2BB82-M68KHigh Precision GNSS Receiver

M68KPro GNSS RECEIVER USER MANUAL V1.0 Copyright © Devecent Information Technology Co., Ltd. 2022. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any ways without prior written consent of Devecent Information Technology Co., Ltd. Trademarks and Permissions and other ZX trademarks are trademarks of Devecent Information Technology Co., Ltd. All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the contract made between Devecent Information Technology and the customers. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. The information in this document is subject to change without notice. Efforts has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute a warranty of any kind, express or implied. FCC warning: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 80 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter, End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Revision History Revised Edition Revision History Date V1.0 Initial Release 2023-5-31 Contents I. Before You Start ....................................................................................................... 1 1.1 Precautions For Safe Operation ........................................................................ 1 1.2 Exemption From Liability ................................................................................ 2 II. M68KPro At A Glance ............................................................................................. 3 2.1 Appearance ....................................................................................................... 3 2.2 Display Screen .................................................................................................. 4 2.3 Power On And Off ............................................................................................ 5 2.4 Insert A SIM Card ............................................................................................. 5 2.5 Charge The Battery ........................................................................................... 5 2.6 Install The Radio Antenna ................................................................................ 6 2.7 Packing Checklist ............................................................................................. 6 III. Web UI ...................................................................................................................... 8 3.1 Status ................................................................................................................. 8 3.2 Info .................................................................................................................... 9 3.3 Skyplot .............................................................................................................. 9 3.4 Data Stream ..................................................................................................... 10 3.5 Command ........................................................................................................ 12 3.6 Mode Config ................................................................................................... 13 3.7 Others Config .................................................................................................. 15 3.8 File .................................................................................................................. 16 3.9 Firmware ......................................................................................................... 16 3.10 Log ................................................................................................................ 17 3.11 Message Text ................................................................................................ 17 3.12 Data Config ................................................................................................... 19 3.13 ZXVPN .......................................................................................…

Text truncated - open the document above for the full version.

Date: 2023-09-07 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (High Precision GNSS Receiver / M68K、M68K Pro、M68K Lite、T20、T20Pro、T30、SP30、SP40、 SP40Pro、F200、G20Plus、M8、M8S / FCC ID: 2BB82-M68K) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagrams, Schematics, Operational Descriptions, BOM, Tune Up Procedure) required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Signature: Name: Li Hua Applicant: Guangzhou Devecent Information Technology Co.,Ltd. Address: Rm 402,Building A,No.11,CaiPin Road,Science City,HuangPu District,GuangZhou,GuangDong,China TEL: +86 15918790220

Declaration on model difference We, Guangzhou Devecent Information Technology Co.,Ltd. the undersigned hereby declare that the difference between M68K and M68K Pro is that the M68K outside is button and LED, and the M68K Pro outside is button and LCD，all the others like device's schematics ，PCB layout and all other electrical aspects of the device are identical. The model no.，appearance color and LOGO of M68K Lite, T20, SP30, F200, G20Plus, M8 and M8S are different from those of M68K ，all the others like device's schematics ， PCB layout and all other electrical aspects of the device are identical. The model no.， appearance color and LOGO of T20Pro, T30, SP40 and SP40Pro are different from those of M68K Pro，all the others like device's schematics ，PCB layout and all other electrical aspects of the device are identical. The differences are model no. for trading purpose. Product Name: High Precision GNSS Receiver Models: M68K, M68K Pro, M68K Lite, T20, T20Pro, T30, SP30, SP40, SP40Pro, F200, G20Plus, M8, M8S

Photo 1. Description: Overall view Photo 2. Description: Overall view VHF Antenna Photo 3. Description: Rear view Photo 4. Description: front view Photo 5. Description: ports view

