2BBAW-PF14SPet Automatic Feeder &Gravity Water Dispenser with WiFi

Pet Automatic Feeder & Gravity Water Dispenser with WiFi User Manual Model: PF14S ON-D230 1. Select a stable and firm location to install the feeder to avoid it from shaking or toppling over. 2. Ensure that the installation environment is dry and away from water sources and damp areas. 3. Before adding pet food, check if the food is suitable for feeding to avoid using deteriorated or unsuitable food. 4. Set an appropriate feeding amount and time, and do not overfeed to prevent pet obesity or indigestion. 5. Observe the pet's eating situation regularly and adjust in time if there is any abnormality. 6. Clean the feeder regularly to keep it clean and hygienic and prevent the growth of bacteria. 7. Pay attention to keeping the battery fully charged or the power connection normal. 8. These packaging bags may cause suffocation. Keep them away from children and pets. 9. Do not use the feeder when the pet cannot reach the food plate or has any physical disability. 10. Do not put your fingers into the food outlet or let your fingers touch the rotor. 11. Do not immerse the base part in water at any time, otherwise it may damage electronic components, such as the control panel. Safety Warning Contents Package Contents Specifications Assemble the Feeder LED Display Introduction Product Overview Model: Dimensions (L × W × H): Tank Capacity: Material: Input: Wi-Fi Frequency: Kibble Size: Power: PF14S 22.6 × 6.46 × 13 in (303 × 161 × 329 mm) 5L (169 oz) Food + 3.5L (118 oz) Water ABS, 304 stainless steel 5V 1A 2.4G Hz & 5G Hz ≤ 0.5 in(13mm) 1. Remove the feeder and all accessories from the packaging. 2. Connect the power cable and adapter to the device.Insert 4×AA alkaline batteries (not included) for backup power. 5. Add dry pet food into the food tank and close the lid. 6. Fill the water tank with water, tighten the cap and place the tank into the designated slot. Press and hold the knob for 3 seconds to unlock. Select RESET, then press and hold the knob for 7 seconds to enter pairing mode. Turn on Bluetooth and Wi-Fi on your phone. Open the App, tap "Add Device" or "+". Select "PF14S" when it appears, then tap "Add". Enter your Wi-Fi name and password, then tap "Next". 4. Open the top lid and place the desiccant bag inside. (We recommend replacing the desiccant monthly.) 3. Place the stainless steel bowl on the base and insert it into the bottom of the feeder main unit. Note: Kibble size allowed: ≤ 0.5 in (13mm) Do not use it for canned food or wet food. Note: Turn knob clockwise to bulb icon, click knob to switch off light. When battery powered only, the icon lights up. Note: Two beeps indicate a successful reset. Note: If the feeder goes offline, the device will continue feeding according to your set plan, but new records will not be saved. Note: After app setup, schedule feedings right from your phone. The app language follows your phone's default language. @Oneisall Official Warranty Information Oneisall offers a standard 2-year warranty. If you have any issues with your Oneisall product, please do not hesitate to contact us. Be sure to include your proof of purchase, model number, and any relevant photos or videos in your message to expedite the process. Our Oneisall support team is available 7 days a week and will respond to your inquiry within 24 hours. Thank you for choosing Oneisall. Please note that the Oneisall warranty does not apply to used products or purchases made from unauthorized sellers. It's important to be aware that the warranty also does not cover consumable parts such as blades, guards, filters, brushes, and similar items. These parts may require regular replacement or maintenance. [email protected] +1877-522-8578(US) Mon-Fri 8am-5pm(PST) www.oneisall.com Oneisall support GPSR Product Information GPSR Manufacturer Information Business Name: Shenzhenbenfendianzishangwuyouxiangongsi Manufacturer's Address: CN, 518000, GuangDong Sheng, Shenzhen, Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B Tel: +86 185 6587 6424 E-Mail: [email protected] 0102030405 01 02 03 03 04 05 07 08 11 12 13 14 15 Safety Warning Product Overview Package Contents Specifications Assemble the Feeder LED Display Introduction Connect to APP Add Device Disassemble for Cleaning Troubleshooting Warranty Information GPSR Product Information FCC Statement 131415 ON-D230 Any problem you have, please contact us: [email protected] Oneisall support 060708 PF14S WIFI款喂食器说明书 尺寸：105X140mm 材质：128g双铜 印刷：封面4色印刷 4色印刷 折叠方式：骑马钉 C0 M63 Y100 K0 Made in China FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. MODIFICATION: Any changes or modifications not expressly approved by the grantee of this devic…

