2BB7M-PUO-001Bluetooth device to control hotel electronic locks with smartphone

page 1 Technical Data Bluetooth module for mobile key in hotel locks. Technical Informa�on Bluetooth Low Energy Interface Technology: Frequency Range:2.4 GHz ~ 2.5 GHz (2400M- 2483.5M) Transmission Power: 5 dBm Receiver Sens�v�:-97dBm Power Requirements Power Supply:Entry: 4-9 V DC Consump�on:<50 mA + Output driver controller consump�on (depends on device a�ached) Environmental Cond�ons Opera�ng Tempera�re – From -10°C to +70°C – Humid� – From 5% to 85% without condensa�on cer�fica�on Direc�ve 2014/53/UE - Radio Electric equipment 2011/65/UE - ROHS 2 Reference Standards EN 301489-1 V2.2.3 EN 55035:2017+A11:2020 EN 301489-1 V3.1.1 EN 50581:2012 EN 62368-1 EN ISO 7010:2020 EN 55032:2016 Safe� Informa�on Please read this important safe� informa�on before you use the device. It contains general safe� informa�on for devices and may include content that does not apply to your device. Follow the warning and cau�on informa�on to prevent injury to yourself or others and prevent damage to your device. Descrip�ons are based on the default device. Some content may di�er from your device depending on the device model, lock, or device func�on. Model: Operto Boost Plus IEEE 802.15.1 DTS GFSK page 2 WARNING – Any external power supply used with the device shall comply with relevant regula�ons and standards applicable in the country of intended use. – The power supply should provide 4-9V DC and a minimum rated current of 50mA. – Do not touch the device, power cords, plugs, or connectors with wet hands or other damp body parts. – Do not directly connect the power cable pos�ve and nega�ve terminals. – Do not drop the device or subject it to excessive impact. – Do not expose this product to water or mois�re, and do not place it on a conduc�ve surface while in opera�on. – Do not store your device near or in heaters, microwaves, hot cooking equipment, or high-pressure containers. – Do not expose this product to heat from any source; it is designed for reliable opera�on at average room tempera�res. – Do not expose the board to high-intens� light sources (e.g., xenon flash or laser). – Take care while handling this product to avoid mechanical or electrical damage to the printed circuit board and connectors. – Avoid handling this product while it is powered. – Only handle by the edges to minimize the risk of electrosta�c discharge damage. – Do not use or store your device in areas a high concentra�ons of dust or airborne materials. – Any peripheral or equipment used with the device should comply with relevant standards for the country of use and be marked accordingly to ensure that safe� and performance requirements are met. Model: Operto Boost Classic page 3 Installa�on Warnings – Do not change the wire that comes with the device. – Use gloves to manipulate the board to minimize the risk of ESD. – Do not force the board into holes or �ght spaces. – Do not bend the wires excessively. – Do not force the connectors in their receptacles. – When the installa�on is finished, before closing the door, check that it works with both the new and old ones. And make sure that it opens appropriately to prevent the door from closing and not be able to be opened. This step is essen�al for locks that do not have a mechanical opening system (physical key). – Make sure that the lock is on �me and that the se�ings are correct. – When closing the lock and installing it on the door, ensure that no wires are pinched or at odd angles. And that none of the cables are damaged or have any defect in the insula�ng cover. – Do not install any device whose model does not correspond to the lock on which it is to be installed. Do not use wiring whose model does not fit the lock on which it is installed. – During installa�on, it is recommended to check and measure the lock’s ba�ery where it is being performed. If the charge is moderately low, it is recommended to replace the ba�ery. – When installing the device, check that the ba�eries do not heat up. If so, disconnect the device, check that the installa�on has been done correctly, check the wiring. If this s�ll occurs, replace the device. – When reinstalling the lock, do not �ghten the screws with excessive force. It may cause mechanical problems and the cranks to jam. – When uninstalling the lock, be careful with the wiring (in some locks, they are hidden), and when disassembling, do it slowly and make sure that all wires are disconnected. Bluetooth module for mobile key in hotel locks. Model: Operto Boost Plus page 4 Be sure that the power connec�on (ba�ery) is first connected to the Operto board and then connect the power wire of the Operto board to the lock itself, not the other way around. Do Not Connect Connec�ng Power Do not connect the power wire of the Operto board to the lock and then connect the ba�ery wires to the Operto board. It may cause a deconfigura�on of the lock. If this happens, you have to reconfigure the lock following my lock manufac�rer instruc�ons for that. ConceptDescrip�on Bluetooth Low Energy Interface Technology Technology2.4 GHz ~ 2.5 GHz (2400M- 2483.5M) Transmission Power Receiver Sens�v�-97dBm Physical Fea�res Dimensions33 × 42 × 8 mm (without wires) Weight150 grams Power Requirements Power SupplyEntry: 4-9 V DC Consump�on <50 mA + Output driver controller consump�on (depends on device a�ached) Environmental Cond�ons Opera�ng Tempera�reFrom -10°C to +70°C Humid�From 5% to 85% without condensa�on Fea�reMinMaxUnit Input Voltage-0.312V Output Current01.8A Junc�on tempera�re range-4085°C Storage tempera�re range-40150°C IEEE 802.15.1 (DTS) +5 dBm (GFSK) page 5 Bluetooth module for mobile key in hotel locks. Safe� Classifica�on The current IP is IP21. It is protected against finger touches and protected from damage due to any build-up of mois�re on surfaces that contact the air. Safe� Cer�ficates (audits) This device has passed the secur� inspec�on of the following companies: – PROSEGUR – S21SEC Mini Installa�on Guide Before installing, be sure you have the necessar…

