ELECTRIC ZONE VALVE ACTUATOR ENERGY HARVESTING SMART VALVE ACTUATOR EHSVA Tunstall Corporation 118 Exchange Street • Chicopee, MA 01013 © December 2022 We reserve the right to alter designs, specifications and information without notice. Phone (413) 594-8695 · Fax (413) 598-8109 www.tunstall-inc.com • www.maconcontrols.com Section: Electric Operators Bulletin-MC-EHSVA-2001.02 1 Description EHSVA is a self-acting actuator that is self- sufficient through energy harvesting. Wirelessly integrate with building automation to allow for suitable heating control on a room-by-room basis. Reduce heating costs by heating exactly when needed. They can be mounted on all Macon NT series valves. NON - ELECTRIC OPERATORS TECHNICAL DATA Operating Temperature Range 32ºF to 104ºF, 70% rH Material Engineered heat resistant thermoplastic (PBT,POM) Transport and Storage Temp. Range -4ºF to 149ºF Maximum Holding Force > 100 N Weight 8.50 oz. Frequency 902 MHz Color White and Silver Radiated Max. Transmitter Power <10 mW (A) 3.17” Max. Movement 0.15” (B) 0.80” Nominal Actuating Speed 0.24 mm/s (C) 2.44” Noise Level <35 dBA (D) 2.48” (E) 2.37” A B C D E ELECTRIC ZONE VALVE ACTUATOR ENERGY HARVESTING SMART VALVE ACTUATOR EHSVA Tunstall Corporation 118 Exchange Street • Chicopee, MA 01013 © December 2022 We reserve the right to alter designs, specifications and information without notice. Phone (413) 594-8695 · Fax (413) 598-8109 www.tunstall-inc.com • www.maconcontrols.com Section: Electric Operators Bulletin-MC-EHSVA-2001.02 2 Operation The EHSVA provides itself with electrical energy through energy harvesting. The electricity is made using a thermoelectric generator (TEG), which utilizes the temperature difference between the heater and room air. The EHSVA is an electric actuator which produc- es it’s own energy and is operated over radio. Integration The EHSVA can be easily integrated into your system. The single room regulation is carried out through the room controller. The Battery-Powered Alternative You can also have our efficient actuators in a bat- tery version of this product. This battery version is not energy self-sufficient, but has a longer working time per battery change than the electric thermostatic valves available. NON - ELECTRIC OPERATORS Safety Instructions • Operate the device only in dry indoor areas. • Ensure that the device does not come into contact with liquids. • Ensure that the device is not covered by objects, curtains, drapes or the like during operation, and that adequate ventilation is provided. • Do not expose the device to heavy mechanical loads, extreme temperatures or strong vibrations. • Only qualified personnel are allowed to open, repair or maintain the device. • Ensure that the device is taken out of operation if safe operation is no longer possible. ELECTRIC ZONE VALVE ACTUATOR ENERGY HARVESTING SMART VALVE ACTUATOR EHSVA Tunstall Corporation 118 Exchange Street • Chicopee, MA 01013 © December 2022 We reserve the right to alter designs, specifications and information without notice. Phone (413) 594-8695 · Fax (413) 598-8109 www.tunstall-inc.com • www.maconcontrols.com Section: Electric Operators Bulletin-MC-EHSVA-2001.02 3 Operating Instructions, Energy Harvesting Actuator Mode of operation: The actuator generates the electrical energy for its operation from the heat of the heating water or steam. The internal battery stores the energy for the operation of the ac- tuator. Field of application: The actuator is designed for use in private and in commercial environments. Charging during operation may be necessary in rarely heated rooms. The device reports this in good time via radio communication. Assembly: The actuator can be installed directly on standard Macon valves. Delivery state: The pin should be completely retracted when you receive the device. If this is not the case, please use a thin pin to press the button for 3-6 seconds (see button opening). Button opening Covered red status LED Micro-USB Pin Normal operation The actuator communicates about every 10 minutes via radio with the room controller, accepts the new setpoints and controls the heating with these values. Press the button once briefly if you require an additional interrogation of the setpoint between the normal transmission intervals (e.g. for quick transfer of the new setpoint after the temperature in the room has been changed). Status LED The covered, red status LED provides feedback for certain functions of the actuator: 1x blinking: Single push of the button with successful teach-in to the remote terminal; or upon successful communication with the remote terminal 3x blinking: Single push of the button with failed teach-in to the remote terminal; or upon failed communication with the remote terminal ELECTRIC ZONE VALVE ACTUATOR ENERGY HARVESTING SMART VALVE ACTUATOR EHSVA Tunstall Corporation 118 Exchange Street • Chicopee, MA 01013 © December 2022 We reserve the right to alter designs, specifications and information without notice. Phone (413) 594-8695 · Fax (413) 598-8109 www.tunstall-inc.com • www.maconcontrols.com Section: Electric Operators Bulletin-MC-EHSVA-2001.02 4 Special functions Interrupted radio connection to the room controller: The actuator regulates to the last desired temperature transmitted. Not enough energy: When the energy accumulator is empty, the actuator opens the radiator valve to 50% and assumes idle state. As soon as sufficient hot water or steam flows, the actuator restarts automatically and controls the heating as before. The ac- cumulator of the actuator can also be recharged via the micro-USB. Calcification protection: To prevent calcification, the actuator opens and closes the valve automatically after a few weeks. Frost protection: At too low a temperature, the actuator opens automatically and regulates the temperature to a value above the freez- ing point. Reset: Press and hold the button to initiate a reset. The red LED lights up after approximately 6s. A reset has b…
