2BBAP-Q350QR Code Scanner

1 Usermanual Pleasereaditcarefullyandkeep itproperly. Fastrecognition Variousoutputinterface Suitableforaccesscontrolscenario 2 Disclaimer Beforeusingtheproduct,pleasereadallthecontentsinthisProductManualcarefullyto ensurethesafeandeffectiveuseoftheproduct.Donotdisassembletheproductortearupthe sealonthedevicebyyourself,orSuzhouCoolCodeTechnologyCo.,Ltd.willnotberesponsiblefor thewarrantyorreplacementoftheproduct. Thepicturesinthismanualareforreferenceonly.Ifanyindividualpicturesdonotmatchthe actualproduct,theactualproductshallprevail.Fortheupgradeandupdateofthisproduct,Suzhou CoolCodeTechnologyCo.,Ltd.reservestherighttomodifythedocumentatanytimewithout notice. Useofthisproductisattheuser'sownrisk.Tothemaximumextentpermittedbyapplicable law,damagesandrisksarisingfromtheuseorinabilitytousethisproduct,includingbutnot limitedtodirectorindirectpersonaldamage,lossofcommercialprofits,SuzhouCoolCode TechnologyCo.,Ltd.willnotbearanyresponsibilityfortradeinterruption,lossofbusiness informationoranyothereconomicloss. AllrightsofinterpretationandmodificationofthismanualbelongtoSuzhouCoolCode TechnologyCo.,Ltd. 3 Edithistory ChangedateVersionDescriptionResponsible 2022.2.24V1.0Initialversion 4 目录 Disclaimer.......................................................................................................................................................................................................................................................2 1.Preface....................................................................................................................................................................................................................................................5 1.1.Productintroduction.......................................................................................................................................................................................................................5 1.2.Productfeature................................................................................................................................................................................................................................5 2.Productappearance..............................................................................................................................................................................................................................6 2.1.1.OVERALLINTRODUCTION............................................................................................................................................................................................................6 3.Productparameters ................................................................................................................................................................................................................................8 3.1.Generalparameters.........................................................................................................................................................................................................................8 3.2.Readingparameter..........................................................................................................................................................................................................................9 3.3.Electricparameters.......................................................................................................................................................................................................................11 3.4.Workingenvironment...................................................................................................................................................................................................................11 4.Interfacedefinition........................................................................................................................................................................................................................12 4.1.RS232,RS485Version....................................................................................................................................................................................................................12 4.2.Wiegand&TTLVersion...................................................................................................................................................................................................................13 4.3.EthernetVersion............................................................................................................................................................................................................................14 4.4.Ethernet+WiegandVersion...........................................................................................................................................................................................................16 5.Deviceconfiguration........................................................................................................................................................................................................................18 5.1configtool.......................................................................................................................................................................................................................................18 6.Mountingmethod..................................................................................................................................................................................................................................22 7.Attention................................................................................................................................................................................................…

Text truncated - open the document above for the full version.

Suzhou CoolCode Technology Co., Ltd. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Suzhou CoolCode Technology Co., Ltd. Address: Floor 2, Workshop No.23, Yangshan Science and Technology Industrial Park, No. 8, Jinyan Road, High-tech Zone, Suzhou, China Product Name: QR Code Scanner FCCID: 2BBAP-Q350 Model(s): Q350 2.911(d)(5)(i) Equipment Type We, [Suzhou CoolCode Technology Co., Ltd.] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Wang Zhonghao Date: Jun. 25, 2023 Signature: Title and Company name: Overseas business manager / Suzhou CoolCode Technology Co., Ltd. NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Suzhou CoolCode Technology Co., Ltd. 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Suzhou CoolCode Technology Co., Ltd. Address: Floor 2, Workshop No.23, Yangshan Science and Technology Industrial Park, No. 8, Jinyan Road, High-tech Zone, Suzhou, China Product Name: QR Code Scanner FCCID: 2BBAP-Q350 Model(s): Q350 2.911(d)(5)(ii) Applicant filing We, [Suzhou CoolCode Technology Co., Ltd.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to §1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Wang Zhonghao Date: Jun. 25, 2023 Signature: Title and Company name: Overseas business manager / Suzhou CoolCode Technology Co., Ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Suzhou CoolCode Technology Co., Ltd. Agent Authorization Company: Suzhou CoolCode Technology Co., Ltd. Address: Floor 2, Workshop No.23, Yangshan Science and Technology Industrial Park, No. 8, Jinyan Road, High-tech Zone, Suzhou, China Product Name: QR Code Scanner Model Number(s): Q350 Product Description: QR Code Scanner We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Jun. 25, 2023 Name: Wang Zhonghao Title: Overseas business manager Company: Suzhou CoolCode Technology Co., Ltd.

Suzhou CoolCode Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jun. 25, 2023 Subject; Request for Confidentiality FCC ID: 2BBAP-Q350 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software security requirement In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Wang Zhonghao Title: Overseas business manager

Annex A External Photos Model No.: Q350 Page 1 of 4 Model No.: Q350 Page 2 of 4 Model No.: Q350 Page 3 of 4 Model No.: Q350 Page 4 of 4

RF Exposure evaluation FCC ID: 2BBAP-Q350 1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. 2. Limit FCC: Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modeled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method FCC： Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Result NFC( Antenna Gain: 0dBi): EIRP(dBm)= 97.0(dBuV/m)-95.2=1.8(dBm) Mode Output Power Output Power (Turn-up Procedure) Antenna Gain (Numeric) Power Density At 20 cm (mW/cm 2 ) Power Density Limit (mW/cm 2 ) Test Results (dBm) dBm mW 13.56MHz 1.8 2 1.58 1.0000 0.000037 0.98 PASS 5. Conclusion This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

