2BAZLBHZD-A40AAC Charging Pile

Operation instruction for AC Charging Pile Nlightend Smart Tech.Co.,Ltd About this instruction: This instruction is applicable to electric vehicle of BHZD. This instruction mainly introduces part features, composition, installation, commissioning, operation and maintenance of BHZD AC Charging Pile. Please read this instruction carefully before use and operate according to it. Catalogue 1. Introduction ..................................................... 3 2. Product features ............................................. 4 3. Main technical parameters ......................... 5 4. Appearance description ............................... 6 5. NOTICES ............................................................ 7 6. Description of packaging accessories ..... 8 7. Installation Settings ....................................... 9 9. Charging Pile Operation Instructions.... 12 10. Common Issues Handling ....................... 13 11. After-sales Service ..................................... 14 1. Introduction BHZD EV AC Charging Pile are developed by the company of BHZD to meet the charging needs of new energy vehicles, Provide maximum 240V 40A charging ability. This product is simply installed in one small areas. It is suitable for private parking garage, public parking garage, community parking lot and company special parking lot. Product outline picture 2. Product features ◆ It has a unique disc design and convenient for hanging. ◆ This part has one 4.3inch display screen. It is configured, and shows the real-time charging status at a glance. ◆ Charging when plug in, Stop charging when full. ◆ it has the functions of over-voltage and under voltage protection, over- temperature protection, over-current protection, leakage protection, lightning protection, emergency stop protection and so on to ensure the safety and reliability of the product. ◆ The structure adopts rainproof and dustproof design, with IP55 protection grade, suitable for indoor and outdoor. ◆ Simple installation, operation and maintenance ◆ This product has voice prompt function and auxiliary prompt charging function. ◆ 10 LED water lamps are designed for breathing and charging state, and different colors are displayed in different states. 3. Main technical parameters AC Series product model BHZD-A32A BHZD-A40A BHZD-A50A Electrical specifications AC input input voltage range 240 VAC Plug NEMA 14-50P Maximum input current 32A 40A 40A frequency 60Hz AC output maximum output current 32A 40A 40A leakage current protection ≤30mA Service Environment working temperature -25°C-55°C humidity Maximum 95% (Relative humidity) altitude ≤2000m Enclosure rating： Type 3R cooling-down method natural cooling External Structure Size (L*W*H) 460*220*200mm Enclosure material ABS+PC net weight 6.6KG (with a Vehicle Connector) Output cable of Vehicle Connector 5m（16 feet） Protection Mechanism Enter the test Low voltage, overvoltage, lightning strike protection, grounding fault Output measurement Overcurrent, control signal fault detection and protection, electric leakage protection interior Over temperature,self-detection protection of leakage current, and error detection of MCU function Certification Specification standard UL2594 UL2231-1/-2 attestation UL/FCC Charging interface SAEJ1772,Type 1 Status Function Status indication LED waterfall light A 4.3-inch OLED display Communication Mode Ethernet way Plug and Play / swipe card start and stop(NFC) communicating function WIFI and Bluetooth 4. Appearance description 1) Housing materials: PC 2) LED display: 4.3-inch LCD display, charging is on real-time display. 3) Emergency stop switch 4) LED indicator: different states display different states 5) 5m (16ft) cable of Vehicle Connector 1 2 4 5 3 6 6) NEMA 14-50P plug 5. NOTICES Before using this product, please read this manual and all instructions and warnings. When using the product, please keep the basic preventive measures, including the following contents: 1) During the installation and replacement of the charging pile, be sure to cut off the power to prevent electric shock 2) The wires of charging pile must be firmly connected, insulated, and well grounding connected. 3) Please operate strictly according to the instructions. Do not install or operate in a non working environment. 4) Please do not insert your finger into the charging hole during charging 5) Do not use the equipment when it is damaged. Please ask professional maintenance personnel to repair or contact after-sales service personnel 6) If the socket is loose, rusty and aging, please stop using it immediately and replace it with a new socket. 7) Do not use in rainstorm. 8) For vehicles that support electronic lock, pull out the pile Vehicle Connector by press the micro button after unlocking. It is not allowed to plug and unplug with force. 9) If you need any maintenance or repair, please contact the sales service in time. Please do not disassemble the equipment by yourself. Improper disassembly may cause electric shock or fire. 6. Description of packaging accessories The packing box contains the following accessories: 1) EV AC Charger (including cable of Vehicle Connector) 2) Operating instructions 3) One Install hanging plate 4) KA4 * 20 expansion screws (including plastic expansion pipe) 4PCS 7. Installation Settings Installation environment requirements: 1) The EV Charger is an indoor and outdoor one, which meets the protection grade of Type 3R and can be installed in the open area. 2) Please ensure that the ambient temperature is within the range of - 25 °C ~ + 55 °C. 3) No inflammable and explosive article near the installation sites. 4) No be in low-lying areas or water areas near the installation sites. 5) The pile installation must be supported by the wall. If there is no wall, it is recommended to use a special column for installation and fixation. 6) When installing the Charger, ensure that the charger is vertical, and the installation height is about 1.1m from the center p…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Nlightend Smart Tech.Co.,Ltd Address No.528,Daluzhou,Meilin street,Ninghai county,Ningbo,China Grantee Code 2BAZL FCC ID 2BAZLBHZD-A40A Authorized Contact Name Feng Liu Contact Email [email protected] Contact Phone (86)0574-59951233 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List Nlightend Smart Tech.Co.,Ltd (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Nlightend Smart Tech.Co.,Ltd (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2023-05-04 Print Name: Feng Liu Title: Director of Sales *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