Text truncated - open the document above for the full version.

C566091_X23_Ed2 1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: VR Scheduler, LLC FRN: 0034018200 Grantee code: 2BB7L Contact Name: Juan Jesus Pinuaga Cascales Address: 520 Kirkland Way, STE 400, Kirkland, Washington, 98033-6256, United States Telephone: +1-844-517-3589 Email: [email protected] This letter is to confirm that the US Agent for Service of Process accepts responsibility to act as a local representative on behalf of Lock Up Smart Doors S.L. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Applicant: Company name: Lock Up Smart Doors S.L. Product Description: Wireless module to add BLE capabilities to hotel locks Grantee code: 2BB7M FCC ID: 2BB7M-PUO-001 Contact Name: Juan Jesus Pinuaga Cascales Address: Calle Escritor Jeronimo Tristante, N10, 3B, 30100, Murcia, Spain Telephone No: +34 649163982 Email: [email protected] The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/07/10 Applicant’s Name: Juan Jesus Pinuaga Cascales US Agent’s Name: Steve Davis Title: Hardware Director Title: CEO Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Lock Up Smart Doors S.L. Grantee code: 2BB7M FCC ID: 2BB7M-PUO-001 Contact Name: Juan Jesus Pinuaga Cascales Address: Calle Escritor Jeronimo Tristante, N10, 3B, 30100, Murcia, Spain Telephone No: +34 649163982 Fax No: Email: [email protected] i. Lock Up Smart Doors S.L. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. Lock Up Smart Doors S.L. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Lock Up Smart Doors S.L. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 2023/July/10 Applicant’s Name: Juan Jesus Pinuaga Cascales Title: Hardware Director Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Lock Up Smart Doors S.L. Address: Calle Escritor Jeronimo Tristante, N10, 3B, 30100, Murcia, Spain Product Name: Boost Plus Model Number: PUO-001 FCC Identifier: 2BB7M-PUO-001 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Juan Jesus Pinuaga Cascales Date: July 10th 202 Title: Hardware Director Signature of applicant:

C5266091_X10_Ed.2 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: July 10 th 2023 Subject: Request for Confidentiality FCC ID: 2BB7M-PUO-001 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☒ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☒ User’s Manual ☐ NOTE 1 ☒ Internal Photos ☐ NOTE 1 ☒ Parts List / Tune Up ☒ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, C5266091_X10_Ed.2 1/1 Signature: Name: Juan Jesus Pinuaga Cascales Title: Hardware Director

C5266091_X9_Ed.2 1/1 Modular Transmitter Approval Request Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Company name: Lock Up Smart Doors S.L. FCC ID: 2BB7M-PUO-001 Gentlemen, In accordance with 47CFR 15.212 Modular Transmitters and KDB 996369 D01 ‘Module Certification Guide v01r04’. FCC ID 2BB7M-PUO-001 has been examined against the following requirements. Items to be covered by Single modular transmitters. Requirement per 15.212 and KDB 996369 D01 ‘Modular Certification Guide v02 Explanation from Grantee (do not write yes/no, but explain why product complies/how it is achieved) 1. The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly No, It’s not shielded. 2. The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal Yes, all inputs to the modules are buffered through logic or microprocessor inputs. 3. The module must contain power supply regulation on the module Yes, a low drop out regulator is used for modular power supply regulation. 4. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) Yes, device is equipped with integral antenna. 5. The module must demonstrate compliance in a stand- alone configuration Yes, distance between modular and all AEs are bigger than 10cm. 6. The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements) Yes, the modular has a permanent fixed label. 7. The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee Yes, the module complies with all specific rules applicable to the transmitter including all the conditions prodivded in installation instructions. Refer to test reports and user manual. 8. The module must comply with RF exposure requirements Yes, Transmitter meets MPE. Refer to MPE report. C5266091_X9_Ed.2 1/1 A limited modular approval (LMA) may be granted for single or split modular transmitters that comply partially with requirements above. Name: Juan Jesus Pinuaga Cascales Date: 19/12/2023 Title: Hardware Director Signature of applicant

OPERTO BOOST PLUS FCC ID: 2BB7M-PUO-001 FCC ID: 2BB7M-PUO-001 INTERNAL AND EXTERNAL PHOTOS OPERTO BOOST PLUS FCC ID: 2BB7M-PUO-001 OPERTO BOOST PLUS FCC ID: 2BB7M-PUO-001 OPERTO BOOST PLUS FCC ID: 2BB7M-PUO-001 OPERTO BOOST PLUS FCC ID: 2BB7M-PUO-001

Artwork: Locationondevice:

OPERTO BOOST PLUS FCC ID: 2BB7M-PUO-001 FCC ID: 2BB7M-PUO-001 INTERNAL AND EXTERNAL PHOTOS OPERTO BOOST PLUS FCC ID: 2BB7M-PUO-001 OPERTO BOOST PLUS FCC ID: 2BB7M-PUO-001 OPERTO BOOST PLUS FCC ID: 2BB7M-PUO-001 OPERTO BOOST PLUS FCC ID: 2BB7M-PUO-001

