2BAY4OMBSX01Sphinx & Chill nipple clamps

SPHINX English OhMiBod is committed to bringing you high quality technology enabled pleasure products and accessories. Before you begin enjoying Sphinx, please take a moment to review this manual. Sphinx - What’s in the box • Bluetooth ® enabled vibrating nipple clamps • Wearable chain • USB charging cable • Privacy pouch Power button USB magnetic charging connector How It Works 1. DOWNLOAD OhMiBod ® Remote App 2. TURN ON Sphinx 3. PAIR devices. Make sure your mobile device’s Bluetooth ® is turned on. Launch the app, and your Sphinx and mobile device will pair automatically. TIP: You can check your vibe status, e.g. if it is paired, turn off the vibe remotely, and even check your vibe battery level in your app profile! Tap the icon to access your profile. Bluetooth ® Mode: The volume on your phone/tablet controls the vibration intensity. Volume must be set at 50% or higher. Manual Mode: 1. Press and hold for 3-4 seconds to turn on. TIP: 1 quick pulsation indicates the vibe is on. 2. Press again to switch to manual mode. Make sure the Sphinx is disconnected from the OhMiBod ® Remote App to use manual mode. First pulsation is a continuous vibration. This confirms manual mode is active. Press to move to next pulsation pattern. There are a total of 5 pulsations. Pressing the button again will cycle back to Bluetooth ® mode, marked by a blinking LED and three quick pulsations. NOTE: The LED will match the pulsations in manual mode. 3. Press and hold for 3-4 seconds to turn off. TIP: 3 quick pulsations indicate the vibe has been turned off. 1. Download and launch the OhMiBod ® Remote App 2. Make sure your device is paired (see ‘How it Works’). Solid LED indicates connection to phone/tablet. 3. Enjoy the different vibration modes! Accessible from in the App. 4. Use the volume on your mobile device to increase or decrease vibration intensity. NOTE: Local play is possible when the massager is within 26 ft (8m), e.g. “Bluetooth ® range” of your device. For longer distance fun, refer to the Remote Play section. Local Play Via App Remote Play Via App 1. Download and launch OhMiBod ® Remote App 2. Make sure your device is paired (see ‘How It Works’). Solid LED indicates connection to phone/tablet. 3. Make sure both you and your partner have an active connection to the internet from your respective devices. 4. To connect with a partner remotely, you will each need to create an account. Select “Register a new account” if you do not have an account, or “Log in to your account” if you have an existing account. 5. After entering your partner’s username or selecting it from your existing connections, you can either request to control their OhMiBod device, or invite them to control yours for remote play! ADDITIONAL SUPPORT can also be found at OhMiBod.com/app. Simply plug the USB charging cable provided with Sphinx into the USB port on your computer or USB wall charger adapter. Connect the other end of the cable into the charging socket on the end of Sphinx (see diagram). The LED on Sphinx will blink indicating the massager is charging. Please be sure that the massager is completely dry before charging. LED will glow steady when fully charged. ≈ 1.5 HRS TO REACH FULL CHARGE Charging Sphinx • Please be sure that the pendant is completely dry before charging. • Only use the charging cable provided to charge the device. • Do not use USB charging hubs to charge the device. • Only use with UL certified USB wall chargers. NOTE: The USB port is for charging use only, not for data transmission functionality. When product is charging, the product will not be able to vibrate until the USB cable is removed from charging socket. If the LED does not blink when the product is connected to the USB cable, check to make sure the USB cable is properly connected to the USB port and Sphinx. • Sphinx contains a rechargeable battery. Please do not dispose of this product with normal household waste. • Please dispose of this product at the appropriate electrical and electronic equipment recycling disposal locations in accordance with government regulations. • The recycling of this product appropriately will help to protect our environment Troubleshooting Battery Disposal Important Safeguards • Do not use on areas that are swollen, inflamed or have skin lacerations. • Stop using the massager if you experience pain or discomfort. • Remove piercings or jewelry from nipples before use. • This product is not designed for anal use. Do not use anally. • Do not use if the massager is damaged. • Keep out of reach of children. • Clean after use with mild soap and water. Dry thoroughly. • Store in privacy pouch to keep clean and safe until next use. Care & Cleaning No medical claims are warranted or implied by the use of this product. Sold as an adult novelty item. OhMiBod warrants this product for a period of one (1) year from the date of original purchase, against defects due to faulty workmanship or materials. In the event that this product fails during the warranty period, simply email us at lovelifetoys.com/ contact and provide us with a valid proof of the date of original purchase and we will replace the faulty product at no extra charge. This warranty does not cover cosmetic deterioration caused by normal wear and tear or damage caused by accident, misuse, neglect or other use not in accordance with this instruction manual. Any attempt to open or take apart this product or its accessories will void the warranty. If you have any questions regarding your new product, please check out additional information at www.lovelifetoys.com/customer-care. You can also reach us via the form at lovelifetoys.com/contact. Contact Us Warranty Specifications Sphinx Materials: Body-safe silicone and ABS Clamp Size: 52mm long and 24mm wide Pendant Size: 47mm long by 30mm wide by 17mm deep Weight: 65g (including cable) Battery: Lithium-ion 3.7V with 210mAH Charging: 1.5 to 2 hours Use time: Up to 2 hours of use WIRELESS SPECIFICATIONS: Bluetooth ® Version…