UNITEDSTATESDESIGNATEDAGENTLETTER Date:26/05/2023 TO:FederalCommunicationCommission EquipmentAuthorizationBranch 7435 OaklandMills Road Columbia,MID 21046 ApplicantU.S. designatedagent CompanyName:NlightendSmartTech.Co.,LtdCompanyName:GSS SERVICEINC GranteeCode:2BAZLFRN:0033402082 ContactName:Feng LiuContactName:MichouxLogan Address:No.528,Daluzhou,Meilin street,Ninghai county,Ningbo,China Address:6547 N AcademyBlvd #2266 ColoradoSpringsCo 80918 USA City/Province/Zip:Ningbo/Zhejiang/chinaCity/Province/Zip:ColoradoSpringsCo /80918 Telephone:(86)0574-59951233Telephone: Fax:(86)0574-65295128Fax: Email:[email protected]: 001-949-2990192 N/A [email protected] ApplicableEquipment:FCC ID: <2BAZLBHZD-A40A> ATTN:Directorof Certification: We, < NlightendSmartTech.Co.,Ltd> and <GSS SERVICEINC > understandand acknowledgethe applicantsconsentand the designatedagent ’s obligationto acceptserviceof processin the United Statesfor mattersrelatedto the applicableequipment,and at the physicalU.S. addressand e-mailof the designatedagent listed above. We, < NlightendSmartTech.Co.,Ltd> and <GSS SERVICEINC > acknowledgethe applicant’s acceptanceof its obligationto maintainan agent for serviceof processin the UnitedStatesfor no less than one year after either the granteehas permanentlyterminatedall marketingand importationof the applicableequipmentwithin the U.S., or the conclusionof any Commission-relatedadministrativeor judicialproceedinginvolvingthe equipment,whicheveris later. ApplicantU.S. designatedagent Name(Printed): Feng LiuName(Printed):MichouxLogan Title: Directorof SalesTitle:PM Signature: Signature:

Nlightend Smart Tech Co.,Ltd Current Date: 2023-05-04 To: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. No. 588 West Jindu Road, Songjiang District, Shanghai, China. 201612 Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE (Nlightend Smart Tech Co.,Ltd) HEREBY DECLARED THAT Product Description AC Charging Pile Model No. BHZD-A32A, BHZD-A40A, Manufacturer’s Name Nlightend Smart Tech Co.,Ltd Manufacturer’s Address N0.528,Daluzhou,Meilin street,Ninghai county Ningbo China *Except that the model number and the maximum output current (The maximum output current of BHZD-A32A is 32A and the maximum output current of BHZD-A40A, BHZD-A50A is 40A, hardware was same, the current is adjust by software, and different currents have no effect on RF circuits) deviation, are identical with the original product as follows: Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical. with the model(s) below which samples we chose to be tested by SGS Model No. (型号): BHZD-A50A Manufacturer’s Name (生产商名称): Nlightend Smart Tech Co.,Ltd Manufacturer’s Address（生产商商地址): N0.528,Daluzhou,Meilin street,Ninghai county Ningbo China Sincerely, Signature (签字): Printed Name (姓名): Feng Liu Position/Title (职位): Director of Sales Contact Number (联系电话): (86)0574-59951233

