2BBCSLKSD16Luckin Coffee Dispenser-Syrup Mark I

V1.4-2/2023 @LKSD-16User manual = Luckin Coffee Dispenser-Syrup Mark I LKSD-16 User manual 2023.2.25 V1. 4 V1.4-2/2023 @LKSD-16User manual documentation Smart Syrup Machine LKSD-16 User Manual Chinese Edition version Revised Content compose Date of writing Audit Review date V1.0 first edition Song Bo 2022.5.6 Wang Jiangfeng 2022.5.6 V1.1 Customer revision Song Bo 2022.5.17 Cheng Yue 2022.5.18 V1.2 Add 4.2 according to customer requirements Song Bo 2022.5. 30 Cheng Yue 2022. 6.2 V1.3 Print proofreading Song Bo 2022.6.16 Xiao Dingyuan 2022.6.16 V1.4 Calibration time, packing list Song Bo 2023.2.22 Xiao Dingyuan 2023.2.25 manufacturer MegaRobo Technologies Co., Ltd No. 277, Dongping Street, Suzhou Industrial Park, Suzhou, Jiangsu Province, China Phone: 400 0601 017 Business consulting and customer service 010-6060 3226 Company global Email: [email protected] The instructions contained in this user manual, especially safety instructions, must be observed. This helps avoid personal injury and property damage. Ensure that all personnel have access to the user manual. Thank you for buying LKSD-16 smart syrup machine. You can learn about all the features of the LKSD-16 in the user manual. If you need more information or have any other questions about the machine, please contact your local service organization or our support team. We hope LKSD-16 can bring you a pleasant experience. Copyright Notice Copying, even partial, is prohibited. No part may be reproduced in any form, nor may any part be used, edited or transmitted by any electronic means (photocopying, photography, tape or other recording program) without the authorization of MegaRobo® . All rights reserved, in particular reproduction, translation, editing, distribution and industrial property and sound recordings. directory V1.4-2/2023 @LKSD-16User manual directory directory ................................................................................ 1 Safety Note 1 ......................................................................... 1 1.1 Intended Use ................................................................................... 1 1.2 Introduction ..................................................................................... 2 1.2.1 The importance of safety instructions ....................................................... 2 1.2.2 Ignoring Security Rules ................................................................................... 2 1.3 Implementation Standards .......................................................... 2 1.4 General Safety Instructions .......................................................... 3 1.5 Disposal Instructions ..................................................................... 5 1.6 Deactivation ..................................................................................... 6 1.6.1 Packaging Materials ........................................................................................ 6 1.6.2 Disassembling the Device .............................................................................. 6 1.7 Special Safety Instructions and Signs ........................................ 6 1.7.1 Flags ...................................................................................................................... 6 1.8 Package Marks ................................................................................ 7 Description 2 ........................................................................ 8 2.1 Description ....................................................................................... 8 2.1.1 Main Functions .................................................................................................. 8 2.2 Overview ........................................................................................... 9 2.2.1 Front View ........................................................................................................... 9 2.2.2 Drawer open .................................................................................................... 10 2.3 Technical Data ............................................................................... 12 2.3.1 Performance ..................................................................................................... 12 2.3.2 Dimensions and weight of the machine ................................................. 12 2.3.3 Electrical data and power supply .............................................................. 13 directory V1.4-2/2023 @LKSD-16User manual 2.3.4 Environmental Conditions ........................................................................... 13 2.3.5 Other Specifications ...................................................................................... 14 2.3.6 Label ................................................................................................................... 15 2.4 Luckin Coffee APP ........................................................................ 15 Debug 3 ............................................................................... 16 3.1 Requirements to be met before commissioning .................. 16 3.2 Specific parameters/factory reset ............................................ 16 Use 4 .................................................................................... 18 4.1 Daily Use Instructions .................................................................. 18 4.2 Boot ................................................................................................. 19 4.2 Silicone plug adapter connection method ............................. 20 4.2. 1 Part description .............................................................................................. 20 4.2. 2 Connection method ..................................................................................... 21 4.3 Replenish the syrup drawer and fill the tubing .................... 22 4.4 Confirm machine status .........................................…

Text truncated - open the document above for the full version.