Text truncated - open the document above for the full version.

August 16, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.08.16 FCC ID: 2BAY4OMBSX01 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Suki, LLC dba OhMiBod (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Suki, LLC dba OhMiBod (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Cover List Link: (https://www.fcc.gov/supplychain/coveredlist) Applicant: Suki, LLC dba OhMiBod Address: 45 Lafayette Road #332, North Hampton, NH 03862 USA Contact Person: Suzanne Dunham Tel.: +1 603-918-0450 Email: [email protected] Sincerely, Suzanne Dunham Founder & CEO

August 14, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 08- 14- 2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID or Grantee Code: 2BAY4OMBSX01 Applicant FRN: 0033693367 Suki, LLC dba OhMiBod (“the applicant”) certifies that, as of the date of the filing of the application, Suki, LLC dba OhMiBod is our designated U.S. agent for service of process for the above referenced FCC ID. Suki, LLC dba OhMiBod accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Suki, LLC dba OhMiBod accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Suki, LLC dba OhMiBod U.S. Agent FRN : 0033693367 Address: 45 Lafayette Road #332, North Hampton, NH 03862 USA Contact Person: Suzanne Dunham Tel.: +1 603-918- 0450 Email: [email protected] Sincerely, Suki, LLC dba OhMiBod Suki, LLC dba OhMiBod Suzanne Dunham Suzanne Dunham Date: 2023-8-11 Signer: Suzanne Dunham

SCS-F019: Confidentiality Request Letter Page 1 of 2 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Website: https://www.cps.bureauveritas.com/ Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 Updated References and Contact Info 6.0 7.0 Aug-30-2020 SCS-F019: Confidentiality Request Letter Page 2 of 2 Rev 7.0 Suki, LLC dba OhMiBod 2023.8.17 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046-1609 Cc: Bureau Veritas Consumer Products Services Inc. 775 Montague Expressway Milpitas, CA 95035 Subject: Confidentiality Request for FCC ID: 2BAY4OMBSX01 Pursuant to CFR 47 sections 0.457 and 0.459, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application be held confidential: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagram Short Term External Photos Short Term Permanent i Internal Photos Short Term Permanent Operational Description/ Theory of Operation Short Term Permanent Parts List Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent i User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: To avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of not to exceed 180 days from the Grant Date The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name: Suzanne Dunham Title :Manager Contact information / address : 45 Lafayette Road #332, North Hampton, NH 03862 USA Permanent confidentiality may be requested in accordance with FCC KDB 726920

Suki, LLC dba OhMiBod Declaration of Identical Product Hereby, Name of manufacturer: Suki, LLC dba OhMiBod Address: 45 Lafayette Road #332, North Hampton, NH 03862 USA City: North Hampton Country: United States declares that: Product description: Sphinx & Chill nipple clamps Type designation(s): Chill nipple clamps Trademark: OhMiBod Family name is technically identical to: Product description: Sphinx & Chill nipple clamps Type designation: Sphinx Trademark: OhMiBod Certificate number (if applicable) The additional model Chill nipple clamps is identical with the test model Sphinx except the program operation for user. Date: 2023.8.17 City: North Hampton Name: Suzanne Dunham Signature

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 5 Report Version A Reference No.: 2306WDG0147 PHOTOGRAPHS OF THE EUT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 5 Report Version A Reference No.: 2306WDG0147 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 5 Report Version A Reference No.: 2306WDG0147 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 5 Report Version A Reference No.: 2306WDG0147 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 5 of 5 Report Version A Reference No.: 2306WDG0147

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 3 Report Version A Reference No.: 2306WDG0147 PHOTOGRAPHS OF THE EUT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 3 Report Version A Reference No.: 2306WDG0147 RF ANT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 3 Report Version A Reference No.: 2306WDG0147

