2BBBB-JKN06204CAMERA

Operationmanual(V5.1) Dearusers,you are welcometo choosethis product.Beforeusingthe product, pleasereadthe instructionmanualcarefullyand keepit for laterreference 03、Adddevice 3.1Registeranaccount Whenyouusethisappatthefirsttime,youneedtouseyouremailtoregisteran account,click"SignUp”andsetapasswordaccordingthisprocedure,orchooseLongin withmobilephonemumber. Ifyouforgetyourpassword,youcanresetyourpassword,justclick"Forgotpassword” ontheloginpage. Passwordshouldbeatleast6charactersandnotlongerthan26characters,Itshouldbe acombinationoflettersandnumbers. Onlysupportmobilephonenumberregistrationinsomeregions. Pleaseuseemailtoregisterinotherareas. 02、DownloadAPP 01、MainFunctionDescription ScantheQRcodeanddownload. Pleasesearchfor"YCC365Plus"download. 3.2Connectthecamera Note:Cameraonlysupports2.4GWIFIbeforeaddingdevices,makesureyourrouteris2.4G WIFI,andyourphoneisconnectedto2.4GWi-Fi. 3.2.1Scancodetoadd ·PleasemakeyourphoneconnecttotheWi-Fi. ·Selectyourown2.4GWi-Fiandenteryourpassword.(5Gnetworkisnotsupported). ·ScanthecameralenstowardtheQRcodeofthephone,(AligntheQRcodewithcamera lensatadistanceof10-20cm)Hearavoiceprompt,Click"Whenyouhearabeeporagreen linght”afterhearingthebeep,Keepthecameracascloseaspossibletotherouter,The connectionprocesstakesabout1-2minutes,afteryouwillhearwelcometousecamera. 3.2.2AdditionofAPhotspot ·Clickthebuttonintheupperrightcomerontheapphomepage. ·ChoosetheAdditionofAPhotspot,Pluginthepowertothecamera,Waitpatientyforthe devicelighttoblinkorhearatone,ClickNextwhendone. ·Ifyoudon’tseeanytips,tryresettingyourdevice,Findtheresetbutton,Longpressforat least5s,clicknextafterprompted. ·pleasegototheWi-FilistandconnecttheWi-Fiinthebluefield“CLOUDCAM_XXXX”Select theWi-FithatmatchestheprefixandconnectReturntoAPPaftersuccessfulconnection. ·Afterconnectingthedevicesuccessfullyclicknext,ChooseyourrouterWi-Fi,EnterWi-Fi password,Clickconfirm,Additionissuccessful,thenyourcanpreviewthescreen. 3.2.3Additionbyconnectiontonetworkcable(OnlysupportLanportdevice) ·Clickthebuttonintheupperrightcomerontheapphomepage. ·Choosethedevicetypeintelligentcamera,choosetheadditionbyconnectingtonetwork cable. ·Pluginthepowertothecamera,Devicenetworkportisconnectedtothenetworkcable ScandevicebodyQRcode,puttheQRcodeonthedevicebodyintotheboxandscanit. ·Pleasewaitpatiently,Theconnectionprocesstakesabout1-2minutes,afteryouwillhear welcometousecamera. 3.2.4APDirectmode(special) ·OpentheYCC365plusapptoenterthelogininterface,click“Locallogin”. ·Clickthebuttonintheupperright“+”ontheapphomepage. ·Click“APnetworkeddevicepreview”andClick“Next”. ·GotoSettingNetworkclickyourphoneconnectto“CLOUDCAM_XXXX”network. ·NetworksettingsettheWi-FihasbeenconnectedwiththisdeviceandClick“Next”. ·EnteruserName:adminPassword:12345Click“Next”,thenyourcanpreviewthe screen. 04、Functionintroduction 4.1Real-timepreviewinterface AParameterMenu BSound CClip DHoldtotalk EVideotothephone FFullScreen GEvent KOperate LReplay 4.1.1Videoplayback Reminder:Cloudvideoplaybackneedstobepurchasedandpaidbeforeitcanbe used. A:Select"Replay"atthebottomrightcorneroftheliveinterfacetoviewthe playbackvideoofthecamera. B:Switchplaybackpath,youcanchoosetowatchcloudplayback/memorycardplayback. 4.1.2Preferences ·Click“”inthepreviewscreenchecktheparametermenu 05、FAQ 1.Howtowatchthecameraonthecomputer? ·Logintothecomputerbrowserinput:www.ucloudcam.com,EnteruserNameandPassword Login. 2、WhydoesitIntermittentvideorecording? ·Thesizeofthevideofileislimited,Oncethevideosizeclosetothecriticalvalue,thevideofile willbecreatedandthenextvideowillcontinuetoberecorded,thereisaintervalbutsoshort. 3、Whydoesthecameraisdisconnected? ·PleasecheckWi-Fiorwhetherthepowerswitchisnormal,Ifit’snormal,PleaseRestart camera,OrdeletethecameraintheAPPandPleasereconnectthecamera. 4、Howtoaddfamilyemailaccount? ·ComerontheApphomepage,ClickSettingstochooseashareddevice,AddfamilyEmail. 