senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack IBAN: DE32840510101113012737 VAT Nr.: DE 199934786 Rico Röhner BIC: HELADEF1ILK Steuernummer: 156 126 00594 http://www.senTec-Elektronik.de Integration instructions for host product manufacturers according to KDB 996369 D03 OEM Manual v01 2.2 List of applicable FCC / ISED rules FCC: ISED: 47CFR Part 15 Subpart C §15.247 RSS-247 2.3 Specific operational use conditions The module has a 10-pin header with a pitch of 2.54 mm to connect it to the host. The voltage supply of the module is 5VDC to 20VDC. For details refer to the operating instruction chapter 3 Electrical Specification. The module has a fixed integrated PCB-antenna. The operation frequency is 903.5Mhz to 927.5MHz. The modulation type is 2GFSK. 2.4 Limited module procedures Installations Notes: The module power supply range is 5VDC to 20VDC. When connect the module to the host device, the host device must power off. Make sure the module pins correctly installed 2.5 Trace antenna designs Not applicable. The module does have a fixed PCB-antenna. 2.6 RF exposure considerations This equipment complies with FCC’s RF radiation exposure limits set forth for an uncontrolled environment. 2.7 Antennas PCB-antenna is permanently attached, can’t be replaced. The PCB-antenna design corresponds to the Silicon Labs reference design WES0118-01-APL915S-01. 2.8 Label and compliance information Each module has its own label with the FCC identification number. It is placed at the shielding of the module. 2.9 Information on test modes and additional testing requirements Contact senTec Elektronik GmbH for information on how to configure test modes for the module. 2.10 Additional testing, Part 15 Subpart B disclaimer The modular transmitter is only FCC authorized for the specific rule parts listed on the grant. The host product manufacturer, is responsible for compliance to any other FCC rules that apply to the host not covered by the modular transmitter grant of certification.

senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack IBAN: DE32840510101113012737 VAT Nr.: DE 199934786 Rico Röhner BIC: HELADEF1ILK Steuernummer: 156 126 00594 http://www.senTec-Elektronik.de Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/13/2023 To whom it may concern: We, senTec Elektronik GmbH, hereby certify that the equipment for which authorization is sought (FCC ID: 2BB4J-WM09A) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Rico Röhner CEO senTec Elektronik GmbH 62_[model] CoveredEq u_2.911(d)(5)(i) and (ii) - U, V03

senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack IBAN: DE32840510101113012737 VAT Nr.: DE 199934786 Rico Röhner BIC: HELADEF1ILK Steuernummer: 156 126 00594 http://www.senTec-Elektronik.de Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/18/2023 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2BB4J- WM09A including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature R.Röhner CEO senTec Elektronik GmbH

senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack IBAN: DE32840510101113012737 VAT Nr.: DE 199934786 Rico Röhner BIC: HELADEF1ILK Steuernummer: 156 126 00594 http://www.senTec-Elektronik.de Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/12/2023 Request for Confidentiality Company name: senTec Elektronik GmbH FCC ID: 2BB4J-WM09A In accordance with CFR 47 §0.457(d) and CFR 47 §0.459 of the Commission’s Rules, Company name hereby requests confidentiality of following exhibits: Exhibit Type: Type of Confidentiality Requested Detailed block diagrams * x Long-term confidentiality Schematic diagrams* x Long-term confidentiality Detailed operational descriptions* x Long-term confidentiality Parts lists/ tune up information* x Long-term confidentiality External photos Short-term confidentiality** Internal photos Short-term confidentiality** Test setup photos Short-term confidentiality** User’s manual Short-term confidentiality** Short-term maximum confidentiality period: 180 days OR: Short-term confidentiality release date (product launch): MM/DD/YYYY * Exhibits not routinely made available to the public. ** Only if applicable: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. When the device is marketed the grantee must inform the TCB to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software - 2/2 - Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack Kto.: 1113012737 BLZ : 84051010 VAT Nr.: DE 199934786 Rico Röhner IBAN: DE32840510101113012737 Steuernummer: 156 118 01480 http://www.senTec-Elektronik.de Long-term confidentiality: The documents indicated as long-term confidential contain detailed system and equipment description and related information about the product which Company name considers to be proprietary, confidential and a custom design and the information is not publicly available. Since the design is a basis from which future technological products will evolve, Company name considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Short-term confidentiality (if applicable): Company name requests the exhibits selected above as short-term confidential to be withheld from public view for the period as indicated above. When the device is marketed, Company name will inform the TCB to release the short-term confidentiality information withheld on the FCC equipment authorization website. Sincerely, Signature Rico Röhner CEO senTec Elektronik GmbH Robert-Bosch-Ring 2 98693 Ilmenau / Thuringia / Germany

senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack IBAN: DE32840510101113012737 VAT Nr.: DE 199934786 Rico Röhner BIC: HELADEF1ILK Steuernummer: 156 126 00594 http://www.senTec-Elektronik.de Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 7/27/23 U.S. Agent Designation senTec Elektronik GmbH acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2BB4J-WM09A): Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] Baihetian acknowledges their obligation to accept service of process on behalf of senTec Elektronik GmbH. senTec Elektronik GmbH with the FRN: 0034007880 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature R.Röhner CEO senTec Elektronik GmbH Signature Kenneth Young Manage Baihetian Innovative Solutions

senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack IBAN: DE32840510101113012737 VAT Nr.: DE 199934786 Rico Röhner BIC: HELADEF1ILK Steuernummer: 156 126 00594 http://www.senTec-Elektronik.de Modular Approval Request Letter Date: 2023-09-19 FCC ID: 2BB4J-WM09A Type of Equipment: Radio module Herewith we state that the requirements according to FCC Part 15.212 are met and the module qualifies for a single modular transmitter approval. # Requirement as per 47 CFR Part 15 Subpart C §15.212 Conditions met? (Y/N) Realisation / Evidence in FORM 731 application filing i RF shielding The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. Y The radio portion has his own shielding (see external photos). ii Buffered modulation/data inputs The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. Y The function has been integrated in the chipset iii Power supply regulation The modular transmitter must have its own power supply regulation. Y The function has been integrated in the chipset (see schematic documents) iv Antenna requirements The modular transmitter must comply with the antenna and transmission system requirements of §§15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). Additional justification and details may be requested – please refer to KDB 996369 Y The module comes with an integrated PCB antenna. For antenna details see 17_AntSpec_WES0119-01-APB915D- 01 The spurious emission requirements are fulfilled (see attached test report). v Stand-alone test configuration The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in §15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see §15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see §15.31(i)). Y The module was tested in a standalone configuration and inserted into a module holder (see test report/test setup photos) vi Labelling The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. Y The module has its own label. It is placed at the shielding of the module vii Compliance on specific rule or operating requirements The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The required FCC rules has been fulfilled and all instructions for maintaining compliance has been clearly stated in the user manual viii RF Exposure Radio frequency devices operating under the provisions of this part are subject to the radio frequency radiation exposure requirements specified in §§1.1307(b), 1.1310, 2.1091, and 2.1093 of this chapter, as appropriate. Applications for equipment authorization of modular transmitters under this section must Y The module complies with any applicable RF exposure requirements. See RF test report. senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software - 2 - Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack Kto.: 1113012737 BLZ : 84051010 VAT Nr.: DE 199934786 Rico Röhner IBAN: DE32840510101113012737 Steuernummer: 156 118 01480 http://www.senTec-Elektronik.de contain a statement confirming compliance with these requirements. The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Rico Röhner CEO senTec Elektronik GmbH

FCC ID: 2BB4J-WM09A IC: 31013-WM09A HVIN: MODUL 868MHZ IX G0M-2302-1909 FCC ID: 2BB4J-WM09A IC: 31013-WM09A HVIN: MODUL 868MHZ IX G0M-2302-1909 FCC ID: 2BB4J-WM09A IC: 31013-WM09A HVIN: MODUL 868MHZ IX G0M-2302-1909 FCC ID: 2BB4J-WM09A IC: 31013-WM09A HVIN: MODUL 868MHZ IX G0M-2302-1909 FCC ID: 2BB4J-WM09A IC: 31013-WM09A HVIN: MODUL 868MHZ IX G0M-2302-1909 FCC ID: 2BB4J-WM09A IC: 31013-WM09A HVIN: MODUL 868MHZ IX G0M-2302-1909

senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack IBAN: DE32840510101113012737 VAT Nr.: DE 199934786 Rico Röhner BIC: HELADEF1ILK Steuernummer: 156 126 00594 http://www.senTec-Elektronik.de Labelling Modul 868MHz IX 13.09.2023 . The label is located on the top of the shielding from the Modul_868MHz_IX. The Label size is 16,2mm x 15mm Information: 1. Software version 5. FCC ID 2. Module address 6. ISED ID 3. FCC mark 7. Production information as QR-Code 4. CE mark 8. Production information as plan text . The manufacturer, product name and the hardware release are printed on the backside of the module. 1 2 3 4 5 6 7 8 senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software -2- Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack Kto.: 1113012737 BLZ : 84051010 VAT Nr.: DE 199934786 Rico Röhner IBAN: DE32840510101113012737 Steuernummer: 156 126 00594 http://www.senTec-Elektronik.de picture Modul 868MHz IX topside

senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack IBAN: DE32840510101113012737 VAT Nr.: DE 199934786 Rico Röhner BIC: HELADEF1ILK Steuernummer: 156 126 00594 http://www.senTec-Elektronik.de Internal photos Modul868MHz_IX senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software - 2/3 - Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack Kto.: 1113012737 BLZ : 84051010 VAT Nr.: DE 199934786 Rico Röhner IBAN: DE32840510101113012737 Steuernummer: 156 118 01480 http://www.senTec-Elektronik.de senTec Elektronik GmbH Robert-Bosch-Ring 2 D-98693 Ilmenau Tel.: +49 (0)3677 / 689 37 - 0 Fax: +49 (0)3677 / 689 37 29 [email protected] Innovation durch Elektronik Sensorelektronik Systemlösungen Telemetrie Hardware Software - 3/3 - Bank: Sparkasse Arnstadt Ilmenau Register: Amtsgericht Jena HRB 304930 Geschäftsführer: Michael Binhack Kto.: 1113012737 BLZ : 84051010 VAT Nr.: DE 199934786 Rico Röhner IBAN: DE32840510101113012737 Steuernummer: 156 118 01480 http://www.senTec-Elektronik.de

Test Report No.: G0M-2302-1909-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 13 RF-EXPOSURE REPORT FCC 47 CFR Part 2.1091 ISED RSS-102 Maximum permissible exposure Report Reference No G0M-2302-1909-TFC091MP-V01 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Test Firm Designation Number: DE0008 ISED Testing Laboratory site: 3470A Applicant senTec Elektronik GmbH Address Robert-Bosch-Ring 2 98693 Ilmenau GERMANY Test Specification According to FCC/ISED rules Standard FCC 47 CFR 2.1091 ISED RSS-102 Non-Standard Test Method None Equipment under Test (EUT): Product Description Radio Modul 868MHz Model(s) Modul 868MHz IX Additional Model(s) None Brand Name(s) None Hardware Version(s) Release 1.x Software Version(s) Version 9.x FCC ID 2BB4J-WM09A IC 31013-WM09A Test Result PASSED Test Report No.: G0M-2302-1909-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 2 of 13 Possible test case verdicts: required by standard but not tested N/T not required by standard N/R test object does meet the requirement P(PASS) test object does not meet the requirement F(FAIL) Testing: Test Lab Temperature 20 °C - 30 °C Test Lab Humidity 25 % - 55 % Date of performance 2023-11-22 Date of receipt of test item 2023-08-31 Report: Compiled by Burkhard Pudell Created by (+ signature) (Responsible) Burkhard Pudell Approved by (+ signature) (Test Lab Engineer) Florian Voigt Date of Issue 2024-02-26 Total number of pages 13 General Remarks: The test results presented in this report relate only to the object tested. The results contained in this report reflect the results for this particular model and serial number. It is the responsibility of the manufacturer to ensure that all production models meet the intent of the requirements detailed within this report. This report shall not be reproduced, except in full, without the written approval of the Issuing testing laboratory. Additional Comments: None Test Report No.: G0M-2302-1909-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 13 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2024-02-26 Initial Release - Test Report No.: G0M-2302-1909-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 13 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EIRP Equivalent Isotropic Radiated Power EUT Equipment Under Test MPE Maximum Permissible Exposure Test Report No.: G0M-2302-1909-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 13 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Reference Documents ................................................................................................................................... 7 1.2 Power density radiation sources.................................................................................................................... 7 1.3 Field strength radiation sources .................................................................................................................... 7 1.4 Concurrent Sources ...................................................................................................................................... 7 2 Result Summary ................................................................................................................................. 8 3 RF-Exposure classification .............................................................................................................. 9 4 RF-Exposure limits .......................................................................................................................... 10 5 RF-Exposure Evaluation ................................................................................................................. 11 6 Single Source Evaluation Results - FCC ...................................................................................... 12 7 Single Source Evaluation Results - ISED ..................................................................................... 13 Test Report No.: G0M-2302-1909-TFC091MP-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 13 1 Equipment (Test Item) Under Test Description Radio Modul 868MHz Model Modul 868MHz IX Additional Model(s) None Brand Name(s) None Hardware Version(s) Release 1.x Software Version(s) Version 9.x PMN MODUL 868MHZ IX HVIN MODUL 868MHZ IX FVIN Version 9…