The results refer only and exclusively to the sample, product or material delivered for testing, and tested under conditions stipulated in this document. The equipment has been tested under conditions stipulated by standard(s) quoted in this document. This document will not be reproduced otherwise than in full. This is the first page of the document, which consists of 10 pages. LGAI Technological center, S.A. Inscrita en el Registro Mercantil de Barcelona, Tomo 35.803, Folio1, Hoja NºB-266.627 Inscripción 1ª. C.I.F. A-63207492 LGAI Technological Center, S.A. (APPLUS) Campus de la UAB. Ronda de la Font del Carme, s/n. 08193 Bellaterra (Barcelona) (Spain) T +34 93 567 20 00 / F +34 93 520 20 01 www.appluslaboratories.com File Number 23/36404072 TECHNICAL REPORT Human exposure Petitioner’s Reference: Lock Up Smart Doors S.L. Company Address: Calle Escritor Jeronimo Tristante, N10, 3B, Murcia, 30100, SPAIN Represented by: Juan Jesus Pinuaga Cascales Equipment: Boost Plus Brand: Operto PMN: PUO-001 Sample #1: N/A Applus Id: 17170-00003 Result: complies It has been tested and complies with the applicable standard. See test result summary section. Applicable Standard: EMC standard/s: FCC 47 CFR Part 2 Subpart J Section 2.1093 (October 2021) 1 KDB 447498 D01 - General RF Exposure Guidance 1 The latest modifications of the standard, published at the date of the tests reported in this document, have been considered. Dates and Test Site: Applus Barcelona, Bellaterra Equipment Reception Date July 11, 2023 Test Initial Date: November 2, 2023 Test Final Date: November 17, 2023 Test Manager: Alejandro Sáez Date of issue: Bellaterra, November 17, 2023 EMC & Wireless Technical Manager Electrical and Electronics LGAI Technological Center S.A. File Number: 23/36404072 Page Number 2/10 Service Quality Assurance Applus+, guarantees that this work has been made in accordance with our Quality and Sustainability System, fulfilling the contractual conditions and legal norms. Within our improvement program we would be grateful if you would send us any commentary that you consider opportune, to the person in charge who signs this document, or to the Quality Manager of Applus+, in the following e-mail address: [email protected] 1 INDEX 1 INDEX ............................................................................................................................................... 2 2 GENERAL DESCRIPTION OF TEST ITEMS ........................................................................................ 3 2.1 EQUIPMENT DESCRIPTION ...................................................................................................... 3 2.2 TEST CONFIGURATION............................................................................................................. 4 2.2.1 Samples ............................................................................................................................... 5 2.2.2 Auxiliary Equipment .............................................................................................................. 6 2.2.3 DUT Modifications performed ................................................................................................. 8 2.3 DUT TEST MODES ..................................................................................................................... 8 2.4 CONTROL AND MONITORING .................................................................................................. 8 3 TEST RESULTS .................................................................................................................................. 9 3.1 HUMAN EXPOSURES STANDARDS ............................................................................................ 9 3.1.1 Test Parameters ................................................................................................................... 9 3.1.2 Test Results ....................................................................................................................... 10 File Number: 23/36404072 Page Number 3/10 Service Quality Assurance Applus+, guarantees that this work has been made in accordance with our Quality and Sustainability System, fulfilling the contractual conditions and legal norms. Within our improvement program we would be grateful if you would send us any commentary that you consider opportune, to the person in charge who signs this document, or to the Quality Manager of Applus+, in the following e-mail address: [email protected] 2 GENERAL DESCRIPTION OF TEST ITEMS 2.1 EQUIPMENT DESCRIPTION This information has been provided by the customer and it is not covered by the accreditation. LGAI does not assume any responsibility from it Table 1: Equipment description Table 2: RF Features EQUIPMENT DESCRIPTION Description Wireless module to add BLE capabilities to hotel locks EUT Version FVIN HVIN 7.5.2 V2 Power supply DC +/- 4 – 11 V -- Hz Modulation GFSK Equipment Type DTS RF FEATURES Radio chipset CC2640 Brand Texas Instruments Module model N/A (Not a module, radio is part of the rest of the system) Peak gain antenna +3.3 dBi FCC ID 2BB7M-PUO-001 ISED ID 30937-PUO001 File Number: 23/36404072 Page Number 4/10 Service Quality Assurance Applus+, guarantees that this work has been made in accordance with our Quality and Sustainability System, fulfilling the contractual conditions and legal norms. Within our improvement program we would be grateful if you would send us any commentary that you consider opportune, to the person in charge who signs this document, or to the Quality Manager of Applus+, in the following e-mail address: [email protected] 2.2 TEST CONFIGURATION Table 3. Test Configuration TEST CONFIGURATION Power Supply Power by 4 x batteries AA 1.5V. Total power 6V Set-up Description Orientation The EUT horizontally, as it is intended to be placed in normal operation. Fig. 1: EUT Orientation Normal test temperatures 15 ºC to 35 ºC Equipment …

Text truncated - open the document above for the full version.

