2BB6YPSYNCC3Psync Camera Genie S

审核 批准 2023.05.10 V1.0 首次创建 2023.08.28 V2.0 首次创建 RVI说明书 曹佳丽 85*65mm PANTONE 432C+ 风琴折 RVIC1- KSZP01 V2.0 RVIC1 IN THE BOX SETUP Psync Camera Genie S × 1 FRONTBACK USB Cable × 1 Power Adapter × 1 Quick Start Guide × 1 1 5 2 3 6 7 4 Lens 1 Microphone 2 LED Spotlight 3 Speaker 4 Light Indicators 5 SETUP Button 6 Power Input 7 2 1 3 Follow the on-screen app instructions. 4 Press and hold the setup button for two seconds. Wait for voice prompt Tap to select cameraFollow the instructionsTap“ ” Scan the QR code below to download Psync app and create an account. QUICK START GUIDE ready to connect Disclaimer: The products, accessories, user interfaces, etc. illustrated in this guide are intended for reference only. Due to product updates, the actual products and illustrations in this guide may vary. Connect the camera to a power outlet. Wait 15 seconds Light indicator will flash red and the camera will open to an upright position. LIGHT INDICATORS DURING INSTALLATION FCC WARNING: FCC RADIATION EXPOSURE STATEMENT: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with part 15 of the FCC Rules. (Aperation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio / TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 8 inches between the radiator and your body. This transmitter must be co-located or operating in conjunction with any other antenna or transmitter. ISED RSS WARNING: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. ISED RADIATION EXPOSURE STATEMENT: NEED HELP? This equipment complies with ISED RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 8 inches between the radiator and your body. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Only use the power supply provided. *The power adapter provided with this product is for indoor use only. Operating Temperature: 32°F ~ 104°F (0ºC ~ 40ºC) Solid red light The device is powered on and initializing. Flashing red light The device is ready to connect and Bluetooth is ready to pair. Flashing blue light Bluetooth is connected and the device is connecting to the network. Solid blue light The device is working properly. LIGHT INDICATORS AFTER SETUP Flashing blue light The device is connecting to the network and server. Solid blue light The device is working properly. Contact our support team [email protected] Visit our support page: https://www.psynclabs.com/pages/support

<PsyncLabs,Inc.> <PsyncLabs,Inc.> <1825AllisonWay,SanJose,California95132> FederalCommunicationCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA <2023/08/02> AttestationStatementaccordingto2.911(d)(5)(i)and2.911(d)(5)(ii) FCCID:<2BB6YPSYNCC3> TOWHOMITMAYCONCERN: Herebywecertifythattheequipmentforwhichauthorizationissoughtisnot“covered” equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903 oftheFCCrules. Furtherwecertifythat,asofthedateofthefilingoftheapplication,<PsyncLabs,Inc.>is notidentifiedontheCoveredListasanentityproducing“covered”equipment. Sincerely, _______________ (signature&companystamp) <PsyncLabs,Inc.> FRN:0034233522 Address:1825AllisonWay,SanJose,California95132 ContactPerson:PEIKAIHOU Tel.:6509666777 Email:[email protected]

<PsyncLabs,Inc.> <PsyncLabs,Inc.> <1825AllisonWay,SanJose,California95132> FederalCommunicationCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA <2023/08/02> AttestationStatementaccordingto2.911(d)(7) FCCID:<2BB6YPSYNCC3> TOWHOMITMAYCONCERN: We,PsyncLabs,Inc.,IncdesignateourselvestoactasU.S.agentforservice ofprocess. PsyncLabs,Inc.,IncherebyacknowledgestheobligationoftheU.S.agent forserviceofprocess.FurtherPsyncLabs,Inc.,Incacceptstomaintainan agentfornolessthanoneyearafterthegranteehasterminatedallmarketingand importationortheconclusionofanyCommission-relatedproceedinginvolvingthe equipment. Sincerely (Signed) CompanyName:PsyncLabs,Inc. FRN:0034233522 Address:1825AllisonWay,SanJose,California95132 ContactPerson:PEIKAIHOU Tel.:6509666777 Email:[email protected]

