT-HP, 24-AT-AP, 24-AT-CG, 24-AT-GB, 24-AT-LG, 24-AT-PG, 24-AT-SB, 24-AT-YY FCC ID: 2BAXL-CK24AT Prepared For: Freemode Go LLC dba CRKD 3142 Constitution drive, Livermore, CA 94551 United States Prepared By: Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Jul. 18, 2024 ~ Jul. 29, 2024 Date of Report: Jul. 29, 2024 Report Number: HK2407184009-E Page 2 of 43 Report No.: HK2407184009-E Test Result Certification Applicant’s Name ................... : Freemode Go LLC dba CRKD Address .................................... : 3142 Constitution drive, Livermore, CA 94551 United States Manufacturer's Name ............. : KINGLINE TECHNOLOGY CO., LTD Address .................................... : 2/F, Building 4, Xifa A Industiral, Yintian, Longteng Community, Xixiang Street, Baoan District, Shenzhen City, Guangdong, 518100 China Product Description Trade Mark ................................. : CRKD Product Name ............................ : Atom Wireless Controller Model and/or Type Reference .. : 24-AT-HP, 24-AT-AP, 24-AT-CG, 24-AT-GB, 24-AT-LG, 24-AT-PG, 24-AT-SB, 24-AT-YY Standards ................................ : 47 CFR FCC Part 15 Subpart C 15.247 KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test .............................................. : Date (s) of Performance of Tests ............... : Jul. 18, 2024 ~ Jul. 29, 2024 Date of Issue ............................................. : Jul. 29, 2024 Test Result ................................................. : Pass Testing Engineer Len Liao Technical Manager Sliver Wan Authorized Signatory Jason Zhou Page 3 of 43 Report No.: HK2407184009-E Contents Page 1 Test Summary ................................................................................................................................................ 5 1.1 Test Description ......................................................................................................................................... 5 1.2 Measurement Uncertainty ......................................................................................................................... 6 1.3 Information of the Test Laboratory ............................................................................................................ 6 2 General Information ....................................................................................................................................... 7 2.1 General Description of EUT ...................................................................................................................... 7 2.2 Description of Test Conditions .................................................................................................................. 9 2.3 Description of Test Setup ........................................................................................................................ 10 2.4 Description of Support Units .................................................................................................................... 11 3 Equipments List for All Test Items ............................................................................................................. 12 4 Test Result .................................................................................................................................................... 13 4.1 Antenna Requirement.............................................................................................................................. 13 4.2 Conduction Emissions Measurement ...................................................................................................... 14 4.3 Radiated Emissions Measurement .......................................................................................................... 18 4.4 Maximum Output Power Measurement ................................................................................................... 27 4.5 Power Spectral Density ........................................................................................................................... 28 4.6 6dB Bandwidth ........................................................................................................................................ 31 4.7 Occupied Bandwidth ................................................................................................................................ 34 4.8 Band Edge ............................................................................................................................................... 35 4.9 Conducted Spurious Emissions .............................................................................................................. 37 5 Test Setup Photos ....................................................................................................................................... 41 6 Photos of the EUT ........................................................................................................................................ 41 Page 4 of 43 Report No.: HK2407184009-E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release Jul. 29, 2024 Jason Zhou Page 5 of 43 Report No.: HK2407184009-E 1 Test Summary 1.1 Test Description Test …

Text truncated - open the document above for the full version.

Antennaspecification DocNo.IS-QR-PD-010 Rev.V1.0 Page 1 / 10 2013/05/22Copyright2013©ShenzhenInnosystemTechnologyLimited Allrightsreserved. Antennaspecification Antennaspecification DocNo.IS-QR-PD-010 Rev.V1.0 Page 2 / 10 2013/05/22Copyright2013©ShenzhenInnosystemTechnologyLimited Allrightsreserved. Antennamodel:MARBATV1.0 APPlications ※BluetoothHomeRF ※ISMband2.4GHzapplications 1.Dimensions ‣CompanyName ShenzhenInnosystemTechnologyLtd ‣ Companyaddress F2Building3ShenzhenSoftwareParkTechnologyMiddle2 RdGaoXinScience&TechnologyParkNorth,S.Z Antennaspecification DocNo.IS-QR-PD-010 Rev.V1.0 Page 3 / 10 2013/05/22Copyright2013©ShenzhenInnosystemTechnologyLimited Allrightsreserved. 2.Specifications numberItemSpecifications 1WorkingCentralFrequency2441MHz 2BandWidth(2402-2480)MHz 3Gain0dBi 4VSWR≤2.0 5AntennatypePCBantenna 6AzimuthBeamwidthOmni‐directional 7Impedance50ohm 8ModulationmodeGFSK 3.simulationparameter ①VSWR Mkr1:2397MHz1.47Mkr2:2450MHz1.51Mkr3:2482MHz1.59 Antennaspecification DocNo.IS-QR-PD-010 Rev.V1.0 Page 4 / 10 2013/05/22Copyright2013©ShenzhenInnosystemTechnologyLimited Allrightsreserved. ②SmithChar Mkr1:2397MHz73.4Mkr2:2450MHz62.7Mkr3:2482MHz66.8 Antennaspecification DocNo.IS-QR-PD-010 Rev.V1.0 Page 5 / 10 2013/05/22Copyright2013©ShenzhenInnosystemTechnologyLimited Allrightsreserved. ③ReturnLoss Mkr1:2397MHz-15Mkr2:2450MHz-18Mkr3:2482MHz-16 Antennaspecification DocNo.IS-QR-PD-010 Rev.V1.0 Page 6 / 10 2013/05/22Copyright2013©ShenzhenInnosystemTechnologyLimited Allrightsreserved. ④SmithChar Mkr1:2400MHz1.234Mkr2:2500MHz1.051Mkr3:2600MHz1.322 Antennaspecification DocNo.IS-QR-PD-010 Rev.V1.0 Page 7 / 10 2013/05/22Copyright2013©ShenzhenInnosystemTechnologyLimited Allrightsreserved. ⑤ReturnLoss Mkr1:2400MHz-19.59Mkr2:2450MHz-27.70Mkr3:2500MHz-31.97Mkr4: 2550MHz-21.83 ` Antennaspecification DocNo.IS-QR-PD-010 Rev.V1.0 Page 8 / 10 2013/05/22Copyright2013©ShenzhenInnosystemTechnologyLimited Allrightsreserved. ⑥Phase Mkr1:2400MHz-54.89Mkr2:2500MHz-82.03Mkr3:2600MHz-102.6 Antennaspecification DocNo.IS-QR-PD-010 Rev.V1.0 Page 9 / 10 2013/05/22Copyright2013©ShenzhenInnosystemTechnologyLimited Allrightsreserved. 4.RadiationPattems XY-plane XZ-plane YZ-plane Antennaspecification DocNo.IS-QR-PD-010 Rev.V1.0 Page 10 / 10 2013/05/22Copyright2013©ShenzhenInnosystemTechnologyLimited Allrightsreserved.  3DRadiationpattern