5、Howmanypeopleaccessanaccountatthesametime? ·Thereisnolimittothenumberofpeoplewhocanaccesstheaccount,Butthesamecameracan support3peoplestoviewthesametime. 6、CannotrecognizeTFcard? ·PleasecheckwhethertheTFcardmeetsthequalityrequirements.IftheWi-Fisignalispoor,it maybethatthecardcannotberead. 7.Afterthecloudserviceexpires,therecordingtimelineisblank. ·Afterthecloudserviceexpires,thevideocannotbereplayed.IfthereisnoTFcardinthe camera,thevideocannotberecorded. ·IftheTFcardcanalwayswork,butthevideofiledisappeared,pleasecheckthe"CheckTFcard" status. ·Ifitisnormalintheapplicationbutnovideohasbeenrecorded,pleaseformattheTFcard.Ifit stillcannotbeused,pleasereplaceitwithanewTFcardandtryagain. 8、Cannotreadthewirelessnetworknameafterconnectingtotheiphone ·First,IOSandAndroiddevicesneedtoenablelocationpermissions. ·ConnecttheiPhonetotheWi-Finetworkthroughconfiguration,andthenaddthecamera, whichcanautomaticallyreadthenetworkname. 9、Whycan'tIswitchtoanotheraccounttoconfigurethecameraWIFI? ·Thecameracanonlybeboundtooneaccount,andotheraccountscanonlybeviewedthrough thesharingmechanism,Ifotheraccountsneedtoreconfigurethecamera,pleaseusetheAPPin thedeletecamerafirst. 10、HowtoconnectmycameratootherWi-Fi? ·Twoways: A:WhenyouneedtochangetoanotherWi-Fiwithoutmovingthelocation. Parametersetting>>Networkinformation>>SelectWi-Fi. B:WhenthecameraisreplacedandnootherWIFIcanbefound,pleasetryresettingyour device,intheapphomepagewillprompt"deviceoffline",click"Troubleshooting",resetthe camera,andthenaddWIFIagain. After-salesinstructions 1、Theproductissubjecttotheactualproduct,thismanualisforreferenceonly. 2、Theproductisupdatedinrealtime,Ifthereareanyupgradeswithoutnotice,pleasecheckthe officialwebsite. 3、Thismanualintroducesthebasicfunctionsoftheproduct,pleasecheckandoperateby yourself. 4、Ifyouhaveanyproblemswhenusingthecamera,pleasecontactthesupplierorcompanyin time. 5、Wehavetriedourbesttoensurethecompletenessandaccuracyofthecontentsinthemanual, butsomedatamaystillexist. 6、Ifthereisanydeviation,ifyouhaveanyquestionsordisputes,pleaserefertothefinal explanationofthecompany. 7、Ifyoudonotfollowtheinstructionsinthemanual,youwillbearanyrespon…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: UGK-LVMUNITEDINC FRN: 0033476375 Contact Name: Jimmychen Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 Telephone No: 001-323-51 04660 Email: [email protected] Applicant: Company name: DongYang shi Paisheng smart home CO.,LTD Grantee code: 2BBBB FCC ID: 2BBBB-JKN06204 FRN: 0033798729 Contact Name: Chenxiansheng Address: No.1, Building 15, Shimentang Village, Jiangbei Street, Dongyang City, Zhejiang Province Telephone No: 15717026117 Email: [email protected] [DongYang shi Paisheng smart home CO.,LTD] certifies that, as of the date of this filing of the application with the TCB, [UGK-LVMUNITEDINC] is our designated US agent for service of process for the above referenced FCC ID. [DongYang shi Paisheng smart home CO.,LTD] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [UGK-LVMUNITEDINC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024/03/04 Applicant’s Name: Chenxiansheng US Agent’s Name: Jimmychen Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: DongYang shi Paisheng smart home CO.,LTD Grantee code: 2BBBB FCC ID: 2BBBB-JKN06204 FRN: 0033798729 Contact Name: Chenxiansheng Address: No.1, Building 15, Shimentang Village, Jiangbei Street, Dongyang City, Zhejiang Province Telephone No: 15717026117 Email: [email protected] i. [DongYang shi Paisheng smart home CO.,LTD] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [DongYang shi Paisheng smart home CO.,LTD] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [DongYang shi Paisheng smart home CO.,LTD] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2024/03/04 Applicant’s Name: Chenxiansheng Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