FCC ID LABEL: Ca: 10mm x 40mm Label Location FCC ID: 2BBAP-Q350

Annex B Internal Photo Model No.: Q350 Page 1 of 5 Model No.: Q350 Page 2 of 5 Model No.: Q350 Page 3 of 5 Model No.: Q350 Page 4 of 5 Antenna Model No.: Q350 Page 5 of 5

RF Exposure evaluation FCC ID: 2BBAP-Q350 1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. 2. Limit FCC: Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modeled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method FCC： Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Result NFC( Antenna Gain: 0dBi): EIRP(dBm)= 97.0(dBuV/m)-95.2=1.8(dBm) Mode Output Power Output Power (Turn-up Procedure) Antenna Gain (Numeric) Power Density At 20 cm (mW/cm 2 ) Power Density Limit (mW/cm 2 ) Test Results (dBm) dBm mW 13.56MHz 1.8 2 1.58 1.0000 0.000037 0.98 PASS 5. Conclusion This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

Antenna specification dimension58mm*68mm shaperectangle type13.56M 2Dplan  Antenna type MR86_miniTX_V1.0 AntennamanufacturerSuzhoukoodletechnologyCo.,Ltd. gain0DBi

Page 1 of 22 Report No.: HK2212085560-E FCC TEST REPORT Test report On Behalf of Suzhou CoolCode Technology Co., Ltd. For QR Code Scanner Model No.: Q350 FCC ID: 2BBAP-Q350 Prepared For : Suzhou CoolCode Technology Co., Ltd. Floor 2, Workshop No.23, Yangshan Science and Technology Industrial Park, No. 8, Jinyan Road, High-tech Zone, Suzhou, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Jun. 05, 2023 ~ Jun. 13, 2023 Date of Report: Jun. 13, 2023 Report Number: HK2212085560-E Page 2 of 22 Report No.: HK2212085560-E TEST RESULT CERTIFICATION Applicant’s name ................. : Suzhou CoolCode Technology Co., Ltd. Address .................................. : Floor 2, Workshop No.23, Yangshan Science and Technology Industrial Park, No. 8, Jinyan Road, High-tech Zone, Suzhou, China Manufacture's Name ............ : Suzhou CoolCode Technology Co., Ltd. Address .................................. : Floor 2, Workshop No.23, Yangshan Science and Technology Industrial Park, No. 8, Jinyan Road, High-tech Zone, Suzhou, China Product description Trade Mark: N/A Product name ............................ : QR Code Scanner Model and/or type reference : Q350 Standards ............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.225 ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests .............. : Jun. 05, 2023 ~ Jun. 13, 2023 Date of Issue ........................................... : Jun. 13, 2023 Test Result ............................................... : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 3 of 22 Report No.: HK2212085560-E TABLE OF CONTENTS 1. TEST RESULT SUMMARY ........................................................................ 5 1.1. INFORMATION OF THE TEST LABORATORY ................................................................................ 5 1.2. MEASUREMENT UNCERTAINTY ..................................................................................................... 5 2. EUT DESCRIPTION ................................................................................... 6 3. GENERA INFORMATION .......................................................................... 7 3.1. TEST ENVIRONMENT AND MODE ................................................................................................... 7 3.2. DESCRIPTION OF SUPPORT UNITS ................................................................................................ 7 4. TEST RESULTS AND MEASUREMENT DATA ........................................ 8 4.1. ANTENNA REQUIREMENT ............................................................................................................... 8 4.2. CONDUCTED EMISSION ................................................................................................................... 9 4.3. RADIATED EMISSION MEASUREMENT ........................................................................................ 11 4.4. OCCUPIED BANDWIDTH ................................................................................................................ 17 4.5. FREQUENCY STABILITY ................................................................................................................ 19 5. APPENDIX A: PHOTOGRAPHS OF TEST SETUP ................................ 21 6. APPENDIX B: PHOTOS OF THE EUT .................................................... 22 Page 4 of 22 Report No.: HK2212085560-E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release Jun. 13, 2023 Jason Zhou Page 5 of 22 Report No.: HK2212085560-E 1. TEST RESULT SUMMARY Requirement CFR 47 Section Result Conduction Emission, 0.15MHz to 30MHz §15.207 N/A Radiation Emission §15.225, §15.205, §15.209, §15.35 PASS Occupied Bandwidth §15.215 PASS Antenna requirement §15.203 PASS Frequency stability §15.225 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 1.1. INFORMATION OF THE TEST LABORATORY Shenzhen HUAK Testing Technology Co., Ltd. Add.: 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Testing Laboratory Authorization： A2LA Accreditation Code is 4781.01. FCC Designation Number is CN1229. Canada IC CAB identifier is CN0045. CNAS Registration Number is L9589. 1.2. MEASUREMENT UNCERTAINTY Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.71dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.90dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 3.90dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.28dB, k=2 Page 6 of 22 Report No.: HK2212085560-E 2. EUT DESCRIPTION Equipment: QR Code Scanner Model Name: Q350 Series Model: N/A Model Difference: N/A FCC ID: 2BBAP-Q350 Antenna Type: PCB Antenna Antenna Gain: 0dBi Operation frequency: 13.56MHz Modulation Type: ASK Power Source: DC 12V 0.1A Power Rating: DC 12V 0.1A Page 7 of 22 Report No.: HK2212085560-E 3. GENERA INFORMATION 3.1. TEST ENVIRONMENT AND MODE Operating Environment: Temperature: 24.0 C Humidity: 54 % RH Atmospheric Pressure: 1010 mbar Test Mode: Operation mode: Keep the EUT in continuous tran…

Text truncated - open the document above for the full version.

Q350 Radiated Emissions