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 6 Report Version A Test Report No.: FM2306WDG0147 RF EXPOSURE REPORT Applicant Suki, LLC dba OhMiBod Address 45 Lafayette Road #332, North Hampton, NH 03862 USA Manufacturer or Supplier ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., LTD. Address NO. 35 FIRST ROAD, ZHUHAI BAIJAO NEW TECHNOLOGICAL & INDUSTRIAL PARK ZHUHAI, GUANGDONG, CHINA Product Sphinx & Chill nipple clamps Brand Name OhMiBod Model Sphinx Additional Model & Model Difference Chill nipple clamps; see section 1 Date of tests Jun. 15, 2023 ~ Aug. 03, 2023 FCC Part 2 (Section 2.1093) KDB 447498 D01 V06 IEEE C95.1 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Andrew Sha Project Engineer / EMC Department Approved by Glyn He Assistant Manager / EMC Department Date: Aug. 23, 2023 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 6 Report Version A Test Report No.: FM2306WDG0147 TABLE OF CONTENTS RELEASE CONTROL RECORD ................................................................................ 3 1. CERTIFICATION .............................................................................................. 4 2. RF EXPOSURE DEFINE ................................................................................. 5 3. CLASSIFICATION ........................................................................................... 5 4. CALCULATED RESULT OF MAXIMUM CONDUCTED POWER .................... 6 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 6 Report Version A Test Report No.: FM2306WDG0147 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED FM2306WDG0147 Original release Aug. 23, 2023 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 6 Report Version A Test Report No.: FM2306WDG0147 1. CERTIFICATION FCC ID: 2BAY4OMBSX01 PRODUCT: Sphinx & Chill nipple clamps BRAND NAME: OhMiBod MODEL NO.: Sphinx ADDITIONAL NO.: Chill nipple clamps APPLICANT: Suki, LLC dba OhMiBod STANDARDS: FCC Part 2 (Section 2.1093) KDB 447498 D01 V06 IEEE C95.1 Note: The additional model Chill nipple clamps are identical with the test model Sphinx except the program operation for user. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 5 of 6 Report Version A Test Report No.: FM2306WDG0147 2. RF EXPOSURE DEFINE The corresponding SAR Exclusion Threshold condition, listed below: 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[ √f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where   f(GHz) is the RF channel transmit frequency in GHz   Power and distance are rounded to the nearest mW and mm before calculation   The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 2) At 100 MHz to 6 GHz and for test separation distances > 50 mm, the SAR test exclusion threshold is determined according to the following: a) [Threshold at 50 mm in step …

Text truncated - open the document above for the full version.

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 37 Report Version 1 Test Report No.: RF2306WDG0147 TEST REPORT Applicant Suki, LLC dba OhMiBod Address 45 Lafayette Road #332, North Hampton, NH 03862 USA Manufacturer or Supplier ZHUHAI WINGPOW EROTIC & NOVELTY MANUFACTURING CO., LTD. Address NO. 35 FIRST ROAD, ZHUHAI BAIJAO NEW TECHNOLOGICAL & INDUSTRIAL PARK ZHUHAI, GUANGDONG, CHINA Product Sphinx & Chill nipple clamps Brand Name OhMiBod Model Sphinx Additional Model & Model Difference Chill nipple clamps; see section 3.1 Date of tests Jun. 15, 2023 ~ Aug. 03, 2023 the tests have been carried out according to the requirements of the following standard: FCC Part 15, Subpart C, Section 15.247 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Andrew Sha Project Engineer / EMC Department Approved by Glyn He Assistant Manager / EMC Department Date: Aug. 23, 2023 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 37 Report Version 1 Test Report No.: RF2306WDG0147 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................................ 4 1 SUMMARY OF TEST RESULTS .................................................................................................... 5 2 MEASUREMENT UNCERTAINTY ................................................................................................. 5 3 GENERAL INFORMATION ............................................................................................................ 6 3.1 GENERAL DESCRIPTION OF EUT........................................................................................... 6 3.2 DESCRIPTION OF TEST MODES............................................................................................. 7 3.2.1. CONFIGURATION OF SYSTEM UNDER TEST ............................................................... 7 3.2.2. TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .................................... 7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................ 9 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................................... 9 3.5 CONFIGURATION OF SYSTEM UNDER TEST ........................................................................ 9 3.6 DUTY CYCLE OF TESET SIGNAL .......................................................................................... 10 4 TEST TYPES AND RESULTS .......................................................................................................11 4.1 RADIATED EMISSION MEASUREMENT ................................................................................. 11 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT ..................................................... 11 4.1.2 TEST INSTRUMENTS ..................................................................................................... 12 4.1.3 TEST PROCEDURES ..................................................................................................... 13 4.1.4 DEVIATION FROM TEST STANDARD ........................................................................... 14 4.1.5 TEST SETUP ................................................................................................................... 15 4.1.6 EUT OPERATING CONDITIONS .................................................................................... 16 4.1.7 TEST RESULTS .............................................................................................................. 17 4.2 6DB BANDWIDTH MEASUREMENT ....................................................................................... 22 4.2.1 LIMITS OF 6DB BANDWIDTH MEASUREMENT ........................................................... 22 4.2.2 TEST INSTRUMENTS ..................................................................................................... 22 4.2.3 TES…