DongYang shi Paisheng smart home CO.,LTD Product Similarity Declaration Company: DongYang shi Paisheng smart home CO.,LTD Address: No.1, Building 15, Shimentang Village, Jiangbei Street, Dongyang City, Zhejiang Province Product Name: CAMERA Model Number: JKN06204 JKN06202, JKN05201, JKN06203, JKN01201, JKN06205, JKN06206, JKN06207, JKW05201, JKW02301, JK2A6, SQ31, CS13, JKN05202, JKN01202, JKN03301, JKN03302, JKN03303, JKN03304, JKN03201, JKN03202, JKS01301, JKN06303, C31, JKN06208, JKN06209, JKN06210, JKN06211, JKN06212, JKN06213, ZF09, ZF10, ZF11, ZF12 FCC Identifier: 2BBBB-JKN06204 We (DongYang shi Paisheng smart home CO.,LTD) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name and appearance color. Client’s signature Name: Chenxiansheng Date: 2024-03-04 Title: Manager Signature of applicant:

DongYang shi Paisheng smart home CO.,LTD 1/1 Letter of Authorization Company: DongYang shi Paisheng smart home CO.,LTD Address: No.1, Building 15, Shimentang Village, Jiangbei Street, Dongyang City, Zhejiang Province Product Name: CAMERA Model Number: JKN06204 JKN06202, JKN05201, JKN06203, JKN01201, JKN06205, JKN06206, JKN06207, JKW05201, JKW02301, JK2A6, SQ31, CS13, JKN05202, JKN01202, JKN03301, JKN03302, JKN03303, JKN03304, JKN03201, JKN03202, JKS01301, JKN06303, C31, JKN06208, JKN06209, JKN06210, JKN06211, JKN06212, JKN06213, ZF09, ZF10, ZF11, ZF12 FCC Identifier: 2BBBB-JKN06204 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Chenxiansheng Date: 2024-03-04 Title: Manager Signature of applicant:

DongYang shi Paisheng smart home CO.,LTD 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-03-04 Subject: Request for Confidentiality FCC ID: 2BBBB-JKN06204 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Chenxiansheng Title: Manager

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(External Photos) ANT Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Size:18*14mm M/N: JKN06204 FCC ID: 2BBBB-JKN06204 Label location

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(Internal Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

FCC ID: 2BBBB-JKN06204 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm EIRP=E Meas +20log(d Meas )-104.7 EIRP is the equivalent isotropically radiated power, in dBm E Meas is the field strength of the emission at the measurement distance, in dBμV/m d Meas is the measurement distance, in m Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation wifi 2.4G mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 15.814 38.1417 0.01337 1.0 PASS 802.11g 13.005 19.9756 0.00700 1.0 PASS 802.11n HT20 13.996 25.0957 0.00880 1.0 PASS 802.11n HT40 12.587 18.1426 0.00636 1.0 PASS Remark: antenna gain=2.46dBi

