SPRINT Handheld Remote REF 9620 BLE Y1 16MHz Crystal Oscillator NOTES: Timing for the BLE Radio is derived from a 16MHz crystal oscillator (Y1 ) that is factory calibrated to 16MHz +/-20Hz (1.25ppm). Y2 is a low power/ low frequency oscillator that controls the unit while in the low power/ sleep state. This crystal is not connected to or used for the BLE radio RF circuitry. Production units are 100% calibrated to this requirement, and if the crystal can’t be calibrated to this specification, the unit is rejected. See 80025-SCH-0000 for connection details and RF output circuit. Qualcomm BLE Radio IC CSR1011 Chip Antenna AH316M245001-T CR2032 Coin Cell Battery 3V SHARP LCD Module 144x168 User Buttons and Slide Switch Y2 32.768KHz Crystal Oscillator

May 16, 2023 Attention: Application Examiner RE: Request for Confidentiality Applicant: SPR Therapeutics FCC ID: 2BBB4-9620 To Whom It May Concern: Permanent Confidentiality Request is hereby submitted by SPR Therapeutics to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: •Schematics Rationale for request for confidentiality: SPR Therapeutics has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading-edge technology developed by us. If you have questions or need further information, please contact the undersigned. Sincerely, Matt Wunzin Principal Engineer SPR Therapeutics

External Photos: Model: Patient Remote, REF 9620 Front View LCD and Branding Side View Slide Switch (Lock/ Unlock) Back View Product Label with FCC ID Number Front ISO View Top Pushbutton Switches (3) NOTE: FCC ID Number is changing to 2BBB4-9620

06/09/2023 Attention: Application Examiner RE: FCC ID Label for Remote – e-label Applicant: SPR Therapeutics The following is an image of the e-label that will be implemented on the patient Remote (REF 9620) to satisfy the requirement for displaying the FCC ID on the product. This gets displayed every time the Remote is unlocked for use (splash screen).

Internal Photos: Model: Patient Remote, REF 9620 Patient Remote Internal view showing Front Cover with PCBA and buttons, Back Cover, & Battery Door. Antenna Location Remote shown face down Antenna Location (Red Dot)

Peripheral Nerve Stimulator – Patient Remote (9620) Bluetooth Low Energy enabled handheld patient remote controller paired to the External Pulse Generator. The remote utilizes an LCD display to provide a user interface to the patient, three pushbutton switches and a slide switch allows them to control their stimulus session to the External Pulse Generator (Ref 9610). The remote is powered using a single replaceable 3V coin cell battery. The remote utilizes a Qualcomm CSR1011 Bluetooth Low Energy radio integrated circuit loaded with the Bluetooth 4.1 software stack.

