2BB7K-SL2001smart lock

Anona Holo User Manual 01 Please read this manual carefully before using the product and keep it in a safe place. Smart lockPlateAdapter × 4 AA battery × 4User manualAdhesive tape Product overview Package contents 02 Product overview Smart lock Reset button Wing latch Indicator light Thumb turn Front plate Battery compartment 03 1. Remove the front plate, pull the thumb turn, and install the batteries with the correct polarity. 2. Place back the front plate. Installing batteries 04 Product usage DescriptionIndicator light status Starting upFlashing green Awaiting binding/ Wi-Fi connectingFlashing blue Bound/Connected successfullySolid green OTA updatingFlashing blue Low batterySolid red DescriptionBuzzer status Abnormal statusBuzzer beeping DescriptionButton operation Entering binding mode Press and hold the reset button for about 5 seconds 05 1. Download and install the Anona app by scanning the QR code or finding “Anona” in the app store. Note: A mobile phone with Android 5.0 or iOS 12.0 or later is required. 2. Open the app and sign in your Anona account. Tap icon "+" in the right upper corner and then follow the on-screen instructions to complete the binding, Wi-Fi connecting and calibrating process. . Binding smart lock Notes: • This product only supports 2.4GHz Wi-Fi networks, 5GHz Wi-Fi networks are not supported. • Before binding, ensure your phone is connected to the Internet and the Bluetooth is enabled. Also ensure the smart lock is in binding mode with indicator light flashing blue. 06 Compatible doors This smart lock is only compatible with the single cylinder deadbolt. 07 Installing smart lock Original screwsTailpiece Bolt Select correct adapter Original thumb turn ① ② 08 Cautions • Temperature for normal use of this product is-10°C to 55°C and temperature for storage of this product is -30°C to 70°C. Do not use or store this product in the environment at too high or too low temperature. • This product is not waterproof. Do not expose the product to any liquid. Do not use the product in a humid environment. • Illustrations of the product, accessories, and user interface in the user manual are for reference purposes only. The actual product and functions may vary due to product enhancements. Specifications Product: Smart Lock Model: SL2001 Item dimensions: 75mm × 75mm × 63mm Input: 4 × AA battery Wireless connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4GHz, Bluetooth® 5.4 09 FCC Caution. 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 10 -Consult the dealer or an experienced radio/TV technician for help. RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC ID: 2BB7K-SL2001 ISED compliance statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada's licence- exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. ISED Radiation Exposure statement This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. Cet équipement est conforme aux limites d'exposition aux radiations IC V1.0-20230822 Service: [email protected] For further information, please go to www.anonasecurity.com Manufacturer: Anona Security Technology Limited Address: 8 The Green,Ste A Dover DE 19901, America CNR-102 établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre corps. IC: 30992-SL2001 The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Anona Security T…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Anona Security Technology Limited. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 09-08-2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2BB7K-SL2001 [Anona Security Technology Limited.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) mingming zhang Rev 1/26/2023 Anona Security Technology Limited. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 09-08-2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2BB7K-SL2001 [Anona Security Technology Limited.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) mingming zhang

Anona Security Technology Limited. 8 The Green,Ste A Dover DE 19901，America Dover United States Date: 09-08-2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2BB7K-SL2001 Applicant FRN: 0034030932 US Agent – Attestation Statement / Part 2.911(d)(7) Anona Security Technology Limited. certifies, that as of 08-28-2023, we have designated Anona Security Technology Limited. to accept service of process on our behalf for FCC ID: 2BB7K-SL2001. Anona Security Technology Limited., accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., o r the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Anona Security Technology Limited., accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Anona Security Technology Limited. for FCC ID: 2BB7K-SL2001. Designated Agent Information: Company Name: Anona Security Technology Limited. FRN: 0034030932 Address: 8 The Green,Ste A Dover DE 19901，America Contact Person: mingming zhang Phone: +86 15801822634 Email: [email protected] Sincerely, Company: Anona Security Technology Limited. Designated Agent: Anona Security Technology Limited. Company Representative: mingming zhang Designated Agent Representative: mingming zhang Signature: Signature:

Anona Security Technology Limited.. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2BB7K-SL2001 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description, Block Diagram Operation Description schematic diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. In accordance with sections 0.457 and 0.459 of CFR 47, Corsair Memory, Inc.. requests short- term Confidentiality of following sections of this application for a period of 180 days after grant is issued. Test setup photos External photos Internal photos User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which 70mai Co.,Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, 70mai Co.,Ltd. feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, mingming zhang Anona Security Technology Limited..