Nlightend Smart Tech.Co.,Ltd Date: 2023-05-04 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2BAZLBHZD-A40A To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Nlightend Smart Tech.Co.,Ltd. This authorization is valid until further written notice from the applicant. Name (Printed): Feng Liu Title: Director of Sales Signature: On behalf of Company: Nlightend Smart Tech.Co.,Ltd Telephone: (86)0574-59951233

Nlightend Smart Tech.Co.,Ltd To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Company Name: Nlightend Smart Tech.Co.,Ltd Address: No.528,Daluzhou,Meilin street,Ninghai county,Ningbo,China Regarding: Confidentiality Request regarding application for FCC ID: 2BAZLBHZD-A40A LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code):Feng Liu Title: Director of Sales Company Name: Nlightend Smart Tech.Co.,Ltd

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 10 External Photos for SHCR2304000695EV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 10 EUT Constructional Details (EUT Photos) Model: BHZD-A50A SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 10 Model: BHZD-A32A SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 8 of 10 Model: BHZD-A40A SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 9 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 10 of 10

Model：BHZD-A32A Rated Input Voltage：240V AC Rated Output Voltage：240V AC Rated Frequency：60Hz Rated Power：7kw Input Current：32A Output Current：32A Ambient temperature rating:-25°C to 50°C Enclosure rating：Type 3R For use with Electric Vehicles Ventilation Not Required Date： FCC ID: 2BAZLBHZD-A40A IC: 30442-BHZD40 CAN ICES-3 (B)/NMB-3(B) BHZD Smart EV AC Charging Pile This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 75x45mm Model：BHZD-A40A Rated Input Voltage：240V AC Rated Output Voltage：240V AC Rated Frequency：60Hz Rated Power：9.6kw Input Current：40A Output Current：40A Ambient temperature rating:-25°C to 50°C Enclosure rating：Type 3R For use with Electric Vehicles Ventilation Not Required Date： FCC ID: 2BAZLBHZD-A40A IC: 30442-BHZD40 CAN ICES-3 (B)/NMB-3(B) BHZD Smart EV AC Charging Pile 75x45mm 65x45mm Warning To avoid a risk of fire or electric shock, do not use this device with an extension cord. Risk of explosion. This equipment has arcing or sparking parts that should not be exposed to flammable vapors. This equipment should be located at least 460 mm (18 inches) above the floor. This device is intended only for charging vehicles not requiring ventilation during charging. CAUTION To reduce the risk of electric shock, connect only to properly grounded outlets. Risk of electric shock. Do not remove cover or attempt to open the enclosure. No user serviceable parts inside. Refer servicing to qualified service personnel. Do not use this product if there is any damage to the unit. Model：BHZD-A50A Rated Input Voltage：240V AC Rated Output Voltage：240V AC Rated Frequency：60Hz Rated Power：11.5kw Input Current：50A Output Current：50A Ambient temperature rating:-25°C to 50°C Enclosure rating：Type 3R For use with Electric Vehicles Ventilation Not Required Date： FCC ID: 2BAZLBHZD-A40A IC: 30442-BHZD40 CAN ICES-3 (B)/NMB-3(B) BHZD Smart EV AC Charging Pile 75x45mm This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 21 Internal Photos for SHCR2304000695EV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 21 EUT Constructional Details (EUT Photos) Model: BHZD-A50A SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 8 of 21 Model: BHZD-A32A SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 9 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 10 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 11 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 12 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 13 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 14 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 15 of 21 Model: BHZD-A40A SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 16 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 17 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 18 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 19 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 20 of 21 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 21 of 21