DATE:Aug.07,2023 PsyncLabs,Inc. 1825AllisonWay,SanJose,California95132 Attn:DirectorofCertification AuthoritytoActasAgent Onourbehalf,Iappointbelowcompanyandperson: NameAaronZhang PositionManager CompanyNameTianjinDongdianTestingServiceCo.,Ltd. AddressBuildingD-1,No.19,WeisiRoad,MicroelectronicsIndustrialPark DevelopmentArea,Tianjin,China. Tel/Fax Tel:+86-22-58038033 [email protected] toactasouragentinthepreparationofthisapplicationforequipmentcertification.I certifythatsubmitteddocumentsproperlydescribethedeviceorsystemforwhich equipmentcertificationissought.Ialsocertifythateachunitmanufactured,importedor marketed,asdefinedintheFederalCommunicationsCommission’sregulationswill haveaffixedtoitalabelidenticaltothatsubmittedforapprovalwiththisapplication. Forinstanceswhereourauthorizedagentsignstheapplicationforcertificationonour behalf,Iacknowledgethatallresponsibilityforcomplyingwiththetermsandconditions forcertification,asspecifiedbycetecomadvancedGmbH,stillresideswith: Applicantname PsyncLabs,Inc. Address 1825AllisonWay,SanJose,California95132 Yourssincerely, Signatory NamePEIKAIHOU PositionCEO CompanyNamePsyncLabs,Inc. Address1825AllisonWay,SanJose,California95132 Tel/Fax 6509666777 [email protected]

CONFIDENTIALITYREQUEST forCertificationServiceinUSA FederalCommunicationCommission EquipmentAuthorizationDivision,ApplicationProcessingBranch 7435OaklandMillsRoad Columbia,MD21048 <08/07/2023> TOWHOMITMAYCONCERN PursuanttoParagraphs§0.457and0.459oftheCommission’sRules(47C.F.R.)and Section§552(b)(4)oftheFreedomofInformationAct,werequestsconfidentialityforthe followingproducts: FCCIDModelname 2BB6YPSYNCC3PSYNCC3 Fortheproductstatedabove,werequestthatthefollowinginformationbeheld confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term ConfidentialityDays ExternalPhotos180days InternalPhotos180days BlockDiagram Schematics TestSetupPhotos180days User’sManual180days PartsList TuneUp OperationalDescriptions Thelong-termconfidentialityexhibitscontainourtradesecretsandproprietary informationthatcouldbeofbenefittoourcompetitors. Theshort-termconfidentialityonthebasisofensuringthatbusinesssensitive informationremainsconfidentialuntiltheactualmarketingofournewdevice. Ifyouhaveanyquestions,pleasefeelfreetocontactmeattheaddressshownbelow. Sincerely, (Signed) Name:PEIKAIHOU Company:PsyncLabs,Inc. Address:1825AllisonWay,SanJose,California95132 Tel.:6509666777 Email:[email protected]

<PsyncLabs,Inc.> <1825AllisonWay,SanJose,California95132> Date:2023/08/07 FCCID:2BB6YPSYNCC3 ModelNumber:PSYNCC3 To: FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD ToWhomItMayConcern, We,PsyncLabs,Inc.declarethatthisEUT(FCCID:2BB6YPSYNCC3)doesn’t haveAdHocmodefunctionon“on-US/Canadafrequencies”.Inaddition.The frequencyselectionfeatureisdisabledbyfirmwarefordevicesmarkedtothe US/Canada.ForDTSpartofthisdevice,onlychannels1-11willbeusedin NorthAmerica,Countrycodeselectionisdisabled. Shouldyouhaveanyquestionsorcommentsregardingthismatter,pleasehave mybestattention. Sincerely, (Signed) Name/Title:PEIKAIHOU/CEO Company:PsyncLabs,Inc. Address:1825AllisonWay,SanJose,California95132 <PsyncLabs,Inc.> <1825AllisonWay,SanJose,California95132> Tel:6509666777 Fax: E-Mail:[email protected]

Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 1 of 13 APPENDIXES Equipment under Test: Psync Camera Genie S Model Number: PSYNCC3 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 2 of 13 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 3 of 13 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 4 of 13

Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 5 of 13 BT/WIFI Antenna Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 6 of 13 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 7 of 13 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 8 of 13 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 9 of 13 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 10 of 13 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 11 of 13 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 12 of 13 Tianjin Dongdian Testing Service Co., Ltd. Report No.: DDT-B23070506-2E Page 13 of 13 END OF APPENDIXES