Text truncated - open the document above for the full version.

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: ANTEK SERVICE INC FRN: 0033437609 Contact Name: Shirley Kwok Address: 901 N PENNSYLVANIA ST STE 0 DENVER, CO 80203, United States Telephone No: 01 303-8006306 Email: [email protected] This letter is to confirm that we (ANTEK SERVICE INC) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: 2026-01-15 Signed by (Printed Name/Title): Shirley Kwok/Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Shenzhenbenfendianzishangwuyouxiangongsi FRN: 0033804329 FCC ID: 2BBAW-PF14S Contact Name: Lisa Zhang Address: Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China Telephone No: 08618026982184 Email: [email protected] Applicant Signature: Date: 2026-01-15 Signed by (Printed Name/Title): Lisa Zhang / Manager

(Shenzhenbenfendianzishangwuyouxiangongsi) (2026.01.19) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:2BBAW-PF14S) [Shenzhenbenfendianzishangwuyouxiangongsi] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, (Applicant signature) (Applicant printed name) Lisa Zhang (Shenzhenbenfendianzishangwuyouxiangongsi) (2026.01.19) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:2BBAW-PF14S) [Shenzhenbenfendianzishangwuyouxiangongsi] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Lisa Zhang

Shenzhenbenfendianzishangwuyouxiangongsi 2026.01.19 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Pet Automatic Feeder &Gravity Water Dispenser with WiFi Trademark: MODEL : PF14S FCC ID : 2BBAW-PF14S To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description - FCC Software Security Requirements for UNII devices Rev 2.1 required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Lisa Zhang / Manager Contact information / address: Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China

Shenzhenbenfendianzishangwuyouxiangongsi 2026.01.19 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen STS Test Services Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Lisa Zhang / Manager Contact information / address: Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China

Page 1 of 11 FCC ID: 2BBAW-PF14S External Photos Page 2 of 11 FCC ID: 2BBAW-PF14S Page 3 of 11 FCC ID: 2BBAW-PF14S Page 4 of 11 FCC ID: 2BBAW-PF14S Page 5 of 11 FCC ID: 2BBAW-PF14S Page 6 of 11 FCC ID: 2BBAW-PF14S

Size:40*30mm Pet Automatic Feeder &Gravity Water Dispenser with WiFi FCC ID: 2BBAW-PF14S This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Label Location

Page 7 of 11 FCC ID: 2BBAW-PF14S Internal Photos Page 8 of 11 FCC ID: 2BBAW-PF14S Page 9 of 11 FCC ID: 2BBAW-PF14S Page 10 of 11 FCC ID: 2BBAW-PF14S Antenna Page 11 of 11 FCC ID: 2BBAW-PF14S