深圳市亚冠天线连接器有限公司 E-mail：[email protected] Http：//www.ygant.com 地址： 东莞市常平镇塘角蓝市路1号4楼 电话：0755-33699568 13631663123 1 / 8 产品规格书 Product Specification 客户名称Customer Name: Quantum Infinite Technology (Huizhou) Co., Ltd. 项目名称Project Name：2.4/5G Dippole antenna 客户地址Customer Address:Floor 7, Building C, Longsheng Science Park, No.11,Qiuchang Xihu Village, Huiyang District, Huizhou City 规格描述Product Spec：YG-2458-SMAJ-108 版 本 REV： V1.0 日 期 Date： ： 2023.03.06 制 作 drawing 审 核 check 批 准 approved 黄勇军 王玉美 蒋振华 深圳市亚冠天线连接器有限公司 E-mail：[email protected] Http：//www.ygant.com 地址： 东莞市常平镇塘角蓝市路1号4楼 电话：0755-33699568 13631663123 2 / 8 测试设备及原理Testing Equipment and Principle 1. 测试设备： 网络分析仪Network Analyzers : Agilent 8753D 5071B 综合测试仪Communications Test Set: Agilent E5515C 3D暗室测试系统 3D Chamber Test System： 2. 测试原理： 深圳市亚冠天线连接器有限公司 E-mail：[email protected] Http：//www.ygant.com 地址： 东莞市常平镇塘角蓝市路1号4楼 电话：0755-33699568 13631663123 3 / 8 一、电性能以及机械性能 电 性 能 指 标 Electrical Specifications 频率范围 2.4/5GHZ Frequency Range 2.4/5.8GHZ 电压驻波比 ≤2.0 VSWR ≤2.0 增益 ≤3DBI GAIN ≤3DBI 辐射方式 全向 Radiation OMNI 极化方式 垂直 Polarizatin LINEAR 输入阻抗 50 Ω Input Impedance 50 Ω 机 械 指 标 Mechanical Specifications 接口形式 SMA-K Input connector SMA-K 天线材质 ABS & COPPER Antenna materia ABS & COPPER 工作温度 -30°C~+80°C Working Temperature -30°C~+80°C 工作湿度 40~85% Working Humidity 40~85% 深圳市亚冠天线连接器有限公司 E-mail：[email protected] Http：//www.ygant.com 地址： 东莞市常平镇塘角蓝市路1号4楼电话：0755-33699568 13631663123 4 / 8 二、天线结构尺寸图 深圳市亚冠天线连接器有限公司 E-mail：[email protected] Http：//www.ygant.com 地址： 东莞市常平镇塘角蓝市路1号4楼 电话：0755-33699568 13631663123 5 / 8 三、无源测试数据 四、增益效率测试数据 深圳市亚冠天线连接器有限公司 E-mail：[email protected] Http：//www.ygant.com 地址： 东莞市常平镇塘角蓝市路1号4楼 电话：0755-33699568 13631663123 6 / 8 五、方向性测试数据 深圳市亚冠天线连接器有限公司 E-mail：[email protected] Http：//www.ygant.com 地址： 东莞市常平镇塘角蓝市路1号4楼 电话：0755-33699568 13631663123 7 / 8 六、 可靠性试验报告 项目 测试条件 规格 储存环境 在没有指定的情况下测试温度、湿度、气压如下： 1. 温度为-40°C～+85°C 2.相对湿度为45%-85% 3.气压为86kpa-106kpa 电气机械性能正常 高低温试验 在70°C与-40°C之间进行5次循环，然后在正常条件下 1-2H，检查外观质量。 尺寸应满足规定并应 满足满足 于机械、电气性能 耐恒定湿热 试验 相对湿度95±3%，试验温度：40°C.持续2H作用后， 试品取出后5min之内测定电气性能，试品在正常条 件下1-2H，检查外观质量 尺寸应满足规定并应 满足满足 于机械、电气性能 振动试验 振频范围10-55HZ，位移幅值：0.35MM，加速度幅值： 50.0M/S，扫频循环次数：30次 电气机械性能正常 跌落试验 1M高空按照互相垂直的轴方向自由跌落3次 电气机械性能正常 深圳市亚冠天线连接器有限公司 E-mail：[email protected] Http：//www.ygant.com 地址： 东莞市常平镇塘角蓝市路1号4楼 电话：0755-33699568 13631663123 8 / 8 产品包装规范Code for product packaging 产品名称/规格 一、标签要求 ****** ****** 采购单号 ************* 采购单号 ************* 物料编码 ***************** 物料编码 ***************** 品名规格 ******** 品名规格 ******* 数量/单位 ***** 数量/单位 ***** 备注 ************* 备注 ************* 二、装箱要求 作业说明： 1．内包装： 产品 50 PCS一小袋 2．外包装： 根据实际数量定数量/箱 注意事项： 1．是否要增设隔板、珍珠棉； 2．标签的贴附，如ROHS等；