Intertek 731 Enterprise Drive Lexington, KY 40510 Tel 859 226 1000 Fax 859 226 1040 www.intertek.com SPR Therapeutics, Inc. SAR EXEMPTION REPORT SCOPE OF WORK SAR EXEMPTION CALCULATION ON THE SPRINT PNS (PATIENT REMOTE REF: 9620) REPORT NUMBER 105410623LEX-009.2 ISSUE DATE REVISED DATE 5/25/2023 6/22/2023 PAGES 11 DOCUMENT CONTROL NUMBER Non-Specific EMC Report Shell Rev. December 2017 © 2017 INTERTEK This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services NA, Inc. SAR EXEMPTION TEST REPORT Report Number: 105410623LEX-009.2 Project Number: G105410623 Report Issue Date: 5/25/2023 Report Revised Date: 6/22/2023 Product Name: SPRINT PNS (Patient Remote Ref: 9620) Model 9620 Standards: FCC Part 2.1093 RSS-102 Issue 5 Tested by: Client: Intertek Testing Services NA, Inc. 731 Enterprise Drive Lexington, KY 40510 USA SPR Therapeutics, Inc. 22901 Millcreek Blvd Ste 500 Cleveland,OH 44122-5724 USA Report prepared by Report reviewed by David Perry, EMC Engineer Brian Lackey, Team Leader Evaluation For: SPR Therapeutics, Inc. Product: SPRINT PNS (Patient Remote Ref: 9620), Model 9620 SAR Exemption Report Date: 6/22/2023 Non-Specific EMC Report Shell Rev. December 2017 Page 3 of 11 Report Number: 105410623LEX-009.2 Table of Contents 1 Introduction and Conclusion ........................................................................................................................... 4 2 Test Summary ................................................................................................................................................ 4 3 Client Information .......................................................................................................................................... 5 4 Description of Equipment under Test and Variant Models .............................................................................. 6 4.1 Variant Models: ...................................................................................................................................... 6 4.2 Antenna Separation ................................................................................................................................ 7 4.3 Maximum Output Power ........................................................................................................................ 8 5 FCC SAR Exemption Criteria ............................................................................................................................ 9 6 ISED SAR Exemption Criteria ........................................................................................................................ 10 7 Revision History ........................................................................................................................................... 11 Evaluation For: SPR Therapeutics, Inc. Product: SPRINT PNS (Patient Remote Ref: 9620), Model 9620 SAR Exemption Report Date: 6/22/2023 Non-Specific EMC Report Shell Rev. December 2017 Page 4 of 11 Report Number: 105410623LEX-009.2 1 Introduction and Conclusion SAR exemption calculations were performed on the product constructed as described in section 4. Information provided by the client including maximum output power, antenna gain(s), and minimum separation distance(s) was used to determine if the product under evaluation was exempt from SAR. Any change in these stated values may invalidate these results. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product under evaluation is exempt from SAR requirements for each of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) evaluated. Intertek does not make any claims of compliance for samples or variants which were not evaluated. 2 Test Summary Section Requirement Result 5 FCC SAR Exemption Criteria (FCC Title 47 CFR Part 1.1307, 2.1093) Exempt from SAR 6 ISED SAR Exemption Criteria (RSS-102 Issue 5) Exempt from SAR Evaluation For: SPR Therapeutics, Inc. Product: SPRINT PNS (Patient Remote Ref: 9620), Model 9620 SAR Exemption Report Date: 6/22/2023 Non-Specific EMC Report Shell Rev. December 2017 Page 5 of 11 Report Number: 105410623LEX-009.2 3 Client Information This product was tested at the request of the following: Client Information Client Name: SPR Therapeutics, Inc. Address: 22901 Millcreek Blvd Ste 500 Cleveland,OH 44122-5724 USA Contact: Jeff Waterman Telephone: (216) 455-7447 Email: [email protected] om Manufacturer Information Manufacturer Name: SPR Therapeutics, Inc. Manufacturer Address: 22901 Millcreek Blvd Ste 500 Cleveland,OH 44122-5724 USA Evaluation For: SPR Therapeutics, Inc. Product: SPRINT PNS (Patient Remote Ref: 9620), Model 9620 SAR Exemption Report Date: 6/22/2023 Non-Specific EMC Report Shell Rev. December 2017 Page 6 of 11 Report Number: 105410623LEX-009.2 4 Description of Equipment under Test and Variant Models Equipment Under Test Product Name SPRINT PNS (Patient Remote Ref: 9620) Model Number 9620 FCC Identifier 2BBB4-9620 Type of Transmission Bluetooth L…

Text truncated - open the document above for the full version.