Anona Security Technology Limited.. Date: 2023-09-08 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2BB7K-SL2001 To Whom It May Concern: This letter is to ascertain that Anona Security Technology Limited.. EUT：smart lock MODEL No.: SL2001 Has been the units used for conducting FCC compliance testing, the SDoC part will be tested by EMTEK (SHENZHEN) CO., LTD. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature ： Client’s name / title ： mingming zhang Contact information / address: Anona Security Technology Limited.. /8 The Green,Ste A Dover DE 19901，America

Anona Security Technology Limited.. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023-09-08 SUBJECT: FCC Application for FCC ID: 2BB7K-SL2001 To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at EMTEK (SHENZHEN) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (SHENZHEN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, mingming zhang Anona Security Technology Limited..

Antenna

FCC ID : 2BB7K-SL2001 RF EXPOSURE EVALUATION According to KDB 447498 D01 v06 According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 ,If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. RF Exposure Information: The radiated output power of this device meets the limits of FCC/IC radio frequency exposure limits.This device should be operated with a minimum separation distance of 20cm (8 inches) between the equipment and a person's body. 11.2 Measurement Result Wifi 2.4G-- Antenna gain: 1.09 dBi modulation Channel Freq. (MHz) Measured power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 11b 2412 10.43 10 to 12 12 1.29 0.00405 1 2437 10.23 10 to 12 12 1.29 0.00405 1 2462 10.33 10 to 12 12 1.29 0.00405 1 11g 2412 13 12 to 14 14 1.29 0.00642 1 2437 13.14 12 to 14 14 1.29 0.00642 1 2462 13.56 12 to 14 14 1.29 0.00642 1 11n HT20 2412 10.29 10 to 12 12 1.29 0.00405 1 2437 10.65 10 to 12 12 1.29 0.00405 1 2462 10.26 10 to 12 12 1.29 0.00405 1 BLE-- Antenna gain: 1.09 dBi modulation Channel Freq. (MHz) Measured power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) BLE_1M 2402 2 1 to 2 2 1.29 0.00041 1 2440 1.61 1 to 2 2 1.29 0.00041 1 2480 1.84 1 to 2 2 1.29 0.00041 1 BLE_2M 2402 1.96 1 to 2 2 1.29 0.00041 1 2440 1.68 1 to 2 2 1.29 0.00041 1 2480 1.91 1 to 2 2 1.29 0.00041 1 Simultaneous Transmission Mode ∑max ratios Limit Results WIFI 2.4G+BLE 0.00683 1.0 PASS

Antenna specification Customer：Anona Project Name：SL2001 Report Number:000920913 Manufacturer：AnonaSecurity Technology Limited. Address：8 The Green,SteA Dover DE 19901，America Wireless connection creats unlimited possibilities Report version：Sep. 11th, 2023A0 Author：liubin 1 Record VersionReport dateRemark A02023.9.11Antenna specification A1 A2 A3 A4 A5 A6 A7 A8 A9 2 /12 Contents 1.Project Overview.................................................................................1 2.Equipment List .................................................................................2 3.Project picture and Testing Device ............................................................3 4.Test equipment .................................................................................4 5.Test program ....................................................................................5 6.Test program ....................................................................................6 7.Passive parameters ..............................................................................7 8.Efficiency and Gain ..............................................................................8 9.Active parameters ..............................................................................9 10.Contents .......................................................................................10 11.Thank You ....................................................................................11 3 /12 Prototype statusDebugging machine Device type Door lock Number of antennasWiFi/BT antenna Frequency band 2.4G WiFi Bluetooth Structural styleFPC+cable Environment adjustment No change Matching modificationNo change Project Overview 4 /12 Equipment List Equipments Items Total Quantity Quantity for Shanghai R&D Quantity for Shenzhen R&D Quantity for ChongQing R&D OTA chamber10451 5G Tester （ SP9500-CTS ） 3111 R&S Tester （ high configuration CMW500 ） 6321 Japan Anritsu Tester （ Dual Channel 8820 ） 422-- NB-IoTTester (SP8315)3111 Agilent Tester （ 8960 ） 944-- Agilent Network Analyzer （ E5062A ） 7331 Agilent Network Analyzer （ E5071C8.5GHZ ) 11551 Agilent Network Analyzer （ E5071B8.5GHZ ) 7331 R&S Network Analyzer （ ZND ） 9441 R&S Network Analyzer （ ZVB ） 3111 OTA head hand / ear hand / arm hand 5221 GPS/WIFIactive test equipment5221 The industry's top64 sensorsOTA chamber Frequency range: 400MHz-11GHz Device Llimitation: 2M Load-bearing limitation:100KG 5 /12 Project picture 6 /12 Test equipment 7 /12 WiFi/Bluetooth test equipment： ROHDE&SCHWARZCMW-500 Test program 8 /12 Using the darkroom testing software, add WiFi and Bluetooth frequency bands to the testing software, select the corresponding comprehensive tester, set the testing mode, angle, and rate, and connect the tested object to the hot spot emitted by the comprehensive tester before measurement Passive parameters S11 9 /12 Efficiency and Gain 10 /12 Freq.EffiEffiMaxGain (MHz)(%)(dB)dBi 2400 38.64-4.13 -0.35 2410 39.12-4.08 -0.46 2420 40.75-3.90 -0.32 2430 41.48-3.82 0.31 2440 42.55-3.71 0.15 2450 41.93-3.77 0.19 2460 42.36-3.73 1.01 2470 41.4-3.83 1.09 2480 40.83-3.89 0.36 2490 40.27-3.95 1.27 2500 39.54-4.03 0.64 11 /12 Active parameters BandChannel Conducted (dBm) TRPTIS 2.4G 802.11B- 119.16-83.13 719.44-83.55 1318.36-82.51 12 /12 Directional pattern Thank You Shanghai R&D Center: 1F, Building 4, No.99, Lane 215, Gaoguang Road, Qingpu District, Shanghai, 201799, PRC Shenzhen R&D Center: Room 405, Jinke Building, No.8, Qiongyu Road, Nanshan District, Shenzhen, 518057, PRC ChongQing R&D Center: 1F, ARM Ecological Industrial Park, 19 East Datugu Road, Xiantao, Yubei District, Chongqing,401120, PRC Huizhou Factory: 4-5F, No.1, Central Village Road, Longhu Industrial Zone, Shuikou Town, Huicheng District, Huizhou, 516255, PRC TEL：021-60835368 E-mail：[email protected] www.sunnyway-iot.com 13 /12

