2BB95-J6Dash Camera

Problems of intallation/operation Product is not as described Item is defective/damaged Missing items? Package Contents Button Function About TF Card Installation Home Screen Power On/Off About the Camera Settings Playback Mode About Wifi and App FAQ GPS Information About Time Setting Appearance 1 2 11 3 4 8 9 10 12 14 15 17 20 Product Specifications 22 JOMISE Short Press to Enter the Settings; Long Press to Lock the Videos. Short Press to Enter Playback; Long Press to Snapshot. Short Press to Start/Pause Recording; Long Press to Turn ON/OFF the Camera. Quick switch Front/Rear camera You can switch between Front/Rear/Front+Rear Split-screen by swiping left/right on any area of the screen. [Resolution]: 3 modes resolution settings,You can choose the video resolution you like. Higher resolution videos will take more storage space. [Loop Recording]: 1/2/3 mins This feature allows camera to continuously record loop by loop so it can delete the oldest video files automatically when the memory card becomes full so you don't have to manually delete them. This feature will split each video files to appropriate length based on your selection. [Parking Mode] : Requires hardwire kit(sold separately), not work without hardwire kit. [G-Sensor]: Off / low / medium / high G-Sensor is a 3-axis impact gravitational accelerometer which is designed to detect physical and gravitational forces on the camera. The video will be locked-In the event when G-Sensor is triggered due to physical or gravitational impact force on the camera, the current loop cycle length of video file will be locked so it will NOT be deleted by loop cyde function. [WiFi]: WiFi on / off [Screen Saver]:OFF-This will keep the video ON all the time. 10S/30S/1Min-The screen will turn off, but the recording will remain. [Frequency]:Here you should choose the frequency accordingly to your power supply specification used in your country based on your geographical location. 60 Hz (USA - North America) 50 Hz (Europe - Most Asian Countries) [Audio]: Sound recording on/ off J6 has built-in microphone to record audio with video. You can choose to record mute video by choosing OFF. You can also press and hold DOWN button for 3 seconds to mute/ un-mute while video is being recorded. [Language]:This setting allows you to choose your language setting for camera's firmware. [Mirror Flip]: You can Mirror image left and right. [Vertical Flip]: You can flip image up and down. [Preview Mode]: You can select Front/Rear/Front&Rear view. [Time-Lapse Recording Frame Rate]: 0.5S/1S/5S [Time-Lapse Recording]: Off/12H/24H [Speeding Alert]: You can set it by your favour. [Time Zone]:Here you can choose your desired or local time zone setting based on GMT value. [GPS Info]:This feature allow you to see your current geographical location in Latitude & Longitude. [Date/Time]:You do not need to manually adjust the time because GPS will automatical- ly update the time based on your location. [Time Format]: Tap to select '24H' or '12H' to change time format to 12-Hours systems or 24-Hours systems [Summer Time]:Turn on/off daylight saving time [Volume]: - Off - Low - Middle - High [Format]:This feature will allow you to format inserted memory card, all the data will be deleted. [Default Setting]:Here you can restore all the settings to factory default settings. [Version]:Here you can check the current firmware version installed on your camera. We will notify you via Amazon if there is a new software version. If you need to track GPS information, please download the dedicated player, the download link(Compatible with Windows) is as follows: http://www.sunningsoft.com/en/pcgps.html For Mac, please search "GXPlayer" in App Store. By using the file playback software [GXPlayer], you can check all drive information such as Time, Location, Speed, and so on Scan the code to download 1. Download the DASH CAM WiFi APP Scan the below QR code to download the mobile APP [Topcam]. On your Smartphone search Topcam. For iPhones search the APP Store or for Android devices via Google Play. 2. In the boot mode, turn on the mobile phone's WIFI. WIFI name: CVR_******** Password: 123456789 3. Open the mobile APP then you can use it. When connecting to the app for the first time, please make sure the app has authorization to access: location, photo album, network, otherwise it will not work. Local Album: You can download the files of video or photo, and save them in the local album. Discover: You can view Installation Guide and FAQ. Mine: You can enter your email address to login APP, set the App Language and submit the Feedback. CVR_12310014 Video: You can view the files of Normal/Emer- gency videos, and download/delete them after selecting the files. (All videos can be edited and shared, the edited videos will be saved in the Local Album of Wonderful.) Photo: You can view the files of photos, and download/delete them after selecting the files. Switch shoots: Switch the front/rear camera. Snapshot: You can view the snapshot images. Wi-Fi: Modify the WIFI password. Resolution: Select the resolution of camera. Recording time: Set the loop time. Encoding Type: Set the video encoding type. Parking Monitoring: Turn On/Off 24H Parking Monitor. (This feature requires the connection of hardwire kit.) Gravity sensor: Set the sensitivity of camera gravity sensing. Recording: Turn On/Off audio recording. Volume: Set the volume of camera. Time-lapse video: Set the time of time-lapse recording. Time Lapse Frame Rate: Set the frame rate of time-lapse recording. Format: Format the TF card, and all the data will be erased. (It is recommended to format the card regularly every month) Version: View the version of the camera. Under normal operating conditions, if there are problems with the device, please refer to the following methods to resolve. Due to the high amount of HD video data being recorded, please use a highspeed micro SD card. To tell if you have the required high speed card, check if it has the ‘M…