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.: STS2512387H01 Issued for Shenzhenbenfendianzishangwuyouxiangongsi Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China Product Name: Pet Automatic Feeder &Gravity Water Dispenser with WiFi Brand Name: Model Name: PF14S Series Model(s): N/A FCC ID: 2BBAW-PF14S Test Standard: FCC 47CFR §2.1091 Page 2 of 8 Report No.: STS2512387H01 TEST REPORT Applicant’s Name ................. : Shenzhenbenfendianzishangwuyouxiangongsi Address ................................. : Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China Manufacturer's Name ........... : Shenzhenbenfendianzishangwuyouxiangongsi Address ................................. : Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China Product Description Product Name ........................ : Pet Automatic Feeder &Gravity Water Dispenser with WiFi Brand Name .......................... : Model Name .......................... : PF14S Series Model(s) ...................... : N/A Test Standards ..................... : FCC 47CFR §2.1091 447498 D01 Interim General RF Exposure Guidance v06 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 25 Nov. 2025 Date (s) of performance of tests ............. : 25 Nov. 2025 to 22 Jan. 2026 Date of Issue .......................................... : 22 Jan. 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 8 Report No.: STS2512387H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1091 REQUIREMENT 7 2.1 TEST STANDARDS 7 2.2 LIMIT 7 2.3 TEST RESULT 8 Page 4 of 8 Report No.: STS2512387H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 22 Jan. 2026 STS2512387H01 ALL Initial Issue Page 5 of 8 Report No.: STS2512387H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Pet Automatic Feeder &Gravity Water Dispenser with WiFi Brand Name Model Name PF14S Series Model(s) N/A Model Difference N/A Product Description The EUT is Pet Automatic Feeder &Gravity Water Dispenser with WiFi Operation Frequency: 2402~2480 MHz 802.11b/g/n 20: 2412~2462 MHz 802.11n40:2422~2452MHz IEEE 802.11a/ n(HT20): 5.180GHz-5.240GHz IEEE 802.11n(HT40): 5.190GHz-5.230GHz IEEE 802.11a/ n(HT20): 5.745GHz-5.825GHz IEEE 802.11a/ n(HT40): 5.755GHz-5.795GHz Modulation Type: GFSK 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-Q AM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-Q AM 802.11a(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK,QPSK,16-QAM,64-QAM Bit Rate of Transmitter: 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz): 65/58.5/52/39/26/19.5/13/6.5Mbps 802.11n(40MHz): 135/121.5/108/81/54/40.5/37/13.5Mbps Antenna gain: BLE/2.4G WIFI: 1.95 dBi U-NII-1: 1.97dBi U-NII-3: -0.76 dBi Antenna Designation: PCB antenna Power Rating DC 6V (1.5V*4) from battery, DC 5V from USB Adapter 1 Model No.: YMK-10W050100 Input: AC 100-240V 50/60Hz 0.3A Output: 5V1A Adapter 2 Manufacture: Guangdong Qingliu Electronics Co.,LTD Model No.: QL010-0501000UU Input: AC 100-240V 50/60Hz 0.45A Output: 5V1A Page 6 of 8 Report No.: STS2512387H01 Battery N/A Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 7 of 8 Report No.: STS2512387H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 3.0-30 1842/f 4.89/f *(900/f²) 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1.34-30 824/f 2.19/f *(180f²) 1500 – 100000 -- -- 1.0 F= Frequency in MHz Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. Page 8 of 8 Report No.: STS25123…

Text truncated - open the document above for the full version.