Text truncated - open the document above for the full version.

Product Specification A10192H-PS-1.2 Page 1 Antennas for Wireless Applications 1. Features • Designed for 2.4GHz applications: BT / BLE, Wi-Fi ® (802.11a/b/g/n), ZigBee ® . • Low profile design • High efficiency • Lightweight • Intended for SMD mounting • Supplied in tape and reel 2. Description Fusca is intended for use with all 2.4 GHz applications. The antenna uses a ground plane in order to radiate efficiently, but this ground plane must not extend underneath the antenna itself. Ideal for small wearables. 3. Applications • Wearables • Medical devices • Sensors Fusca 2.4GHz SMD Antenna Part No. A10192H gigaNOVA ® Product Specification Fusca Part No. A10192H Antennas for Wireless Applications Product Specification A10192H-PS-1.2 Page 2 4. Part Number Fusca: A10192H 5. General Data 6. RF Characteristics Product name Fusca Part Number A10192H Frequency 2.4 – 2.5GHz Polarization Linear Operating temperature -40°C to140°C Environmental condition test ISO 16750-4 5.1.1.1/5.1.2.1/5.3.2 Impedance with matching 50 Ω Weight <0.03g Antenna type SMD Dimensions 4 x 3 x 1.1 (mm) 2.4 – 2.5 GHz Peak gain 0.8dBi Average gain (Linear) -1.9dBi Average efficiency 65% Maximum return loss <-10dB Maximum VSWR 2:1 All data measured on Antenova’s evaluation PCB Part No. A10192H-EVB-1 Fusca Part No. A10192H Antennas for Wireless Applications Product Specification A10192H-PS-1.2 Page 3 7. RF Performance 7.1 Return Loss 7.2 VSWR Fusca Part No. A10192H Antennas for Wireless Applications Product Specification A10192H-PS-1.2 Page 4 7.3 Antenna pattern 7.3.1 2400 MHz – 2500 MHz 3D pattern at 2450 MHz Drag to rotate pattern and PCB by using Adobe Reader (Click to Activate) -40 -25 -10 5 0 30 60 90 120 150 180 210 240 270 300 330 -40 -25 -10 5 0 30 60 90 120 150 180 210 240 270 300 330 -40 -25 -10 5 0 30 60 90 120 150 180 210 240 270 300 330 2.4GHz2.45GHz2.5GHz XYXZYZ Fusca Part No. A10192H Antennas for Wireless Applications Product Specification A10192H-PS-1.2 Page 5 8. Antenna Dimensions Fusca: A10192H All Dimensions in (mm) 3 solder pads (1.0 x 0.8 mm) Bottom Side Top side Fusca Part No. A10192H Antennas for Wireless Applications Product Specification A10192H-PS-1.2 Page 6 9. Schematic symbol and Pin definition The circuit symbol for the antenna is shown below. The antenna has 5 pins with only two as functional. All other pins are for mechanical strength. 10. Antenna footprint The recommended host PCB footprint is below. Pin Description 1,2 Feed 3 Not used (Mechanical only) Fusca Part No. A10192H Antennas for Wireless Applications Product Specification A10192H-PS-1.2 Page 7 11. Electrical Interface 11.1 Transmission Line All transmission lines should be designed to have a characteristic impedance of 50Ω. • The length of the transmission lines should be kept to a minimum • Any other parts of the RF system like transceivers, power amplifiers, etc, should also be designed to have an impedance of 50 Ω Once the material for the PCB has been chosen (PCB thickness and dielectric constant), a coplanar transmission line can easily be designed using any of the commercial software packages for transmission line design. For the chosen PCB thickness, copper thickness and substrate dielectric constant, the program will calculate the appropriate transmission line width and gaps on either side of the track, so the characteristic impedance of the co-planar transmission is 50 Ω. 11.2 Matching Circuit The antenna requires a matching circuit that must be optimized for each pro…

Text truncated - open the document above for the full version.