Report No. ENS2305290073W00201R Page 1 of 49 Ver.1.0 TEST REPORT Product Name ： smart lock Model Number ： SL2001 FCC ID ： 2BB7K-SL2001 Prepared for : Anona Security Technology Limited. Address : 8 The Green,Ste A Dover DE 19901，America Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2305290073W00201R Date(s) of Tests : May 30, 2023 to August 25, 2023 Date of issue : August 28, 2023 Report No. ENS2305290073W00201R Page 2 of 49 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ........................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION .......................................................................................................... 5 3 SUMMARY OF TEST RESULT............................................................................................................... 6 4 TEST METHODOLOGY .......................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS................................................................... 7 4.2 MEASUREMENT EQUIPMENT USED ............................................................................................. 7 4.3 DESCRIPTION OF TEST MODES ................................................................................................... 8 5 FACILITIES AND ACCREDITATIONS .................................................................................................... 9 5.1 FACILITIES ....................................................................................................................................... 9 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ........................................................................ 9 6 TEST SYSTEM UNCERTAINTY ........................................................................................................... 10 7 SETUP OF EQUIPMENT UNDER TEST .............................................................................................. 11 7.1 RADIO FREQUENCY TEST SETUP 1 ........................................................................................... 11 7.2 RADIO FREQUENCY TEST SETUP 2 ........................................................................................... 11 7.3 CONDUCTED EMISSION TEST SETUP ....................................................................................... 13 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ........................................................... 14 7.5 SUPPORT EQUIPMENT ................................................................................................................ 14 8 TEST REQUIREMENTS ....................................................................................................................... 15 8.1 DTS 6DB BANDWIDTH .................................................................................................................. 15 8.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER ...................................................................... 18 8.3 MAXIMUM POWER SPECTRAL DENSITY .................................................................................... 21 8.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS .................................... 24 8.5 RADIATED SPURIOUS EMISSION ................................................................................................ 34 8.6 CONDUCTED EMISSIONS TEST .................................................................................................. 47 8.7 ANTENNA APPLICATION ............................................................................................................... 48 Report No. ENS2305290073W00201R Page 3 of 49 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Anona Security Technology Limited. Address : 8 The Green,Ste A Dover DE 19901，America Manufacturer : Anona Security Technology Limited. Address : 8 The Green,Ste A Dover DE 19901，America EUT : smart lock Model Name : SL2001 Trademark : Anona Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2 , Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report Date of Test : May 30, 2023 to August 25, 2023 Prepared by : Una Yu/Editor Reviewer : Joe Xia/Supervisor Approved & Authorized Signer : Lisa Wang/Manager Report No. ENS2305290073W00201R Page 4 of 49 Ver.1.0 Modified Information Version Report No. Revision Date Summary Ver.1.0 ENS2305290073W00201R / Original Report Report No. ENS2305290073W00201R Page 5 of 49 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Product smart lock Model Number SL2001 Device Type BLE V5.3 Data Rate : 1Mbps 2Mbps Modulation: GFSK Operating Frequency Range: 2402-2480MHz Number of Channels: 40 Channels Antenna Type: FPC Antenna Antenna Gain: 1.09 dBi Power Supply DC 6V Temperature Range: -10°C ~ 55°C Note: for more details, please refer to the user’s manual of the EUT. Report No. ENS2305290073W00201R Page 6 of 49 Ver.1.0 3 SUMMARY OF TEST RESULT FCC Part Clause Test Parameter Verdict Remark 15.247(a)(2) DTS (6dB) Bandwidth PASS 15.247(b)(3) Maximum Peak Conducted Output Power PASS 15.247(e) Maximum Power Spectral Density Level PASS 15.247(d) Unwanted Emission Into Non-Restricted Frequency Bands PASS 15.247(d) 15.209 Unwanted Emission Into Restricted Frequency Bands (conducted) PASS 15.247(d) 15.209 Radiated Spurious Emission PAS…

