2BB8U-WS8856Wireless Transceiver Module

WS8856 WirelessTransceiverModule DataSheet  Supportforawiderangeoffrequencyband861-930MHz  Supports1,000node-likenetworks  Supportforhighairrate,upto300kbps  SupportfortheWi-SUNFAN1.0protocolstack  Supportupto20dBmoutputpower,multi-stagepoweradjustable  Supportformulti-channelfrequencyhoppingtransmission  Supports the bidirectional communication between the repeater and the terminal to establish a mesh network  Supportformulti-hopnetworksbetweenrepeaters(relayfunction)  Supporttheserialportcommandparameterconfiguration  Antennainterfacestamphole(50 Ω impedance)  Smallsize:22mmx15mmx2.8mm Wir eles s Tra nsc eiv er WS8856DataSheet ChengduSilentSmartTechnologyCo.,Ltd 2   Documentinformation productmodelWS8856 Productoverview861-930MHzWirelessTransceiverModule typeofdocumentationDatasheet Documentnumber DocumentversionV1.32023.05.29  Documentversionupdate order number version number RevisedcontentReviseddateRevised 1V1.0Theinitialversion2023.04.03ZJX 2V1.1Increaseofcrystalvibrationparameters2023.05.09ZJX 3V1.2Modifythedescriptionofthecrystalvibration parametersandaddthehardwareversion 2023.05.23ZJX 4V1.3Correctthelimitoperatingvoltageandcorrect theemissioncurrent 2023.05.31ZJX   WS8856DataSheet ChengduSilentSmartTechnologyCo.,Ltd 3 1 Product overview .................................................................................................................................................................................... 4 1.1 Product Introduction .................................................................................................................................................................... 4 1.2 Features ........................................................................................................................................................................................ 4 1.3 Application Scenario .................................................................................................................................................................... 4 2 Pound definition ..................................................................................................................................................................................... 5 3 Hardware design ..................................................................................................................................................................................... 6 4 Electrical and other parameters ............................................................................................................................................................... 6 4.1 Limit parameters .......................................................................................................................................................................... 6 4.2 Working parameters ..................................................................................................................................................................... 7 4.3 RF performance parameters ......................................................................................................................................................... 7 4.4 Crystal vibration parameters ........................................................................................................................................................ 8 4.5 Other parameters .......................................................................................................................................................................... 8 5. Module package dimensions .................................................................................................................................................................. 9 6 Production guidance ............................................................................................................................................................................. 10 6.1 Reflow welding curve graph ...................................................................................................................................................... 10 6.2 Reflow welding temperature and time ....................................................................................................................................... 10 7 FCCWarning Statement ........................................................................................................................................................................ 11 8 Contact us ............................................................................................................................................................................................. 14 WS8856DataSheet ChengduSilentSmartTechnologyCo.,Ltd 4 1Productoverview 1.1ProductIntroduction WS8856 Is an 861-930 MHz serial port WirelessTransceivermodule independently developed by Chengdu SilentInformationTechnology,Themaximumemissionpowercanreach20dBm,ThemoduleadoptsTI'sCC1352P 7high-performanceRFchip,SupportforIEEE802.15.4g,smartobjects(6LoWPAN)forIPv6,miotic®,Wi-SUN®, proprietary systems (including TI 15.4-Stack (Sub-1GHz)), and concurrent multiple protocols via Dynamic Multi-protocolManager(DMM)drives. WS8856SerialportWi-Sunmodulecontainsboundaryrouting(borderrouter),routing(router)twomodes, mode can be through serial command set function configuration,modulehasthenetworkfunction,multiple Wi-SUN network, node replacement, network topology acquisitionand automatic routing function, remote configuration, multicast transmission function, UDP transmission function, to meet the needs of various applicat…