Shenzhen South Star Technology Co. Ltd. Shanghai South Star Technology Co. Ltd. SPECIFICATION FOR APPROVAL CUSTOMER : PART NAME : PART NO. : NDX NO. : REV. : Shenzhen southstar technology.co.,LTD 深圳市南斗星科技有限公司 Address：No.1606,Build C6,HengFeng industrial city,xixiang street,baoan district,Shenzhen Shenzhen southstar technology co., LTD. Shanghai branch 深圳市南斗星科技有限公司上海分公司 103B, Build10, No.198 Zhang Heng Road , Pudong New Area,Shanghai WBR3D PCB Antenna 2.4G- 5.8G TUYA Antenna Assembly Specification(With housing) 1.Electrical Properties 1.3 VSWR ................................................................ ...<2 1.4 Radiation................................................................Omni 1.5 Gain(Peak).............................................................1dBi 1.6 Polarization............................................................Linear 1.7 Admitted Power.....................................................1W 1.8 Connector...............................................................MH 1.1 Frequecy range.............................................2.412~2.472GHz 1.2 Impedance.......................................................50Ω Norminal F 2.Physical Properties 2.1 Working Temperature.........................................-20°C~+65°C 2.2 Storage Temperature...........................................-30°C~+75°C Shenzhen South Star Technology Co. Ltd. 103B, Build10, No.198 Zhang Heng Road , Pudong New Area,Shanghai Antenna Design for 2.4G-5.8G Document NumberNDX-1908020 Released Date20/08/2019 AuthorMingchao Zhang Review ByZhongyi Zhao Shenzhen South Star Technology Co. Ltd. 103B, Build10, No.198 Zhang Heng Road , Pudong New Area,Shanghai Revised History DateVersionRevised Recored 20/08/20191.00 1st Released Shenzhen South Star Technology Co. Ltd. 103B, Build10, No.198 Zhang Heng Road , Pudong New Area,Shanghai 1.Antennas' setup and enviroment With housing 板载2.4G-5.8G Shenzhen South Star Technology Co. Ltd. 103B, Build10, No.198 Zhang Heng Road , Pudong New Area,Shanghai 2.Analyzer Measurement 2.1 Ant 2.4G -5.8G S11 VSWR Shenzhen South Star Technology Co. Ltd. 103B, Build10, No.198 Zhang Heng Road , Pudong New Area,Shanghai 3.Gain & Patterns test results 3.1 Measurement setting-XYZ Shenzhen South Star Technology Co. Ltd. 103B, Build10, No.198 Zhang Heng Road , Pudong New Area,Shanghai 3.2 Ant 2.4G 3D Patterns Shenzhen South Star Technology Co. Ltd. 103B, Build10, No.198 Zhang Heng Road , Pudong New Area,Shanghai 3.2 Ant 5.8G 3D Patterns Shenzhen South Star Technology Co. Ltd. 103B, Build10, No.198 Zhang Heng Road , Pudong New Area,Shanghai 3.2 Ant 2.4G 2D Patterns Shenzhen South Star Technology Co. Ltd. 103B, Build10, No.198 Zhang Heng Road , Pudong New Area,Shanghai 3.2 Ant 5.8G 2D Patterns Shenzhen South Star Technology Co. Ltd. 103B, Build10, No.198 Zhang Heng Road , Pudong New Area,Shanghai 4. Peak Gain & Efficiency FreqEffiEffiGain (MHz)(%)(dB)(dBi) 240021.72-6.630.47 241024.64-6.081.17 242027.86-5.551.95 243026.18-5.821.71 244024.58-6.091.5 245023.27-6.331.17 246024.25-6.151.22 247021.7-6.630.55 248019.44-7.11-0.22 249016.86-7.73-1.02 510032.86-4.831.22 520039.24-4.061.97 530032.14-4.931.08 540054.54-2.632.64 550033.93-4.691.6 560034.27-4.650.65 570030.77-5.12-0.76 580035.7-4.47-0.84 590033.5-5.31-1.2