Text truncated - open the document above for the full version.

Report No. ENS2305290073W00201R Page 1 of 55 Ver.1.0 TEST REPORT Product Name ： smart lock Model Number ： SL2001 FCC ID ： 2BB7K-SL2001 Prepared for : Anona Security Technology Limited. Address : 8 The Green,Ste A Dover DE 19901，America Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone,Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2305290073W00201R Date(s) of Tests : May 30, 2023 to August 25, 2023 Date of issue : August 28, 2023 Report No. ENS2305290073W00201R Page 2 of 55 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ...................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION .................................................................................................................... 4 3 SUMMARY OF TEST RESULT ........................................................................................................................... 5 4 TEST METHODOLOGY ...................................................................................................................................... 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................................ 6 4.2 MEASUREMENT EQUIPMENT USED ....................................................................................................... 6 4.3 DESCRIPTION OF TEST MODES ................................................................................................................ 8 5 FACILITIES AND ACCREDITATIONS ............................................................................................................. 9 5.1 FACILITIES.................................................................................................................................................... 9 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................ 9 6 TEST SYSTEM UNCERTAINTY ...................................................................................................................... 10 7 SETUP OF EQUIPMENT UNDER TEST ......................................................................................................... 11 7.1 RADIO FREQUENCY TEST SETUP 1 ......................................................................................................... 11 7.2 RADIO FREQUENCY TEST SETUP 2 ......................................................................................................... 11 7.3 CONDUCTED EMISSION TEST SETUP ................................................................................................... 12 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM .................................................................... 13 7.5 SUPPORT EQUIPMENT .............................................................................................................................. 13 8 TEST REQUIREMENTS .................................................................................................................................... 14 8.1 DTS (6DB) BANDWIDTH ........................................................................................................................... 14 8.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER .............................................................................. 15 8.3 MAXIMUM POWER SPECTRAL DENSITY ............................................................................................. 23 8.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS ............................................ 27 8.5 RADIATED SPURIOUS EMISSION ........................................................................................................... 41 8.6 CONDUCTED EMISSIONS TEST .............................................................................................................. 53 8.7 ANTENNA APPLICATION ......................................................................................................................... 54 Report No. ENS2305290073W00201R Page 3 of 55 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Anona Security Technology Limited. Address : 8 The Green,Ste A Dover DE 19901，America Manufacturer : Anona Security Technology Limited. Address : 8 The Green,Ste A Dover DE 19901，America EUT : smart lock Model Name : SL2001 Trademark : Anona Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK (SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. Date of Test : May 30, 2023 to August 25, 2023 Prepared by : Una Yu /Editor Reviewer : Joe Xia /Supervisor Approved & Authorized Signer : Lisa Wang/Manager Report No. ENS2305290073W00201R Page 4 of 55 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Note: for more details, please refer to the User’s manual of the EUT. Characteristics Description Product smart lock Model Number SL2001 Sample 1# IEEE 802.11 WLAN Mode Supported 802.11b 802.11g 802.11n(20MHz channel bandwidth) Data Rate 802.11 b:1,2,5.5,11Mbps; 802.11 g:6,9,12,18,24,36,48,54Mbps; 802.11n(HT20): up to 72.2Mbps; Modulation DSSS with DBPSK/DQPSK/CCK for 802.11b; OFDM with BPSK/QPSK/16QAM/64QAM for 802…

Text truncated - open the document above for the full version.
