If you have any questions, please feel free to contact us on [email protected] Take out 2 covers from the bottom. Plug LED bulbs into the USB ports on the mirror. After installing all the bulbs, connect the adapter and turn the mirror on. Take out 4 screws from the bases. Install the two bases with the screws. A B Please plug in all bulbs before powering on. Please do not touch the bulb base directly after the mirror is on, in order to avoid possible electric shocks. When a bulb needs to be removed, please turn off the mirror first, then hold it tightly and pull it out. Do not plug other USB devices into any port on the mirror. Do not install the bulb into the USB port of any other devices. 1 2 3 4 5 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement This device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device complies with Part 15 of the FCC rules. Operation is subject to thefollowing two conditions: 1.This device may not cause interference. 2.This device must accept any interference, including interference that may cause undesired operation of the device. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may causeharmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. This device must operate with a minimum distance of 2 0 cm between the radiator and user body. NOTE: If you want to attach the mirror to the wall, please put the covers back after you remove the bases. LevelPencilHammerSafety Goggles Electric DrillPhillips Screwdriver Tape Measure Measure the distance between two mounting holes, and draw a horizontal line of the same distance on the wall with a lever, then mark the spots. Slightly loosen the screws from the anchors, with a 7mm gap to the wall. Then mount the mirror and make sure it’s hang firmly. Drill holes at the marked spots and apply the wall anchors. 7mm Press the button and the bulbs will be gradually lit up to avoid a sudden dazzling light. 1 Press and select the color temperature of the bulb, with three options (warm, natural, cool) available. 2 Press to adjust the brightness of the bulb (five brightness levels to choose), or touch and hold it to switch the brightness. 3 Connect and charge smart devices when there is no socket within reach. 4 1.Turn on the mirror; 2.Connect " Vanity Mirror " through the mobile phone’s bluetooth funnction; 3.Play the songs in your mobile phone. * Adapter shall be installed near the equipment and shall be easily accessible. The plug considered as disconnect device of adapter. 1 2 3 4
Guangzhou Zhuo Rui Smart Home Technology Co., LTD Room 911, 912 No.8 East Pazhou Avenue, Haizhu District, Guangzhou Covered Equipment Certification Attestation Letter 7/21/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2BB2A-HZ-02A-8166 Guangzhou Zhuo Rui Smart Home Technology Co., LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List , the applicant should include an explanation on why the equipment is not “covered” equipment. Guangzhou Zhuo Rui Smart Home Technology Co., LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Jiazheng Cheng Title:CEO Company Name: Guangzhou Zhuo Rui Smart Home Technology Co., LTD Date: 7/21/2023
1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: Wilson Tech Service LLC FRN: 0033402033 Contact Name: Wilson Cheung Address: 1312 17th Street Suite 692, Denver, CO, 80202, US Telephone No: +1-716-965-5112 Email:[email protected] Applicant: Company name: Guangzhou Zhuo Rui Smart Home Technology Co., LTD Product Description: Hollywood Makeup Mirror Grantee code: 2BB2A FCC ID: 2BB2A-HZ-02A-8166 Contact Name: Jiazheng Cheng Address: Room 911, 912 No.8 East Pazhou Avenue, Haizhu District, Guangzhou, China Telephone No: +86-18688442640 Email: [email protected] [Guangzhou Zhuo Rui Smart Home Technology Co., LTD] certifies that, as of the date of this filing of the application with the TCB, [Wilson Tech Service LLC] is our designated US agent for service of process for the above referenced FCC ID. [Guangzhou Zhuo Rui Smart Home Technology Co., LTD ] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [Wilson Tech Service LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/07/17 Applicant’s Name: Jiazheng Cheng US Agent’s Name: Wilson Cheung Title:Manager Title: Manager Signature Signature
DATE:2023-07-21 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent Onourbehalf,IappointDongguan New Testing Centre Co., Ltd;3F, No. 1 the 1st North Industry Road, Songshan Lake Science &Technology Park, Dongguan, Guangdong, China, 523808. toactasouragentinthepreparationofthisapplicationforequipmentcertification.Icertifythatsubmitte ddocumentsproperlydescribethedeviceorsystemforwhichequipmentcertificationissought.Ialsoc ertifythateachunitmanufactured,importedormarketed,asdefinedintheFederalCommunicationsC ommission’sregulationswillhaveaffixedtoit a label identical to that submitted for approval with thisapplication. Forinstanceswhereourauthorizedagentsignstheapplicationforcertificationonourbehalf,Iack nowledgethatallresponsibilityforcomplyingwiththetermsandconditionsforcertification,stillres ideswith Guangzhou Zhuo Rui Smart Home Technology Co., LTD;Room 911, 912 No.8 East Pazhou Avenue, Haizhu District, Guangzhou <Signature> Name: Jiazheng Cheng Title: CEO Applicant Company: Guangzhou Zhuo Rui Smart Home Technology Co., LTD
DATE 2023-07-21 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:2BB2A-HZ-02A-8166 Product Name:Hollywood Makeup Mirror Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Jiazheng Cheng Title: CEO Applicant Company: Guangzhou Zhuo Rui Smart Home Technology Co., LTD
Page 1 of 3 FCC-ID:2BB2A-HZ-02A-8166 External photos Model No: HZ-02A-8166-BT Page 2 of 3 FCC-ID:2BB2A-HZ-02A-8166 Page 3 of 3 FCC-ID:2BB2A-HZ-02A-8166
Page 1 of 1 FCC-ID:2BB2A-HZ-02A-8166 Label and label location Model No: HZ-02A-8166-BT Hollywood Makeup Mirror Model:HZ-02A-8166-BT FCC:2BB2A-HZ-02A-8166 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 1 of 3 FCC-ID:2BB2A-HZ-02A-8166 Internal Photos Model No: HZ-02A-8166-BT Page 2 of 3 FCC-ID:2BB2A-HZ-02A-8166 BT Antenna Page 3 of 3 FCC-ID:2BB2A-HZ-02A-8166
RF Exposure evaluation According to 447498 D04 Interim General RF Exposure Guidance v01 NOTE: The distance between EUT and user is no less than 20cm Ant gain = -0.58dBi (-0.58-2.15=-2.73dBd) MAX output power :9.887dBm@2402MHz ERP=9.887dBm -2.73dBd= 7.157dBm WORSE CASE: 9.887dBm 10^0.9887=9.743 mW < 3060 mW Then SAR evaluation is not required