Application Report 2.4-GHz Inverted F Antenna ABSTRACT This document describes a printed-circuit board (PCB) antenna design that can be used with all 2.4-GHz transceivers and transmitters from Texas Instruments ™ . The maximum gain when used on the reference board is measured to be +3.3 dBi, and the overall size requirements for this antenna are 25.7 × 7.5 mm (not including ground plane). Table of Contents 1 Description of the antenna Design........................................................................................................................................2 2 Measurement Results.............................................................................................................................................................3 2.1 Radiation Pattern...............................................................................................................................................................3 2.2 Reflection.........................................................................................................................................................................10 2.3 Bandwidth.........................................................................................................................................................................11 3 Summary................................................................................................................................................................................11 4 References.............................................................................................................................................................................11 5 Revision History...................................................................................................................................................................12 Trademarks Texas Instruments ™ is a trademark of Texas Instruments. All trademarks are the property of their respective owners. www.ti.comTable of Contents SWRU120D – APRIL 2007 – REVISED JANUARY 2019 Submit Document Feedback 2.4-GHz Inverted F Antenna1 Copyright © 2021 Texas Instruments Incorporated 1 Description of the antenna Design It is important to make an exact copy of the antenna dimensions to obtain optimum performance. The easiest approach to implement the antenna in a PCB CAD tool is to import the antenna layout from a gerber file or a DXF file. Such files are included in CC2430DB reference design [1]. The gerber file is called Inverted_F_Antenna.spl and the DXF file is called Inverted_F_Antenna.dxf. If the antenna is implemented on a PCB that is wider than the antenna, avoid placing components or having a ground plane close to the end points of the antenna. If the CAD tool being used does not support importing gerber or DXF files, see Figure 1-1 and Table 1-1. The antenna impedance is tuned to 50 ohm on the reference board. The impedance will however be affected by different size and shape of the ground plane, objects in the antenna nearfield such as mechanical assemblies (housing, batteries, etc.), PCB thickness, PCB material and so on. It is therefore recommended to add a pi-network close to the antenna feedpoint for impedance matching. The results presented in this document are based on an antenna implemented on a PCB with a 1-mm thickness using standard FR-4 material. Figure 1-1. IFA Dimensions Table 1-1. IFA Dimensions H15.70 mmW20.46 mm H20.74 mmL125.58 mm H31.29 mmL216.40 mm H42.21 mmL32.18 mm H50.66 mmL44.80 mm H61.21 mmL51.00 mm H70.80 mmL61.00 mm H81.80 mmL73.20 mm H90.61 mmL80.45 mm W11.21 mm Description of the antenna Designwww.ti.com 22.4-GHz Inverted F AntennaSWRU120D – APRIL 2007 – REVISED JANUARY 2019 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated 2 Measurement Results All of the results presented in this section are based on measurements performed with the CC2430DB [1] evaluation board. 2.1 Radiation Pattern Figure 2-1 shows how to relate all of the radiation patterns to the orientation of the antenna. The radiation patterns were measured with the CC2430 device programmed to 0-dBm output power. Figure 2-1. Relating Antenna to Radiation Patterns www.ti.comMeasurement Results SWRU120D – APRIL 2007 – REVISED JANUARY 2019 Submit Document Feedback 2.4-GHz Inverted F Antenna3 Copyright © 2021 Texas Instruments Incorporated Figure 2-2 shows the XY plane vertical polarization. Figure 2-2. XY Plane–Vertical Polarization Measurement Resultswww.ti.com 42.4-GHz Inverted F AntennaSWRU120D – APRIL 2007 – REVISED JANUARY 2019 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated Figure 2-3 shows the XY plane horizontal polarization. Figure 2-3. XY Plane–Horizontal Polarization www.ti.comMeasurement Results SWRU120D – APRIL 2007 – REVISED JANUARY 2019 Submit Document Feedback 2.4-GHz Inverted F Antenna5 Copyright © 2021 Texas Instruments Incorporated Figure 2-4 shows the XZ plane vertical polarization. Figure 2-4. XZ Plane–Vertical Polarization Measurement Resultswww.ti.com 62.4-GHz Inverted F AntennaSWRU120D – APRIL 2007 – REVISED JANUARY 2019 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated Figure 2-5 shows the XZ plane horizontal polarization. Figure 2-5. XZ Plane–Horizontal Polarization www.ti.comMeasurement Results SWRU120D – APRIL 2007 – REVISED JANUARY 2019 Submit Document Feedback 2.4-GHz Inverted F Antenna7 Copyright © 2021 Texas Instruments Incorporated Figure 2-6 shows the YZ plane vertical polarization. Figure 2-6. YZ Plane–Vertical Polarization Measurement Resultswww.ti.com 82.4-GHz Inverted F AntennaSWRU120D – APRIL 2007 – REVISED JANUARY 2019 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated Figure 2-7 shows the YZ plane horizontal polarization. Figure 2-7. YZ Plane–Horizontal Polarization www.ti.comMeasurement Results SWRU120D – APRIL 2007 – REVISED JANUARY 2019 Submit Document Feedback 2.4-GHz Inverted F Antenna9 Copyright © 202…