Tianjin Dongdian Testing Service Co., Ltd Report No.:DDT-B23070506-2E03 Page 1 of 8 RF EXPOSURE REPORT Report No.: DDT-B23070506-2E03 Issued By: Tianjin Dongdian Testing Service Co., Ltd. Address: Building D-1, No. 19, Weisi Road, Microelectronics Industrial Park Development Area, Tianjin, China. Tel: +86-22-58038033, E-mail: [email protected], http://www.ddttest.com Applicant : Psync Labs, Inc. Address : 1825 Allison Way, San Jose, California 95132 Equipment under Test : Psync Camera Genie S Model No. : PSYNCC3 Trade Mark : psync FCC ID : 2BB6YPSYNCC3 Manufacturer : Psync Labs, Inc. Address : 1825 Allison Way, San Jose, California 95132 Tianjin Dongdian Testing Service Co., Ltd Report No.:DDT-B23070506-2E03 Page 2 of 8 TABLE OF CONTENTS Test report declares......................................................................................................3 1. General information ...................................................................................................... 5 1.1. Description of Equipment .............................................................................................. 5 1.2. Assess laboratory ......................................................................................................... 6 2. RF Exposure Evaluation ............................................................................................... 7 2.1. Requirement ................................................................................................................. 7 2.2. Calculation method ....................................................................................................... 7 2.3. Estimation result ........................................................................................................... 8 Tianjin Dongdian Testing Service Co., Ltd Report No.:DDT-B23070506-2E03 Page 3 of 8 TEST REPORT DECLARE Standard Used: KDB447498 D01 General RF Exposure Guidance v06 We Declare: The equipment described above is assessed by Tianjin Dongdian Testing Service Co., Ltd and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Tianjin Dongdian Testing Service Co., Ltd is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No: DDT-B23070506-2E03 Date of Receipt: Jul. 14, 2023 Date of Test: Jul. 14, 2023 ~ Jul. 27, 2023 Prepared By: Approved By: ___________________ _____________________ Sunny Zhang/Engineer Aaron Zhang/RF Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Tianjin Dongdian Testing Service Co., Ltd. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. Government. Applicant : Psync Labs, Inc. Address : 1825 Allison Way, San Jose, California 95132 Equipment under Test : Psync Camera Genie S Model No. : PSYNCC3 Trade mark : psync Manufacturer : Psync Labs, Inc. Address : 1825 Allison Way, San Jose, California 95132 Tianjin Dongdian Testing Service Co., Ltd Report No.:DDT-B23070506-2E03 Page 4 of 8 Revision History Rev. Revisions Issue Date Revised By --- Initial issue Jul. 27, 2023 Tianjin Dongdian Testing Service Co., Ltd Report No.:DDT-B23070506-2E03 Page 5 of 8 1. General information 1.1. Description of Equipment EUT* Name : Psync Camera Genie S Model Number : PSYNCC3 EUT function description : Please reference user manual of this device Power Supply : DC 5V by ac/dc adapter Radio Specification : IEEE 802.11b/g/n Operation frequency : IEEE 802.11b: 2412MHz-2462MHz IEEE 802.11g: 2412MHz-2462MHz IEEE 802.11n HT20: 2412MHz-2462MHz Modulation : IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n HT20: OFDM (64QAM, 16QAM, QPSK, BPSK) Data rate : IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n HT20: MCS0~MCS7 Antenna Type : FPC antenna with IPEX connector, maximum PK gain: 5.83dBi Exposure category : General population/uncontrolled environment Device Type : Mobile Device Target power and tolerance : BLE 17±2dBm， 2.4G WIFI 22±2dBm EUT* Name : Psync Cam3 Model Number : PSYNCC3 EUT Function Description : Please reference user manual of this device Power Supply : DC 5V by ac/dc adapter Radio Specification : Bluetooth V5.0 Operation Frequency : 2402 MHz - 2480 MHz Modulation : GFSK Data Rate : 1 Mbps Antenna Type : FPC antenna with IPEX connector, maximum PK gain: 5.83dBi Tianjin Dongdian Testing Service Co., Ltd Report No.:DDT-B23070506-2E03 Page 6 of 8 1.2. Assess laboratory Tianjin Dongdian Testing Service Co., Ltd. Address: Building D-1, No. 19, Weisi Road, Microelectronics Industrial Park Development Area, Tianjin, China. Tel: +86-22-58038033, http://www.ddttest.com, Email: [email protected] NVLAP (National Voluntary Laboratory Accreditation Program) CODE: 500036-0 CNAS (China National Accreditation Service for Conformity Assessment) CODE: L13402 FCC Designation Number: CN5004; FCC Test Firm Registration Number: 368676 ISED (Innovation, Science and Economic Development Canada) Company Number: 27768 Conformity Assessment Body Identifier: CN0125 VCCI Facility Registration Number: C-20089, T-20093, R-20125, G-20122 Tianjin Dongdian Testing Service Co., Ltd Report No.:DDT-B23070506-2E03 Page 7 of 8 2. RF Exposure Evaluation 2.1. Requirement Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall co…