MegaRobo Technologies Co., Ltd U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Unite d Consulting Technology Services Co., Ltd. FRN : 0033495714 Contact Name: Davi d Wu Street Address: 17800 CASTLETON ST STE 665 CITY OF INDUSTRY City/Province/Zip: CA 91748 Telephone No: (626) 217-4022 Email: [email protected] This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as require d by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: 2023-06-07 Signed by (Printed Name/Title): David Wu/CEO The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: MegaRobo Technologies Co., Ltd Grantee Code: 2BBCS FCC ID: 2BBCSLKSD16 Contact Name: Liting Dai Street Address: No. 277, Dongping Street, Suzhou Industrial Park, Suzhou, China Telephone No: +86 18351106300 Email: [email protected] Applicant Signature: Date: 2023-06-01 Signed by (Printed Name/Title): Liting Dai

MegaRobo Technologies Co., Ltd Current Date 2023-05-31 To: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. No. 588 West Jindu Road, Songjiang District, Shanghai, China. 201612 Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE, MegaRobo Technologies Co., Ltd, HEREBY DECLARED THAT Our product: Product Description: Luckin Coffee Dispenser-Syrup Mark I And the models below : Model No.: LKSD-16-1, LKSD-16-2, LKSD-16-3 Manufacturer’s Name: MegaRobo Technologies Co., Ltd Manufacturer’s Address: No.277, Dongping Street, Suzhou Industrial Park, Suzhou, Jiangsu Province, China *Except that the model number and appearance deviation, are identical with the original product as follows: Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical. with the model(s) below which samples we chose to be tested by SGS Model No.: LKSD-16 Manufacturer’s Name: MegaRobo Technologies Co., Ltd Manufacturer’s Address: No.277, Dongping Street, Suzhou Industrial Park, Suzhou, Jiangsu Province, China Sincerely, Signature: Printed Name : Liting Dai Position/Title : QS Manager Contact Number: +86 18351106300

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 4 External Photos for SHCR2303000496HS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 4 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 4 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 4

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 10 Internal Photos for SHCR2303000496HS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 10 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 8 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 9 of 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 10 of 10

