2BB2F-Y28AIntelligent bird feeder

V1.0 What’s in the box Bird feeder structure Bird feederBracketAnchors*4 Micro-usb Charging cable Screws for wood*4screw washers*4Screws for wall*4Pin Solar panel Camera Bird Stand Bracket Bird feeder cover Hummingbird feeder - 1 - Camera structure Camera Specifica�on Sync/Reset Camera bracket Power ON/OFF Speaker Lens PIR moun�ng sensor Microphone TF card slot Infrared led Charging port Light sensor LED indicator light Power Consumption 2W Watts(max.) Standby current <500uA Battery life 4-6 months Pixel 2 megapixel 1080P Viewing angle 170° Night visual range 8m(max) Wireless connection 2.4G Anti-flicker 50HZ 60HZ Operating temperature -20.5°C~48°C Operating humidity 10%~95% non-condensing Product model Y28-A - 2 - STATUS LED Read Before Installa�on: 1.Power on: Blue light on 2.Charging: Red light on 3.Connec�ng to network: Blue light flashing 4.Connected to network successfully: Blue light on constantly 5.Fully charged: Red light off 1.Please keep the bird feeder and all accessories out of the reach of children and pets. 2.Ensure that the camera has been fully charged before connec�ng and se�ng it up. 3.Opera�ng temperature range: -5°F to -120°F (-20 to 48.5). 4.Opera�ng rela�ve humidity range: 10% to 95%. 5.Do not expose the camera lens to direct sunlight. 6.The camera has an IP65 waterproof ra�ng, and can operate normally in rainy and snowy weather condi�ons, but should not be submerged in water. NOTE: 1.The bird feeder supports 2.4G WiFi networks. 2.When connec�ng to WiFi for setup and using the camera, try to stay within range of a strong WiFi signal to avoid weak signal issues that may affect camera setup and use. 3.Avoid placing the device near furniture or other products that generate electromagne�c interference, such as microwaves. Battery capacity 4500mAh Maximum capacity of memory card 128G solar charging 5V/200mAh Power supply DC 5V2A - 3 - Installing a bird feeder: wall and wood surface installa�on I. Wall Installa�on: 1.Begin by marking the loca�ons for the screw holes on the wall according to the bracket holes, then drill four holes using the drill bit (Note: the narrow end of the bracket hook should face upwards). 2.Place four anchors into the drilled holes, then place the larger wall screws into the bracket's grooves and use the iron wrench provided with the product to �ghten the screws and secure the bracket. 3.Use two iron wrenches to �ghten the screws on the adjustable parts of the bracket up and down to adjust the bird feeder's direc�on. When the bird feeder's direc�on is set, �ghten the screws as much as possible to support the bird feeder and prevent it from �l�ng. 4.Adjust the �ghtness of the screws as needed and fix the bird feeder bracket in the le� and right direc�ons. - 4 - II. Wood surface installa�on: 5.Align the slot on the back of the bird feeder with the card holder on the bracket, and insert it to complete the installa�on. If needed, you can �ghten the small screw next to the card holder to secure the connec�on between the bird feeder and the bracket. 1.Start by marking the four screw posi�ons on the wood surface according to the small screw holes on the bracket base (Note: the narrow end of the bracket hook should face upwards). Then, insert the screw washers onto the screws and use a screwdriver or electric screwdriver to secure the bracket to the wood surface. - 5 - 2.Use the two wrenches to �ghten the screws on the moving parts of the bracket to adjust the up and down direc�on of the bird feeder. Once the direc�on is set, firmly �ghten the screws to support the bird feeder and prevent �l�ng. 3.Depending on the required �ghtness, adjust the screws to fix the bird feeder bracket in the le� and right direc�ons. 4.Align the slot on the back of the bird feeder with the card holder on the bracket, and insert it to complete the installa�on. If needed, you can �ghten the small screw next to the card holder to secure the connec�on between the bird feeder and the bracket. - 6 - Installing the app Download the iWFCam from APP Store or Google Play.The iWFCam App connects your camera to your Android or iOS mobile device ensuring you are always connected to what ma�ers most. To get the App, search for "iWFCam”in the Google Play or App Store and download it.You can also use your mobile to scan the QR-Code to download the "iWFCam" App. 1.A�er opening the app and entering itPlease click"agree" [user agreement and privacy policy] and allow the iWFCam app to access your pictures and video, or it may lead to fail to connect to wifi. - 7 - 2.Click on the '+' to add a device." 3.Click 'OK' to proceed to the next step." 4.Click 'ALLOW ONLY WHILE IN USE' to proceed to the next step." - 8 - 5.Click 'ALLOW' to proceed to the next step." 6.Select the first op�on "Setup Device WIFI connec�on" and proceed to the next step. 7.If the camera blue light is flashing slowly, it means that the camera is ready to be connected to the network. Click "Light is slow flashing(1 sec)->Next". 8.Click "I want to connect my phone to the AP now" to proceed to the next step. - 9 - 9.Select the WiFi hotspot with the prefix "KCKJA**********". 10.Click "CONNECT" to connect and once the connec�on is successful, click the arrow (←) on the top le� corner to return to the app interface. Note: The Android system will prompt you with the following content. Please select "CONNECT" to proceed. - 10 - 11.Select your home WiFi (if not displayed, please click the double arrow on the right to refresh), enter the WiFi password (you can click the icon on the right to show the input content to ensure that the password is entered correctly), and click "Start configuring WIFI" and then "OK" to enter the camera's connec�on se�ngs. 12.When the camera enters the network configura�on se�ng, there will be a "beep" sound. A�er wai�ng for a while, there will be two "beep beep" sounds, indica�ng that the camera has been successfully set up for networking. Click "OK" to proceed. - 11 - 13.Once the camera is set up successfull…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: UGK-LVMUNITEDINC FRN: 0033476375 Contact Name: Jimmychen Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 Telephone No: 001-323-51 04660 Email: [email protected] Applicant: Company name: Shenzhen Kechuang Technology Co., Ltd. Grantee code: 2BB2F FCC ID: 2BB2F-Y28A Contact Name: Jason lu Address: 8/F,Building C10,Fuyuan Mill Town,Jiuwei Village,Xixiang Street,Baoan District Telephone: 15914015276 Fax: 15914015276 E-mail: [email protected] [Shenzhen Kechuang Technology Co., Ltd.] certifies that, as of the date of this filing of the application with the TCB, [UGK-LVMUNITEDINC] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen Kechuang Technology Co., Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [UGK-LVMUNITEDINC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/07/11 Applicant’s Name: Jason lu US Agent’s Name: Jimmychen Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Kechuang Technology Co., Ltd. Grantee code: 2BB2F FCC ID: 2BB2F-Y28A Contact Name: Jason lu Address: 8/F,Building C10,Fuyuan Mill Town,Jiuwei Village,Xixiang Street,Baoan District Telephone: 15914015276 Fax: 15914015276 E-mail: [email protected] i. [Shenzhen Kechuang Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Kechuang Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Kechuang Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2023/07/11 Applicant’s Name: Jason lu Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen Kechuang Technology Co., Ltd. Product Similarity Declaration Company: Shenzhen Kechuang Technology Co., Ltd. Address: 8/F,Building C10,Fuyuan Mill Town,Jiuwei Village,Xixiang Street,Baoan District Product Name: Intelligent bird feeder Model Number: Y28-A Y28-B, Y28-C, Y28-D, Y28-E, Y28-F, Y28-G, Y28-H, Y28-I, Y28-J, Y28-K FCC Identifier: 2BB2F-Y28A We (Shenzhen Kechuang Technology Co., Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name and appearance color. Client’s signature Name: Jason lu Date: 2023-07-11 Title: Manager Signature of applicant:

Shenzhen Kechuang Technology Co., Ltd. 1/1 Letter of Authorization Company: Shenzhen Kechuang Technology Co., Ltd. Address: 8/F,Building C10,Fuyuan Mill Town,Jiuwei Village,Xixiang Street,Baoan District Product Name: Intelligent bird feeder Model Number: Y28-A Y28-B, Y28-C, Y28-D, Y28-E, Y28-F, Y28-G, Y28-H, Y28-I, Y28-J, Y28-K FCC Identifier: 2BB2F-Y28A We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Jason lu Date: 2023-07-11 Title: Manager Signature of applicant:

Shenzhen Kechuang Technology Co., Ltd. 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-07-11 Subject: Request for Confidentiality FCC ID: 2BB2F-Y28A To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jason lu Title: Manager

Size: 22*18mm M/N: Y28-A FCC ID: 2BB2F-Y28A Label location

ANT

FCC ID: 2BB2F-Y28A RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm EIRP=E Meas +20log(d Meas )-104.7 EIRP is the equivalent isotropically radiated power, in dBm E Meas is the field strength of the emission at the measurement distance, in dBμV/m d Meas is the measurement distance, in m Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation wifi 2.4G mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 16.601 45.7193 0.01981 1.0 PASS 802.11g 13.478 22.2741 0.00965 1.0 PASS 802.11n HT20 14.463 27.9447 0.01211 1.0 PASS 802.11n HT40 13.852 24.2773 0.01052 1.0 PASS Remark: antenna gain=3.38dBi

Summary Antenna Specification ITEMANT SPEC Model Name2.4G ANT MAX. Gain 3.38dBi PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length38.20mm Manufacture Shenzhen Kechuang Technology Co., Ltd. Antenna Photo & Length (mm) ÏÚ 2‹ Œøº∑ø ̈∑±≤ Ω ∏øÆøΩ ̈ªÆ∑≠ ̈∑Ω≠ ±∫ ø≤ ̈ª≤≤ø PHI 0° PHI90° THETA90 °