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230400069504 Page: 1 of 8 Parlam Zhan Laboratory Manager 1 Cover Page RF Exposure Evaluation Report Application No.: SHCR2304000695EV FCC ID: 2BAZLBHZD-A40A IC: 30442-BHZD40 Applicant: Nlightend Smart Tech Co.,Ltd Address of Applicant: No.528, Daluzhou, Meilin street, Ninghai county, Ningbo, China Manufacturer: Nlightend Smart Tech Co.,Ltd Address of Manufacturer: No.528, Daluzhou, Meilin street, Ninghai county, Ningbo, China Factory: Nlightend Smart Tech Co.,Ltd Address of Factory: No.528, Daluzhou, Meilin street, Ninghai county, Ningbo, China Equipment Under Test (EUT): EUT Name: AC Charging Pile Model No.: BHZD-A50A Add Model No.: BHZD-A32A, BHZD-A40A Standard(s) : FCC Rules 47 CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 RSS-102 Issue 5 Amendment 1 (February 2, 2021) Date of Receipt: 2023-04-10 Date of Test: 2023-05-05 to 2023-05-17 Date of Issue: 2023-05-30 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230400069504 Page: 2 of 8 Revision Record Version Description Date Remark 00 Original 2023-05-30 / Authorized for issue by: Bill Wu/Project Engineer Parlam Zhan /Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230400069504 Page: 3 of 8 2 Contents Page 1 COVER PAGE .......................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................... 3 3 GENERAL INFORMATION ..................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T. ............................................................................................................ 4 3.2 TECHNICAL SPECIFICATIONS .................................................................................................................... 4 3.3 TEST LOCATION ....................................................................................................................................... 5 3.4 TEST FACILITY ........................................................................................................................................ 5 4 TEST STANDARDS AND LIMITS .......................................................................................................... 6 4.1 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ............................................................................. 6 4.2 IC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ................................................................................ 6 5 MEASUREMENT AND CALCULATION ................................................................................................ 7 5.1 MAXIMUM TRANSMIT POWER ................................................................................................................... 7 5.2 MPE CALCULATION ................................................................................................................................ 8 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230400069504 Page: 4 of 8 3 General Information 3.1 General Description of E.U.T. Power supply: AC 240V/60Hz S/N: BHZD-A40A-A1 Firmware Version: V2.6 3.2 Technical Specifications BLE Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V4.0 LE Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: PCB Antenna Antenna Gain: 2.54 dBi (Provided by manufacturer) 2.4GHz WiFi Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK);802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11 Channel Spacing: 5MHz Antenna Type: PCB Antenna Antenna Gain: 2.54 dBi (Provided by manufacturer) Date Rate: 802.11b:1/2/5.5./11Mbps 802.11g:6/9/12/18/24/36/48/54Mbps 802.11n:MCS0-MCS7 13.56MHz Operation Frequency 13.56MHz Modulation Technique: ASK Antenna Type: Loop antenna Number of Channel: 1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230400069504 Page: 5 of 8 3.3 Test Location All tests were performed at: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. E&E Lab 588 West Jindu Road, Xinqiao, Songjiang, 201612 Shanghai, China. Tel: +86 21 6191 5666 Fax: +86 21 6191 5678 No tests were sub-contracted. Note: 1. SGS is not responsible for wrong test results due to incorrect information (e.g. max. clock frequency, highest internal frequency, antenna gain, cable loss, etc ) is provided by the applicant. (if applicable). 2. SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (if applicable). 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 6332.01) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. is accredited by the American Association for Laboratory Accreditation(A2LA). • FCC (Designation Number: CN1301) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. has been recognized as an accredited testing laboratory. • ISED (CAB Identifier: CN0020) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. EMC Laboratory has been recognized by Innovation, Science and Economic Development Canada (ISED) as an accredited testing laboratory. Company Number: 8617A • VCCI (Member No.: 3061) The 3m Semi-anechoic chamber and Shielded Room of SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. has been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: R-13868, C-14336, T-12221, G-10830 respectively. SGS-CSTC Sta…