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049603 Page: 1 of 12 Parlam Zhan Laboratory Manager 1 Cover Page RF Exposure Evaluation Report Application No.: SHCR2303000496HS FCC ID: 2BBCSLKSD16 IC: 30648-LKSD16 Applicant: MegaRobo Technologies Co., Ltd Address of Applicant: No.277, Dongping Street, Suzhou Industrial Park, Suzhou, Jiangsu Province, China Manufacturer: MegaRobo Technologies Co., Ltd Address of Manufacturer: No.277, Dongping Street, Suzhou Industrial Park, Suzhou, Jiangsu Province, China Equipment Under Test (EUT): EUT Name: Luckin Coffee Dispenser-Syrup Mark I Model No.: LKSD-16, LKSD-16-1, LKSD-16-2, LKSD-16-3  Remark : Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 RSS-102 Issue 5 Amendment 1 (February 2, 2021) Date of Receipt: 2023-03-16 Date of Test: 2023-03-17 to 2023-03-29 Date of Issue: 2023-05-05 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049603 Page: 2 of 12 Revision Record Version Description Date Remark 00 Original 2023-05-05 / Authorized for issue by: Wade Zhang/Project Engineer Parlam Zhan/Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049603 Page: 3 of 12 2 Contents Page 1 COVER PAGE .............................................................................................................................. 1 2 CONTENTS .................................................................................................................................. 3 3 GENERAL INFORMATION ........................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T. ............................................................................................ 4 3.2 DETAILS OF E.U.T. .................................................................................................................. 4 3.3 SEPARATION DISTANCE............................................................................................................ 4 3.4 TEST LOCATION ...................................................................................................................... 5 3.5 TEST FACILITY ........................................................................................................................ 5 4 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS ........................................................ 6 4.1 RF EXPOSURE TEST EXEMPTIONS FOR SINGLE RF SOURCES ....................................................... 6 4.1.1 Blanket 1 mW Blanket Exemption.................................................................. 6 4.1.2 MPE-based Exemption ................................................................................... 6 4.1.3 SAR-based Exemption .................................................................................... 7 4.2 RF EXPOSURE TEST EXEMPTIONS FOR SIMULTANEOUS TRANSMISSION ........................................ 8 5 IC RADIOFREQUENCY RADIATION EXPOSURE LIMITS ......................................................... 10 6 MEASUREMENT AND CALCULATION ...................................................................................... 11 6.1 MAXIMUM TRANSMIT POWER ................................................................................................... 11 6.2 RF EXPOSURE CALCULATION ................................................................................................. 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049603 Page: 4 of 12 3 General Information 3.1 General Description of E.U.T. Power supply: AC 120V 60Hz S/N: SRLKSD160222D0001 Firmware Version: V1.50 3.2 Details of E.U.T. BLE Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V4.0 LE Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: PCB Antenna Antenna Gain: 4 dBi (Provided by manufacturer) 2.4G WiFi Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK);802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11 Channel Spacing: 5MHz Antenna Type: PCB Antenna Antenna Gain: 4 dBi (Provided by manufacturer) Date Rate: 802.11b:1/2/5.5./11Mbps 802.11g:6/9/12/18/24/36/48/54Mbps 802.11n:MCS0-MCS7 3.3 Separation Distance Separation distance between the antenna to person (R): ＞20cm Remark: This minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. R has been stated in user manual. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049603 Page: 5 of 12 3.4 Test Location All tests were performed at: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. E&E Lab 588 West Jindu Road, Xinqiao, Songjiang, 201612 Shanghai, China. Tel: +86 21 6191 5666 Fax: +86 21 6191 5678 No tests were sub-contracted. Note: 1. SGS is not responsible for wrong test results due to incorrect information (e.g. max. clock frequency, highest internal frequency, antenna gain, cable loss, etc ) is provided by the applicant. (if applicable). 2. SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (if applicable). 3.5 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 6332.01) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. is accredited by the Ameri…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049602 Page: 1 of 107 Parlam Zhan Laboratory Manager TEST REPORT Application No.: SHCR2303000496HS FCC ID: 2BBCSLKSD16 IC: 30648-LKSD16 Applicant: MegaRobo Technologies Co., Ltd Address of Applicant: No.277, Dongping Street, Suzhou Industrial Park, Suzhou, Jiangsu Province, China Manufacturer: MegaRobo Technologies Co., Ltd Address of Manufacturer: No.277, Dongping Street, Suzhou Industrial Park, Suzhou, Jiangsu Province, China Equipment Under Test (EUT): EUT Name: Luckin Coffee Dispenser-Syrup Mark I Model No.: LKSD-16, LKSD-16-1, LKSD-16-2, LKSD-16-3  Remark : Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: Standard(s) : 47 CFR Part 15, Subpart C 15.247 RSS-247 Issue 2, February 2017 RSS-Gen RSS-Gen Issue 5 Amendment 2 (February 2021) Date of Receipt: 2023-03-16 Date of Test: 2023-03-17 to 2023-03-29 Date of Issue: 2023-05-05 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049602 Page: 2 of 107 Revision Record Version Description Date Remark 00 Original 2023-05-05 / Authorized for issue by: Wade Zhang/Project Engineer Parlam Zhan/Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049602 Page: 3 of 107 2 Test Summary Radio Spectrum Technical Requirement Item FCC Requirement IC Requirement Method Result Antenna Requirement 47 CFR Part 15, Subpart C 15.203 & 15.247(c) RSS-Gen Clause 6.8 N/A Customer Declaration N/A: Not applicable Radio Spectrum Matter Part Item FCC Requirement IC Requirement Method Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.207 RSS-Gen Clause 8.8 ANSI C63.10 (2013) Section 6.2 Pass Minimum 6dB Bandwidth 47 CFR Part 15, Subpart C 15.247a(2) RSS-247 Clause 5.2(a) ANSI C63.10 (2013) Section 11.8.1 Pass Conducted Average Output Power 47 CFR Part 15, Subpart C 15.247(b)(3) RSS-247 Clause 5.4(d) ANSI C63.10 (2013) Section 11.9.2 Pass Power Spectrum Density 47 CFR Part 15, Subpart C 15.247(e) RSS-247 Clause 5.2(b) ANSI C63.10 (2013) Section 11.10.2 Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247(d) RSS-247 Clause 5.5 ANSI C63.10 (2013) Section 11.13.3.2 Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247(d) RSS-247 Clause 5.5 ANSI C63.10 (2013) Section 11.11 Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.209 & 15.247(d) RSS-247 Section 3.3 & RSS-Gen Section 8.9 ANSI C63.10 (2013) Section 6.10.5 Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.209 & 15.247(d) RSS-247 Section 3.3 & RSS-Gen Section 8.9 ANSI C63.10 (2013) Section 6.4,6.5,6.6 Pass 99% Bandwidth - RSS-Gen Section 6.7 ANSI C63.10 Section 6.9.3 Pass Note: There are series models mentioned in this report, and they are the similar in electrical and electronic characters. Only the model LKSD-16 was tested since their differences were the model number and appearance. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049602 Page: 4 of 107 3 Contents Page 1 COVER PAGE ..................................................................................................................................... 1 2 TEST SUMMARY ................................................................................................................................. 3 3 CONTENTS ......................................................................................................................................... 4 4 GENERAL INFORMATION .................................................................................................................. 6 4.1 DETAILS OF E.U.T. ......................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS .................................................................................................... 6 4.3 POWER LEVEL SETTING USING IN TEST: ............................................................................................. 6 4.4 MEASUREMENT UNCERTAINTY & DECISION RULE............................................................................... 7 4.5 TEST LOCATION ............................................................................................................................. 7 4.6 TEST FACILITY ............................................................................................................................... 8 4.7 DEVIATION FROM STANDARDS ......................................................................................................... 8 4.8 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 8 5 EQUIPMENT LIST ............................................................................................................................... 9 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................11 6.1 ANTENNA REQUIREMENT ................................................................................................................11 6.1.1 Test Requirement: ..................................................................................................................11 6.1.2 Conclusion ..............................................................................................................................11 7 RADIO SPECTRUM MATTER TEST RESULTS .................................................................................12 7.1 CONDUCTED EMISSIONS AT AC POWER LINE (150KHZ-30MHZ) ........................................................12 7.1.1 E.U.T. Operation ..............................................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049601 Page: 1 of 63 Parlam Zhan Laboratory Manager TEST REPORT Application No.: SHCR2303000496HS FCC ID: 2BBCSLKSD16 IC: 30648-LKSD16 Applicant: MegaRobo Technologies Co., Ltd Address of Applicant: No.277, Dongping Street, Suzhou Industrial Park, Suzhou, Jiangsu Province, China Manufacturer: MegaRobo Technologies Co., Ltd Address of Manufacturer: No.277, Dongping Street, Suzhou Industrial Park, Suzhou, Jiangsu Province, China Equipment Under Test (EUT): EUT Name: Luckin Coffee Dispenser-Syrup Mark I Model No.: LKSD-16, LKSD-16-1, LKSD-16-2, LKSD-16-3  Remark : Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: Standard(s) : 47 CFR Part 15, Subpart C 15.247 RSS-247 Issue 2, February 2017 RSS-Gen RSS-Gen Issue 5 Amendment 2 (February 2021) Date of Receipt: 2023-03-16 Date of Test: 2023-03-17 to 2023-03-29 Date of Issue: 2023-05-05 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049601 Page: 2 of 63 Revision Record Version Description Date Remark 00 Original 2023-05-05 / Authorized for issue by: Wade Zhang/Project Engineer Parlam Zhan/Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049601 Page: 3 of 63 2 Test Summary Radio Spectrum Technical Requirement Item FCC Requirement IC Requirement Method Result Antenna Requirement 47 CFR Part 15, Subpart C 15.203 & 15.247(c) RSS-Gen Clause 6.8 N/A Customer Declaration N/A: Not applicable Radio Spectrum Matter Part Item FCC Requirement IC Requirement Method Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.207 RSS-Gen Clause 8.8 ANSI C63.10 (2013) Section 6.2 Pass Minimum 6dB Bandwidth 47 CFR Part 15, Subpart C 15.247a(2) RSS-247 Clause 5.2(a) ANSI C63.10 (2013) Section 11.8.1 Pass Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247(b)(3) RSS-247 Clause 5.4(d) ANSI C63.10 (2013) Section 11.9.1 Pass Power Spectrum Density 47 CFR Part 15, Subpart C 15.247(e) RSS-247 Clause 5.2(b) ANSI C63.10 (2013) Section 11.10.2 Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247(d) RSS-247 Clause 5.5 ANSI C63.10 (2013) Section 11.13.3.2 Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247(d) RSS-247 Clause 5.5 ANSI C63.10 (2013) Section 11.11 Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.209 & 15.247(d) RSS-247 Section 3.3 & RSS-Gen Section 8.9 ANSI C63.10 (2013) Section 6.10.5 Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.209 & 15.247(d) RSS-247 Section 3.3 & RSS-Gen Section 8.9 ANSI C63.10 (2013) Section 6.4,6.5,6.6 Pass 99% Bandwidth - RSS-Gen Section 6.7 ANSI C63.10 Section 6.9.3 Pass Note: There are series models mentioned in this report, and they are the similar in electrical and electronic characters. Only the model LKSD-16 was tested since their differences were the model number and appearance. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230300049601 Page: 4 of 63 3 Contents Page 1 COVER PAGE ..................................................................................................................................... 1 2 TEST SUMMARY ................................................................................................................................. 3 3 CONTENTS ......................................................................................................................................... 4 4 GENERAL INFORMATION .................................................................................................................. 6 4.1 DETAILS OF E.U.T. ......................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS .................................................................................................... 6 4.3 POWER LEVEL SETTING USING IN TEST: ............................................................................................. 6 4.4 MEASUREMENT UNCERTAINTY & DECISION RULE............................................................................... 7 4.5 TEST LOCATION ............................................................................................................................. 7 4.6 TEST FACILITY ............................................................................................................................... 8 4.7 DEVIATION FROM STANDARDS ......................................................................................................... 8 4.8 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 8 5 EQUIPMENT LIST ............................................................................................................................... 9 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................11 6.1 ANTENNA REQUIREMENT ................................................................................................................11 6.1.1 Test Requirement: ..................................................................................................................11 6.1.2 Conclusion ..............................................................................................................................11 7 RADIO SPECTRUM MATTER TEST RESULTS .................................................................................12 7.1 CONDUCTED EMISSIONS AT AC POWER LINE (150KHZ-30MHZ) ........................................................12 7.1.1 E.U.T. Operation .....................................................................................…