Spec Sheet http://www.ty-top.com The data i s reference only. Electrical c haracteristics vary depending on environment or measurement condition. TAIYO YUDEN reserves t he right t o make change to the data at any t ime without notice. Before making final s election, please check product specification. Chip Antennas(Multilayer) AH316M245001-T Features Item Summary MonoPole, 3.2x1.6x0.5mm, for Bluetooth/W-LAN/ZigBee Lifecycle Stage New PN available Standard packaging quantity (minimum) Taping Embossed 3000pcs Products characteristics table SystemBluetooth/W-LAN/ZigBee Frequency Band Width2400 to 2500 MHz Center Frequency2450 MHz Gain1 (Peak Gain)(typ)+1.6 dBi Gain2 (Ave. Gain at OMNI plane)-0.1 dBi Efficiency (typ)-1.4 dB (72 %) VSWR (typ)3 TypeMonoPole Operating Temp. Range-40 to +85 °C RoHS Compliance (10 subst.)Yes REACH Compliance (223 subst.)Yes Halogen FreeYes SolderingReflow External Dimensions Dimension L3.2 ±0.15 mm Dimension W1.6 ±0.15 mm Dimension T0.5 ±0.1 mm Dimension E0.5 ±0.2 mm Dimension bMin 1.0 mm 2022.06.09 Powered by TCPDF (www.tcpdf.org) 1 / 1 ■ Notice for TA I YO YUDEN Products Please read this notice before using the TA I YO YUDEN products. ■ Please conduct validation and verification of our products in actual condition of mounting and operating environment before using our products. ■ The product listed in this spec sheet is intended for use in general electronic equipment (e.g., AV equipment, OA equipment, home electric appliances, office equipment, information and communication equipment including, without limitation, mobile phone, and PC). Please be sure to contact TA I YO YUDEN for further information before using the products for any equipment which may directly cause loss of human life or bodily injury (e.g., transportation equipment including, without limitation, automotive powertrain control system, train control system, and ship control system, traffic signal equipment, disaster prevention equipment, medical equipment classified as Class I, II or III by IMDRF, highly public information network equipment including, without limitation, telephone exchange, and base station). Please do not incorporate our products into any equipment requiring high levels of safety and/or reliability (e.g., aerospace equipment, aviation equipment, medical equipment classified as Class IV by IMDRF, nuclear control equipment, undersea equipment, military equipment). When our products are used even for high safety and/or reliability‐required devices or circuits of general electronic equipment, it is strongly recommended to perform a thorough safety evaluation prior to use of our products and to install a protection circuit as necessary. Please note that unless you obtain prior written consent of TA I YO YUDEN, TA I YO YUDEN shall not be in any way responsible for any damages incurred by you or third parties arising from use of the product listed in this spec sheet for any equipment requiring inquiry to TA I YO YUDEN or prohibited for use by TA I YO YUDEN as described above. ■ Information contained in this spec sheet is intended to convey examples of typical performances and/or applications of our products and is not intended to make any warranty with respect to the intellectual property rights or any other related rights of TA I YO YUDEN or any third parties nor grant any license under such rights. ■ Please note that the scope of warranty for our products is limited to the delivered our products themselves and TA I YO YUDEN shall not be in any way responsible for any damages resulting from a fault or defect in our products. Notwithstanding the foregoing, if there is a written agreement (e.g., supply and purchase agreement, quality assurance agreement) signed by TA I YO YUDEN and your company, TA I YO YUDEN will warrant our products in accordance with such agreement. ■ The contents of this spec sheet are applicable to our products which are purchased from our sales offices or authorized distributors (hereinafter “TAIYO YUDEN’s official sales channel”). Please note that the contents of this spec sheet are not applicable to our products purchased from any seller other than TA I YO YUDEN’s official sales channel. ■ Caution for Export The product listed in this spec sheet may require specific procedures for export according to “U.S. Export Administration Regulations”, “Foreign Exchange and Foreign Trade Control Law” of Japan, and other applicable regulations. Should you have any questions on this matter, please contact our sales staff. ! REMINDERS REMINDERS Safety Design When using our products for high safety and/or reliability-required equipment or circuits, please fully perform safety and/or reliability evaluation. In addition, please install ( i ) systems equipped with a protection circuit and a protection device and/or ( ii ) systems equipped with a redundant circuit or other system to prevent an unsafe status in the event of a single fault for a failsafe design to ensure safety. Intellectual Property Rights Information contained in this catalog is intended to convey examples of typical performances and/or applications of our products and is not intended to make any warranty with respect to the intellectual property rights or any other related rights of TAIYO YUDEN or any third parties nor grant any license under such rights. Limited Warranty Please note that the scope of warranty for our products is limited to the delivered our products themselves conforming to the product specications specied in the individual product specication sheets, and TAIYO YUDEN shall not be in any way responsible for any damages resulting from a failure or defect in our products. Notwithstanding the foregoing, if there is a written agreement ( e.g., supply and purchase agreement, quality assurance agreement ) signed by TAIYO YUDEN and your company, TAIYO YUDEN will warrant our products in accordance with such agreement, provided, however, that our products shall be used for general-purpose and standar…