Test Report Number: BTF230718R01001 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 1 3 0 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 1 o f 52 FCC Part 15C Test Report FCC ID: 2BB2F-Y28A Applicant: Shenzhen Kechuang Technology Co., Ltd. Address: 8/F,Building C10,Fuyuan Mill Town,Jiuwei Village,Xixiang Street,Baoan District Manufacturer: Shenzhen Kechuang Technology Co., Ltd. Address: 8/F,Building C10,Fuyuan Mill Town,Jiuwei Village,Xixiang Street,Baoan District EUT: Intelligent bird feeder Trade Mark: N/A Model Number: Y28-A Y28-B, Y28-C, Y28-D, Y28-E, Y28-F, Y28-G, Y28-H, Y28-I, Y28-J, Y28-K Date of Receipt: Jun. 27, 2023 Test Date: Jun. 27, 2023 - Jul. 06, 2023 Date of Report: Jul. 06, 2023 Prepared By: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2013 Test Result: Pass Report Number: BTF230718R01001 Project Engineer: Elma.yang EMC Manager: Ryan.CJ This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of BTF Testing Lab (Shenzhen) Co., Ltd. Test Report Number: BTF230718R01001 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 1 3 0 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 2 o f 52 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 10 3.2 RADIATED EMISSION MEASUREMENT 11 3.2.1 RADIATED EMISSION LIMITS 11 3.2.2 TEST PROCEDURE 12 3.2.3 DEVIATION FROM TEST STANDARD 12 3.2.4 TEST SETUP 12 3.2.5 EUT OPERATING CONDITIONS 13 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 14 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 15 3.2.8 TEST RESULTS (1GHZ~25GHZ) 17 3.3 RADIATED BAND EMISSION MEASUREMENT 21 3.3.1 TEST REQUIREMENT: 21 3.3.2 TEST PROCEDURE 21 3.3.3 DEVIATION FROM TEST STANDARD 21 3.3.4 TEST SETUP 21 3.3.5 EUT OPERATING CONDITIONS 22 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 27 3.4.1 APPLICABLE STANDARD 27 3.4.2 TEST PROCEDURE 27 3.4.3 DEVIATION FROM STANDARD 27 3.4.4 TEST SETUP 27 3.4.5 EUT OPERATION CONDITIONS 27 Test Report Number: BTF230718R01001 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 1 3 0 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 3 o f 52 Table of Contents Page 3.4.6 TEST RESULTS 27 4 . AVERAGE OUTPUT POWER 31 4.1 APPLIED PROCEDURES / LIMIT 31 4.1.1 TEST PROCEDURE 31 4.1.2 DEVIATION FROM STANDARD 31 4.1.3 TEST SETUP 31 4.1.4 EUT OPERATION CONDITIONS 31 4.1.5 TEST RESULTS 32 5 . POWER SPECTRAL DENSITY TEST 35 5.1 APPLIED PROCEDURES / LIMIT 35 5.1.1 TEST PROCEDURE 35 5.1.2 DEVIATION FROM STANDARD 35 5.1.3 TEST SETUP 35 5.1.4 EUT OPERATION CONDITIONS 35 5.1.5 TEST RESULTS 36 6 . 6DB BANDWIDTH TEST 39 6.1 APPLIED PROCEDURES / LIMIT 39 6.1.1 TEST PROCEDURE 39 6.1.2 DEVIATION FROM STANDARD 39 6.1.3 TEST SETUP 39 6.1.4 EUT OPERATION CONDITIONS 39 6.1.5 TEST RESULTS 40 7 . ANTENNA REQUIREMENT 43 7.1 STANDARD REQUIREMENT 43 7.2 EUT ANTENNA 43 8 . TEST SEUUP PHOTO 44 9 . EUT PHOTO 45 Test Report Number: BTF230718R01001 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 1 3 0 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 4 o f 52 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.205, 15.209, 15.247(d) Radiated Spurious Emission PASS 15.205, 15.247(d) Band Edge Emission& Conducted Spurious Emissions PASS 15.247(b) Average Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2MHz Test Report Number: BTF230718R01001 Te s t R e p o r t Te l : + 8 6-0 7 5 5-2 3 1 4 6 1 3 0 Em a il: R y a n . c j @ b t f-l a b . c o m P a g e 5 o f 52 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: Intelligent bird feeder Trademark N/A Model No.: Y28-A Y28-B, Y28-C, Y28-D, Y28-E, Y28-F, Y28-G, Y28-H, Y28-I, Y28-J, Y28-K Model Difference The product's different for model number and appearance color. Operation Frequency: 2412~2462 MHz for 802.11b/g/nHT20 2422~2452 MHz for 802.11nHT40 Channel numbers: 11 Channels for 802.11b/g/n(HT20) 7 channels for 802.11nHT40 Channel separation: 5MHz Modulation technology: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n(20): DSSS (CCK, DQPSK,DBPSK)+OFDM (QPSK, BPSK, 16-QAM, 64-QAM) Rate of Transmitter 802.11b: 11/5.5/2/1Mbps 802.11g: 54/48/36/24/18/12/9/6Mbps 802.11n: up to 150Mbps Antenna Type: Built-in antenna Antenna gain: 3.38 dBi Power supply: DC 3.7V from battery Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2.The EUT’s all information provided by client. Test Report Number: BTF230718R01001 Te s t R e p o r t Te l : + 8 …

Text truncated - open the document above for the full version.

Radiated Measurement Photos