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20240221031E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 45 FCC Part 15C Test Report FCC ID: 2BBBB-JKN06204 Applicant: DongYang Shi Paisheng Smart Home CO.,LTD Address: No.1, Building 15, Shimentang Village, Jiangbei Street, Dongyang City, Zhejiang Province Manufacturer: DongYang Shi Paisheng Smart Home CO.,LTD Address: No.1, Building 15, Shimentang Village, Jiangbei Street, Dongyang City, Zhejiang Province EUT: CAMERA Trade Mark: N/A Model Number: JKN06204 JKN06202, JKN05201, JKN06203, JKN01201, JKN06205, JKN06206, JKN06207, JKW05201, JKW02301, JK2A6, SQ31, CS13, JKN05202, JKN01202, JKN03301, JKN03302, JKN03303, JKN03304, JKN03201, JKN03202, JKS01301, JKN06303, C31, JKN06208, JKN06209, JKN06210, JKN06211, JKN06212, JKN06213, ZF09, ZF10, ZF11, ZF12 Date of Receipt: Feb. 21, 2024 Test Date: Feb. 21, 2024 - Mar. 01, 2024 Date of Report: Mar. 01, 2024 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2013 Test Result: Pass Report Number: DL-20240221031E Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20240221031E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 45 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 10 3.2 RADIATED EMISSION MEASUREMENT 13 3.2.1 RADIATED EMISSION LIMITS 13 3.2.2 TEST PROCEDURE 14 3.2.3 DEVIATION FROM TEST STANDARD 14 3.2.4 TEST SETUP 14 3.2.5 EUT OPERATING CONDITIONS 15 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 16 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 17 3.2.8 TEST RESULTS (1GHZ~25GHZ) 19 3.3 RADIATED BAND EMISSION MEASUREMENT 23 3.3.1 TEST REQUIREMENT: 23 3.3.2 TEST PROCEDURE 23 3.3.3 DEVIATION FROM TEST STANDARD 23 3.3.4 TEST SETUP 24 3.3.5 EUT OPERATING CONDITIONS 24 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 29 3.4.1 APPLICABLE STANDARD 29 3.4.2 TEST PROCEDURE 29 3.4.3 DEVIATION FROM STANDARD 29 3.4.4 TEST SETUP 29 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20240221031E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 45 Table of Contents Page 3.4.5 EUT OPERATION CONDITIONS 29 3.4.6 TEST RESULTS 29 4 . AVERAGE OUTPUT POWER 33 4.1 APPLIED PROCEDURES / LIMIT 33 4.1.1 TEST PROCEDURE 33 4.1.2 DEVIATION FROM STANDARD 33 4.1.3 TEST SETUP 33 4.1.4 EUT OPERATION CONDITIONS 33 4.1.5 TEST RESULTS 34 5 . POWER SPECTRAL DENSITY TEST 37 5.1 APPLIED PROCEDURES / LIMIT 37 5.1.1 TEST PROCEDURE 37 5.1.2 DEVIATION FROM STANDARD 37 5.1.3 TEST SETUP 37 5.1.4 EUT OPERATION CONDITIONS 37 5.1.5 TEST RESULTS 38 6 . 6DB BANDWIDTH TEST 41 6.1 APPLIED PROCEDURES / LIMIT 41 6.1.1 TEST PROCEDURE 41 6.1.2 DEVIATION FROM STANDARD 41 6.1.3 TEST SETUP 41 6.1.4 EUT OPERATION CONDITIONS 41 6.1.5 TEST RESULTS 42 7 . ANTENNA REQUIREMENT 45 7.1 STANDARD REQUIREMENT 45 7.2 EUT ANTENNA 45 8 . TEST SEUUP PHOTO 45 9 . EUT PHOTO 45 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20240221031E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 45 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.205, 15.209, 15.247(d) Radiated Spurious Emission PASS 15.205, 15.247(d) Band Edge Emission& Conducted Spurious Emissions PASS 15.247(b) Average Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2MHz Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20240221031E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 45 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: CAMERA Trademark N/A Model No.: JKN06204 JKN06202, JKN05201, JKN06203, JKN01201, JKN06205, JKN06206, JKN06207, JKW05201, JKW02301, JK2A6, SQ31, CS13, JKN05202, JKN01202, JKN03301, JKN03302, JKN03303, JKN03304, JKN03201, JKN03202, JKS01301, JKN06303, C31, JKN06208, JKN06209, JKN06210, JKN06211, JKN06212, J…

Text truncated - open the document above for the full version.

Shenzhen DL Testing Technology Co., Ltd. EUT TEST PHOTO Radiated Measurement Photos Shenzhen DL Testing Technology Co., Ltd. Conducted Measurement Photos ※※※※※ END OF REPORT ※※※※※