Text truncated - open the document above for the full version.

电性测试报告 TestReports 1W ipex O.D.1.13mm//125mm 东莞市脉讯电子有限公司Tel:0769-33691210Fax:0769-82381572 ElectricalProperties Frequency2.4GHz Impedance500hmNominal V.S.W.R1.92:1Max ReturnLoss-10dBMax RadiationOmni-directional Gain(Peak)4dBi CableLoss3.2dB/mMax@2450MHz PolarizationLinear,Vertical AdmittedPower Connector PhysicalProperties AntennaMaterialPCB CableType OperatingTemp. -10~+60 ̊C StorageTemp. -10~+70 ̊C S 参数测试 SParameterTest AgilentE5071C 东莞市脉讯电子有限公司Tel:0769-33691210Fax:0769-82381572 增益测试 GainTest Antenna Radiation Pattern VS Gain 0 45 90 135 180 225 270 315 0 0 -10 -10 -20 -20 -30 -30 -40 -40 东莞市脉讯电子有限公司Tel:0769-33691210Fax:0769-82381572

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 3 Appendix Photographs of Test Setup for SHCR2303000496HS Test Model No.: LKSD-16 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) RF Conducted SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 3 Radiated Spurious Emissions Below 1GHz Radiated Spurious Emissions Above 1GHz