The XXXX is the location where the importer information is reserved

BT/WIFI Antenna 2G/3G/4G Antenna

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Radio Test Report Report No.: STS2307029H02 Issued for Guangzhou Devecent Information Technology Co.,Ltd. Rm 402, Building A, No.11, CaiPin Road, Science City, HuangPu District, GuangZhou, GuangDong, China Product Name: High Precision GNSS Receiver Brand Name: ZX,TokNav, SphereFix, GINTEC, Meridian, KanQ Model Name: M68K Pro Series Model(s): M68K, M68K Lite, T20, T20Pro, T30, SP30, SP40, SP40Pro, F200,G20Plus, M8, M8S FCC ID: 2BB82-M68K Test Standard: FCC 47CFR §2.1091 Page 2 of 10 Report No.: STS2307029H02 TEST REPORT Applicant’s Name ................. : Guangzhou Devecent Information Technology Co.,Ltd. Address ................................. : Rm 402, Building A, No.11, CaiPin Road, Science City, HuangPu District, GuangZhou, GuangDong, China Manufacturer's Name .......... : Guangzhou Devecent Information Technology Co.,Ltd. Address ................................. : Rm 402, Building A, No.11, CaiPin Road, Science City, HuangPu District, GuangZhou, GuangDong, China Product Description Product Name ........................ : High Precision GNSS Receiver Brand Name........................... : ZX,TokNav, SphereFix, GINTEC, Meridian, KanQ Model Name .......................... : M68K Pro Series Model(s) ...................... : M68K, M68K Lite, T20, T20Pro, T30, SP30, SP40, SP40Pro, F200,G20Plus, M8, M8S Test Standards ..................... : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date of receipt of test item ...................... : 06 July 2023 Date (s) of performance of tests ............. : 06 July 2023 ~ 30 Aug. 2023 Date of Issue ........................................... : 30 Aug. 2023 Test Result ............................................... : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Sean she) Authorized Signatory : (Chris Chen) Page 3 of 10 Report No.: STS2307029H02 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 Page 4 of 10 Report No.: STS2307029H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 17 Aug. 2023 STS2307029H02 ALL Initial Issue Page 5 of 10 Report No.: STS2307029H02 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name High Precision GNSS Receiver Brand ZX,TokNav, SphereFix, GINTEC, Meridian, KanQ Model Number M68K Pro Series Model(s) M68K, M68K Lite, T20, T20Pro, T30, SP30, SP40, SP40Pro, F200,G20Plus, M8, M8S Model Difference Differences in screen function and brand. Brand LED Model LCD Model ZX M68K M68K Pro ZX M68K Lite / TokNav T20 T20Pro TokNav T30 / SphereFix SP30 / SphereFix SP40 SP40Pro GINTEC F200 / GINTEC G20Plus / Meridian M8 / KanQ M8S / Product Description The EUT is High Precision GNSS Receiver Operation Frequency: GSM 850: 824 MHz ~ 849MHz GSM 1900: 1850 MHz ~ 1910MHz WCDMA 1900: 1850 MHz ~1910MHz WCDMA 1700: 1710 MHz ~ 1755 MHz WCDMA 850: 824 MHz ~ 849 MHz LTE Band 2:1850~1910MHz LTE Band 4:1710~1755MHz LTE Band 5:824~849MHz LTE Band 7:2500~2570MHz LTE Band 12:699~716MHz LTE Band 13:777~787MHz LTE Band 25:1850~1915 MHz LTE Band 26: 814~849 MHz LTE Band 38: 2570~2620 MHz LTE Band 41: 2496~2690 MHz UHF: 421-470MHz Bluetooth: 2402 MHz to 2480 MHz 2.4G WLAN: 802.11b/g/n(20MHz): 2412MHz to 2462 MHz 802.11n(40MHz): 2422MHz to 2452 MHz Modulation Type: GMSK and 8PSK for EDGE WCDMA: QPSK LTE: QPSK /16QAM UHF: 4FSK BLE: GFSK 2.4G WLAN: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g/n(OFDM):BPSK,QPSK,16-QAM,64- QAM Page 6 of 10 Report No.: STS2307029H02 Antenna gain: BT: 1.6dBi 2.4G WIFI:1.6dBi UHF: 2dBi GSM 850: -0.28dBi GSM 1900: 2.95dBi WCDMA 1900: 2.95dBi WCDMA 1700: -1.42dBi WCDMA 850: -0.28dBi LTE Band 2: 2.95dBi LTE Band 4: -1.42dBi LTE Band 5: -0.28dBi LTE Band 7: 2.88dBi LTE Band 12: -15.9dBi LTE Band 13: -9.6dBi LTE Band 25: 2.95dBi LTE Band 26:-0.28dBi LTE Band 38: -1.42dBi LTE Band 41: 2.88dBi Antenna Designation: GSM / WCDMA / LTE :Internal Antenna UHF: Rod Antenna Bluetooth/2.4G WLAN/ Fixed antenna Rating Input: 5VDC 3A or 15VDC 2A IP68 Class III(Supplied by USB type C port or 7.4V, 6500mAh internal rechargeable battery pack) Hardware Version M68K-PCBA.1.1.230225 Software Version m68.2.438.2307.1755 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in Page 7 of 10 Report No.: STS2307029H02 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Fre…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Radio Test Report Report No.: STS2307029W04 Issued for Guangzhou Devecent Information Technology Co.,Ltd. Rm 402, Building A, No.11, CaiPin Road, Science City, HuangPu District, GuangZhou, GuangDong, China Product Name: High Precision GNSS Receiver Brand Name: ZX,TokNav, SphereFix, GINTEC, Meridian, KanQ Model Name: M68K Pro Series Model(s): M68K, M68K Lite, T20, T20Pro, T30, SP30, SP40, SP40Pro, F200,G20Plus, M8, M8S FCC ID: 2BB82-M68K Test Standards: 47 CFR Part 2, 22, 24, 27, 90 Page 2 of 122 Report No.: STS2307029W04 TEST REPORT Applicant’s Name ................. : Guangzhou Devecent Information Technology Co.,Ltd. Address .................................. : Rm 402, Building A, No.11, CaiPin Road, Science City, HuangPu District, GuangZhou, GuangDong, China Manufacturer’s Name ........... : Guangzhou Devecent Information Technology Co.,Ltd. Address .................................. : Rm 402, Building A, No.11, CaiPin Road, Science City, HuangPu District, GuangZhou, GuangDong, China Product Description Product Name ........................ : High Precision GNSS Receiver Brand Name ........................... : ZX,TokNav, SphereFix, GINTEC, Meridian, KanQ Model Name ........................... : M68K Pro Series Model(s) .................... : M68K,M68K Lite,T20,T20Pro,T30,SP30,SP40,SP40Pro, F200,G20Plus, M8, M8S Test Standards ...................... : 47 CFR Part 2, 22, 24, 27, 90 Test Procedure ....................... : KDB 971168 D01 v03r01,ANSI C63.26( 2015) This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document.. Date of Test ................................ : Date of receipt of test item .......... : 06 July 2023 Date (s) of performance of tests . : 06 July 2023 ~ 22 Sept. 2023 Date of Issue .............................. : 22 Sept. 2023 Test Result .................................. : Pass Testing Engineer : (Lenon Hou) Technical Manager : (Sean she) Authorized Signatory : (Chris Chen) Page 3 of 122 Report No.: STS2307029W04 Table of Contents Page 1 INTRODUCTION 7 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2 PRODUCT INFORMATION 8 3 TEST CONFIGURATION OF EQUIPMENT UNDER TEST 10 4 MEASUREMENT INSTRUMENTS 12 5 TEST ITEMS 13 5.1 CONDUCTED OUTPUT POWER&TRANSMITTER RADIATED POWER 13 5.2 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT 64 APPENDIX-PHOTOS OF TEST SETUP 122 Page 4 of 122 Report No.: STS2307029W04 Revision History Rev. Issue Date Report No. Effect Page Contents 00 22 Sept. 2023 STS2307029W04 ALL Initial Issue Page 5 of 122 Report No.: STS2307029W04 SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The radiated emission testing was performed according to the procedures of KDB 971168 D01 v03r01 and ANSI C63.26( 2015) Test Description FCC Rules Band Test Limit Test Result Conducted Output Power 2.1046 / Reporting Only N/A Transmitter Radiated Power 22.913 B5, B26 ERP < 7 Watt PASS 24.232(c) B2, B25, B35 EIRP < 2Watt 27.50(b) B13 ERP < 3 Watt 27.50(c) B12 ERP < 3 Watt 27.50(d) B4 EIRP < 1Watt 27.50(h) B7, B38, B41 EIRP < 2Watt 90.635(b) B26 ERP < 100Watt Peak-to-Average Ratio 22.913(d) B5, B26 < 13 dB N/A 24.232(d) B2, B25 27.50 B4, B7, B12, B13, B38, B41 Occupied Bandwidth 2.1049 / Reporting Only N/A Frequency Stability 2.1055 / < 2.5 ppm N/A 22.355 B5, B26 24.235 B2, B25 27.54 B4, B7, B12, B13, B38, B41 90.213 B26 Spurious Emission at Antenna Terminals 2.1051 / < 43+10log10(P[Watts]) N/A 22.917 B5, B26 24.238(a) B2, B25 Page 6 of 122 Report No.: STS2307029W04 Note: The module has been certified, the module number FCC ID is "XMR201903EG25G". In this report, this certified module is same as the original filling. We have tested the new radiation emi ssion and conduction emission. 27.53(c) B13 27.53(g) B12 27.53(h) B4 90.691 B26 27.53(m) B7, B41 < 55+10log10(P[Watts]) Band Edge 2.1051 / Please refer to standard N/A 22.917 B5, B26 24.238(a) B2, B25 27.53(c) B13 27.53(g) B12 27.53(h) B4 27.53(m) B7, B41 90.691 B26 Field Strength of Spurious Radiation 2.1053 / < 43+10log10(P[Watts]) PASS 22.917 B5, B26 24.238(a) B2, B25 27.53(c) B13 27.53(g) B12 27.53(h) B4 90.691 B26 27.53(m) B7, B41 < 55+10log10(P[Watts]) Page 7 of 122 Report No.: STS2307029W04 1 INTRODUCTION 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The measurement uncertainties shown below were calculated in accordance with the requirements ofANSI C63.4-2014. All measurement uncertainty values are shown with a coverage factor of k = 2 toindicate a 95% level of confidence. The measurement data shown herein meets or exceeds the UCISPRmeasurement uncertainty values specified in CISPR 16-4-2 and, thus, can be compared directly tospecified limits to determine compliance. No. Item Uncertainty 1 RF output power, conducted ±1.197dB 2 Unwanted Emissions, conducted ±2.896dB 3 All emissions, radiated 9K-30MHz ±3.84dB 4 All emissions, radiated 30M-1GHz ±3.94dB 5 All emissions, radiated 1G-6GHz ±4.59dB 6 All emissions, radiated>6G ±5.22dB 7 Conducted Emission (9KHz-150KHz) ±2.14dB 8 Conducted Emission (150KHz-30MHz) ±2.54dB Page 8 of 122 Report No.: STS2307029W04 2 PRODUCT INFORMATION Product Name High Precision GNSS Receiver Br…

Text truncated - open the document above for the full version.

Page 1 of 1 FCC ID: 2BB82-M68K FCC Setup photo Model name: M68K Pro Radiation Low Radiation High