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.: STS2512387W01 Issued for Shenzhenbenfendianzishangwuyouxiangongsi Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China Product Name: Pet Automatic Feeder &Gravity Water Dispenser with WiFi Brand Name: Model Name: PF14S Series Model(s): N/A FCC ID: 2BBAW-PF14S Test Standards: FCC Part15.247 Page 2 of 78 Report No.: STS2512387W01 TEST REPORT Applicant’s Name ................. : Shenzhenbenfendianzishangwuyouxiangongsi Address ................................. : Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China Manufacturer's Name .......... : Shenzhenbenfendianzishangwuyouxiangongsi Address ................................. : Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China Product Description Product Name ....................... : Pet Automatic Feeder &Gravity Water Dispenser with WiFi Brand Name .......................... : Model Name .......................... : ... : PF14S Series Model(s) .................... : N/A Test Standards ..................... : FCC Part15.247 Test Procedure ...................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the IC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ..................... : 25 Nov. 2025 Date (s) of performance of tests ............. : 25 Nov. 2025 to 22 Jan. 2026 Date of Issue .......................................... : 22 Jan. 2026 Test Result.............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 78 Report No.: STS2512387W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.6 EQUIPMENTS LIST 12 RF RADIATION TEST EQUIPMENT 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 15 4. RADIATED EMISSION MEASUREMENT 19 4.1 RADIATED EMISSION LIMITS 19 4.2 TEST PROCEDURE 21 4.3 TEST SETUP 22 4.4 EUT OPERATING CONDITIONS 22 4.5 FIELD STRENGTH CALCULATION 23 4.6 TEST RESULTS 24 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 41 5.1 LIMIT 41 5.2 TEST PROCEDURE 41 5.3 TEST SETUP 41 5.4 EUT OPERATION CONDITIONS 41 5.5 TEST RESULTS 41 6. POWER SPECTRAL DENSITY TEST 42 6.1 LIMIT 42 6.2 TEST PROCEDURE 42 Page 4 of 78 Report No.: STS2512387W01 Table of Contents Page 6.3 TEST SETUP 42 6.4 EUT OPERATION CONDITIONS 42 6.5 TEST RESULTS 42 7. BANDWIDTH TEST 43 7.1 LIMIT 43 7.2 TEST PROCEDURE 43 7.3 TEST SETUP 43 7.4 EUT OPERATION CONDITIONS 43 7.5 TEST RESULTS 43 8. PEAK OUTPUT POWER TEST 44 8.1 LIMIT 44 8.2 TEST PROCEDURE 44 8.3 TEST SETUP 44 8.4 EUT OPERATION CONDITIONS 44 8.5 TEST RESULTS 44 9. ANTENNA REQUIREMENT 45 9.1 STANDARD REQUIREMENT 45 9.2 EUT ANTENNA 45 APPENDIX 1-TEST DATA 46 APPENDIX 2- EUT TEST PHOTO 78 Page 5 of 78 Report No.: STS2512387W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 22 Jan. 2026 STS2512387W01 ALL Initial Issue Page 6 of 78 Report No.: STS2512387W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 78 Report No.: STS2512387W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 78 Report No.: STS2512387W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Pet Automatic Feeder &Gravity Water Dispenser with WiFi Brand Name Model Name PF14S Series …

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.: STS2512387W02 Issued for Shenzhenbenfendianzishangwuyouxiangongsi Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China Product Name: Pet Automatic Feeder &Gravity Water Dispenser with WiFi Brand Name: Model Name: PF14S Series Model(s): N/A FCC ID: 2BBAW-PF14S Test Standards: FCC Part15.247 Page 2 of 91 Report No.: STS2512387W02 TEST REPORT Applicant’s Name ................. : Shenzhenbenfendianzishangwuyouxiangongsi Address ................................. : Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China Manufacturer's Name ........... : Shenzhenbenfendianzishangwuyouxiangongsi Address ................................. : Longhua District, Minxin Community Bishui Longting Building 6 Unit, 7B, Shenzhen GuangDong Sheng, 518000, China Product Description Product Name ........................ : Pet Automatic Feeder &Gravity Water Dispenser with WiFi Brand Name ........................... : Model Name .......................... : PF14S Series Model(s) .................... : N/A Standards ............................. : FCC Part 15.247 Test Procedure........................: ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 25 Nov. 2025 Date (s) of performance of tests ............. : 25 Nov. 2025 to 22 Jan. 2026 Date of Issue .......................................... : 22 Jan. 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 91 Report No.: STS2512387W02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 RADIATED EMISSION MEASUREMENT 19 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 39 4.1 LIMIT 39 4.2 TEST PROCEDUR…

Text truncated - open the document above for the full version.