Text truncated - open the document above for the full version.

The results refer only and exclusively to the sample, product or material delivered for testing, and tested under conditions stipulated in this document. The equipment has been tested under conditions stipulated by standard(s) quoted in this document. This document will not be reproduced otherwise than in full. This is the first page of the document, which consists of 73 pages. LGAI Technological center, S.A. Inscrita en el Registro Mercantil de Barcelona, Tomo 35.803, Folio1, Hoja NºB-266.627 Inscripción 1ª. C.I.F. A-63207492 LGAI Technological Center, S.A. (APPLUS) Campus de la UAB. Ronda de la Font del Carme, s/n. 08193 Bellaterra (Barcelona) (Spain) T +34 93 567 20 00 / F +34 93 520 20 01 www.appluslaboratories.com File Number 23/36404070M1 TEST REPORT Radiofrequency Petitioner’s Reference: Lock Up Smart Doors S.L. Company Address: Calle Escritor Jeronimo Tristante, N10, 3B, 30100, SPAIN Represented by: Juan Jesus Pinuaga Cascales Equipment: Boost Plus Brand: Operto PMN: PUO-001 Sample #1: N/A Applus Id: 17170-00002 Sample #2: N/A Applus Id: 17170-00003 Result: complies It has been tested and complies with the applicable standard. See test result summary section. Applicable Standard: EMC standard/s: FCC 47 CFR Part 15 Subpart C (October 2021) 1 RSS-247 – Issue 3 (August 2023) 1 The latest modifications of the standard, published at the date of the tests reported in this document, have been considered. Dates and Test Site: Applus Barcelona, Bellaterra Equipment Reception Date July 11, 2023 Test Initial Date: July 12, 2023 Test Final Date: October 31, 2023 Modification Description: M1 This report replaces and supersedes the report 23/36404070 dated on November 17, 2023. Modifications performed: General information updated. It is responsibility of the petitioner to replace the previous version with this one. Test Manager: Alejandro Sáez Date of issue: Bellaterra, December 21, 2023 EMC & Wireless Technical Manager Electrical and Electronics LGAI Technological Center S.A. File Number: 23/36404070M1 Page Number 2/73 Service Quality Assurance Applus+, guarantees that this work has been made in accordance with our Quality and Sustainability System, fulfilling the contractual conditions and legal norms. Within our improvement program we would be grateful if you would send us any commentary th…

Text truncated - open the document above for the full version.
